MOTORINO ASSEMBLY AND USER'S MANUAL
Model: XPv
For the most recent version of this user's manual and for all updated
product information please visit www.motorinocycles.com or call your local dealer
GREENWIT TECHNOLOGIES Inc. 2009
READ THIS MANUAL BEFORE OPERATING YOUR
GREENWIT Ltd. STRONGLY SUGGESTS THE
OPERATOR OF THIS PRODUCT BE 16 YEARS OF AGE OR OLDER.
MOTORINOTM
TM

1
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR
ACCIDENTS INVOLVINGTHE USE OFTHE . TO DETERMINE IF
COVERAGE IS PROVIDED YOU SHOULD CONTACT YOUR INSURANCE
MOTORINO
TM
THANKYOU FOR PURCHASING OUR PRODUCT
PLEASE READ THIS MANUAL CAREFULLY AS IT IS BASED ON OUR LONG
EXPERIENCE DEDICATED TO ENGINEERING, SALES AND MAINTANENCE OF
LIGHT ELECTRICVEHICLES. ITWILL HELPYOU ENJOYYOUR
AND EXTEND ITS LIFE.
GreenwitTechnologiesteam
MOTORINO
TM

2
Table of Contents ..................................................................................................................
Features and Specifications ...............................................................................................
 Contentsofthebox..............................................................................................................
Generalsafetyguidelines .................................................................................................... ................
 Before each ride .....................................................................................................
 After each ride ........................................................................................................
Assembly Instructions..........................................................................................................
Battery........................................................................................................................................
General Usage Notes............................................................................................................
Maintenance............................................................................................................................
Break Maintenance................................................................................................
FlatTire Repair ........................................................................................................
Operating Instructions.....................................................................................................
Key andThrottle operation................................................................................
Display........................................................................................................................
Main Components................................................................................................
Troubleshooting ...................................................................................................................
Warranty..................................................................................................................................
Warranty Service .................................................................................................................
Return Policy...........................................................................................................................
Notes..........................................................................................................................................
2
3
3
4
6
7
8
10
12
13
13
14
15
15
16
17
18
19
20
21
22
TABLE OF CONTENTS

3
FEATURES & SPECIFICATIONS
FEATURES AND SPECIFICATIONS
- Motor Specs:Brushless DC Motor,Continuous Rotational Power:500W,Speed:400rpm
- Controller - CCT type with three independent continuous current electronic gears
- RechargeTime for the Battery:4-6 Hours
- One Full Charge Lasts up to 50 km with a single battery and 80 km with dual.
- Speeds up to 32km/h on level pavement with a 75 kg rider
-Weight of MOTORINO:75 kg
 *Moredetailsavailableatwww.motorino.ca
CONTENT OFTHE BOX
- 48V 22AH battery installed (charging required)
- Left and right pedals (to be attached,no tool required)
- 48V charger for 110V AC outlet
- Rain cape and bike rain cover
-Two Ignition Keys (also used for under seat storage and main battery compartment)
-Two remote alarm controls
-Two mirrors (left and right)
-Two Storage Box Keys
UNDERSTANDINGTHIS MANUAL
Within this manual you will find sections marked with a sign. This is to warn
you that failure to abide by the following instructions may result in injury to the rider or
others. Although your MOTORINO is classified as a bicycle,it is a much heavier vehicle and
should be ridden with the care and control of a full sized motorcycle. A loss of control at
speed can result in serious injury or death.
We constantly strive to improve and upgrade our product;as such your MOTORINO may
include updated components which are not covered by this manual. If you notice that parts
of your bike differ from the parts pictured herein,contact your local MOTORINO dealer to
ensure that everything on your machine is up to specification.
Thank you for purchasing the low speed electrically powered
Your complies with the Canadian MotorVehicle Safety Regulation Act
(CMVSRA),and is classified as a Power Assisted Bicycle under section 1.2.1 of that act.It is also
compliant with US Public Law 107-319 for importation and use in all states where it is enacted
MOTORINO
TM
MOTORINO
TM

