GREMO 1050F4 Installation and user guide

Applies to serial numbers 41101, 51102, 61101–
Gremo AB
311 51 Ätran
Sweden
Tel. [phone]
Fax. [phone]
www.gremo.com
[email protected]
Release
Service and maintenance
manual in original
1050F 04EN
©Gremo 2019
Gremo
1050F4
Service and maintenance manual

Gremo1050F4 Service and maintenance
manual Contents
1 Service and maintenance ......................... 1
1.1 Safety rules during service ............... 1
1.2 Service and maintenance ................. 3
1.3 Volume specifications ....................... 4
1.4 Working with oils ............................... 4
1.5 Oil, requirement specification ........... 5
1.6 Antifreeze, requirement
specification..................................... 7
1.7 Fuel, requirement
specification..................................... 8
1.8 Cleaning of Safety Glass
Windows .......................................... 9
1.9 Welding Repairs.............................. 10
1.10 Tyres — Air pressure:
Manufacturer’s
recommendations.......................... 12
1.11 Daily maintenance (every 8-10
operating hours) ............................ 16
1.12 Inspection every 50 hours of
operation or every week ................ 19
1.13 Inspection every 500 hours of
operation or every three
months ........................................... 24
2 Service and maintenance during the
warranty period....................................... 53
2.1 Report, service during the
warranty period after 100 hours of
operation........................................ 54
2.2 Report, service during the
warranty period after 100 hours of
operation (cont'd.).......................... 55
2.3 Fault report 100 h............................ 56
2.4 Report, service during the
warranty period after 100 hours of
operation Copy Customer's
Copies............................................ 57
2.5 Report, service during the
warranty period after 100 hours of
operation (cont'd.) Copy Customer's
Copies............................................ 58
2.6 Fault report 100 h Copy
Customer's Copies ........................ 59
2.7 Report, service during the
warranty period after 500 hours of
operation........................................ 60
2.8 Report, service during the
warranty period after 500 hours of
operation (cont'd.).......................... 61
2.9 Fault report 500 h............................ 62
2.10 Report, service during the
warranty period after 500 hours of
operation Copy Customer's
Copies............................................ 63
2.11 Report, service during the
warranty period after 500 hours of
operation (cont'd.) Copy Customer's
Copies............................................ 64
2.12 Fault report 500 h Copy Customer's
Copies............................................ 65
2.13 Report, service during the
warranty period after 1,000 hours of
operation........................................ 66
2.14 Report, service during the
warranty period after 1,000 hours of
operation (cont'd.).......................... 68
2.15 Fault report 1,000 h....................... 69
2.16 Report, service during the
warranty period after 1,000 hours of
operation Copy Customer's
Copies............................................ 70
2.17 Report, service during the
warranty period after 1,000 hours of
operation (cont'd.) Copy Customer's
Copies............................................ 72
2.18 Fault report 1,000 h Copy
Customer's Copies ........................ 73
2.19 Report, service during the
warranty period after 1,500 hours of
operation........................................ 74
2.20 Report, service during the
warranty period after 1,500 hours of
operation (cont'd.).......................... 75
2.21 Fault report 1,500 h....................... 76
2.22 Report, service during the
warranty period after 1,500 hours of
operation Copy Customer's
Copies............................................ 77
2.23 Report, service during the
warranty period after 1,500 hours of
operation (cont'd.) Copy Customer's
Copies............................................ 78
2.24 Fault report 1,500 h Copy
Customer's Copies ........................ 79
2.25 Report, service during the
warranty period after 2,000 hours of
operation........................................ 80
2.26 Report, service during the
warranty period after 2,000 hours of
operation (cont'd.).......................... 81
2.27 Fault report 2,000 h....................... 82
2.28 Report, service during the
warranty period after 2,000 hours of
operation Copy Customer's
Copies............................................ 83
2.29 Report, service during the
warranty period after 2,000 hours of
operation (cont'd.) Copy Customer's
Copies............................................ 84
2.30 Fault report 2,000 h Copy
Customer's Copies ........................ 85
2.31 Report, service during the
warranty period after 2,500 hours of
operation........................................ 86
2.32 Report, service during the
warranty period after 2,500 hours of
operation (cont'd.).......................... 87

