Grizzly G1079R Instruction Manual

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2Model G1079R
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G1079R 16" DRUM SANDER W/ RUBBER
CONVEYOR
Product Dimensions:
Weight.............................................................................................................................................................. 283 lbs.
Length/Width/Height.................................................................................................................36-1/2 x 27 x 42-1/2 in.
Foot Print (Length/Width)............................................................................................................................. 32 x 29 in.
Shipping Dimensions:
Type.........................................................................................................................................................Not Available
Content.................................................................................................................................................... Not Available
Weight.............................................................................................................................................................. 304 lbs.
Length/Width/Height........................................................................................................................... N/A x N/A x N/A
Electrical:
Switch...................................................................................................................On/Off Toggle with Safety Lock Tab
Switch Voltage......................................................................................................................................................220V
Cord Length............................................................................................................................................................. 8 ft
Cord Gauge....................................................................................................................................................10 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included............................................................................................................................................................No
Motors:
Sanding
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................12A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer .................................................................................................................... Single V-Belt Drive
Bearings..........................................................................................................................Sealed and Lubricated
Conveyor
Type..................................................................................................................TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................1/4 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps...............................................................................................................................................................1A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ................................................................................................................................Chain Drive
Bearings..........................................................................................................................Sealed and Lubricated

The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2Model G1079R
Main Specifications:
Operation Information
No Of Sanding Drums.......................................................................................................................................2
Maximum Board Width.........................................................................................................................15-3/8 in.
Minimum Board Width..................................................................................................................................2 in.
Maximum Board Thickness....................................................................................................................3-1/2 in.
Minimum Board Thickness........................................................................................................................1/4 in.
Minimum Board Length................................................................................................................................9 in.
Sanding Belt Speed............................................................................................................................2100 FPM
Sanding Drums Speed....................................................................................................................... 2100 FPM
Conveyor Feed Rate.............................................................................................................................. 11 FPM
Sanding Belt Length.............................................................................................................................95-1/2 in.
Sanding Belt Width.......................................................................................................................................6 in.
Drum Information
Infeed Sanding Drum Type.................................................................................................................Aluminum
Infeed Sanding Drum Size........................................................................................................................... 6 in.
Outfeed Sanding Drum Type.............................................................................................................. Aluminum
Outfeed Sanding Drum Size.........................................................................................................................6 in.
Construction
Conveyor Belt Construction.................................................................................................Heavy Duty Rubber
Body Construction.......................................................................................................................................Steel
Paint...........................................................................................................................................Powder Coated
Other Related Information
Floor To Belt Height................................................................................................................................... 34 in.
No Of Pressure Rollers.....................................................................................................................................3
Pressure Roller Type...............................................................................................................................Rubber
Pressure Roller Size.............................................................................................................................. 1-5/8 in.
Conveyor Belt Length.................................................................................................................................73 in.
Conveyor Belt Width...................................................................................................................................16 in.
Belt Roller Size.......................................................................................................................................1-7/8 in.
No Of Dust Ports...............................................................................................................................................2
Dust Port Size.............................................................................................................................................. 4 in.
Mobile Base.................................................................................................................................G7315, G8685
Other Specifications:
Country Of Origin ..............................................................................................................................................Taiwan
Warranty ............................................................................................................................................................1 Year
Serial Number Location .............................................................................................ID Label on Center of the Stand
Assembly Time ...........................................................................................................................................20 minutes
Features:
Drums are Non-Rubberized
Includes Stand
Computer Balanced Drums
Dual Sanding Drums
Four Leadscrew Table Lifting and Lowering System
Includes a Heavy-duty Rubber Conveyor Belt Similar to Wide-belt Sanders
