Griven Moon AL5325 User manual

Moon Recessed Adjustable User’s Manual
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
© Copyright Griven 2018 -Griven reserves the right to make
changes to this product and related instructions at any time
without prior notice and such changes shall be effective
immediatly.
Tel. [phone]
E-mail: [email protected]
Web: www.griven.com
Rev. 2.0
Date:28/12/2022
page 1 of 12
Size / Dimensioni
551182
Code / Codice AL5325
Moon Recessed Adjustable W Moon Recessed Adjustable RGBW /DW
SP/NA/ME/WI/EW ULTRASPOT
Power consumption
Consumo di energia 8W MAX 3W MAX 4,6W MAX
Remote Power supply
Alimentatore Remoto
Constant Current:
250 mA
Constant Current:
800mA
Costant Voltage:
24 Vdc
Foward voltage 35 V 3 V
Electrical class
Classe elettrica III
Weight / Peso 1 Kg / 2,2 lb
Operating temperature
Temperatura di funzionamento -30°C to 40°C / (-22°F to 104°F)
IP rating / Grado IP IP68
IK rating / Grado IK IK10
+/- 15° TILT
Ø 87 mm
3.4”
94 mm
3.7”
5
10
15
0
15
10
5
WALK
OVER
ALL GLASS FRAME DRIVEOVER
DRIVE
OVER
115 [4.53] 15 [0.59]
2 [
0.08 in
]
130 [5.11]
TWO SIDE
KNOCKOUT
HOLE
Ø25mm
1.0in
170
6.69
N° 5 HOLES
Ø 5 mm [ 0,19 in]
200
7.87
+/- 15° TILT
Ø100 mm
4.0”
94 mm
3.7”
5
10
15
0
15
10
5
+/- 15° TILT
Ø112 mm
4.4”
94 mm
3.7”
5
10
15
0
15
10
5
WALK
OVER

