Grizzly G2790 User manual

UNIVERSAL KNIFE GRINDER
MODEL G2790
PARTS LIST
COPYRIGHT © 1992 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED APRIL, 1999. PRINTED IN U.S.A.
PARTS LIST DISCLAIMER
THIS PARTS LIST AND DRAWINGS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CON-
FIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS
LIST MAY NOT DEPICT YOUR MACHINE EXACTLY. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES.
PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.

-B- G2790 Universal Knife Grinder
PARTS DIAGRAM

G2790 Universal Knife Grinder -C-
024
025
026
027
028
029
030
031
032
033
034
035
036
037
038
039
040
041
042
043
044
045
046
Ref. # Part # Description Ref. # Part # Description
P2790001 Knob
P2790002 Knife Lock Plate
P2790003 Sliding Knife Support
P2790004 O-Ring
PN05 Nut 1/4" - 20
P2790006 Knob
P2790007 Work Plate
P2790008 Right Lock Bar
P2790009 Left Lock Bar
P2790010 Knob
P2790011 Pivot Knob
PW06 Washer 1/4"
P2790013 Pivot Rotation Knob
P2790014 Pivot Plate
P2790014A Degree Scale
PB09 Hex Bolt 5/16" - 18 x 1/2"
P2790016 Tool Clamp Knob
P2790017 Tool Clamp
P2790018 Special Lock Nut
P2790019 Dressing Tool Guide
PSS02 Setscrew 5/16" - 18 x 3/8"
P2790021 Power Cord
P2790022 Switch
P2790023 Cover Plate
P2790024 Rubber Base Feet
PW07 Washer 5/16"
PS01 Screw 10 - 24 x 1/2"
P2790027 Capacitor
P2790028 Motor Housing
P2790029 Inner Flange
G2791 120 Grit Wheel
P2790031 Outer Flange
P2790032 Socket Cap Screw
PN02 Nut 5/16" - 18
P2790034 Table Lock Lever
P2790035 Table Adj. Screw
P2790036 Ball Bearings
P2790037 Handwheel
PB02 Hex Bolt 1/4” - 20 x 5/8”
P2790039 Socket Cap Screw
P2790040 Fence
P2790041 Spacer
P2790042 Table
P2790043 Decal
P2790044 Cord Clip
PW07 Washer 5/16"
PWRN01 Wire Nut
001
002
003
004
005
006
007
008
009
110
011
012
013
014
014A
015
016
017
018
019
020
021
022
023
PARTS LIST