Contents Gremo1050F4 Service and maintenance
manual
2.33 Fault report 2,500 h....................... 88
2.34 Report, service during the
warranty period after 2,500 hours of
operation Copy Customer's
Copy .............................................. 89
2.35 Report, service during the
warranty period after 2,500 hours of
operation (cont'd.) Copy Customer's
Copy .............................................. 90
2.36 Fault report 2,500 h Copy
Customer's Copy ........................... 91
2.37 Report, service during the
warranty period after 3,000 hours of
operation........................................ 92
2.38 Report, service during the
warranty period after 3,000 hours of
operation (cont'd.).......................... 93
2.39 Fault report 3,000 h....................... 94
2.40 Report, service during the
warranty period after 3,000 hours of
operation Copy Customer's
Copy .............................................. 95
2.41 Report, service during the
warranty period after 3,000 hours of
operation (cont'd.) Copy Customer's
Copy .............................................. 96
2.42 Fault report 3,000 h Copy
Customer's Copy ........................... 97
2.43 Report, service during the
warranty period after 3,500 hours of
operation........................................ 98
2.44 Report, service during the warranty
period after 3,500 hours of operation
(cont'd.).......................................... 99
2.45 Fault report 3,500 h..................... 100
2.46 Report, service during the
warranty period after 3,500 hours of
operation Copy Customer's
Copy ............................................ 101
2.47 Report, service during the
warranty period after 3,500 hours of
operation (cont'd.) Copy Customer's
Copy ............................................ 102
2.48 Fault report 3,500 h Copy
Customer's Copy ......................... 103
2.49 Report, service during the
warranty period after 4,000 hours of
operation...................................... 104
2.50 Report, service during the
warranty period after 4,000 hours of
operation (cont'd.)........................ 105
2.51 Fault report 4,000 h..................... 106
2.52 Report, service during the
warranty period after 4,000 hours of
operation Copy Customer's
Copy ............................................ 107
2.53 Report, service during the
warranty period after 4,000 hours of
operation (cont'd.) Copy Customer's
Copy ............................................ 108
2.54 Fault report 4,000 h Copy
Customer's Copy ......................... 109

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.1 Safety rules during service
1 Service and maintenance
1.1 Safety rules during service
NOTICE
Read all signs and instructions on the machine and in
the safety regulations in the Instruction Manual before
you start servicing the machine.
Each of these contains important information about
handling and service.
Servicing which is not done correctly can present risks.
Make sure that you have enough knowledge, the correct
information, the correct tools and the correct equipment in
order to be able to carry out the service correctly. Repair or
replace broken tools or broken equipment.
You are not allowed to service the machine unless you
have the correct knowledge to do the work.
When you handle oil or fuel you should take measures to
avoid waste. Oil which is dumped on the ground will cause
damage to the environment and may also cause fire. Used
oils and fluids should always be taken care of by an
authorised company.
If you plan to install a comms radio, mobile phone or
similar equipment then the installation must be done
professionally in order to eliminate interference with
certain electronic components controlling the machine.
NOTICE
Always switch off the engine during service.
WARNING
Risk of serious crushing injury or fatal accident!
Always switch off the engine before releasing the cab to
tip it up.
Never go under a tipped-up cab unless it is propped up.
Ensure that the cab is propped up if you need to go
under it!
1

1 Service and maintenance
1.1 Safety rules during service
Gremo1050F4 Service and maintenance
manual
WARNING
During all work on the machine, remember the risk of
slipping. You should always use a safety helmet, safety
goggles, gloves, safety boots, breathing protection and
other necessary protective equipment when required.
WARNING
The bogie lift can be used as a lifting aid during service
and repairs, but always prop up the machine.
WARNING
When you lift or prop up the machine or parts of the
machine, make sure that the equipment you use is
intended for this purpose, is appropriately dimensioned,
and cannot slip or tip over!
CAUTION
When you are about to change the engine oil, hydraulic
oil or transmission oil: remember that the oil may be hot
and can cause burns. Avoid contact with skin and note
that oil vapours can cause irritation to airways.
CAUTION
The exhaust pipes are very hot and can cause serious
burns!
NOTICE
In case of hose breakage: connect the vacuum pump
(additional equipment) so that unnecessary oil does not
leak out!
2

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.2 Service and maintenance
1.2 Service and maintenance
Preventive maintenance measures are divided into time
intervals: daily checks (every 8-10 operating hours),
weekly checks every 50 operating hours and checks every
500, 1,000, 2,000 and 5,000 operating hours.
NOTICE
Regular servicing, and maintenance and servicing
during the guarantee period, i.e. the first 2,000 operating
hours, are described in the Service and Maintenance
Manual.
The daily maintenance includes a systematic inspection of
all screw joints. This measure is particularly important
when the machine is new or has been dismantled. The
more accuracy and care you put into the inspection at this
stage, the less is the risk of loose screw joints in the future.
Torque
Torque table (Nm).
Threading
Quality 8.8 Quality 10.9 Quality 12.9
M8 24 33 40
M10 47 65 79
M12 81 114 136
M14 128 181 217
M16 197 277 333
M18 275 386 463
M20 385 541 649
M24 665 935 1120
M27 961 1350 1620
With NordLock Increase torque by 20%
3