Moon Rev. 2.0
page 2 of 12
551182
- This product must be installed in accordance with applicable national and local
electrical and construction codes by a person familiar with the construction and
operation of the product and the hazards involved. Failure to comply with the
following installation instructions may result in death or serious injury.
- Do not stare at the operating light source.
- The fi xture might be damaged by excess voltage. The installation of an overvolta-
ge protection device on the electrical system (SPD) is recommended for
reduce the risk of damage.
- The use of an adequate magnetothermic switch along the power supply line is
recommended.
-Connect the fi xtures to each other only when disconnected from mains.
- Never leave cables and connectors unconnected or unprotected for long periods.
- Disconnect power before installing or servicing to avoid electrical shock.
- Disconnect power before any connection operation.
- Check voltage and frequency before powering the fi xture. Do not exceed fi xture
specifi ed voltage.
- Do not handle the unit with wet hands or in wet environments.
- Apply to qualifi ed staff for any maintenance service not described in this instruc-
tions manual.
- Do not exceed the maximum quantity of fi xtures per line in order to avoid power
surges.
- Before powering the unit, ensure to use cables and connectors with proper
section and length, according to its power consumption.
- Fix the projector by using screws, hooks or other adequate supports that can
bear its weight.
- If the external fl exible cable of this appliance is damaged, it must only be repla-
ced by the manufacturer, its assistance service or equivalent qualifi ed personnel in
order to avoid hazards.
- Integrated temperature control, the projector reduces power when Ta >35°C.
- The luminaire should be positioned so that prolonged observation of the luminaire
at a distance of less than 2 meters (6.56 ft) is not expected.
- Questo prodotto deve essere installato secondo le normative locali, da personale
specializzato. La mancata osservanza delle istruzioni di installazione può portare
a situazioni di pericolo all’incolumità della persone.
- Non fi ssare la sorgente luminosa durante il suo funzionamento.
- Apparecchiatura sensibile alle sovratensioni. Si consiglia l’installazione di un
dispositivo di protezione delle sovratensioni (SPD) sull’impianto elettrico per
attenuare l’intensità di questi fenomeni proteggendo gli apparecchi dal rischio che
vengano danneggiati.
- E’ consigliato l’uso di un adeguato interruttore magnetotermico/differenziale sulla
linea di alimentazione.
- Collegare tra loro i proiettori solo quando nessuno di essi è collegato alla rete
elettrica.
- Non lasciare mai per lungo tempo agli agenti atmosferici cavi e connettori non
collegati o non protetti.
- Togliere l’alimentazione prima di effettuare qualsiasi operazione all’interno
dell’apparecchiatura.
- Togliere l’alimentazione prima di effettuare qualsiasi operazione di connessione
tra gli apparecchi.
- Prima di connettere l’apparecchio alla rete elettrica, verifi cate la compatibilità di
tensione e frequenza.
- Non maneggiate il prodotto con mani bagnate o in presenza di acqua.
- Rivolgersi ad un tecnico qualifi cato per qualsiasi operazione di manutenzione
ordinaria non descritta nel presente manuale.
- Non superare il numero massimo specifi cato di apparecchi per linea per evitare
pericolori sovraccarichi di corrente.
- Prima di effettuare le connessioni verifi care la portata dei cavi / connettori e la
lunghezza dei cavi tenendo conto dell’assorbimento del prodotto.
- Fissare il proiettore con viti, ganci o altri supporti in grado di sostenerne il peso.
- Se il cavo fl essibile esterno di questo apparecchio vienne danneggiato, deve
essere sostituito esclusivamente dal produttore, dal suo servizio di assistenza o da
personale qualifi cato equivalente, al fi ne di evitare pericoli.
- Controllo della temperatura integrato, il proiettore reduce la potenza ad una
Ta >35°C
- l’apparecchio di illuminazione dovrebbe essere posizionato in modo che non sia
prevista un’osservazione prolungata dell’apparecchio ad una distanza inferiore a
2 metri.
CAUTION: Prolonged staring at the LED source should be
avoided by placing the xture in a proper position.
ATTENZIONE! Fissare la sorgente LED per un periodo prolungato
va evitato posizionando l’apparecchio nella posizione appropriata.
WARNING ! Fixing and connecting operations must
mandatorily be carried out by qualied personnel only !
ATTENZIONE ! Le operazioni di ssaggio e collegamento
devono essere eseguite solo e obbligatoriamente da perso-
nale qualicato!
WARNING ! Make sure that power supply is o before
connecting or disconnecting xtures !
ATTENZIONE ! Assicurarsi che l’alimentazione sia spenta
prima di collegare o scollegare i dispositivi!
Replaceable control gear by a professional Alimentatore sostituibile da un professionista
Replaceable (LED only) light source by a professional Sorgente luminosa (solo LED) sostituibile da un
professionista
La possibilità di riutilizzare alcune parti elettriche del disposi-
tivo è subordinata alla totale responsabilità dell’utilizzatore.
Nell’etichetta è stato riportato il simbolo indicato nel D.lgs n.49
del14Marzo2014cherecepisceladirettiva2012/19/UE,ilquale
indica la necessità di smaltire il prodotto nei riuti dierenzia-
ti, nello specico nei riuti di tipo elettrico ed elettronico. Fare
riferimento al centro di raccolta riuti situato nella Vostra zona.
The possibility of reusing some electrical parts of the devi-
ce is subject to the total responsibility of the user. The la-
bel shows the symbol indicated in Legislative Decree n.49
of 14 March 2014 which transposes Directive 2012/19 / EU,
which indicates the need to dispose of the product in sepa-
rate waste, specically in electrical waste. and electronic.
Refer to the waste collection center located in your area.
This product contains a light source of energy eciency
class:
Questo prodotto contiene una sorgente luminosa di classe
di ecienza energetica:
Important notices - Avvisi importanti

Moon Rev. 2.0
page 3 of 12
551182
Installation - Installazione
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
SOLID SOIL in concrete - Prearrange an adequate support for the formwork as well as a drainage system through a pipe that allows the
water to ow without creating stagnations.
TERRENO SOLIDO in cemento - Predisporre un adeguato supporto alla cassaforma ed un drenaggio attraverso un tubo che permetta all’
acqua di dreanare senza creare ristagni.
DRAINAGE PIPE
SOFT SOIL - Arrange an adequate water drainage system with pebbles.
TERRENO MORBIDO - Predisporre un adeguato drenaggio con ciotoli per il drenaggio dell’acqua.
INCORRECT INSTALLATION
INSTALLAZIONE NON CORRETTA