Your provincial motor vehicle branch or city or county may have additional laws
regulating the use of vehicles like the
MOTORINOTM . Some provinces or states may
require a driver's license or minimum age requirements for the
MOTORINOTM . Some
provinces in Canada and some states in the US may classify your
MOTORINOTM as a
Limited Speed Motorcycle or Moped. Please check with your local motor vehicle
branch or insurance company for information specific to your area.
If your province or state allows the MOTORINOTM to be used on vehicle roadways
please make sure you are familiar with all traffic laws such as:yielding to pedestrians
and other motorists, signaling, riding as far to the right edge of the roadway as
possible, obeying traffic signs etc.Your provincial MVB or state DOT can provide you
with materials related to these traffic laws. In addition to those traffic laws abide by
the following general principals:
1.You are sharing the road or the path with others - motorists,pedestrians and other
cyclists.
Respect their rights,and be yielding if they infringe on yours.
2.Ride defensively.
3.Look ahead of where you're going,and be ready to avoid:
- Vehicles slowing or turning in front of you, entering the road or your lane ahead of
you,or coming up behind you.
- Parked car doors opening in front of you.
- Pedestrians stepping out in front of you.
- Children or dogs playing near the road.
-Potholes, sewer gratings, railroad tracks, expansion joints, road or sidewalk
construction, debris and other obstructions that could cause you to swerve into
traffic,catch your wheel,orotherwise lose control and have an accident.
4. Ride on the right side of the road, in the same direction as vehicle traffic and as
close to the outisde edge of the road as possible.
5. Stop at stop signs and traffic lights; slow down and look both ways at street
intersections.
6. Always use signal lights or hand signals for turning and stopping. Learn the local
vehicle code for the correct signal.
7. Don't weave through traffic or make any moves that may surprise people with
whom you are sharing the road.
8.Never carry anything which obstructs your vision or your complete control of the
or which could become entangled in the moving parts of the MOTORINOTM
9. Never hitch a ride by holding on to another vehicle.Remember that the
MOTORINOTM will always lose in a collision with a motor vehicle,so be prepared to yield
even if you have the right of way.
4
GENERAL SAFETY GUIDELINES & RESTRICTIONS

GENERAL SAFETY GUIDELINES & RESTRICTIONS
US and Canadian safety regulations require that you
wear any helmet suitable for use with a regular bicycle.
The MOTORINOTM should not be used under any
circumstances without properly wearing a helmet.
5
NEITHER GREENWIT Ltd.NORTHE RETAIL SELLER OFTHE
MOTORINO
TM
IS RESPONSIBLE FORTHE CONSEQUENCES
OF FAILURETO COMPLYWITH FEDERAL AND PROVINCIAL
TRAFFIC ORDINANCES
IN ADDITION TO THE REQUIREMENTS ABOVE, THE
MOTORINOTM IS NOT TO BE RIDDEN / USED:
ALWAYS USE A HELMET WHILE RIDING
THE MOTORINOTM
1" inch
22" inch
A
B
C
1.on anyroadwayswherethespeedlimit is
inexcess of50km/h
2.on anysidewalksorpedestrianwalkways
3.on anybumpy,roughorunpavedsurfaces
4.in darknesswithoutproperillumination
5. onsandy orgravelsurfaces
6.by anypersonweighingmorethan225 lbs
7.by anypersonwithaninseamof lessthan22"

8.byanyphysicallyormentallychallengedperson
9.byanypersonwith vision,balance,hearing orcoordinationimpairments
10.byanypersonusing headphonesoracellularphone
11.tocarry morethan10lbsofcargoin thecargocompartment
12.inexcessof20mph(with orwithoutthemotoractivated)
13.bybarefootridersor thosewearingsandals,open toed,highheeled,platformor
slipon footwear
14.byanypersonwho hasingestedanyalcoholordrugthatcouldimpairtheir
abilitytooperatethe
15.withouttwohandson thehandlebar
16.whilenot properly seated
17.tojumpramps,curbs,or objectsorattemptanystunts
18.withclothing orextremitiesin closeproximitytothedrivechain oranymoving
parts
19.beyondyourabilityand experience
20.bystoppingwithonlythefrontbrake.Usebothbrakessimultaneously
21.Donottry toaccelerateand engage thebrake atthesametime.
[Thismay causedamage tothemotorfromexcessheat]
BEFORE EACH RIDE:
1.Makesureyouproperlywearahelmet
2.Wearprotectiveclothingandgloves
3.Weareyeprotectionthatdoes notinterferewith yourperipheralvision
4.Checklocalandstatelawsbeforeoperatingthe inanyarea
5.Makesurealltail/brakelights,turnsignals andtheheadlightareoperational
6.Makesurethehornisoperational
7.Makesurethebrakesareproperlyadjustedandworking correctly (seefurther
detailedinstructions).
8.Makesureyouunderstandhowthebrakes workandthatyourhandscanreach
andsqueezetheleverscomfortablyandhardenoughtostopthe
safely.
9.Makesurethechainisproperlyadjusted(seefurtherdetailedinstructions).
GENERAL SAFETY GUIDELINES & RESTRICTIONS
6
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM

