Greenwit Xt Use and care manual

Assembly and User's Manual

Model: XT/ST/VT

For the most recent version of this user's manual and for all updated

product information please visit www.greenwit.com or call

Customer Service / Technical Support at:

604-331-0555

Tus - Sun 11am - 6pm PST

GREENWIT

#405 - 201 Alvin Narod Mews

Vancouver, BC, V6B 8P5 website: www.greenwit.com

READ THIS MANUAL BEFORE OPERATING YOUR

GREENWIT Ltd. STRONGLY SUGGESTS THE

OPERATOR OF THIS PRODUCT BE 16 YEARS OF AGE OR OLDER.

MOTORINOTM

YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS

INVOLVING THE USE OF THE . TO DETERMINE IF COVERAGE IS

PROVIDED YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.

MOTORINOTM

Table of Contents...................................................................................................................

Features and Specifications...............................................................................................

Contents of the Box..............................................................................................................

General Usage Restrictions and General Safety Instructions.

................

Assembly Instructions..........................................................................................................

Battery........................................................................................................................................

General Usage Notes............................................................................................................

Drive Chain Maintenance...................................................................................................

Tire Maintenance...................................................................................................................

Front Wheel Removal...........................................................................................................

Flat Tire Repair........................................................................................................................

Brake Maintenance...............................................................................................................

Fuse Replacement................................................................................................................

Key and Throttle Operation...............................................................................................

Parts.............................................................................................................

Replacements Parts List........................................................................

Warranty & Limitations....................................................................................................

Warranty Service Options & Exclusions........................................................................

Return Policy..........................................................................................................................

Notes....................................................................................................................................

25,26

TABLE OF CONTENTS

MOTORINOTM

FEATURES & SPECIFICATIONS

FEATURES AND SPECIFICATIONS

- Motor Specs: Bbrushless DC Motor, Rotated Pick Power: 500W, Speed: 400r/min

- Recharge Time for the Battery: 4-6 Hours

- Battery Holds 4-6 Hours of ride Time

- One Full Charge Lasts up to 50 km with single battery and 80 km with dual. Regeneration  

models can go up to 100 km.

- Speeds up to 32km/h on level pavement with 75 kg rider

- Weight of MOTORINO: 55 kg

CONTENTS OF THE BOX

- with 48V battery installed (charging required)

- Left and right pedals (to be attached, no tool required)

- 48V charger for 110V AC outlet

- User's manual

- Two Ignition Keys (also used for under seat storage and main battery compartment)

- Two Storage Box Keys

GENERAL USAGE RESTRICTIONS AND GENERAL SAFETY INSTRUCTIONS

This Manual contains many notes concerning the consequences of failure to

maintain or inspect your

MOTORINOTM

. A means that failure to follow the

instructions following it may result in injury to the rider or others during use, which may

include loosing control and falling. Because any fall can result in serious injury or even death,

we do not repeat the warning of possible injury or death whenever the risk of falling is

mentioned. A on the other hand means that failure to follow the instructions

following it may result in damage to the MOTORINO™ or component during installation or

use. (I.e. risk of property (product) damage only)

Thank you for purchasing the low speed electrically powered

MOTORINOTM

The

MOTORINOTM

complies with the Canadian Motor Vehicle Safety Regulation Act

(CMVSRA) It is classified as Power Assisted Bicycle in section 1.2.1 in the above mentioned

act.

MOTORINOTM

GENERAL SAFETY GUIDELINES & RESTRICTIONS

Your province motor vehicle branch, or the city or county where it will be used, may regulate the

use of devices like the

MOTORINOTM

. Some provinces may require a driver's license or

minimum age to use the

MOTORINOTM

. In some provinces it may be referred to as an "power

assisted bicycle" or "restricted use motorcycle". Please check with your local motor vehicle

branch or insurance company on requirements for using the

MOTORINOTM

If your province or municipality allows the

MOTORINOTM

to be used on vehicle roadways please

make sure you are familiar with all traffic laws, such as yielding to pedestrians and other

motorists, signaling, riding as far to the right edge of the roadway as possible, obeying traffic

signs etc.Your province MVB can provide you with materials related to these traffic laws.

