Grunbeck GENO-Multi Niveau User manual

We understand water.
Filling level indicator | GENO-Multi Niveau
Operation manual

General Contact
Germany
International Sales
[phone]
Service
[phone]
[email protected]
Availability
Monday to Thursday
7:00 am - 6:00 pm
Friday
7:00 am - 4:00 pm
We reserve the right to technical modifications.
© by Grünbeck Wasseraufbereitung GmbH
Original operation manual
Edition: September 2022
Order no.: 712940_inter_175

Table of contents
3 | 64
Table of contents
1Introduction ..................................... 5
1.1 Validity of the manual ...................... 5
1.2 Other applicable documents ............ 5
1.3 Product identification ....................... 6
1.4 Symbols used .................................. 7
1.5 Depiction of warnings ...................... 8
1.6 Demands on personnel.................... 9
2Safety ............................................. 11
2.1 Safety measures............................ 11
2.2 Product-specific safety
instructions..................................... 13
2.3 Conduct in emergencies ................ 13
3Product description ...................... 14
3.1 Intended use.................................. 14
3.2 Product components...................... 15
3.3 Functional description.................... 16
4Transport and storage.................. 17
4.1 Transport ....................................... 17
4.2 Storage .......................................... 17
5Installation ..................................... 18
5.1 Requirements for the installation
site ................................................. 19
5.2 Checking the scope of supply........ 20
5.3 Water installation ........................... 21
5.4 Electrical installation ...................... 25
6Start-up/commissioning............... 32
6.1 Checking the product..................... 32
6.2 Setting the control unit ................... 33
6.3 Handing over the product to the
owner/operator/operating
company ........................................ 33
7Operation ....................................... 34
7.1 Operation of the control unit .......... 34
7.2 Programming the parameters........ 37
8Maintenance and repair................ 45
8.1 Cleaning ........................................ 45
8.2 Intervals ......................................... 46
8.3 Inspection ...................................... 47
8.4 Maintenance .................................. 48
8.5 Spare parts .................................... 49
8.6 Wearing parts ................................ 49
9Troubleshooting............................ 50
9.1 Messages ...................................... 50
9.2 Other observations ........................ 51
10 Decommissioning......................... 52
10.1 Temporary standstill ...................... 52
10.2 Decommissioning .......................... 52
10.3 Restart/recommissioning ............... 52
11 Dismantling and disposal ............ 53
11.1 Dismantling.................................... 53
11.2 Disposal......................................... 53

Table of contents
4 | 64
12 Technical specifications............... 55
13 Operation log................................. 57
13.1 Start-up/commissioning log............ 57

Introduction
5 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
1 Introduction
This manual is intended for owners/operators/operating companies,
users as well as qualified specialists and ensures the safe and effi-
cient handling of the product. The manual is an integral part of the
product.
●Carefully read this manual and the included manuals on the
components before you operate your product.
●Obey all safety and handling instructions.
●Keep this manual and all other applicable documents, so that
they are available when needed.
Illustrations in this manual are for basic understanding and can differ
from the actual design.
1.1 Validity of the manual
This manual applies to the product below:
●Filling level indicator GENO-Multi Niveau with level probe
1.2 Other applicable documents
●Manuals for components from other manufacturers

Introduction
6 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
1.3 Product identification
You can identify your product based on the product designation and
the order no. indicated on the type plate.
►Check whether the products indicated in chapter 1.1 corre-
spond to your product.
The type plate of the filling level indicator GENO-Multi Niveau is lo-
cated on the fastening plate.
The label with the technical data is on the right side of the housing.
Designation
1
EAC test mark
2
CE mark
3
Disposal information
4
Obey the operation manual
5
Product designation
6
Ambient temperature
7
Dimensions
Designation
8
Operating weight
9
Date of manufacture
10
Serial no.
11
Order no.
12
Power supply
13
Rated frequency
14
Power input

Introduction
7 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
The type plate for the complete filling level indicator GENO-Multi
Niveau with level probe is enclosed in the cardboard box.
►Stick this type plate on the basic pure water tank close to the
level probe.
Designation
1
Product designation
2
Order no.
3
Signal output
4
Cable length of level probe
Designation
5
Measuring range in mWC
6
Measuring range in bar
7
Water temperature
1.4 Symbols used
Symbol
Meaning
Danger and risk
Important information or requirement
Useful information or tip
Written documentation required