GENERAL SAFETY GUIDELINES & RESTRICTIONS
10.Make sure all parts of the are properly and securely fastened and
adjusted,including but not limited to pedals,crank arms,wheels,all controls and cargo
box (Please refer to Assembly Instructions)
11.Make sure the tires are not excessively worn, do not have tears or cuts,are properly
seated on the rim and inflated to the proper pressure on the sidewall (45-50psi)
(DO NOT USE GAS STATION PUMPS FOR INFLATION WITHOUT A PRESSURE GAUGE)
12.Make sure the wheels spin freely,are well aligned,and that the rims are not bent or
damaged (the front wheel must be undamaged for the front brake to work properly)
13.Do not turn the key until you are seated on the bike and have checked that the
throttle is OFF.Since the motor is silent it is easy to forget the bike is active; this can be
hazardous when pushing the bike with a hand on the throttle
AFTER EACH RIDE:
1. Make sure that the ignition key is turned OFF and that all keys are removed and
kept in a safe place
2. Make sure to plug the battery into an outlet to charge it
3. Make sure the throttle is rotated to the off position
4. Ensure that the kickstand is on stable ground so the will not fall
over and get damaged
5. Ensure the is not kept outdoors or where moisture can damage it
6. Do not charge or store the closer than 20 feet from any heat source
(e.g.furnace, fireplace, water heater,space heater)
7. Do not allow children under 16 to play on or near the unattended
FAILURE TO FOLLOW THESE OPERATION INSTRUCTIONS CAN RESULT IN
SERIOUS INJURY OR DEATH OR COULD RESULT IN AN ELECTRICAL SHORT OR FIRE.
DO NOT MAKE ANY ALTERATIONS OR MODIFICATIONS TO THE ,
OR ADD ANY PARTS NOT AUTHORIZED BY GREENWIT Ltd. EXCEPT THOSE
DISCUSSED IN THIS MANUAL OR THOSE REQUIRED BY LAW. DO NOT REMOVE ANY
REFLECTORS, LIGHTS OR OTHER STANDARD EQUIPMENT.DOING SO WILL VOID
YOUR WARRANTY.
All authorized replacement parts are listed on the parts list enclosed
or available at www.greenwit.com and www.motorino.ca or by calling your local
- dealer.
7
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM

ASSEMBLY INSTRUCTIONS
8
HANDLE BAR
Insert the top part of the handlebar into the handlebar post as shown on the picture.Locate
the attachment bolt with the nut and the spacer.Place the curved side of the spacer over the
hole on the front of the bar,insert the bolt through the spacer and the bar,screw the nut in
behind and tighten it.After attached,the handlebar should look as on the picture below.
Your Motorino will come in one of three different states:
a) 95% assembled - you only need to install the mirrors and the cargo box
b) 90% assembled - you need to install (a) plus front wheel
c) 85% assembled - you need to install (b) plus the handle bar and some plastic elements
All instructions for (a),(b) and (c) are described below with supporting pictures
FRONTWHEEL ASSEMBLY
If the front wheel of your bike is
assembled,proceed to the next
section.Otherwise read below:
Before installing the front wheel
gently take apart disk break pads
using a wide flat screwdriver so the
wheel disk can squeeze between the
pads.Push the black speedometer
cap against the wheel and position
it in the way that the axle bolt can go
through it. Be sure that the two teeth in
the speedometer cog properly mate with the wheel. Firmly tighten the nut at the opposite side.

