Grizzly G0634X User manual

COPYRIGHT © APRIL, 2007 BY GRIZZLY INDUSTRIAL, INC., REVISED APRIL, 2022 (CS)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#BL8977 PRINTED IN TAIWAN V5.04.22
MODEL G0634X
12" JOINTER/PLANER
W/V-HELICAL CUTTERHEAD
OWNER'S MANUAL
(For models manufactured since 11/20)
***Keep for Future Reference***

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

Table of Contents
INTRODUCTION............................................... 2
Contact Info ................................................... 2
Manual Accuracy ........................................... 2
Main Identification.......................................... 3
Controls & Components................................. 4
Machine Data Sheet ...................................... 7
SECTION 1: SAFETY....................................... 9
Safety Instructions for Machinery .................. 9
Additional Safety for Jointers........................11
Additional Safety for Planers ....................... 12
SECTION 2: POWER SUPPLY ...................... 13
SECTION 3: SETUP ....................................... 15
Needed for Setup......................................... 15
Unpacking .................................................... 15
Inventory ...................................................... 16
Cleanup........................................................ 17
Site Considerations...................................... 18
Lifting & Placing ........................................... 19
Assembly ..................................................... 19
Dust Collection............................................. 20
Power Connection ....................................... 21
Test Run....................................................... 21
Recommended Adjustments........................ 22
Tighten V-Belts............................................. 22
SECTION 4: OPERATIONS ........................... 23
Operation Overview ..................................... 23
Stock Inspection & Requirements ............... 25
Wood Types ................................................. 26
Setting Jointer Depth of Cut ........................ 27
Squaring Stock For Jointing ........................ 28
Surface Planing On Jointer.......................... 29
Edge Jointing ............................................... 30
Bevel Cutting On Jointer.............................. 31
Jointer/Planer Conversion ........................... 32
Planing Tips ................................................. 33
Common Planing Problems ......................... 34
Setting Planer Depth of Cut......................... 35
SECTION 5: ACCESSORIES......................... 36
SECTION 6: MAINTENANCE......................... 37
Schedule ...................................................... 37
Cleaning & Protecting .................................. 37
Lubrication ................................................... 37
SECTION 7: SERVICE ................................... 40
Troubleshooting ........................................... 40
Tensioning/Replacing V-Belts ...................... 42
Adjusting Pulley Alignment .......................... 43
Setting Outfeed Table Height....................... 44
Checking Jointer Table Parallelism.............. 45
Checking Planer Table Parallelism .............. 48
Replacing Carbide Inserts ........................... 49
Adjusting Table Lock Levers........................ 49
Calibrating Depth Scale ............................... 50
Setting Fence Stops .................................... 50
Adjusting Gibs.............................................. 51
Adjusting Roller Spring Tension................... 52
Anti-Kickback Fingers .................................. 52
SECTION 8: WIRING...................................... 53
Wiring Safety Instructions ............................ 53
Wiring Diagram ............................................ 54
Electrical Component Photos ...................... 55
SECTION 9: PARTS....................................... 56
Stand............................................................ 56
Stand Parts List ........................................... 57
Jointer Table................................................. 58
Cutterhead & Motor ..................................... 59
Drive Assembly ............................................ 60
Planer Table ................................................. 61
Limit Switch.................................................. 62
Fence ........................................................... 63
Labels & Cosmetics ..................................... 64
WARRANTY & RETURNS ............................. 65

-2- Model G0634X (Mfd. Since 11/20)
We stand behind our machines! If you have ques-
tions or need help, contact us with the information
below. Before contacting, make sure you get the
serial number
and manufacture date from the
machine ID label. This will help us help you faster.
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: [phone]
Email: [email protected]
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Email: [email protected]
Contact Info
We are proud to provide a high-quality owner’s
manual with your new machine!
We
made every effort to be exact with the
instruc-
tions, specifications, drawings, and photographs
in this manual. Sometimes we make mistakes, but
our policy of continuous improvement also means
that
sometimes the machine
you receive is
slightly different than shown in the manual
.
If you find this to be the case, and the difference
between the manual and machine leaves you
confused or unsure about something
,
check our
website for an updated version. W
e post
current
manuals and
manual updates for free
on our web-
site at
www.grizzly.com.
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write
down the
manufacture date and
serial number
from the machine ID label (see below). This
information is required for us to provide proper
tech support, and it helps us determine if updated
documentation is available for your machine.
Manufacture Date
Serial Number
Manual Accuracy
INTRODUCTION

Model G0634X (Mfd. Since 11/20) -3-
Main Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
Planer Table Height
Lock Lever
Planer
Table Height
Handwheel
Emergency Stop
Button
Magnetic
Switch
Table Lock
Lever (1 of 2)
Planer
Table
Jointer
Dust Port
Jointer
Table Height
Adjustment
Knob (1 of 2)
Infeed
Table
Jointer
Depth-of-Cut
Scale
Cutterhead
Guard
Outfeed
Table
Thickness
Scale
Planer
Dust Port
Fence
Jointer/
Planer
Selection
Lever
For Your Own Safety Read Instruction Manual Before Operating Jointer
a) Wear eye protection.
b) Always keep cutterhead and drive guards in place and in proper operating condition.
c) Never make jointing or planing cut deeper than 1⁄8in.
d) Always use hold-down/push blocks for jointing material narrower than 3 inches, or planing
material thinner than 3 inches.
e) Never perform jointing or planing cuts on pieces shorter than 12 inches in length.