In addition to those traffic laws abide by the following general principals:

1. You are sharing the road or the path with others - motorists, pedestrians and other cyclists.

Respect their rights, and be tolerant if they infringe on yours.

2. Ride defensively.

3. Look ahead of where you're going, and be ready to avoid:

- Vehicles slowing or turning in front of you, entering the road or your lane ahead of you, or

coming up behind you.

- Parked car doors opening in front of you.

- Pedestrians stepping out in front of you.

- Children or dogs playing near the road.

- Pot holes, sewer grating, railroad tracks, expansion joints, road or sidewalk construction,

debris and other obstructions that could cause you to swerve into traffic, catch your wheel or

otherwise cause you to lose control and have an accident.

- The many other hazards and distractions which can occur while using the

MOTORINOTM

during a ride.

4. Ride on the right side of the road, in the same direction as vehicle traffic and as close

to the edge of the road as possible.

5. Stop at stop signs and traffic lights; slow down and look both ways at street intersections.

Remember that the

MOTORINOTM

will always lose in a collision with a motor vehicle, so be

prepared to yield even if you have the right of way.

6. Use hand signals for turning and stopping. Learn the local vehicle code for the correct

signal.

GENERAL SAFETY GUIDELINES & RESTRICTIONS

HELMET USE WHILE RIDING THE

IN ADDITION TO THE REQUIREMENTS ABOVE, THE IS NOT

TO BE RIDDEN / USED:

1. on any roadways where the speed limit is in excess of 50 km/h

2. on any sidewalks or pedestrian walkways

3. on any bumpy, rough or unpaved surfaces

4. in darkness

5. on sandy, wet or gravel covered surfaces

6. by any person weighing more than 225 lbs

8. by any person with an inseam of less than 22"

MOTORINOTM

8. Don't weave through traffic or make any moves that may surprise people with whom

you are sharing the road.

9. Never carry anything which obstructs your vision or your complete control of the

or which could become entangled in the moving parts of the

10. Never hitch a ride by holding on to another vehicle.

NEITHER GREENWIT Ltd. NOR THE RETAIL SELLER OF THE

IS RESPONSIBLE FOR THE CONSEQUENCES OF FAILURE TO COMPLY WITH

FEDERAL AND PROVINCIAL ORDINANCES RELATING TO THE USE OF THE

This product contains lead and lead compounds, chemicals known to cause cancer

and reproductive harm. Wash hands after handling.

CMVSRA requires that you use a helmet like those

used by human powered bike riders while riding the

. should not be used under any

circumstances without properly wearing a helmet.

MOTORINO

TM MOTORINO

7. by any person shorter than 60"

MOTORINOTM

1" inch

22" inch

9. by more than one rider at a time (no passengers)

10.by any physically or mentally challenged person

11.by any person with vision, balance,hearing or coordination impairments

12.by any person using headphones or a cellular phone [They mask traffic sounds

and emergency vehicle sirens, distract you from concentrating on what's going on

around you, and their wires can tangle in the moving parts of the ,

causing you to lose control]

13.to carry more than 10 lbs of cargo in the cargo compartment (in addition to the rider)

14.in excess of 20 mph (with or without the motor activated)

15.by barefoot riders or those wearing sandals,open toed,high heeled,platform or

slip on footwear

16.on steep inclines or on uneven terrain

17.by any person who has ingested any alcohol or drug that could impair their ability

to operate the

18.without 2 hands on the handle bar

19.while not seated on the seat

20.to jump ramps, curbs,or objects or attempt any stunts

21.with excessive speed for the terrain, circumstances or maneuver with clothing or

extremities in close proximity to the drive chain or any moving parts

22.beyond your ability or prior experience

23.by stopping with only the front brake.Use both brakes simultaneously

24.Do not try to accelerate and have the brake (s) on at the same time.

[This may cause damage to the motor or drive train or cause the motor or drive

train to overheat.]

BEFORE EACH RIDE:

1. Make sure you properly wear a helmet

2. Wear protective clothing and gloves

3. Wear eye protection that does not interfere with your peripheral vision

4. Check local and state laws before operating the in any area

5. Make sure all tail/brake lights, turn signals and headlight are operational

6. Make sure the horn is operational

7. Make sure the brakes are properly adjusted and working correctly (see page #15).

8. Make sure you understand how the brakes work (right lever for rear brake) and

that your hands can reach and squeeze the levers comfortably and hard enough

to stop the safely.