ASSEMBLY INSTRUCTIONS
9
STORAGE BOX
Locate the storage box and the hardware
necessary to mount it on the back of the
scooter.Use the two metal brackets to secure the
box by placing them underneath the attachment
rack and connecting them to the box with the
supplied bolts. Tighten the bolts enough to achieve
a secure grip on the rack.
Locate Pedals (Set of 2).The pedals are labeled
L and R near the threads,the cranks are labeled
on their inside surface.The pedals have opposite
threading and are not interchangeable.
Screw the Left and Right pedals to their
cranks and tighten them with an adjustable
wrench. Align the hole in the crank with the
round pin in the pedal axle and connect the pedals.
To remove use a tool to depress the pin in the pedal axle
and briskly remove the pedal.
PEDALS
MIRRORS
Locate the mirrors included with your MOTORINO scooter. Insert the threaded part of
the mirrors to designated holes on the handle bar and secure them with provided nuts.
Turn the cone shape nut on top clock wise to secure the mirrors.
Make sure to adjust the mirrors before use.
Once mirrors are installed,they should look like the picture below.

10
BATTERY
BEFORE OPERATINGYOUR NEW ,FORTHE FIRSTTIME,CHARGETHE BATTERY
FOR 8-12 HOURS.
-The batteries will take about two weeks to become conditioned; slightly shorter
ranges may be experienced before this.
-Charge the batteries as often as possible; Be sure to charge the after each
use.Keeping the battery properly charged will extend the battery life.
-Draining the battery completely is best avoided; they do not endure well when
deep-cycled. This is counterintuitive for many people because of their experience
with NiCAD and some Lithium batteries.
-Sulphation occurs when the battery is left discharged or partially charged for a
length of time.Insulating sulphur crystals accumulate on the Anode and will render
the battery useless in a matter of days.This is why we stress regular and frequent
charging.
-Using a desulphator is a good preventative measure,but once sulphation reaches a
certain point the cell is a loss. Best results are achieved when the desulphator is
used right from the beginning.
-Replacing the batteries is an inevitable cost of ownership.With frequent charging
and limited drain 350-400 full charge cycles is common. Partially drained and
promptly recharged battery is not considered a full cycle; maximum battery life is
achieved by partial drains and prompt charging.
-Installing a second battery is a good way to prevent deep-cycling,this will not only
extend the range but prolong the life of both batteries as well.
-If second battery is installed later, charge each battery separately before you
connect them in parallel. Unless charged separately the second battery will take a
long time to charge,and will not be properly conditioned.
-If you need extra range we recommend to install a second battery in the first six
months of use.This will prevent an unequal charge of the older battery.
-Cold weather can shorten a batteries useful life and reduce its capacity. If you use
your
MOTORINO
TM
bike in colder climate avoid storing the battery under freezing
temperature.
- If you notice anything unusual about the battery such as a cracked or leaking battery case,
a battery that gets hot while being used or charged, a battery case that appears "puffy"
or"bloated" etc,or there are any other problems with the battery,please contact your local
MOTORINO
TM
dealer.
- Do not attempt to repair, remove, adjust or in any way alter any internal or electrical
components, controls or wiring without first speaking with a customer service
representative.Doing so will void your warranty.
MOTORINO
TM
MOTORINO
TM