Introduction
8 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
Symbol
Meaning
Reference to further documents
Work that must be carried out by qualified specialists only
Work that must be carried out by qualified electricians only
Work that must be carried out by technical service personnel only
1.5 Depiction of warnings
This manual contains information and instructions that you must
obey for your personal safety. The information and instructions are
highlighted by a warning symbol and are structured as shown below:
1.1.1.1
1.1.1.2 SIGNAL WORD
1.1.1.3 Type and source of hazard
1.1.1.4
●Possible consequences
►Preventive measures
The signal words below are defined subject to the degree of danger
and might be used in the present document:
Warning symbol and
signal word
Consequences if the information/
instructions are ignored
DANGER
Personal
injury
Death or serious injuries
WARNING
Possible death or serious injuries
CAUTION
Possible moderate or minor injuries
NOTE
Damage to
property
Possible damage to components, the
product and/or its functions, or an object
in its vicinity

Introduction
9 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
1.6 Demands on personnel
During the individual life cycle phases of the product, different peo-
ple carry out work on the product. This work requires different quali-
fications.
1.6.1 Qualification of personnel
Personnel
Requirements
User
•No special expertise required
•Knowledge of the tasks assigned
•Knowledge of possible dangers in case of incor-
rect behaviour
•Knowledge of the required protective equipment
and protective measures
•Knowledge of residual risks
Owner/operator/
operating company
•Product-specific expertise
•Knowledge of statutory regulations on work
safety and accident prevention
Qualified specialist
•Electrical engineering
•Sanitary engineering
(HVAC and plumbing)
•Transport
•Professional training
•Knowledge of relevant standards and regula-
tions
•Knowledge of detection and prevention of po-
tential hazards
•Knowledge of statutory regulations on accident
prevention
Technical service
(Grünbeck's technical service/
authorised service company)
•Extended product-specific expertise
•Trained by Grünbeck

Introduction
10 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
1.6.2 Authorisations of personnel
The table below describes which tasks may be carried out by whom.
User
Owner/
operator/
operating
company
Qualified
specialist
Technical
service
Transport and storage
X
X
X
Installation and mounting
X
X
Start-up/commissioning
X
X
Operation and handling
X
X
X
X
Cleaning
X
X
X
X
Inspection
X
X
X
X
Maintenance
semi-annually
X
X
X
annually
X
X
Troubleshooting
X
X
X
Repair
X
X
Decommissioning and
restart/recommissioning
X
X
Dismantling and disposal
X
X
1.6.3 Personal protective equipment
►As an owner/operator/operating company, make sure that
the required personal protective equipment is available.
The components below fall under the heading of personal protective
equipment (PPE):
Protective gloves

Safety
11 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
2 Safety
2.1 Safety measures
●Only operate your product if all components are installed
properly.
●Obey the local regulations on drinking water protection, acci-
dent prevention and occupational safety.
●Do not make any changes, alterations, extensions or program
changes on your product.
●Only use genuine spare parts for maintenance or repair.
●Keep the premises locked against unauthorised access to
protect imperilled or untrained persons from residual risks.
●Comply with the maintenance intervals (refer to chapter 8.2).
Failure to comply can result in the microbiological contamina-
tion of your drinking water system.
2.1.1 Mechanical hazards
●You must never remove, bridge, or otherwise tamper with
safety equipment.
●Make sure that the product is securely fastened on the wall or
on the tank and that this is guaranteed at all times.

Safety
12 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
2.1.2 Electrical hazards
●There is an immediate danger of fatal injury from electric
shock when touching live parts. Damage to the insulation or
individual components can be lethal.
●Only have qualified electricians carry out electrical work on
the product.
●In case of damage to live components, switch off the voltage
supply immediately and arrange for repair.
●Switch off the supply voltage before working on electrical sys-
tem parts. Discharge residual voltage.
●Never bridge electrical fuses. Do not disable fuses. Use the
correct current ratings when replacing fuses.
●Keep moisture away from live parts. Moisture can cause
short-circuits.
2.1.3 Groups of persons requiring protection
●This product is not designed to be used by persons (including
children) with reduced capabilities, lack of experience or lack
of knowledge.

Safety
13 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
2.2 Product-specific safety instructions
WARNING
Lethal voltage
●Severe burns, cardiovascular failure, fatal electric shock
►Only have qualified electricians carry out electrical work on
the product.
►Only open the housing of the device when the device is de-
energised.
Labels on the product
Risk of electric shock
The affixed information and pictograms must be clearly legible.
They must not be removed, soiled or painted over.
►Obey all warnings and safety instructions.
►Immediately replace illegible or damaged symbols and picto-
grams.
2.3 Conduct in emergencies
2.3.1 In case of water leaks
1. Disconnect the system from the power supply –unplug the
mains plug.
2. Locate the leak.
3. Eliminate the cause of the water leak.