Moon Rev. 2.0
page 4 of 12
551182
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
SECTION VIEW
TILED CONCRETE
100 mm
3.94 inch
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
SECTION VIEW SECTION VIEW
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
70 mm
115 [4.53] 15 [0.59]
2 [0.08 in]
130 [5.11]
TWO SIDE
KNOCKOUT
HOLE
Ø25mm
1.0in
170
6.69
N° 5 HOLES
Ø 5 mm [ 0,19 in]
200
7.87
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
Open the formwork on one side for the passage of the corrugated pipe. If necessary, also open it on the other side.
Rimuovere dalla cassaforma il primo tassello per il passaggio del tubo corrugato. Se necessario rimuovere anche il secondo tassello.
Insert the pipe into the formwork and then x it to the ground through the specic xing holes.
ATTENTION: Point the at side of the formwork towards the wall as shown in the image below.
Posizionare il tubo corrugato nell’apposita apertura ricavata nella cassaforma e successimente ssare la cassaforma al terreno utilizzando
gli appositi fori di ssaggio. ATTENZIONE Orientare la faccia piana della cassaforma parallelamente al muro come indicato nell’immagine.
ATTENZIONE: versare il cemento no al livello del tappo.
ATTENTION: pour cement up to the level of the cap.

Moon Rev. 2.0
page 5 of 12
551182
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
SECTION VIEW
TILED CONCRETE
100 mm
3.94 inch
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
SECTION VIEW SECTION VIEW
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
70 mm
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
SECTION VIEW
TILED CONCRETE
100 mm
3.94 inch
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
SECTION VIEW SECTION VIEW
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
70 mm
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
SECTION VIEW
TILED CONCRETE
100 mm
3.94 inch
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
SECTION VIEW SECTION VIEW
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
70 mm
ATTENTION: To facilitate the removal of the cap, its recomanded to use a release agent for formworks.
ATTENZIONE: Per facilitare l’estrazione del tappo si consiglia di utilizzare un agente distaccante per cassaforme.
Fill with cement up to the level of the cap and clean o any material in excess that may prevent the removal of the cap
Riempire con cemento no al livello del tappo e rimuovere l’eventuale materiale in eccesso che possa impedire la rimozione del tappo.
Before installing the xture, remove the cap from the formwork by using
pliers.
Prima di iniziare l’installazione dell’apparecchio rimuovere il tappo della cas-
saforma.
Facilitare l’operazione aiutandosi con una pinza per imprimere maggiore
forza.
INCORRECT INSTALLATION
INSTALLAZIONE NON CORRETTA
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
SECTION VIEW
TILED CONCRETE
100 mm
3.94 inch
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
SECTION VIEW SECTION VIEW
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
70 mm

Moon Rev. 2.0
page 6 of 12
551182
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
4
3
Connect the xture to the power cable. Put the heat shrink tube tted with glue “1” on the power cable. Connect to the mains through the
connectors “2”, pressing them with the appropriate tool “3”. Heat the tube using the heater “ 4” until it completely shrinks. This connection
will feature an IP67 protection degree.
Connettere il proiettore al cavo di alimentazione. Inserire la guaina termorestringente con collante “1” sul cavo di alimentazione.
Eettuare il collegamento alla rete tramite i connettori testa - testa “2”, premendoli con l’apposito attrezzo “3”.
Riscaldare il tubo utilizzando un riscaldatore per tubi termoretraibili “4” no a completo restringimento.
La connessione così ottenuta ha un grado di protezione IP67.
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE
HOLE
Ø 90 mm Frame / AllGlass
Ø 105 mm DriveOver