10
6.  DONOT KEEPTHE CONNECTEDTOTHE CHARGER
FORLONGERTHAN 18HOURS UNDERANY CIRCUMSTANCES!DOINGSOCOULD
CAUSETHEBATTERYOR CHARGERTOOVERHEAT ANDCAUSEAFIRE.
7. When the light on the 48V charger is red,the battery is being properly
charged. When the MOTORINO
TM
battery is fully charged,the light will turn green. If this
 does not occur after 16 hours of charging,unplug the charger and call your local
  dealer. Normal recharge time for the main battery is 4-6 hours
(assuming it is not 100% discharged).
8.Disconnect the charger from the 110V Power Source.
9.Disconnect the Input Cord from the Charging Receptacle.
10.  NEVERLEAVETHEBATTERYCHARGERCONNECTEDTOTHE110V
POWERSOURCEORTHE WHENNOTCHARGINGTHEBATTERY.
KEEPINGTHECHARGERPLUGGEDINTOTHE110VPOWERSOURCEANDNOT
THEBATTERYCOULDCAUSETHECHARGERTOOVERHEAT ANDOR CAUSE
AFIRE.
11.When storing your for lengthy periods of time,the battery should
be charged at least once a month to avoid full depletion.
 FAILURETOKEEPTHE BATTERYCHARGEDWILL
CAUSE TOTAL BATTERY FAILURE. DO NOT ALLOW BATTERY TO BECOME FULLY
DISCHARGED!!! ALWAYS RECHARGE THE BATTERY BEFORE THE POWER INDICATOR ON
THEINSTRUMENTPANELSHOWSNOPOWER.
BATTERY
11
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
1. DO NOT CHARGE OR STORETHE CLOSERTHAN 20 FEET
FROM ANY HEAT SOURCE (E.G.FURNACE,FIREPLACE,WATER HEATER,SPACE HEATER)
2.Be sure to only use 110V AC with the charger.
3.PLUG the POWER INPUT CORD into the charging receptacle located below
the front of the seat.
4.Plug the 48V battery charger into a 110V AC power source.
5.The CHARGER INDICATOR LIGHT will illuminate confirming that power is connected to the
charger.If the light does not come on check all connections.If it still does not come on after
checking all connections,fuses and that your AC plug is working,unplug the charger and call
your local dealer.
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
BATTERY RECYCLING
When maintained and used properly,(by following charging and storage guidelines),
the Lead Acid Battery Pack used in this product has a normal lifespan of two to three
years.When the battery pack no longer holds a charge or is unable to be charged
properly,it should be removed from the bike and delivered to a recycling facility.
Federal Lawsprohibit disposal of lead-acid batteries in everyday trash.Please contact
your local solid waste or recycling authority for recycling information in your area.

BRAKE-IN PERIOD
Your will last longer and work better once it is broken in properly.
Brake control cables,chains and axle nuts may get loose when a new
is first used and may require adjustment.We suggest that the brakes and axle nuts
be checked every 30 days and adjusted if necessary.The scooter can be used without
pedals,but pedaling the during acceleration will save battery life and
will make it easier to balance.The can also be pedaled in situations
where the battery power is too low due to a failure to charge or exceeding its
maximum range.The rider can also rest his or her feet on the pedals while riding the
MOTORINO
TM
Riding constantly at full throttle will reduce the scooter's range and battery life. A
smart rider will accelerate gently,gradually turning the throttle until the vehicle is at
speed. When riding downhill or approaching an intersection,release the throttle and
let the vehicle coast to conserve power. Apply the brakes gently to draw stopping
force from the regenerative brakes,and not the mechanical brakes.Since all Motorino
XP scooters have tubeless tires, it is a good idea to purchase tubeless tire repair kit
and apply the plug when they have a puncture. A 48/12V inverter can be used to
power a small compressor via a cigarette lighter; with this a flat can be repaired and
pumped on the spot, rather than pushing the bike to a station, which may damage
the wheel.
A CRASH OR OTHER IMPACT CAN PUT EXTRAORDINARY STRESS ON
COMPONENTS, CAUSING THEM TO FATIGUE PREMATURELY. COMPONENTS
SUFFERING FROM STRESS FATIGUE CAN FAIL SUDDENLY AND CATASTROPHICALLY,
CAUSINGLOSSOFCONTROL,SERIOUS INJURYORDEATH.
First,check yourself for injuries, and take care of them as best you can.Seek medical
help if necessary.Next,if your is damaged,perform the checks described
in this manual. If you are unable to fix any or all damage/problems,or if you find any
bent,scored,or discolored parts,please call your local dealer

IFYOUHAVE ANYDOUBTABOUTTHECONDITIONOFTHE
MOTORINO
TM
ORANYOFITS PARTS,DONT USEIT . CALL YOUR DEALERFOR
INSPECTION
GENERAL USAGE NOTES
12
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM

