Grosvenor GT10S User manual

GT10S
Installation Guide
General
The GT10S Data Collection
Terminal is a modular design which
can be customised by adding easy
to install optional modules to the
terminal.
The GT10S terminal includes an
inlay which can include customised
artwork (subject to minimum order
quantities).
Green - PoE power present
Blue - 12V in power present
Red - Running on battery
Camera active
Application LED - Red, Green, Blue
Front Indicators
Memory Card Slot
Supports SD ash card
Wireless Module Indicators
BT Indicator
- Indicates Bluetooth Enabled
(requires supporting module)
WiFi Indicator
- Indicates WiFi Enabled
M.2 Port
Supports WiFi extension modules
USB Ports
Six USB2 full size sockets for
devices such as memory stick,
barcode scanner, extension
modules
USB Debug Port
For development use, allows loading
of applications
Swipe Reader Module Connector
Reader Modules include
- Mag Swipe
- Barcode Swipe
Proximity Reader Module
Connector
Reader Modules include
- HID Prox and iClass
- Feig Prox
- Generic Prox 5V or 12V
For full list of supported proximity
modules and formats refer to GTL
website
RTC Backup Battery
Real Time Clock Backup Battery
maintains time during power
disconnection. 10 year life
Camera and Microphone Module
Camera and microphone may be
removed by extracting the two
screws and withdrawing the module
Speakers (one each side)
2W per channel stereo
High e󰀩ciency class D amplier
RECOVERY Switch
Press the Recovery
button for Factory Reset
RESET Switch
Press to initiate hardware
reset, Terminal will reboot
Options include:
Mains or PoE Power Supply
Reader Module
(Proximity and/or Swipe)
Biometric Module
Enterprise grade
WiFi module
Part numbers: FP-GT10S-A
FP-GT10S-L
Version 1.4 October 2021
Power over Ethernet (PoE)
Module Position
Optional module enables terminal to
be powered via the Ethernet cable
using IEEE802.3af or IEEE802.3at
Ethernet switch or mid-span injector.
Battery Connector
For connection of the GTL Li-Ion
Battery Pack
EM-BB-2HR-A
Provides up to 2 hour runtime
Battery backup may be used with all
power options including PoE
Battery Housing
Housing for 2 hour battery with
securing strap
Ethernet Connector
10/100/1000baseT
Full duplex, auto crossover,
supports PoE (when optional
module tted)
Warning: Only t battery pack
specied, failure to observe may
result in re hazard
Power IN Connector (2.1mm)
12V DC External PSU (centre
positive) 12V± 5% with minimum 2A
capacity (refer to Power Loading for
current calculation)
PWR Indicator
Indicates 12V power present
Note: It is strongly recommended
that POE+ (IEEE802.3at) is used to
ensure that there is su󰀩cient power
available for the device.
Stress relief clip*
Self-adhesive clip tted to protect
DC Jack socket if/when panel is
removed from the wall
*Stress relief clip
To use the clip and protect the DC/Jack socket:
- twist the cable to create a loop
- thread the loop through the clip
Proximity Reader
Mounting Position
Swipe
Reader
Mounting
Position
Operating Temperature: 0 to +45C (14 to 113F)
Humidity: 5-90% non condensing Weight 1.5Kg (3.3lb)
Power Loading: 620mA @12V Power IN

Email: [e-mail]
Telephone: [phone]
Web: www.grosvenortechnology.com
EMEA HQ
[email protected]
[phone]
www.gtclocks.com
North America HQ
GT10S
Installation Guide
1. Insert the key
2. While pressing the key in
rotate clockwise
3. Front panel bottom can
now be pulled forward
4. When separated, lift front
panel to remove
Opening and tting Front Panel to Back Panel
1
2
3
Installing the GT10S
Secure to a vertical surface
Before mounting the back panel rst t any Biometric Reader
options as these need access from the rear of the unit.
Bring in any cables through snip-out apertures (A or B). Cables may
be routed within the cabling cavity between the back panel and
mounting surface (C).
For installations in the USA the unit may be mounted over a
power outlet with PSU (wall wart) inside the case. For this type of
installation snip-out the large aperture (B)
Fix the back panel to a at vertical surface at a height that will be
comfortable for users to see and touch the screen observing any
national regulations. Use suitable screws through any of the xing
points (D) circled to rmly secure the device taking care to not over-
tighten the screws or distort the case.
Extension Modules e.g. EM-IO-USB-IT may be tted in the area (E)
Fitting Reader Modules
IT series Proximity Reader Modules may be tted using the two
mounting screws provided. Connect the ribbon cable and apply
power to the terminal.
The reader type will be automatically detected. Within the Settings
menu select Readers & peripherals to access the reader settings
page.
GT10S-A Conguration
To access the Settings menu
allow the Terminal to boot then
select ‘Admin’. A PIN is required
to enter setup mode, the default
is 1905. From the Apps menu
select ‘settings’ then select
‘Readers & peripherals’.
GT10S-L Conguration
Once the unit is fully booted,
the initial screen gives you
the opportunity to enter the
Terminal Setup by pressing
the Cog Icon (bottom right of
screen).
DDDDD
D
DD
E
CA
B
The default
PIN is 1905