-4- Model G0634X (Mfd. Since 11/20)
Controls &
Components
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Refer to the following figures and descriptions to
become familiar with the basic controls and com-
ponents of this machine. Understanding these
items and how they work will help you understand
the rest of the manual and minimize your risk of
injury when operating this machine.
Jointer Table Adjustment Controls
D. Infeed Table Height Adjustment Knob:
Adjusts position of jointer infeed table (when
infeed table height lock is loosened).
E. Infeed Table Height Lock: Secures infeed
table height adjustment (requires 6mm hex
wrench).
Figure 2. Location of infeed jointer table
adjustment controls.
Figure 3. Location of outfeed jointer table
adjustment controls.
F. Outfeed Table Height Adjustment Knob:
Adjusts position of jointer outfeed table (when
outfeed table height lock is loosened).
G. Outfeed Table Height Lock: Secures
outfeed table height adjustment (requires
6mm hex wrench).
Power Controls
A. Emergency Stop Button: Stops motor when
pressed. Remains depressed until manually
reset. Reset by twisting button clockwise until
it springs outward.
B. ON Button: Starts motor. (Only if Emergency
Stop button is not in depressed position).
C. OFF Button: Stops motor when pressed.
Figure 1. Locations of ON Button, OFF Button,
and Emergency Stop button.
AB
C
D
E
F
G

Model G0634X (Mfd. Since 11/20) -5-
H. Fence Tilt Scale: Indicates angle of fence tilt
adjustment.
I. 90° Fence Stop: Allows fence to be quickly
positioned at 90° when adjusting tilt setting.
J. Fence Tilt Lock: Tightens to secure fence tilt
setting at desired angle; loosens to allow tilt
adjustment.
K. Fence Lock Lever: Tightens to secure lateral
fence position along width of tables; loosens
to allow adjustment.
Jointer Fence Controls
Figure 5. Location of 45° fence stop.
L. 45° Fence Stop: Allows fence to be quickly
positioned at 45° when adjusting tilt setting.
Figure 4. Locations of jointer fence controls.
Jointer/Planer Conversion
Components
Figure 6. Location of fence lock.
M. Fence Lock Lever: Loosen to allow removal
of fence when converting jointer to planer.
H
I
J
K
L
M
Figure 7. Locations of table lock levers.
N. Table Lock Levers: Loosen and pull out to
swing jointer tables into UP position when
converting jointer to planer.
N
N

-6- Model G0634X (Mfd. Since 11/20)
Planer Controls
Q. Thickness Scale: Indicates thickness of
finished workpiece.
R. Table Height Handwheel: Rotates to raise
and lower planer table.
S. Table Height Lock Lever: Tightens to secure
planer table height adjustment; loosens to
allow adjustment.
Figure 10. Locations of planer controls.
P. Jointer/Planer Selection Lever: Moves UP
to engage feed rollers for planer operation.
Moves DOWN to disengage feed rollers for
jointer operation.
Figure 9. Location of jointer/planer selection
lever.
Figure 8. Location of jointer table lock knobs.
O. Jointer Table Lock Knobs: Secure jointer
tables in UP position during planing.
O
P
Serious personal injury could occur if you
place fingers between tables and base
or between pivot points. Hands could be
pinched or crushed!
Q
R
S