9. Make sure the chain is properly adjusted (see page #12).

GENERAL SAFETY GUIDELINES & RESTRICTIONS

MOTORINO

GENERAL SAFETY GUIDELINES & RESTRICTIONS

10.Make sure all parts of the are properly and securely fastened and adjusted,

including but not limited to pedals, crank arms, wheels,all controls and cargo

(Please refer to Assembly Instructions)

11.Make sure the tires are not excessively worn,do not have tears or cuts, and are properly

seated on the rim and inflated to the proper pressure on the sidewall

(DO NOT USE GAS STATION PUMPS FOR INFLATION)

12.Make sure the wheels spin straight and that the rims are not bent or damaged

(front wheel must be undamaged for front brake to work properly)

13.Make sure the throttle is in the "OFF" position before turning key on.

This will prevent the from moving forward without notice once the

ignition key is turned.

AFTER EACH RIDE:

1. Make sure that the ignition key is turned OFF and that all keys are removed and

kept in a safe place

2. Make sure that the battery is not left fully discharged or close to fully discharged

3. Make sure the throttle is rotated to the off position

4. Ensure that the kickstand is used so the will not fall over and get damaged

5. Ensure the is not kept outdoors or where moisture can damage it

6. Do not charge or store the closer than 20 feet from any flame

(e.g. furnace, fireplace, water heater, space heater)

7. Do not allow children under 16 to play on or near the unattended



 FAILURE TO FOLLOW THESE OPERATION INSTRUCTIONS CAN RESULT IN

SERIOUS INJURY OR DEATH OR COULD RESULT IN AN ELECTRICAL SHORT AND OR

FIRE.



DONOTMAKEANYALTERATIONS ORMODIFICATIONSTOTHE ,

OR ADD ANY PARTS NOT AUTHORIZED BY GREENWIT Ltd. EXCEPT THOSE

DISCUSSED IN THIS MANUAL OR THOSE REQUIRED BY LAW. DO NOT REMOVE ANY

REFLECTORS, LIGHTS OR OTHER STANDARD EQUIPMENT.

All authorized replacement parts are listed on the parts list enclosed

or available at www.greenwit.com or www.e-ride.ca or by calling Greenwit customer

service at 1-888-331 - 0555 Thu - Sun 11am - 6pm PST.

MOTORINOTM

ASSEMBLY INSTRUCTIONS

Pedal Crank Arm

Pedal

HexagonalKey

Mirror

Nut

side of the (your left side as if seated on the

). The inside surface of the crank arms are labeled "L" and "R" like the pedals. The

Left pedal has reverse threading meaning it tightens by turning it to the left (counter-clockwise).

The Right pedal has normal threading and tightens by turning it to the right (clockwise). After

threading the pedals into the crank arms as far as possible with your fingers (to avoid cross

threading), tighten them snugly with an adjustable wrench.

REARVIEW MIRRORS

After unpacking your there is minimal assembly to be completed. Assembly

consists of attaching the pedals to the and attaching the rearview mirrors.

PEDALS

Locate Pedals (Set of 2) The pedals are labeled

left and right near the threads. They are not

interchangeable. The left pedal goes into the

threaded hole on the left crank arm on the left

You have now successfully assembled your !

If you have any questions about assembly please call :

Greenwit Customer Service / Technical Support

Toll-Free at 1-888-331-0555 Thu - Sun 11-am - 6pm PST.

Locate the chrome mirrors included with your .

These have threaded ends and include a nut. With the

Hexagonal ("Allen" or "Hex" wrench) remove the screw and

nut as shown in the pictures. Once the nut is removed from

the threaded end of each mirror, insert the threaded end of

the mirror as shown on picture at left. Then screw the nut onto

the mirror's threaded end as shown on picture below.

The mirror needs to be

tightened fully for assembly

to be safe. Repeat the

process for the other mirror.

