Grindmaster B-SAP User manual

Digitally controlled airpot brewer holds brew temperature to + 1°F throughout brew cycle.
Brew temperature, brew volume, operator defined pre-infusion/pulse brewing, and
low temp/no brew are programmable from the front display.
Model B-SAP
Airpot Brewer
Model B-SAP
(Airpot sold separately)

Grindmaster® Coffee Grinders and Brewers • Espressimo® Espresso Machines • Crathco® Hot Beverage Dispensers
Crathco® Cold and Frozen Beverage Dispensers • American Metal Ware® Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
•Model B-SAP is a single, digitally controlled brewer that
brews into a 1.9L (64oz.) up to 2.5L (85oz) Airpot
(Airpot sold separately).
•The Airpots hold freshly brewed coffee for hours without
additional heat.
•Precise Brew Temperature - The brewer will hold the brew
temperature to +/- 1°F during the complete brew cycle.
•Brew Volume - can be set by ‘teach’ mode to eliminate
trial-and-error set-up.
•Pulse brewing/pre-infusion - Allows the brew sequence to
extract up to 20% more dissolved solids per batch of
coffee. Programmable: number of pulses, pulse-on time
and pulse-off time. Changing the pulse sequence does not
affect the brew volume.
•Low Temp/No Brew - Allows the brew cycle to begin only
when the water has reached the optimum brew temperature.
•Cycle Counter - The brewer counts the total number of brew
cycles.
•Programming Lock-Out - The brewer settings can be
“locked” to prevent tampering.
•Pour-Over Capability - Automatically converts to pour-over
mode when the inlet valve does not sense water. Also
capable of being manually set to pour-over mode through
the front.
•Dual Voltage with toggle switch models are available to
accept 120/240V or 120V supply.
•Gourmet brew basket (pn 71431) available as an option.
•Warranty - 2 years parts and labor on the brewer.
4 years part warranty on the control board.
Specification Model B-SAP
Electrical
120V/ 1780W/ 14.9A
120/240V/ 3500W/ 14.6A
120/208V/ 2630W/ 12.7A
Brew Capacity
(# of 2.2 liter airpots / hour)
@ 120V: 8
@ 240V: 16
@ 208V: 12
Water Line 1/4” flare
Water Line Pressure 30-80 psi
Tank Drain Yes
Tank Size 1.38 gallons
Dimensions (H x W x D) 25” x 8-1/4” x 17-3/4” (64 cm x 20 cm x 46 cm)
Ship Dimensions (H x W x D) 28” x 13” x 24” (69 cm x 30.5 cm x 61 cm)
Weight 28 lbs (12.7 kg)
Ship Weight 37 lbs (16.8 kg)
Listings UL, CUL, NSF, (CE for E models only)
0905 Form # AM-202-04
© Grindmaster Corporation, 2003
PRINTED IN USA
Model B-SAP
Specifications are subject to improvement or change without notice.
0.38 - 0.63"
13.8
GOURMET
BASKET
8.1 17.8
24.5
2.7
14.6
STD
BASKET
Side View
Front View