Model G0634X (Mfd. Since 11/20) -7-
Page 1 of 3Model G0634X
MODEL G0634X
12" JOINTER/PLANER w/V-HELICAL CUTTERHEAD
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
Product Dimensions:
Weight ........................................................................................................................................................................... 610 lbs.
Width (side-to-side) x Depth (front-to-back) x Height .......................................................................... 67-1/2 x 24 x 41-1/2 in.
Footprint (Length x Width) ...................................................................................................................................26 x 19-1/2 in.
Shipping Dimensions:
Type ........................................................................................................................................................................ Wood Crate
Content .......................................................................................................................................................................... Machine
Weight ............................................................................................................................................................................ 704 lbs.
Length x Width x Height .....................................................................................................................................72 x 46 x 30 in.
Must Ship Upright .................................................................................................................................................................Yes
Electrical:
Power Requirement ........................................................................................................................ 220V, Single-Phase, 60 Hz
Full-Load Current Rating ...................................................................................................................................................... 25A
Minimum Circuit Size ........................................................................................................................................................... 30A
Connection Type ..................................................................................................................................................... Cord & Plug
Power Cord Included ............................................................................................................................................................Yes
Power Cord Length .............................................................................................................................................................10 ft.
Power Cord Gauge ....................................................................................................................................................... 12 AWG
Plug Included ......................................................................................................................................................................... No
Recommended Plug Type .................................................................................................................................................L6-30
Switch .............................................................................................................Magnetic Switch w/Thermal Overload Protection
Motor:
Main
Horsepower ...............................................................................................................................................................5 HP
Phase .......................................................................................................................................................... Single-Phase
Amps .......................................................................................................................................................................... 25A
Speed ...............................................................................................................................................................3450 RPM
Type ................................................................................................................................ TEFC Capacitor-Start Induction
Power Transfer ............................................................................................................................................................Belt
Bearings ................................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Fence Information
Fence Length .....................................................................................................................................................51-1/4 in.
Fence Width ...............................................................................................................................................................2 in.
Fence Height ..............................................................................................................................................................6 in.
Fence Stops ............................................................................................................................................. 45 and 90 deg.
Cutting Capacities (Jointer)
Bevel Jointing .................................................................................................................................................. 0 - 45 deg.
Maximum Width of Cut .............................................................................................................................................12 in.
Maximum Depth of Cut ...........................................................................................................................................1/8 in.
Number of Cuts Per Minute ....................................................................................................................................20,136
Minimum Stock Length .............................................................................................................................................12 in.
Minimum Stock Thickness .......................................................................................................................................1/4 in.

-8- Model G0634X (Mfd. Since 11/20)
Model G0634XPage 2 of 3
Cutting Capacities (Planer)
Maximum Width of Cut .......................................................................................................................................11-3/4 in.
Maximum Depth of Cut Planing Full Width .............................................................................................................1/8 in.
Maximum Depth of Cut Planing 6" Wide Board ....................................................................................................5/32 in.
Number of Cuts Per Minute ....................................................................................................................................20,136
Number of Cuts Per Inch ...............................................................................................................................................75
Planing Feed Rate ................................................................................................................................................ 22 FPM
Minimum Stock Length .............................................................................................................................................12 in.
Minimum Stock Thickness .......................................................................................................................................1/4 in.
Maximum Stock Thickness .........................................................................................................................................8 in.
Cutterhead Information
Cutterhead Type ................................................................................................................................................. V-Helical
Cutterhead Diameter ............................................................................................................................................3-1/8 in.
Number of Cutter Rows ...................................................................................................................................................4
Number of Indexable Cutters ........................................................................................................................................48
Cutter Insert Type ................................................................................................................................ Indexable Carbide
Cutter Insert Length .................................................................................................................................................15mm
Cutter Insert Width ..................................................................................................................................................15mm
Cutter Insert Thickness ..........................................................................................................................................2.5mm
Cutterhead Speed ............................................................................................................................................5034 RPM
Table Information (Jointer)
Table Length ......................................................................................................................................................59-1/2 in.
Table Width ..............................................................................................................................................................14 in.
Table Thickness ...................................................................................................................................................1-5/8 in.
Floor to Table Height ..........................................................................................................................................35-1/2 in.
Adjustment Type ...................................................................................................................................................... Knob
Table Information (Planer)
Table/Headstock Movement .......................................................................................................................................8 in.
Table Length ......................................................................................................................................................23-1/8 in.
Table Width ........................................................................................................................................................12-1/4 in.
Table Thickness ...................................................................................................................................................1-5/8 in.
Floor to Table Height ..........................................................................................................................................32-1/2 in.
Construction
Body Assembly ................................................................................................................................................... Cast Iron
Infeed Roller ..............................................................................................................................................................Steel
Outfeed Roller .......................................................................................................................................................Rubber
Fence Assembly ................................................................................................................................................Aluminum
Guard ..................................................................................................................................................Die-Cast Aluminum
Stand ...................................................................................................................................... Heavy Gauge Sheet Metal
Table ................................................................................................................................................................... Cast Iron
Paint Type/Finish ......................................................................................................................................Powder Coated
Other Information
Number of Dust Ports ......................................................................................................................................................2
Dust Port Size ............................................................................................................................................................4 in.
Measurement Scale (Jointer) ..................................................................................................................................... Inch
Measurement Scale (Planer) ........................................................................................................................... Inch/Metric
Other Specifications:
Country of Origin ............................................................................................................................................................. Taiwan
Warranty ........................................................................................................................................................................... 1 Year
Approximate Assembly & Setup Time ...................................................................................................................... 30 Minutes
Serial Number Location ................................................................................................................................................ ID Label
ISO 9001 Factory ..................................................................................................................................................................Yes