Once mirrors are installed,

they should look like the

picture on left. Make sure to

adjust the mirrors before

use so that you can see

behind you as you ride.

MOTORINOTM

BATTERY

BEFORE OPERATING YOUR NEW , FOR THE FIRST TIME, CHARGE THE BATTERY

FOR 14-16 HOURS, BUT UNDER NO CIRCUMSTANCES IN EXCESS OF 18 HOURS.

Be sure to charge the after each use. Keeping the battery properly charged

will help extend the battery life. Do not use the while the power indicator on

the instrument panel shows low energy. If the is over-used the battery's life

will be reduced.The uses a 48V (volt) battery pack.To charge the battery,

connect the 3-pin plug into the charging receptacle located directly below the front of seat.

The battery must be charged while installed in the . If you notice anything

unusual about the battery such as a cracked or leaking battery case, a battery that gets hot

while being used or charged, a battery case that appears "puffy" or

"bloated" etc, or there are any other problems with the battery,

please contact Greenwit Customer Service / Technical Support Toll-Free at:

1-888-331-0555 Thu-Sun 11am - 6pm PST.

The battery is sealed and is NOT user serviceable. Do not attempt to

repair, remove, adjust or in any way alter any internal or electrical

components, controls or wiring without first speaking with a customer

service representative.

The main battery weighs approximately twenty eight (37) pounds.

There is no need to remove it from the unless you are

replacing it. Use caution on removal.To replace the main battery pack, lift

the foot mat and unlock the lock located on the left side of the (using the

ignition key). Proceed to pull the battery out utilizing the handle. Disconnect the battery cable.

The is equipped with a 48V battery charger that will interrupt the

charging process once the battery has received a sufficient charge. Greeenwit Ltd strongly

suggests that the charger not be used in excess of 18 hours to prevent any

unnecessary wear on the battery or charger itself. Charging for periods greater than 18

hours may reduce the overall life expectancy and efficiency of these items.

    BATTERY

*****DO NOT DROP THE BATTERY*****

CHARGING THE BATTERY

TO AVOID DAMAGE TO THE BATTERY WHEN CHARGING, USE ONLY THE

CHARGER PROVIDED WITH YOUR .

1. DO NOT CHARGE OR STORE THE CLOSER THAN 20 FEET

FROM ANY FLAME (E.G. FURNACE, FIREPLACE,WATER HEATER, SPACE HEATER)

2. Be sure to only use 110V AC with the charger. Also make sure the plug is

inserted into a three prong grounded AC outlet.

3. PLUG the POWER INPUT CORD into the charging receptacle located below

the front of the seat. See picture above.

4. Plug the 48V battery charger into a 110V AC power source.

5.The CHARGER INDICATOR LIGHT will illuminate confirming that power is connected to the

charger. If the light does not come on check all connections. If it still does not come on after

checking all connections, fuses and that your AC plug is working, unplug the charger and call

Greenwit Customer Service/ Technical Support Toll-Free at

1-888-331-0555 Thu-Sun 11am - 6pm PST

MOTORINOTM

6.  DO NOT KEEP THE CONNECTED TO THE CHARGER

FOR LONGER THAN 18 HOURS UNDER ANY CIRCUMSTANCES! DOING SO COULD

CAUSE THE BATTERY OR CHARGER TO OVERHEAT AND CAUSE A FIRE.

When the light on the 36V charger is blinking, the

battery is being properly

charged. When the

MOTORINOTM

battery is fully charged, the light will remain lit without

blinking (see 48V charger for example). If this does not occur after approximately

16 hours of charging, unplug the charger and call Greenwit Customer

Service/Technical Support. Normal recharge time for the main battery is 4-6 hours

(assuming it is not 100% discharged).

8. Disconnect the Input Cord from the Charging Receptacle.

9. Disconnect the charger from the 110V Power Source.

10.  NEVER LEAVE THE BATTERY CHARGER CONNECTED TO THE 110V

POWER SOURCE OR THE WHEN NOT CHARGING THE BATTERY.

KEEPING THE CHARGER PLUGGED INTO THE 110V POWER SOURCE AND NOT

THE BATTERY COULD CAUSE THE CHARGER TO OVERHEAT AND OR CAUSE

A FIRE.