Product description
14 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
3 Product description
3.1 Intended use
●The filling level indicator GENO-Multi Niveau is used in the in-
dustrial and commercial sector to indicate the filling level of
permeate/pure water tanks.
●The filling level indicator GENO-Multi Niveau is used in the
swimming pool sector to indicate the filling level of raw water
tanks.
3.1.1 Application limits
When using a tank from another manufacturer, make sure that the
tank can be filled smoothly and steadily, so that the filling level
does not fluctuate too much due to wave action.
●When using a suitable level probe or a suitable pressure
transducer, a filling height in the range of 100 –1000 cm can
be indicated as well.
●Only tanks with linearly increasing filling volume can be evalu-
ated.
●Cylindrical tanks lying in a horizontal position as well as
spherical or conical tanks cannot be evaluated.
3.1.2 Foreseeable misuse
●Use in sea or salt water pools

Product description
15 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
3.2 Product components
Designation
Function
1
Fastening plate
•To fasten the GENO-Multi Niveau
∙With reclosable fasteners on the back for in-
stallation on the tank
∙With 4 bores for wall mounting
2
Filling level indicator
•Control unit to display the filling level, the filling
height and the filling volume of the tank
•Parameter programming
3
Transformer
•Power supply unit for converting the mains volt-
age 230 V AC to 24 V AC
•Mains line of 2 m in length with Schuko plug
4
Cable of level probe
•Connection to GENO-Multi Niveau
5
Tank feed-through
•For fastening the level probe on the tank
6
Protective hose
•Feed-through into the tank
∙The length depends on the design of the
measuring probe
7
Level probe
•Measurement of water pressure

Product description
16 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
3.3 Functional description
The filling level indicator GENO-Multi Niveau is designed to meas-
ure and display the filling level in permeate/pure water or raw water
tanks.
Membrane systems, pressure booster systems or pool water sys-
tems and make-up water feed systems can be controlled via pro-
grammable switching contacts.
Pressure measurement
By means of a level probe at the bottom of the tank, the pressure
generated by the water column is registered and emitted as a
4 –20 mA signal.
The filling level indicator GENO-Multi Niveau converts the pressure
signal into a filling height (cm), a filling level (%) or a filling volume
(m³).

Transport and storage
17 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
4 Transport and storage
4.1 Transport
►Transport the product in its original packaging only.
►Protect the product from frost or high temperature during
transport.
►Upon receipt, check the product for completeness and
transport damage.
4.2 Storage
►Protect the product from the impacts below when storing it:
•Dampness, moisture
•Environmental impacts such as wind, rain, snow, etc.
•Frost, direct sunlight, severe heat exposure
•Chemicals, dyes, solvents and their vapours

Installation
18 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
5 Installation
The installation of the product must be carried out by a qualified
specialist only.
WARNING
Actuation of an on-site solenoid valve
●The coil of the solenoid valve can become hot
●Burns at temperatures of > 50 °C
►Check whether protection against direct contact with the so-
lenoid valve is required on site.
Installation examples
Designation
1
Schuko socket
2
Tank, e.g. GT 1000
3
Connection for level probe
Designation
Installation on the tank
Wall mounting

Installation
19 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
5.1 Requirements for the installation site
●The installation site must be frost-proof and ensure the
product's protection from direct sunlight, chemicals, dyes, sol-
vents and their vapours, etc.
●The installation site must be adequately illuminated and venti-
lated.
●The installation site must be easily accessible for mainte-
nance purposes.
●In case of wall mounting, the distance between the filling level
indicator and the level probe must not exceed max. 2.5 m due
to the allowable length of the cable.
●For the electrical connection, a Schuko socket (230 V/50 Hz)
is required within a range of approx. 1.6 m of the product.

Installation
20 | 64
BA_712940-inter_175_GENO-Multi Niveau.docx
5.2 Checking the scope of supply
Designation
1
Filling level indicator
GENO-Multi Niveau (mounted
on fastening plate)
2
Transformer with Schuko plug
(mounted on fastening plate)
3
Level probe with 10 m cable
incl. tank feed-through (1" male
thread)
Designation
4
Fastening material:
3x Reclosable fastener on the
fastening plate (for installation
on the tank) or 4x screws with
dowels (for wall mounting)
5
Operation manual
6
Type plate for tanks with level
probe (for order no. 712 425
and 712 465 only)
►Check the scope of supply for completeness and damage.
