RM-MAG-IT/RS
Installation Guide
Version 1.0 August 2020
Magstripe IT/RS
Reader Module
General
The RM-MAG-IT/RS is an internal
swipe card reader for magnetic
stripe cards:
Standard Clock and Data output
Reads cards encoded to ISO
7811 in either direction
Switch selection for Track 1 or
Track 2 with software override
on IT series equipment
Easy to t - no wiring required
Automatic conguration when
used in IT series equipment
This Reader Module is suitable for
both RS and IT series Terminals
including the following:
RS21
IT31
GT4
The Reader Module locates in the
Front Panel and connects
to the Terminal main board using
the ribbon cable provided.
Module Power Loading
8mA @12V Terminal Power IN
Track Select Switch
Track 1 < > Track 2
Diagnostic LED
Slow ash indicates
healthy module
Mounting Screw Position
Screws are provided
Mounting Screw Position
Screws are provided
Reader Module
Ribbon Connector
Connects to
terminal front panel
Reader Module Position
The Reader Module is positioned on the Front Panel as indicated.
RS21 IT31 GT4
1
1
1
1
2
2
2
2
3
3
3
3
3
3
3
Reader Connector Module Position Screw Fixings

Email: [e-mail]
Telephone: [phone]
Web: www.grosvenortechnology.com
RM-MAG-IT/RS
Installation Guide
The tting method is the same for
RS21, IT31 and GT4.
Ensure Terminal is powered down
and follow the procedure below.
1. Remove Slot Filler
Press slot ller bar from inside
face of Front Panel while slightly
exing bottom of Front Panel so
as to open the slot wider.
2. Screw Module In Position
Screw the Reader Module in
position using the two screws
provided. Screw tension should
be su󰀩cient to hold module
rmly but avoid over tightening.
3. Connect Module
Fit the ribbon cable connector
to the Front Panel observing
polarising bump position.
4. Set Track Select Switch
Set module switch to Track 1 or
2 as required.
5. Congure Terminal for Module
Once hardware installation is
complete power-up Terminal and
if necessary congure Terminal
(see: Reader Setup).
Fitting the Reader Module Reader Setup
IT31 and GT4
When tted in an IT31 or GT4
Terminal there is no need to
congure the reader type as
the system will interrogate the
module and setup relevant drivers
automatically.
RS Series - Setting Reader
Interface Parameter
With RS series Terminals such as
RS21 the reader type needs to be
congured for correct operation.
This can be done using the front
panel display and keyboard as
follows:
Press F1 and F5 simultaneously
to enter setup mode
Enter the password ‘1905’ and
press the enter key
Move cursor to position ‘I’
Enter ‘9’ as reader type (ABA
Omron)
Reader Interface, at ‘I’ enter -
0 for Barcode / Raw F2F
1 for Wiegand Proximity
2 for ABA (Omron) External,
Magstripe Internal
3 for Mifare
4 for Dallas I-button
5 for Mifare Card ID
6 for ACG EM4102
7 for Ski Data V3
9 for ABA (Omron) Internal and
External
Reader Module Diagnostics
When connected to IT and GT
Series equipment the module
provides diagnostic information to
the host including:
Power supply Voltage
Power supply Current
Temperature
Serial number
Firmware version.
Diagnostic information
for all installed modules
may be viewed remotely.