In order to minimize the chances of an accident and possible injury,it is critical that you
have all repair and maintenance work performed regularly
For more detailed maintenance instructions or for ordering replacement parts please
contact your dealer.Local bicycle retail stores, which have service facilities in your area
can also assist you with certain non-electrical repairs or adjustments that you are not
qualified to make,or for which you do not have the specific or specialized tools needed
to repair.
The fact that these scooters have no combustion engine, no transmission, no belts, no
chains,no clutch,no ignition plugs,no carburetor,and use no gasoline and no lubricants
means it requires almost no maintenance.The unique design of the direct drive system
and the use of regenerative brushless motor braking system limits all friction in the
scooter to the two bearings of the front axle and the two bearings in the motor and
make it much easier to maintain than other electric scooters.In general,the only regular
maintenance is to:
- Adjust the brakes
- Check the axle nuts
- Check tire pressure
- Check the chain
If your is equipped with hydraulic disk brakes you don'i need to adjust
them - they are self adjustable.You only have to check and maintain the brake fluid level
in the brake fluid tank.
If your has drum brakes they may need to be adjusted once in a while.
Front and rear break cables may get stretched.Tighten the nuts at the threaded end of
the cable to adjust them. If the breaking power decrease,check the break pads.
Check both axle nuts regularly
and especially the rear one.Make sure to
tighten the nuts firmly when you change
a tube.
MAINTENANCE
BRAKES MAINTENANCE
13
MOTORINO
TM
Rear Axle nuts - Check them regularly
MOTORINO
TM

MAINTENANCE
If your comes with tube tires,follow the next instructions:
1. Depress the tire valve to let all the air out of the tube,which will assist in removing
the tube from the wheel .
2. Remove the wheel from the using a wrench. Loosen the nuts
counterclockwise and make sure to remove the wheel retention clips on the rear wheel.
Be sure to remember where all the spacers and washers belong. For rear tire removal
you will also need to slip the chain off the rear sprocket to remove the wheel.The chain
must be properly reinstalled and re-tentioned when reinstalling the rear wheel.
3.Remove one bead of the tire from the rim by grasping it at a point opposite the valve
stem with both hands and,at the same time,lifting and peeling one side of the tire off
the rim.If the bead is on too tight for you to unseat it with your hands use tire levers to
lift the bead carefully over the tire rim.Tire levers can be purchased at any local bike
shop.Push the valve stem through the wheel rim.Remove the inner tube.
4. Carefully check the outside and inside of the tire for the cause of the puncture and
remove any debris or damaging material from the inside or outside of the tire.
PATCHING A TUBE IS AN EMERGENCY REPAIR. CARELESS PATCHING OR
APPLYING SEVERAL PATCHES CAN SERIOUSLY WEAKEN THE TUBE, RESULTING IN
POSSIBLE TUBE FAILURE, WHICH COULD CAUSE YOU TO LOSE CONTROL AND FALL.
REPLACEAPATCHEDTUBEASSOONASPOSSIBLE.
5. Reinstall the tire and tube. Slip one tire bead over the rim. Insert the tube valve
through its hole in the rim. Feed the tube carefully into the cavity of the tire.Inflate the
tube just enough to give it some shape.Starting at the valve stem and working around
both sides of the rim to the side opposite the valve stem,use your thumbs to push and
seat the other bead of the tire inside the rim.
IF YOU USE A SCREWDRIVER OR ANY TOOL OTHER THAN A TIRE LEVER,
YOUARELIKELYTOPUNCTURETHETUBE.
6. Check to make sure that the tire is evenly seated around both sides of the rim and
that the tube is inside the tire beads. Inflate the tube slowly to the recommended
pressure on the tire sidewall,all the while checking to make sure that the tire beads stay
seated in the rim.
14
MOTORINO
TM
FLATTIRE REPAIR
Your may come with tubeless tires or tires with tubes.For tubeless tires we
recommend you carry a tubeless tire repair kit and use it on any minor puncture.Consult with
professional tire repair service shop to make sure your repair will hold.It is a good idea to
carry a portable compressor and tubeless tire liquid sealer.That will help you to be back on
road in a few minutes if you have flat without even removing the wheel.
Don't ride or push your with a flat tire.This will cause the tire
beads to detach from the rim and possibly damage the rim.
IFTHETIRE IS CUT,or if the puncture is too large to be effectively plugged
YOU MUST REPLACETHETIRETO PREVENT ANY SUDDEN AND
CATASTROPHIC FAILURE CAUSING LOSS OF CONTROL,SERIOUS INJURY
OR DEATH.
MOTORINO
TM
MOTORINO
TM
MOTORINO
TM