1 Service and maintenance
1.3 Volume specifications
Gremo1050F4 Service and maintenance
manual
1.3 Volume specifications
Part Total volume Replacement volume
Engine 11 litres (including filter
replacement) *)
10 litres (without filter
replacement)
Cooling system approx. 20 litres 15 litres
Hub reductions 2.4 litres x 8 2.4 litres x 8
Differential 8.0 litres x 2 8.0 litres x 2
Bogie cases 9.0 litres x 4 9.0 litres x 4
Gearbox 3.4 litres 3.4 litres
Hydraulic system 130 litres 90 litres
Fuel tank 120 litres
Crane base, crane
Cranab FC8
5.6 litres 5.6 litres
Crane base, crane
Loglift F59
7 litres 6.5 litres
Cab tilt pump 0.7 litres 0.7 litres
*) incl. the oil in the filter
1.4 Working with oils
CAUTION
All work where you may get into contact with oil involves
a risk of skin trouble, e.g. eczema. The risk is greatest in
the case of hydraulic oils, but there is also a risk with
other types of oil. Careful hygiene is therefore always of
great importance!
Some hints to remember and observe:
• Avoid contact with oil, especially hot oil!
• If your skin has been exposed to oil, clean it as soon as
possible with water and soap, or with a suitable washing
cream and water.
4

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.5 Oil, requirement specification
• Use protective gloves! Wash your hands before putting
the gloves on. A protective cream on your hands will
make it easier to clean them later.
• Don’t keep any oil-stained rags in your pockets!
• Change oil-stained clothes for fresh ones!
• Always keep an extra overall easily available e.g. in
your car or work-shed. Not in the machine where it
easily gets dirty.
• Cuts and small wounds must be treated immediately by
cleaning and applying dressings!
• Avoid breathing oil fumes!
• Wash your hands and arms at every meal break, or as
often as possible!
NOTICE
Oil drums standing outdoors collect water in the lid, and
this water can run down into the oil.
Water-damaged oil results in machine breakdown.
Store oil drums lying horizontally under a roof.
1.5 Oil, requirement specification
Temperature ºF
All Seasons
Winter Conditions
Winter Conditions
Arctic Conditions
All Seasons
-40 -30 -20 -10 0 10 20 30 40 50 60
-40 -20 0 20 40 60 80 100 120 140
Temperature ºC
0W30
5W30
10W30
10W30
5W40 or 15W40
G01482
Fig. 1 Lubricating oil viscosity
As the viscosity of lubricating oil is dependent on
temperature, the choice of viscosity grade (SAE grade)
should be governed by the ambient temperature prevailing
at the engine operating site.
The optimum operating conditions are attained if you use
the oil viscosity figure shown here as a guide.
Should the temperature fall temporarily below the limits,
cold starting may be affected but the engine will not be
damaged.
In order to keep wear to a minimum, do not exceed the
operating limits for extended periods of time.
Oil changes dictated by the seasonal changes can be
avoided by using multi-grade lubricating oils. Multi-grade
oils also reduce fuel consumption.
Part Oil/lubricant
Diesel engine Engines should be lubricated with MOTOREX engine oil or
equivalent which meets the manufacturer's specifications, see sub-
supplier's documentation for diesel engine.
Hub reductions, MOTOREX LS UNIVERSAL SAE 90 GL5 or similar.
5

1 Service and maintenance
1.5 Oil, requirement specification
Gremo1050F4 Service and maintenance
manual
Part Oil/lubricant
Differential cases,
Bogie cases
Gearbox
Crane base
Hydraulic system MOTOREX COREX HV 46
Cab tilt pump TEXACO Rando Ashless 8401
Articulated joint For maximum bearing life, use LGHB204 grease for all articulated
joints.
Grease, normal TEXACO Universal Grease Type EP or similar. Use a grease
containing lithium or silicone. Type: NLGI class 2. Not with
molybdenum disulphide!
6

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.6 Antifreeze, requirement specification
1.6 Antifreeze, requirement specification
Approved antifreeze is propylene glycol.
NOTICE
Do not mix ethylene glycol and propylene glycol. If you
have the slightest doubt, pour out, clean and refill with a
new mixture.
7