11.When storing your for lengthy periods of time, the battery should

be charged at least once a month to avoid full depletion.



FAILURE TO KEEP THE BATTERY CHARGED WILL

CAUSE TOTAL BATTERY FAILURE. DO NOT ALLOW BATTERY TO BECOME FULLY

DISCHARGED!!! ALWAYS RECHARGE THE BATTERY BEFORE THE POWER INDICATOR

ON THE INSTRUMENT PANEL SHOWS NO POWER. ALLOWING THE BATTERY TO FULLY

DISCHARGE WILL REDUCE BATTERY LIFE AND MAY RUIN THE BATTERY OR COULD

CAUSE THE BATTERY OR CHARGER TO OVERHEAT AND CAUSE A FIRE THE NEXT TIME

THE IS CHARGED.

BATTERY POSTS, TERMINALS, POWER CORDS AND BRAKE CABLES MAY CONTAIN

LEAD AND LEAD COMPOUNDS, CHEMICALS KNOWN TO CAUSE CANCER AND

REPRODUCTIVE HARM. WASH HANDS AFTER HANDLING.

BATTERY

MOTORINOTM

BATTERY

BATTERY RECYCLING

When maintained and used properly, (by following charging and storage guidelines),

the Lead Acid Battery Pack used in this product has a normal lifespan of many miles.

When the battery pack no longer holds a charge or is unable to be charged properly, it

should be removed from the and delivered to a recycling facility. Fedral

Laws prohibit disposal of lead-acid batteries in everyday trash. Please contact your

local solid waste or recycling authority for recycling information in your area.

Break-in Period: Your will last longer and work better when it is broken in

properly. Brake control cables and chains may stretch or "seat" when a new

i Is first used and may require an adjustment. We suggest that the brakes

and chain be checked every 30 days and adjusted if necessary.

The is not intended to be used without the installation of the pedals.

Pedaling the upon starting will save battery life and will make it easier to

balance. The can also be pedaled in situation where the battery power

is too low due to a failure to charge the or exceeding its distance range.

The rider can also rest his or her feet on the pedals while riding the

MOTORINOTM

under electrical power.

It is a good idea to keep a tool kit with you when you ride. You should also carry 2

spare inner tubes that fit the wheel and tire size as well as a manual air pump (with

gauge) to re-inflate the tire if you have a flat or it becomes low during use.

If your sustains an impact:

 A CRASH OR OTHER IMPACT CAN PUT EXTRAORDINARY STRESS ON

COMPONENTS, CAUSING THEM TO FATIGUE PREMATURELY. COMPONENTS

SUFFERING FROM STRESS FATIGUE CAN FAIL SUDDENLY AND CATASTROPHICALLY,

CAUSING LOSS OF CONTROL, SERIOUS INJURY OR DEATH.

First, check yourself for injuries, and take care of them as best you can.

Seek medical help if necessary. Next, if your is damaged, perform the

checks described in this manual. If you are unable to fix any or all damage/problems,

or if you find any bent, scored, or discolored parts, please call Greenwit Service at 1-

888-331-0555 M-F 11am - 9pm PST.

