Grizzly H7762 Quick start guide

-24- H7762 Heavy Duty Tool Grinder




 
 








 
 

 
 











 










 
















 
















 




























 


Parts Breakdown

H7762 Heavy Duty Tool Grinder -25-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH7762001 SHAFT END BUSHING 36 PH7762036 CORD BUSHING
2 PN15M HEX NUT M18-1.5 37 PH7762037 MOTOR BASE
3 PH7762003 SPECIAL SCREW M8-1.25 X 12 38 PH7762038 CORD CLIP FIXING PLATE
4 H8873 GRINDING WHEEL 39 PH7762039 CORD CLIP
5 PH7762005 CONNECTION PLATE 40 PH7762040 LAMP
6 PH7762006 RUBBER WASHER 41 PLW04M LOCK WASHER 8MM
7 PB10M HEX BOLT M6-1 X 25 42 PB09M HEX BOLT M8-1.25 X 20
8 PS09M PHLP HD SCR M5-.8 X 10 43 PTLW11M INTERNAL TOOTH WASHER 4MM
9 PW02M FLAT WASHER 5MM 44 PS38M PHLP HD SCR M4-.7 X 10
10 PH7762010 LEFT-HAND POINTER 45 PH7762045 BOTTOM COVER
11 PH7762011 DIAL SET PIN 46 PN06M HEX NUT M5-.8
12 PH7762012 WHEEL COVER 47 PH7762047 CAPACITOR FIXING RING
13 PH7762013 WATER CUP SET PIN 48 PH7762048 CAPACITOR 50M 300VAC 3.75" X 2"
14 PN03M HEX NUT M8-1.25 49 PH7762049 SWITCH FIXING PLATE
15 PW01M FLAT WASHER 8MM 50 PH7762050 SWITCH
16 PH7762016 ANGLE GAUGE 51 PH7762051 SPECIAL WAVE WASHER 35MM
17 PW04M FLAT WASHER 10MM 52 PH7762052 MITER FIXING BRACKET
18 PLW06M LOCK WASHER 10MM 53 PH7762053 STRAIGHT PIN
19 PH7762019 HANDLE PIN BUSHING 54 PH7762054 MITER GAUGE
20 PH7762020 LOCK HANDLE M10-1.5 X 23 55 PH7762055 INDICATOR PIN
21 PH7762021 LOCK HANDLE ARM 56 PH7762056 LOCKING BOLT M5-.8 X 13
22 PH7762022 WATER TRAY 57 PH7762057 WING NUT M5-.8
23 PH7762023 SUPT SCREW M8-1.25 X 18 58 PH7762058 NAMEPLATE RIVET 2.5 X 4
24 PH7762024 WATER TRAY POSITIONING PIN 59 PH7762059 SCALE PLATE
25 PH7762025 WORK SUPPORT 60 PH7762060 WATER CUP
26 PH7762026 RIGHT-HAND POINTER 61 PH7762061 VALVE
27 PH7762027 ADJUSTING BUSHING 62 PH7762062 WATER PIPE
28 PS47M PHLP HD SCR M6-1 X 25 63 PH7762063 RIGHT MOTOR END CAP
29 PLW03M LOCK WASHER 6MM 64 PB104M HEX BOLT M5-.8 X 30
30 PH7762030 LEFT MOTOR END CAP 65 PLW01M LOCK WASHER 5MM
31 P6204 BEARING 6204 66 PLW02M LOCK WASHER 4MM
32 PH7762032 BEARING FIXING RING 67 PN22M HEX NUT M12-1
33 PH7762033 SPRING TYPE STRAIGHT PIN 68 PW06M FLAT WASHER 12MM
34 PH7762034 ROTOR 69 PH7762069 CORD & PLUG
35 PH7762035 STATOR 70 PH7762070 MACHINE ID LABEL
Parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at [phone] or www.grizzly.com to order new labels.