1 Service and maintenance
1.7 Fuel, requirement specification
Gremo1050F4 Service and maintenance
manual
1.7 Fuel, requirement specification
Engines should be run on commercial diesel fuel which
meets the manufacturer's specifications, see sub-
supplier's documentation for diesel engine.
NOTICE
It is important to only use fuel that meets the standards
specified.
Fuel with a higher sulphur content will damage the
engine and the after-treatment system.
Only low-sulphur fuel should be used.
8

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.8 Cleaning of Safety Glass Windows
1.8 Cleaning of Safety Glass Windows
1.8.1 Cleaning
Wash the window with lukewarm water and a mild neutral
detergent. Use washing-up detergent or a similar soap-
based detergent. Rinse carefully with clean water, then
wipe dry with a soft, clean cloth.
1.8.2 Removing stains
Remove stains of resin, paint, grease, etc. before the stain
dries. Use a soft cloth with one of the approved solvents
listed below. After the stain has been removed, clean
according to the above instructions.
Approved solvents for cleaning of Safety Glass Windows
Pure Isopropyl Alcohol (IPA)
Ethanol
Hexane
Butanol
White Spirit
Heptane
Light petrol
Butyl-Ethyl Glycol
CAUTION
Solvents can cause skin problems and eczema.
Solvents can be poisonous. Breathing solvent fumes can
be dangerous. Solvents can be inflammable. Follow the
instructions from the solvent manufacturer.
9

1 Service and maintenance
1.9 Welding Repairs
Gremo1050F4 Service and maintenance
manual
1.9 Welding Repairs
NOTICE
Prior to beginning any welding, read this chapter
carefully!
1.9.1 Prior to welding, the following measures
must be taken
• Turn off the main power switch.
• (Disconnect the earth cable between the battery and
the frame).
• (Disconnect the generator’s plus cables).
• Disconnect the fire extinguishing system’s central unit
by removing main fuse F57.
• Fit the safety screw in the fire extinguisher tank.
• Connect the ground terminal of the welding equipment
as close as possible to the welding location.
• Disconnect all computer cables when welding is taking
place near the cab, engine control, climate system,
DASA, GreControl, radio, etc.
After any welding, ensure that you reset all the necessary
items correctly before restarting the machine.
CAUTION
Heated paint emits poisonous fumes which are
dangerous to inhale. Always remove all paint from the
welding location!
NOTICE
Never carry out any welding repairs on frames,
articulated joint or crane without first contacting an
authorised service dealer or the service department at
Gremo AB.
NOTICE
Always bear in mind the danger of fire. Always keep a
hand-held fire extinguisher within reach!
10

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.9 Welding Repairs
NOTICE
Remember that welding close to the fire extinguishing
system’s detector coil may cause it to burn off and
release the contents of the fire extinguisher tank! In
order to ensure that the fire extinguisher tank is not
accidentally deployed, fit the safety screw. See Other
equipment and optional equipment; Fire extinguishing
system in the Instruction Manual.
1.9.2 General
The machine is fabricated from high-tensile steel in the
frames and the articulated mid-joint. The standard beams
and grille are made of special steel. Welding repairs can
be carried out on them using the following electrodes:
Welding electrodes, recommendations
Type of electrode: pin
Elga P 62MR
OK 48.08 (ESAB)
OK 48.00 (ESAB)
Type of electrode: tube bar
Elga Core MXA100XP
ESAB OK Tubrod 14.10
Type of electrode: solid bar
ESAB OK Autrod 12.51
11

1 Service and maintenance
1.10 Tyres — Air pressure: Manufacturer’s
recommendations
Gremo1050F4 Service and maintenance
manual
1.10 Tyres — Air pressure: Manufacturer’s
recommendations
DANGER
Never stand in front of a tyre while it is being inflated! Do
not exceed the prescribed tyre pressure, which should
be checked at ambient temperature. If there is a change
to a different version of tyre or wheel rim, a different tyre
pressure may apply — contact Gremo.
Danger!
To avoid serious accidents, always follow directions for
inflating tyres.
WARNING
Before a wheel is replaced, the tyre must first be emptied
of air.
Risk of tyre explosion! Danger!
Empty the tyre by removing and dismantling the valve.
WARNING
If the wheel rim is damaged, handling the wheel is
extremely dangerous!
Risk of tyre explosion! Danger!
Have wheels replaced by a service department
authorised to handle tyres!
WARNING
Antifreeze can be explosive When tyres are inflated, the
air must therefore not contain any antifreeze.
Table 1 Nokian Recommended air pressure
Front/Tractor Front/Tractor Rear/Carriage Rear/Carriage
Nokian With or without
anti-skid device
With tracks With or without
anti-skid device
With tracks
600/50-22.5 TRS
LS-2 SF/16
350 kPa 430 kPa 430 kPa 430 kPa
12