 IF YOU HAVE ANY DOUBT ABOUT THE CONDITION OF THE

MOTORINOTM

OR ANY OF ITS PARTS, DONT USE IT . CALL GREENWIT CUSTOMER SERVICE AT 1-888-331-0555

Thu-Sun 11AM - 6PM PST AND THEY WILL ASSIST YOU IN PERFORMING A THOROUGH CHECK

GENERAL USAGE NOTES

``````````````

MOTORINOTM

MAINTENANCE

Technological breakthroughs have made components more complex than ever before, and the

pace of innovation is increasing. This on-going revolution makes it impossible for this manual to

provide all the information required to properly repair and/or maintain your

In order to help minimize the chances of an accident and possible injury, it is critical that you have

all repair and maintenance work performed regularly.

For more detailed maintenance instructions or for ordering replacement parts please contact

Greenwit Customer Service / Technical Support Toll-Free at 1-888-331-0555 Thu-Sun 11am - 6pm

PST.

Local bicycle retail stores, which have service facilities in your area, can also assist you with certain

non-electrical repairs or adjustments that you are not qualified to make or for which you do not

have the specific or specialized tools needed for repair.

Periodic adjustments of the drive chain will be necessary to

maintain proper tension. If the drive chain is loose, it may make a

"popping" noise, which indicates a need for immediate

adjustment. To manually check the drive chain tension, make sure

the drive chain is properly seated on both the front and rear

sprockets. Move the top portion of the drive chain in an upward

direction. approximately 1". If there is greater than approximately

1" of movement, the drive chain must be adjusted before use to

avoid unseating "falling-off". Before adjusting the chain, please make sure the key is in the "

position and disconnect the battery power to prevent any injuries or damage.To disconnect the

main battery power, lift the foot mat and unlock the lock located on the left side of the

MOTORINOTM

(using the ignition key). Proceed to pull the battery out utilizing the handle.

Disconnect the battery cable. Loosen both rear axle nuts until the wheel will move freely in the

behind the rear axle until the proper tension is achieved.The screws must

be turned clockwise to tighten, and counter-clockwise to loosen the

chain. Check the tension by rotating the wheel by hand. Be sure that the

drive chain is not too tight, if so, the chain will break.Tighten the rear axle

nuts and re-check the tension. Make sure that the rear wheel is installed

straight and that the tension adjustment screws have not caused the rear

wheel to sit crooked once the axle nuts are tightened. The chain should

be cleaned and lubricated with bicycle chain lubricant (available at local

bike shops) after every 100 miles of riding (or every three rides) or after

riding the

MOTORINOTM

in wet road conditions.

DRIVE CHAIN MAINTENANCE

MOTORINOTM

MAINTENANCE

TIRE MAINTENANCE

Make sure that the air pressure for all tires is correct. The proper inflation amount is listed on

the sidewall of the tire. If the tires have less than the recommended amount of pressure, this

will decrease the battery usage time and may cause the unit to handle poorly or cause damage

to the tires. Use an air pressure gauge to check for the air pressure of the tire.

DO NOT USE GAS STATION AIR FILLING STATIONS AS THE PRESSURE IS USUALLY

TOO HIGH AND THE GAUGES ARE INACCURATE. OVER INFLATION OF THE TIRE COULD CAUSE A

BLOW OUT AND CRASH.

MOTORINOTM

FRONT WHEEL REMOVAL

The front forks utilize a secondary

wheel retention device to keep the wheel from

disengaging if the axle nut is insufficiently

tightened. Secondary retention devices are not

a substitute for correct axle nut tightening. Call

Greenwit Customer Service / Technical Support

Toll-Free at 1-888-331-0555 Thu-Sun 11am - 6pm

PST to explain the particular secondary

retention device on your

MOTORINOTM

or if you

do not understand how to properly remove and

replace the front wheel properly with the

secondary retention device.

Permanent removal or disabling

the secondary retention device is extremely

dangerous and may lead to serious injury or

death. It also will void the warranty.

MAINTENANCE

FLAT TIRE REPAIR (continued)

1. Depress the tire valve to let all the air out of the tube, which will assist in removing the wheel

