Grizzly G1036 User manual

SLOW-SPEED GRINDER
MODEL G1036
PARTS LIST
COPYRIGHT © 1993 BY GRIZZLY INDUSTRIAL, INC. REG. TX 3 627 012
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED FEBRUARY, 1999. PRINTED IN U.S.A.
PARTS LIST DISCLAIMER
This parts list and drawings represent the configuration of the machine as it is currently being shipped. The machine configuration can change as product
improvements are incorporated. If you own an earlier version of the machine, this parts list may not depict your machine exactly. Contact Customer Service
if you have any questions about part differences. Previous parts list versions are not available on-line.

G1036 Slow-Speed Grinder -3-
01 P1036001 BASE
02 P1036002 GEAR BOX
03 P1036003 SPINDLE
04 P6001 BEARING 6001-2RS
05 PK37M KEY 4 X 4 X 16
06A P1036006A GEAR, PLASTIC
07 PN13 HEX NUT 1⁄2" - 13
08 PW06 WASHER 1⁄4"
09 PB19 HEX BOLT 1⁄4" - 20 X 1⁄2"
10 P1036010 FLANGE
11 P1036011 10'' GRINDING WHEEL
12 P1036012 FLANGE
13 P1036013 GUIDE CLAMP
14 PSB04 CAP SCREW 1⁄4" - 20 X 1⁄2"
15 PSB05 CAP SCREW 1⁄4" - 20 X 3⁄4"
16 P1036016 OIL FEEDER
18 P1036018 WORM SHAFT
19 PN06 HEX NUT 1⁄2" - 12
20 P1036020 GEAR BOX COVER
21 P1036021 WHEEL GUARD
23 PB19 HEX BOLT 1⁄4" - 20 X 1⁄2"
24 P1036024 SPACER
25 P1036025 FLANGE
26 P1036026 GRINDING WHEEL
27 P1036027 LEFT HAND NUT, 1⁄2" - 13
28 P1036028 WHEEL COVER
29 PS06 SCREW 10-24 X 3⁄8"
30 P1036030 EYE SHIELD
31 P1036030 SHIELD BRACKET W/30
32 PS24 PHLP HD SCREW 8-32 X 3⁄8"
33 P1036033 KNOB
34 PN14 HEX NUT 8-32
35 P1036035 KNOB
36 PN02 HEX NUT 5⁄16" - 18
37 PW07 FLAT WASHER 5⁄16"
38 P1036038 TOOL REST
39A P1036039A COMPLETE MOTOR
39B P1036039B MOTOR FAN *
46A P1199046A SWITCH
46B PHTEK1 SELF TAP PHLP SCREW
49 P1036049 POWER CORD
50 PSB05 CAP SCREW 1⁄4'' - 20 X 3⁄4''
51 P1036051 TABLE BRACKET
52 P1036052 TOOL REST TABLE
53 P1036053 SUPPORT BRACKET
54 PW06 FLAT WASHER 1⁄4''
56 P1036056 ADJUSTABLE HANDLE
59 PW06 FLAT WASHER 1⁄4''
60 PB31 HEX BOLT 1⁄4'' - 20 X 1''
64 P1036064 DEGREE SCALE
65 P1036065 DRAIN PLUG SEAL
66 P1036066 DRAIN PLUG
67 P1036067 MOTOR LABEL
68 P1036068 STRAIN RELIEF
69 P1036069 CORD PROTECTOR
70 PW03 FLAT WASHER #10
71 PS06 PHLP SCREW 10-24 X 3/8"
73 P1036073 ROTATION DIRECTION
75 P1036075 DEGREE SLIDE
76 P1036076 KNOB
REF PART # DESCRIPTION REF PART # DESCRIPTION