Moon Rev. 2.0
page 7 of 12
551182
0
15°
+15°
0°
-15°
-15°
BEAM ORIENTATION - The beam can be tilted by 15° by using a screwdriver on the brass pin, as shown in the image below.
ORIENTAMENTO DEL FASCIO - E’ possibile inclinare il fascio del proiettore di 15° agendo con un cacciavite sul perno in ottone come
indicato nell’immagine sotto.
0
15°
+15°
0°
-15°
-15°
ADDRESS THIS SIDE TO THE WALL
DRAINAGE
MATERIAL SOIL
CONCRETE
TILED CONCRETE
CONCRETE
PAVING
INCORRECT
TILED CONCRETE
Driveover
HARD GROUND
WALK OVER and DRIVE OVER APPLICATION
SOFT GROUND
WALK OVER APPLICATION
130 mm
5.11 inch
CONCRETE
FIXTURE CABLE
SUPPLY CABLE
2 END TO END CONNECTOR
1 HEAT SHRINK TUBE

Moon Rev. 2.0
page 8 of 12
551182
Conguration scheme - MOON RECESSED ADJUSTABLE W
Schemi di congurazione - MOON RECESSED ADJUSTABLE W
LED -
LED +
L
N
220-240 Vac 50/60 Hz
1.5 m
Fixture
Cable
length
AL5295/ 250
PSU DALI
Costant Current
Setting: 250 mA
B
Vac
+ + + +
A
MINIMUM 1 FIXTURE MAXIMUM 3 FIXTURE
Distance between PSU and the last xture: 20 meters
RED / ROSSO
BLACLK / NERO
CABLE/CAVI USE/UTILIZZO
V+
V-

Moon Rev. 2.0
page 9 of 12
551182
Conguration scheme - MOON RECESSED ADJUSTABLE W ULTRASPOT
Schemi di congurazione - MOON RECESSED ADJUSTABLE W ULTRASPOT
220-240 Vac 50/60 Hz
1.5 m Fixture Cable length
AL4324/800
PSU DALI
Costant Current
Setting: 800 mA
Vac
+ + + + + + + + +
A
MINIMUM 1 FIXTURE MAXIMUM 8 FIXTURE
Distance between PSU and the last xture: 42 meters
+
-N
L
RED / ROSSO
BLACLK / NERO
CABLE/CAVI USE/UTILIZZO
V+
V-

Moon Rev. 2.0
page 10 of 12
551182
Conguration scheme - MOON RECESSED ADJUSTABLE RGBW and DW
Schemi di congurazione - MOON RECESSED ADJUSTABLE RGBW and DW
AL4487/2
Vac
BROWN / MARRONE
BLUE / BLU
BLACK / NERO
WHITE / BIANCO
CABLE/CAVI USE/UTILIZZO
V+
V-
DMX DATA +
DMX DATA -
V+
V -
Dmx DATA +
Dmx DATA -
MAXIMUM 10 FIXTURE
Distance between PSU and the last fixture: max. 50 meters
AL0512
CAVO DMX
DMX CABLE
DATA +
DATA -
GND
V-
V+
V+
V-
LINE END CAP INCLUDED IN AL5296
TAPPO FINE LINEA INCLUSO IN AL5296
Use 120Ω Resistor
Usare Resistenza 120Ω
DATA +
DATA -
CONTROLLER DMX
AL4487/2
IP67 POWER SUPPLY UNIT 120W
AL5296
3-way junction box
AL5296
3-way junction box
AL5296
3-way junction box
1.5 m Fixture Cable length
CAVO Ø 4mm 4x0,25 mm²
CABLE Ø 4mm 4x0,25 mm²
100-277 Vac
Junction Box
Pozzetto di derivazione
CONTROLLER
DMX