from the .

2. Remove the wheel from the using a wrench. Loosen the nuts counterclockwise

and make sure to remove the wheel retention clips on the front wheel. Be sure to remember

where all the spacers and washers belong. For rear tire removal you will also need to slip the

chain off the rear sprocket to remove the wheel. The chain must be properly reinstalled and re-

tensioned when reinstalling the rear wheel. Make certain the chain is properly positioned on both

front and rear sprockets before re-tightening rear wheel.

3. Remove one bead of the tire from the rim by grasping it at a point opposite the valve stem with

both hands and, at the same time, lifting and peeling one side of the tire off the rim. If the bead is

on too tight for you to unseat it with your hands use tire levers to lift the bead carefully over the

tire rim. Tire levers can be purchased at any local bike shop. Push the valve stem through the

wheel rim. Remove the inner tube.

4. Carefully check the outside and inside of the tire for the cause of the puncture and remove any

debris or damaging material from the inside or outside of the tire.

IF THE TIRE IS CUT, YOU MUST REPLACE THE TIRE TO PREVENT ANY SUDDEN

AND CATASTROPHIC FAILURE CAUSING LOSS OF CONTROL, SERIOUS INJURY OR DEATH.

Replacement parts are able to be purchased by calling the Greenwit Customer Service at 1-800

331 0555 M-F 10am - 9pm PST or by visiting Greenwits's web site at www.greenwit.com.

PATCHING A TUBE IS AN EMERGENCY REPAIR. CARELESS PATCHING OR APPLYING

SEVERAL PATCHES CAN SERIOUSLY WEAKEN THE TUBE, RESULTING IN POSSIBLE TUBE FAILURE,

WHICH COULD CAUSE YOU TO LOOSE CONTROL AND FALL. REPLACE A PATCHED TUBE AS

SOON AS POSSIBLE.

5. Reinstall the tire and tube. Slip one tire bead over the rim. Inset the tube valve through its hold

in the rim. Feed the tube carefully into the cavity of the tire. Inflate the tube just enough to give it

some shape. Starting at the valve stem and working around both sides of the rim to the side

opposite the valve stem, use your thumbs to push and seat the other bead of the tire inside the

rim. Be careful not to pinch the tube between the tire bead and the wheel rim. If you have trouble

getting the last few inches of bead over the edge of the rim with thumb pressure, use a tire lever

and be careful not to pinch the tube.

IF YOU USE A SCREWDRIVER OR ANY TOOL OTHER THAN A TIRE LEVER, YOU ARE

LIKELY TO PUNCTURE THE TUBE.

6. Check to make sure that the tire is evenly seated around both sides of the rim and that the tube

is inside the tire beads. Push the valve stem into the tire to make sure that its base is seated within

the tire's beads. Inflate the tube slowly to the recommended pressure on the tire sidewall, all the

while checking to make sure that the tire beads stay seated in the rim. Replace the valve cap.

Replace the wheel in the .

MOTORINO TM

MAINTENANCE

RIDING YOUR WITH A FLAT OR UNDER-INFLATED TIRE CAN

SERIOUSLY DAMAGE THE TIRE, RIM (WHEEL), TUBE, AND THE . IT MAY

ALSO CAUSE YOU TO LOSE CONTROL AND FALL.

Make sure that the air pressure for all tires is correct. The proper inflation amount is

listed on the sidewall of the tire. If the tires have less that the recommended amount

of pressure, this will decrease the battery usage time and may cause the unit to

handle poorly or cause damage to the tires. Use an air pressure gauge to check for

the air pressure of the tire.

DO NOT USE GAS STATION AIR FILLING STATIONS AS THE PRESSURE IS

USUALLY TOO HIGH AND THE GAUGES ARE INACCURATE. OVER INFLATION OF THE

TIRE COULD CAUSE A BLOW OUT AND CRASH.

BRAKE MAINTENANCE

Take a look at the brake pads before every ride. If when the brake lever is engaged

(approximately one (1) inch of brake lever movement) and the brake pads are not firmly

against the wheel rim, do NOT ride the . Call Greenwit Customer Service at

1-888-331-0555 Thu-Sun 11am - 6pm PST or visit your local bicycle dealership and have

them adjusted or replaced.

Check the control cables and cable housings. Any rust? Kinks? Fraying? If so, do NOT

ride the . Call Greenwit Customer Service at 1-888-331-0555 Thu-Sun 11am

- 6pm PST or visit your local bicycle dealership and have them adjusted or replaced.

Adjusting the brake cables at the brake lever can be accomplished by most people,

