GROTHE CALIMA 200 Series User manual

Installation and Operating Instructions
CALIMA 200 Series Wireless Chime Kit
Kit consisting of a
wireless chime
with LED ring and
wireless bell button

2
Dear Customer,
With this device you have acquired a quality product which we have developed
and produced for you with the greatest possible care and to the highest
standards. The statutory guarantee period applies. Defects caused by improper
handling, misuse or disregard of the installation and operating instructions are
excluded from this guarantee
.
Package contents (please check the package contents for
completeness)
o 1 CALIMA 200 wireless chime
o 1 wireless bell button
o 2 wall plugs and 2 Phillips screws for mounting the wireless bell
button
o 1 Allen key for opening the cover of the wireless bell button
You also need (not included in the package)
o 4 x 1.5 V (AA type) batteries for the wireless chime
o 2 x 1.5 V (AAA type) batteries for the wireless bell button
o Tools / aids such as drill bits, screwdriver, coin
Alternative fixing option (not included)
o Velcro tape or double-sided adhesive tape instead of mounting
with screws
Guarantee / Package contents / Materials required

3
Safety instructions / Cleaning
Do not expose the wireless chime to dripping or splashing liquid! Do not place
any vessels filled with liquid on it! Do not cover it with objects or blankets,
curtains, etc. and protect it from direct sunlight and naked flames!
Do not expose the batteries in the wireless bell button to excessive heat
(e.g. sunlight, fire or similar)!
Intended use
The devices described here are solely intended as a radio-controlled bell and
signalling system for private use. The function can be impaired by different
influences (flat batteries, radio interference, etc.). Never use this wireless
chime kit in safety-related areas!
If failure of the device could cause a hazard for people, or other consequential
damage is possible, you MUST prevent this through suitable additional safety
measures!
Cleaning
Please clean using only a slightly damp cloth, not a microfibre cloth, as this
could scratch the surface.

4
Initial information:
• Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• What else you need . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• Alternative fixing option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
• Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
• Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
• Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CALIMA 200 – the highlights explained briefly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
First-time use of the wireless chime
• Inserting the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
First-time use of the wireless bell button
• Mounting, inserting the batteries, writing on the nameplate . . . . . . . . . . . . . . . . . . . . . 10
Individual settings of the wireless chime
• Setting the melody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Setting the colour of the LED ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
• Setting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Mute / slumber function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
• Switching mute on/off (for an undefined period) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
• Switching on / prematurely ending slumber function for 1, 3, 9 hours . . . . . . . . 20
Table of Contents

5
Coupling
• Coupling the wireless chime and wireless bell button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
• Optional: Extending by adding further wireless bell buttons /
wireless chimes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
• Deleting the coupling between wireless chime and wireless bell button . . . 24
Optional: Using the alarm function
(only with MISTRAL SE03.1 wireless bell button)
• Alarm function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Acoustic warning if batteries are low . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Radio range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Possible combinations / networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Troubleshooting and help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Declarations of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Disposal and recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Guarantee and liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Quick-start guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
• Melody selection
• LED ring colour selection
• Volume
• Coupling
• Mute / slumber function
Table of Contents

6
x
CALIMA 200 – the highlights explained briefly
The wireless chime kit is made up of a wireless chime and a wireless bell button.
The wireless chime can be installed in any place in the house or, for example,
on the patio – wherever it is needed. It fits harmoniously into your furnishings
and is nonetheless an eye-catcher. A large number of varied melodies are
clearly distinguished from ambient noises; in addition, the flashing coloured
LED ring assists perception in an ideal way. Thanks to the large range,
CALIMA always announces your visitors or suppliers reliably, even in the
garden.
Ready for use immediately: The wireless bell button is coupled with the
wireless chime in the factory, so that you can use the wireless chime kit
immediately. You can change settings such as the required melody, colour of
the LED ring and volume later.
Networking and individual settings: Several wireless bell buttons and wireless
chimes can be combined with each other and a different melody and colour of
the LED ring can be set for each wireless bell button. So that you know
immediately at which door your visitor is.
Optional alarm function: You can use the wireless chime in combination with
a wireless bell button of the type MISTRAL SE03.1 (not included in the kit) as
an alarm generator. With this wireless bell button, a quickly usable, flexible
and above all, mobile in-house help call system is created. In this way, for
example, a person in need of help can easily draw attention to themselves. To
do this, the wireless bell button must only be pressed for around 3 seconds.
Extendable system: The wireless chime kit can be extended to include an
additional wireless bell button and wireless chime. You can couple a wireless
bell button with any number of wireless chimes1and up to 11 wireless bell
buttons can be coupled with one wireless chime. Interference caused by
other transmitters is prevented, as each wireless bell button sends its own
individual code.
1(Wireless chimes of the ECHO, MISTRAL, CALIMA series only)

7
Battery
compartment
cover
Battery
compartment
Battery holder
Select button
Menu button
Button Nameplate
CALIMA 200 wireless chime kit product overview
Screws
Loudspeaker
Radio chimeWireless bell button
LED
LED ring

8
First-time use / starting up – wireless chime
Before using for the first time, you
only have to insert the batteries into
the wireless chime and wireless bell
button and mount the wireless bell
button. Simply install the wireless
chime in the required place.
The batteries required are not
included.
Wireless chime:
4 x 1.5 V (AA type) batteries
Wireless bell button:
2 x 1.5 V (AAA type) batteries
1
Open the battery compartment by
using a coin to unscrew the cover
anti-clockwise.
Re-insert the battery holder into the
chime with the springs into front.
4