OPERATING INSTRUCTIONS
KEY ANDTHROTTLE OPERATION
ON/OFF/LOCK Switch:(ignition)
1.
BEFOREOPERATINGYOUR MAKESURETHATTHETHROTTLEGRIPISNOTROTATED
TOTHE"ON"POSITION!!!MAKEALSOSURETHATYOURTHROTTLEISNOT"STICKY" ANDROTATES
FREELYBACKTOTHEINITIALPOSITION
THROTTLE CONTROL
The uses a speed changing throttle grip. It is on the right side of the
handlebar. Rotate the throttle grip toward the seat to accelerate and rotate forward
away from the seat to slow down.
All MOTORINO XP models are equipped with a CCT electronic gear switch which allows
you to select between high torque,high speed and economy mode depending on the
road conditions or your preferences. High torque (middle position of the switch) is
suitable for hills and flat terrain.We suggest you to avoid using high speed mode on
hills to avoid draining your battery faster.Instead you can use high speed when
approaching hills and then switch to high torque when the bike begins to slow.Once
you are on flat pavement and your acceleration is constant the CCT automatically
switches to economy mode.We suggest you use high torque mode most of the
time,as the most practical MOTORINO CCT setting.
15
MOTORINO TM
MOTORINO
TM
MOTORINOTM
is ON. Turn it ON only when you are ready
to go.Turn it OFF when you are not riding and remove key.
2. is OFF.Turn it OFF when not in use to preserve
the battery.
3. Push the key in on this position to lock the handlebar and
turn it to position 4
4. Handlebar is locked.The key can be removed
MOTORINO TM
It is suggested after acceleration to turn back 1/4 turn the throttle.This will increase your range
and increase your battery life.
LEFT RIGHT

OPERATING INSTRUCTIONS
BEFOREOPERATINGYOUR MAKESURETHATTHETHROTTLEGRIPISNOTROTATED
TO THE "ON" POSITION!!! MAKE ALSO SURE THAT YOUR THROTTLE IS NOT "STICKY" AND ROTATES
FREELYBACKTOTHEINITIALPOSSITION
16
MOTORINO
TM
The distance and speed depend upon the riding style and the road conditions. A constant
speed and less stops will ensure longer range. Other factors include weather, vehicle
condition,andbatterycharge. Driversmustbecautiouswhendrivingonroughroads,inpoor
weather,or when the battery charge is low. Always check the battery gauge while you are
ridingandbesurethatitdoesnotgettoolowtoooften.
1. Position yourself behind the handlebar with your feet on both sides of your bike and turn
the ignition key on.Do not turn it on when you are beside the bike.
2. Push the bike forward to release it from the main kick stand and then turn theThrottle
gradually to accelerate.Do not turn theThrottle until you are in position to drive.
3.To prevent losing control of the vehicle,please turn theThrottle slowly until the speed
increases.This will also protect your battery from stress,increase your range and prolong
battery life.
4.To stop,release the throttle and apply the front and rear brake simultaneously.You can
decelerate by slightly pressing the brakes to start regeneration mode.The noise and slight
vibration caused by regeneration is normal.
6.When you change direction turn on the signal switch left or right and don't forget to press it
to turn it off.
7. The Brushless motor makes a small electromagnetic noise when accelerating.
8.Always remove the key from the ignition when not using the bike.
9.We suggest you use the main kickstand rather than the side one.

OPERATING INSTRUCTIONS
17
MOTORINO TM
MAIN BREAKER
SECOND BATTERY
CABLE
48/12V DC/DC INVERTER
ALARM
The scooters driving system
consist of four main components:
 - Battery
 - Controller
 -Throttle
 - Motor
When the throttle is twisted a signal goes
to the controller communicating the desired
motor rpm.The controller then draws current
from the battery to accelerate to and maintain
the desired speed.Higher speeds and steep hill
climbing demand more from the battery,and
will reduce your range.A second battery can
be connected to the extra battery cable to
extend the range,and prolong the life of both
batteries.The main breaker under the seat
works as a high current protector.
48V DC to 12V DC inverter inverts the voltage
to 12V.All light bulbs work on 12V.
The alarm works on 48V.It is vibration sensitive.
No matter that it consumes very little amount of
power,it is recommended when the
is stored for a long period of time the main breaker
to be turned OFF.
CCT CONTROLLER
THROTTLE
MAIN COMPONENTS
MOTOR
MOTORINO TM