however brake pad adjustment or cable replacement should only be performed by

people with expertise in performing such adjustments or repairs. Call the Greenwit

Customer Service / Technical Support Toll-Free Number at: 1-888-331-0555 Thu-Sun

11am - 6pm PST for additional information about brake repairs or adjustments.

MOTORINOTM

MOTORINO

MOTORINO TM

MAINTENANCE

MAIN BATTERY FUSE REPLACEMENT

The has one 20 Amp fuse located on the main battery

pack. Replacement fuses are supplied in the user's manual bag. To

replace the fuse from the main battery pack, lift the foot mat.

Unlock the lock located on the left side of the (using the

longer in length ignition key). Proceed to pull the battery out

utilizing the handle. Disconnect the battery cable. Once the battery

has been pulled out of the compartment, locate the fuse holder

located next to the plug on the bottom of battery. Replace this fuse

with same type and amperage. Using the wrong fuse will result in

damage to the . Replacement fuses are supplied in the

user's manual bag.

Contact Greenwit Customer Service / Technical Support Toll-Free at

1-888-331-0555 Thu-Sun 11am - 6pm PST to purchase additional

spare fuses.

USING THE WRONG FUSE WILL RESULT IN DAMAGE TO THE . MAKE SURE THE

REPLACEMENT FUSE IS A STANDARD 20 AMP FUSE THAT PROPERLY FITS INTO THE FUSE HOLDER. IF YOU USE

THE WRONG SIZE OR AMPERAGE FUSE IT COULD RESULT IN A FIRE OR DAMAGE TO THE

MOTORINOTM

(OPTIONAL) SPARE BATTERY FUSE REPLACEMENT

The spare battery pack is optional and is not shipped with the . One can be purchased from Greenwit

Customer Service / Technical Support Toll-Free at 1-888-331-0555 Thu-Sun 11am - 6pm PST. The spare battery is

used to extend the riding range of the .

The spare battery is located in the under-seat storage

compartment. This compartment can be used for

storage if no spare battery is being used. To access this

spare battery, locate the seat lock on the left side of the

MOTORINO . Raise the seat to expose the spare battery.

Remove the power cable from the socket on the

battery. Using the handle, lift the battery out of the

battery compartment. It weighs approximately twenty

eight (28) pounds so be careful not to drop it (use

caution). The fuse holder is located next to the power

socket on battery. Replace this fuse with the same

type and amperage.

MOTORINOTM

MOTORINO TM

OPERATING INSTRUCTIONS

KEY AND THROTTLE OPERATION

ON/OFF Switch: (ignition)

1. OFF Position: is OFF

2. "center" ON Position: is ON, utilizes the primary battery.

3. ON Position: is ON, utilizes power from the optional

spare battery under the seat.

BEFORE OPERATING YOUR MAKE SURE THAT THE THROTTLE GRIP IS NOT ROTATED

TO THE "ON" POSITION!!! MAKE ALSO SURE THAT YOUR THROTTLE IS NOT "STICKY" AND ROTATES

FREELY BACK TO THE INITIAL POSSITION

SEE PICTURE FOR CORRECT PLACEMENT OF LEVER BEFORE USAGE!!!

Front Brake

Throttle Grip

Throttle Off Position

Horn

Signals

Rear Brake

Lights On/Off

Signals

THROTTLE CONTROL

The uses a speed changing throttle grip. It is on the right side of the

handlebar. Rotate the throttle grip toward the seat to accelerate and rotate forward

away from the seat to slow down.

MOTORINOTM

PARTS

14 15

55 45

PARTS - ST430/ST480/XT480

MOTORINOTM

PARTS

28 30

PARTS - ST430/ST480/XT480

MOTORINOTM

This manual suits for next models

Table of contents

Other Greenwit Scooter manuals

Greenwit

Greenwit XPv User manual

Popular Scooter manuals by other brands

Malaguti

Malaguti Centro 50 4T Workshop manual

DI BLASI

DI BLASI R30 owner's manual

Ninebot

Ninebot KickScooter MAX user manual

Eton America

Eton America Beamer R4 150CC Service manual

PGO

PGO BR-500 Service manual

Slane

Slane CALEDON user manual

Merits

Merits S731 owner's manual

PURE

PURE Advance Flex manual

Cobi Rehab

Cobi Rehab MobiBed quick guide

HOMCOM

HOMCOM AA1-080 Operational instructions

DAELIM

DAELIM E-FIVE manual

Swagway

Swagway X1 user manual

camry

camry CR 1035 user manual

Currie tech

Currie tech e4.5 eZip owner's manual

Nilox

Nilox DOC 6.5 manual

Insportline

Insportline IN 12568Handy J1 user manual

IMMOTOR

IMMOTOR GO quick start guide

Generic

Generic Ideo 50 user manual

Greenwit XT Use and care manual

Popular Scooter manuals by other brands