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.10 Tyres — Air pressure: Manufacturer’s
recommendations
Table 1 Nokian Recommended air pressure (cont.)
Front/Tractor Front/Tractor Rear/Carriage Rear/Carriage
710/40-22.5/
Forest King SB-
16
310 kPa 430 kPa 390 kPa 430 kPa
710/40-22.5/LS-
2 SF/16
310 kPa 430 kPa 390 kPa 430 kPa
Table 2 Trelleborg Recommended air pressure
Front/Tractor Front/Tractor Rear/Carriage Rear/Carriage
Trelleborg With or without
anti-skid device
With tracks With or without
anti-skid device
With tracks
600/50-22.5 LS 2
16
350 kPa 500 kPa 450 kPa 500 kPa
650-12-T422 ET-
20
350 kPa 500 kPa 450 kPa 500 kPa
710/40-22.5 LS 2
16
300 kPa 500 kPa 400 kPa 500 kPa
Table 3 Tianli Recommended air pressure
Front/Tractor Front/Tractor Rear/Carriage Rear/Carriage
Tianli With or without
anti-skid device
With tracks With or without
anti-skid device
With tracks
600/50-22.5 HF-
2 16
350 kPa 500 kPa 400 kPa 500 kPa
700/45-22.5 HF-
2 16
350 kPa 500 kPa 450 kPa 500 kPa
100 kPa = 1 bar
All tyres are from the factory (Gremo) and inflated to 450
kPa.
The minimum pressure is approximately 50 kPa below the
stated values and the maximum pressure is around 50 kPa
above the stated values.
• Use min. pressure if the ground is easy to drive on and
relatively free from stones
13

1 Service and maintenance
1.10 Tyres — Air pressure: Manufacturer’s
recommendations
Gremo1050F4 Service and maintenance
manual
• Use max. pressure on difficult and stony ground.
NOTICE
You should check tyre pressure regularly. Remember to
check tyre pressure at low temperatures, the pressure is
then lower than in hot summer weather.
NOTICE
The machine must not be loaded when the tyre pressure
is checked.
Low tyre pressure, advantages:
• Good comfort.
• Large contact surface.
• Lower ground pressure
• Increased traction
• Reduced formation of wheel tracks.
Low tyre pressure, disadvantages:
• Reduced stability.
• Increased risk of hose damage/wear.
High tyre pressure, advantages:
• Gives better protection against tyre side damage.
• Increased stability.
• Requirement for track use.
High tyre pressure, disadvantages:
• Reduced comfort.
• Increased risk of cutting and puncture damage.
• Increased sensitivity to spot loads.
• Increased formation of wheel tracks
• Poorer grip.
1.10.1 Filling of fluid in forestry tyres
Fig. 2 Level, filling tyres with fluid
The tyres can be filled with fluid to increase the machine’s
stability and traction
Gremo recommends filling 50% of the tyres’ volume.
Maximum permitted is 75%.
The fluid should consist of water. At temperatures below
zero, the fluid used should be a mixture of calcium
chloride/water or glycol/water
14

Gremo1050F4 Service and maintenance manual 1 Service and maintenance
1.10 Tyres — Air pressure: Manufacturer’s
recommendations
By turning the wheel and pressing in the valve needle, it is
easily possible to determine whether the tyre is filled to
75% or 50% fluid.
Calcium chloride increases the fluid’s density by up to 1.2
kg/litre in a 35% blend.
Fluid-filled tyres are less elastic owing to their smaller air
volume and are therefore more vulnerable to spot loads.
Rolling resistance and the dynamic forces acting on the
wheel rims and suspension components are also higher.
NOTICE
When changing tyres, use the right kind of tyre paste
intended for heavy vehicles or forestry machinery.
Otherwise, the tyre may slip on the rim.
15

1 Service and maintenance
1.11 Daily maintenance (every 8-10 operating
hours)
Gremo1050F4 Service and maintenance
manual
1.11 Daily maintenance (every 8-10 operating
hours)
1.11.1 Lubrication
Fig. 3 L= Lubricate= Lubricate
Pos. Lubrication point Nipples Comments/reference
L1 Support bearing, propeller
shaft
1 Drawn out to the left-hand lubrication point
at the side.
L2,
L3
Steering cylinder 1+1 right
1+1 left
L4 Articulated steering joint 1+1 To be lubricated with LGHB204, an SKF
grease for bearing joints subject to heavy
loads.
L5 Rotator link 1+1 See sub-supplier documentation for rotator.
16