Moon Rev. 2.0
page 11 of 12
551182
DMX Chart
Mode Channel Function Value
Mode 4 channel - “RGBW 4ch”
#1
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
Mode 5 channel - “RGBW 5ch”
#2
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
5 0-100% Dimmer 0-255
Mode 6 channel - “RGBW 6ch”
#3
1 0-100% Red 0-255
2 0-100% Green 0-255
3 0-100% Blue 0-255
40-100% White 0-255
5 0-100% Dimmer 0-255
6
No Strobo 0-5
0-100% Strobo 6-250
100% Strobo 251-255
Mode 4 channel - “RGBW MIX”
#4
1 0-100% Red 0-255
2 0-100% Geen 0-255
3 0-100% Blue 0-255
40-100% Calibrated White
(aects RGB channels) 0-255
RGBW and DW
DW (Dynamic White)
Mode Channel Function Value
Mode 2 channel - “Dynamic White 2ch”
#1
1
Warm White 100% / Cold White 0% 0-003
Warm White 100% / Cold White 0%-100% 004-122
Warm White 100% / Cold White 100% 123-132
Warm White 100%-0% / Cold White 100% 133-251
Warm White 0% / Cold White 100% 252-255
2 DIMMER 0-100% 0-255
Mode 2 channel - “Separate White 2ch”
#2
10%-100% Warm white 0-255
20%-100% Cold white 0-255
Note: in absence of DMX signal the LEDs will remain ON.

Moon Rev. 2.0
page 12 of 12
551182
Note: Allowed operation only between sunset and sunrise
Nota: Accensione dell’apparecchio ammessa soltanto tra gli orari di tramonto e alba
Forward
voltage led Current Code Description PSU ON/OFF IP20 1 PSU for (X)  xutures
PSU DALI IP20
1 PSU for (X)  xutures
PSU ON/OFF IP67
1 PSU for 1  xutures
PSU ON-OFF AND DALI IP67
1 PSU for (X)  xutures
PSU 0-10V IP67
1 PSU for (X)  xutures
35V 250mA AL5309 / AL5327 Moon Marine W N.A AL5295/250 (DALI)
(1-3pcs)
AL5363/250 (DALI)
(1pc) N/A N/A
35V 250mA AL5311 / AL5325 Moon Recessed W / Moon Recessed
Adjustable N.A AL5295/250 (DALI) (1-3pcs)
AL5363/250 (DALI)
(1pc) N/A N/A
35V 350mA AL5310 / AL5312 /
AL5314 Moon W AL5360/350 (ON/OFF) (1pc)
AL5295 (DALI)
(1-3pcs)
AL5363/350 (DALI)
(1pc)
AL5364/350
(1pc)
AL5364/350
(1pc)
3V 700mA AL5317 Half Moon Recessed W AL5360/700
(ON/OFF) (1-12pcs)
AL4324/700 (DALI)
(1-9pcs) N/A AL5363/700 (4-14pcs)
AL5364/700
(4-14pcs)
3V 800mA AL5309 / AL5327 Moon Marine Ultraspot W AL5360/800
(ON/OFF) (1-12pcs)
AL4324/800 (DALI)
(1-8pcs) N/A AL5364/800 (4-14pcs)
AL5364/800
(4-14pcs)
3V 800mA AL5311 / AL5325 Moon Recessed Ultraspot W / Moon
Recessed Adjustable Ultraspot W
AL5360/800
(ON/OFF) (1-12pcs)
AL4324/800 (DALI)
(1-8pcs) N/A AL5364/800 (4-14pcs)
AL5364/800
(4-14pcs)
3V 900mA AL5315/ AL5316 /
AL5318 Half Moon W AL5360/900 (ON/OFF) (1-12pcs)
AL4324/900 (DALI)
(1-8pcs) N/A AL5364/900 (4-14pcs)
AL5364/900
(4-14pcs)
3V 900mA AL5324 / AL5326 Half Moon Marine W AL5360/900
(ON/OFF) (1-12pcs)
AL4324/900 (DALI)
(1-8pcs) N/A AL5364/900 (4-14pcs)
AL5364/900
(4-14pcs)
3V 1000mA AL5310 / AL5312 /
AL5314 Moon Ultraspot W AL5360/1000 (ON/OFF) (1-12pcs)
AL4324/1000 (DALI)
(1-8pcs) N/A AL5364/1000 (4-14pcs)
AL5364/1000
(4-14pcs)
Remote PSU / Alimentatori Esterni