9
First-time use / starting up – wireless chime
Remove the battery holder from the
chime.
Close the battery compartment by
using a coin to screw the cover
clockwise.
2 3
Insert 4 x 1.5 V (AA type) batteries
into the battery holder. Note the
polarity.
Please note:
• The contact springs on the
battery holder must always be
positioned where “+” and “–” are
visible at the edge of the bottom
of the housing.
• The two small metal clips inside
the housing must touch the
contact springs of the battery
holder. Otherwise the batteries do
not have any contact.
5

10
First-time use / starting up – wireless bell button
Wireless bell button:
Mount, insert batteries, write on nameplate
1
3
Use the Allen key to undo the screws in the cover of the wireless bell button,
and then remove the top half.
Insert 2 x 1.5 V (AAA type) batteries into the bottom part of the wireless bell
button. Note the polarity (see markings).
Undo screws

2
Use the screws supplied to fix the bottom part of the wireless bell button
through the mounting holes and onto the wall.
11
First-time use / starting up – wireless bell button
To label, pull the nameplate out at the side and then push it back in again.
Use the hexagon socket screws to screw the top part of the wireless bell
button firmly onto the bottom part.
Note: Where possible, do not mount the wireless bell button on metal
parts, as this reduces the range significantly.
4
Mounting holes

12
Individual settings – melody
Press the Select button until the
required melody is played.
You will hear “Melody selection”.
The wireless chime is set and
operated by 2 buttons:
• Selection button (left)
• Menu button (right)
The voice output of the wireless
chime signals the respective
status of the settings.
Press the wireless bell button, that
corresponds to the melody that you
want to set.
4
MELODY SELECTION
5
1
1x

13
Individual settings – melody
The LED ring flashes blue as
confirmation.
You will hear "Setting finished” as
confirmation.
Then, press the Menu button on
the wireless chime in its normal
state once.
From now on, you hear the last
played melody when the wireless
bell button is pressed.
Note: The wireless chime
automatically returns to the normal
state, if no button has been
pressed for 7 seconds.
Repeat this process to set the
melody for other wireless bell
buttons.
2
1x
3
FLASHES BLUE
6
SETTING FINISHED

14
Individual settings – colour of the LED ring
Press the wireless bell button to
set the colour of the LED ring on the
wireless chime
.
Then, press the Menu button in the
normal state twice.
7 seconds after the last button
was pressed you will hear “Setting
finished”.
From now on, the LED ring lights up
in the set colour when the wireless
bell button is pressed.
The wireless chime automatically
returns to the normal state if no
button has been pressed for
7 seconds.
2
2x
5
SETTING FINISHED
1
1x

15
Individual settings – colour of the LED ring
You will hear “Colour selection”. The
LED ring lights up with the currently
set colour.
Now, press the Select button until
the LED ring lights up in the required
colour. Your selection is saved
automatically if no button is pressed
for 7 seconds.
Good to know: You can set the colour with which the LED ring lights up
when a specific wireless bell button is pressed.
If you use several wireless bell buttons, this enables you to differentiate at
which door the bell was rung.
3
COLOUR SELECTION
4

16
Individual settings – volume
The LED ring flashes green as
confirmation.
Press the Menu button 3 times in the
normal state.
7 seconds after the last button was
pressed you will hear “Setting
finished”. From now on, the wireless
chime signals with the last selected
volume.
The wireless chime automatically
returns to the normal state,
if no button has been pressed for
7 seconds.
2
5
SETTING FINISHED
1
3x
FLASHES GREEN

17
Individual settings – volume
You will hear “Volume”. Press the Select button until the
melody is played with the required
volume. Your selection is saved
automatically if no button is pressed
for 7 seconds.
Note: The volume of the wireless chime can always only be set the same
for all wireless bell buttons
used.
4
3
VOLUME

18
Mute / slumber function
If you do not want to be disturbed,
you can mute the wireless chime so
that neither a melody is played, nor
does the LED ring flash. The
wireless chime signals neither
visually nor acoustically.
To do this, two options are available
for you to choose from:
• The function can either be
activated for a previously defined
period (slumber function)
• or for an unlimited time (mute).
Both functions, i.e. mute and
slumber mode, are indicated
visually. The LED ring flashes green
until the wireless chime is back in
active mode, and therefore serves
as a reminder to end muting.
Press the Select button in the normal
state once.
1
1x

19
Switching mute on /off (for an undefined period)
If mute is active, the LED ring flashes
green at regular intervals.
Press the Select button to end mute.
As confirmation, the LED ring lights
up green while you press the button.
FLASHES GREEN
1x
2 3
LIGHTS UP GREEN

20
Start / prematurely end slumber function for 1, 3, 9 hours
Press the Select button 2, 3 or 4
times at one second intervals in the
normal state to activate the slumber
function for 1, 3 or 9 hours.
As confirmation, the LED ring then
flashes yellow 2 to 4 times,
depending on how often you pressed
the Select button (see table).
12
FLASHES 2 – 4 X YELLOW
2– 4x
• You can use the slumber function to mute the wireless chime for a period
limited from the start, i.e. the wireless chime switches back to active mode
automatically.
• You can also end the slumber function at any time before the set period
has expired.
• On the other hand, if you have set mute for an unlimited period, you must
end it actively.
