Grip MIRACLE Instruction Manual

1.
Content of the package:
- Mirror 600x700mm or 700x900mm
- Esther LED-lamp with attachment accessories
- Attachment screws, installment pieces and wall plugs
for mirror
- Wall fasteners and anchor screws (A)
- Installment pieces; 4 small ( B ) and 2 large ( C )
- Lock fitting ( D ) and locking spring ( E )
- Locking key ( F )
- Attachment screws M3x16mm PZ1
- Nail clip plug / Hammer plug Ø6x30mm
- Screw Ø4x30mm PZ2
Mirror can be installed both horizontally or vertically.
Please ensure the firmness and carrying capacity of the
installment spot before installation.
Instructions for installing
MIRACLE
ILLUMINATED MIRROR
Gripshop Finland ·Yrittäjäntie 6, 60100 Seinäjoki Finland · Tel. [phone] · asiakaspalvelu@gripshop.fi · www.gripshop.fi
F
B
C
D
E
A
2. 3.
Installment of the mirror:
Measure the attachment spots for the desired height on
the wall, 12mm downwards from the upper edge of the
mirror. Make sure that there is sufficient amount of space
between attachment spots.
Anchor screws (Ø10) are provided for installation.
Add huge installment piece ( C ) between the wall and wall
fastener (A) and start to fasten the fasteners on their
respective spots.
Lift the mirror into the hooks of wall fasteners and adjust
widthwisely to the right spot. Adjust the height with the
adjustment screw if needed.
When the mirror has reached its desired height, mark the
locking screw’s spot on the wall, 12mm inwards from the
external rim of the frame.
Attach the screw (4x30mm) with the assistance of hammer
plug (Ø6) into the wall, leave the screw’s stem 4mm away
from the wall.
12mm
Upperside of mirror
Wall fasteners and
anchor screws (A)
Installment of the mirror:
The frame has an iron levelling rod that can be moved on
every side, in which both the light and the lock fitting can
be attached.
Fasten the light into the levelling rod in upper edge of the
frame by using the small installment pieces ( B ) and the
screws (M3x16) provided with them.
When choosing suitable spot for lock fitting on the lower
edge or side of the mirror, make sure that the lock is
capable to be opened on the spot with provided key.
Fasten the lock fitting, the exceeding part of the fitting
facing inwards, by using the small installment pieces ( B )
and M3x16 screws.
Set the mirror back to the fasteners. Direct the screw into
mirror’s lock fitting and push the second piece of the lock
fitting, spring ( E ), into its spot by letting the smooth side
of the spring face the wall. Lock is opened by pressing the
spring out with a key ( F )

6.
8.
7.
Mirror’s installment areas and casing classification:
Esther light’s casing classification (IP classification) is IP44,
which stands for the protection from moisture when
installed correctly.
Illuminated mirror is recommended to be installed on
areas 2 and 3. (see picture)
Gripshop Finland ·Yrittäjäntie 6, 60100 Seinäjoki Finland · Tel. [phone] · asiakaspalvelu@gripshop.fi · www.gripshop.fi
Installment of Esther LED-light:
Connecting to the power supply
If the light is including Europlug socket, it can be plugged
directly into 230V power socket.
CAUTION! If the light is intended to install without the
Europlug socket, the coupling must be done by an
authorized electrician.
Esther light does not include residual current switch.
Warranty and maintenance:
The mirror and Esther light have a warranty of 2 years.
Warranty covers only manufacturing defects.
Warranty does not cover breakdown of the product due to
mechanical impact, incorrect transportation or installation
or inappropriate handling, cleansing or maintenance
procedures.
In matters regarding spare parts, please contact Gripshop.
Cleaning instructions:
Clean the mirror only by using water-soaked cloth and dry
with fluff-free cloth.
Use of chemicals and scouring can damage the mirror’s
surface or its silver-plating.