18
Troubleshooting
Problem
Condition
Check
Solution
When I turn my
vehicle on nothing
happens.
1. No light
indications on the
display.
1. Check that the main
breaker under the seat
ison“ON” position.
2. Check power plug
connection and battery
level.
1. Flip the breaker lever
to “ON”
2. Fasten connections
2. Power indication
light is on
3. Check battery and
motor connection. Contact the
supplier.
3. Clean and fasten
battery terminal
connectors
4. Fasten the motor
connections with the
controller under seat. Contact
the supplier.
3. Power indication
light is on and the
brake light is on
4. Check that the brake
levers return to their
normal position.
5. Loosen the brake. If
there is any corrosion,
replace. Contact the
supplier.
5. Battery voltage is
below 42 volts.
6. Charge or replace
battery. Inquire about
desulphation
The Throttle does
not function properly, the
vehicle
moves without
acceleration.
1. The Throttle does
not return to the OFF
position.
1. Check the grip for
Damage
2. Check the Throttle
spring.
3.Check if the Throttle handle
is loose
1.Use a flat head
screwdriver to adjust
the gap between the
rubber handle and the
cover.
2. Readjust the Throttle
spring position. Ensure the
spring is properly fastened to
the throttle interior
3. Tighten the bolt on the
underside with an Allen key
The range is low
Charger light is off
1. Bad connection
between the charger
and the battery.
2.Charger doesn’t
charge
1. Check the charger
plug for corrosion.
2. Check fuses inside the
charger, Replace the charger
or fuses.
Battery doesn’t hold
a charge
1. Connections between
the battery Batteries are lose
2. Bad battery cell
1.Check all connections
between the batteries
2. Replace the bad
battery cell
The brakes are not
working properly
1. Brake levers feel too soft
2. No braking power
1. Needs adjustment
2. Brake pads are dirty
or need replacement
3.Low level Brake fluid
1. Adjust the brake
cable –see instructions
2. Clean brake pads
using sand paper or
replace
3. Add Brake fluid

22
WARRANTY INFO
Warranty
To activate your warranty you should go to www.motorino.ca/warranty,
or fill out the warranty form at the retailer you purchased your Greenwit
product from.
Greenwit Ltd.warrants to the original retail purchaser ("you") that the
Greenwit Motorino scooter for which this warranty has been issued is
free from defects in materials and workmanship as follows:
Frame - 24 month warranty (excluding kick stands)
Electric Motor - 12 month warranty
Controller and electric circuits - 12 month warranty
Battery and charger - 6 month warranty
This warranty is not transferable to a subsequent purchaser.Greenwit's
dealers sole obligation under this warranty is to repair or replace the
product,at their option.Greenwit's dealer must be notified in writing of
any claim under this warranty within 10 days of the discovery of any fault or defect.
Immediately report any abnormal product behavior to Greenwit or a Greenwit dealer.
Warranty Limitations
The duration of any implied warranty or condition, of merchantability for a particular
purpose,or otherwise,on this product shall be limited to the duration of the warranty
expressed above.In no event shall Greenwit or Greenwit dealers be liable for any loss,
inconvenience or damage, whether direct, incidental, consequential or otherwise,
resulting from a breach of any expressed or implied warranty condition, of
merchantability for a particular purpose, or otherwise with respect to this product,
except as set forth herein.This warranty gives you specific legal rights, in addition to
other consumer rights bestowed by your province or state.
This warranty will be interpreted pursuant to the laws of Canada and USA.The original
English language version of this warranty supersedes all translations and Greenwit is
not responsible for any errors in translation of this warranty or any product literature.
This warranty is not intended to confer any additional legal,jurisdictional or warranty
rights to you other that those set forth herein or required by law.If any portion of this
warranty is held to be invalid or unenforceable for any reason, such finding will not
invalidate any other provision.For products purchased outisde Canada please contact
Greenwit's authorized distributor in that country.
Under no circumstances is Greenwit liable for any consequences of the
assembly,inspection or service work of their dealers.
19
