Grundfos SE1 50 User manual

SE1 50, 80, 100
SEV 65, 80, 100
Safety instruction
GRUNDFOS INSTRUCTIONS
QR96046675
Installation and operating instructions
http://net.grundfos.com/qr/i/96046675

English (GB)
2
English (GB) Safety instructions and other important information
Original service instructions
These safety instructions give a quick overview of
the safety precautions to be taken in connection with
any work on this product.
Observe these safety instructions during handling,
installation, operation, maintenance, service and
repair of this product.
These safety instructions is a supplementary
document, and all safety instructions will appear
again in the relevant sections of the installation and
operating instructions.
Keep these safety instructions at the installation site
for future reference.
Read this document
before installing the
product. Installation and
operation must comply
with local regulations
and accepted codes of
good practice.
This appliance can be
used by children aged
from 8 years and above
and persons with
reduced physical,
sensory or mental
capabilities or lack of
experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and
understand the hazards
involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.

English (GB)
3
Approvals
The standard versions of SE1 and SEV pumps have
been tested by VDE, and the explosion-proof
versions approved by DEKRA according to the ATEX
directive.
The standard variants are approved by LGA (notified
body under the Construction Products Directive)
according to EN 12050-1 or EN 12050-2 as specified
on the pump nameplate.
The SE1 and SEV pumps have the following
explosion protection classifications:
• CE 0344 II2 GD Ex db eb h mb IIB T4, T3 Gb:
Ex h mb tb IIICT135 °C, T200 °C Db.
Maximum surface temperature is 135 °C (T4) in
direct-drive pumps and 200 °C (T3) in pumps driven
by frequency converter, according to EN 60079-0
Frequency converter operation
All SE1, SEV pump types are designed for frequency
converter operation to keep the energy consumption
at a minimum.
For frequency converter operation, please observe
the following information:
Requirements must be fulfilled.
Recommendations ought to be fulfilled.
Consequences ought to be considered.
Requirements
• The thermal protection of the motor must be
connected.
• Minimum switching frequency: 2.5 kHz.
• Peak voltage and dU/dt must be in accordance
with the table below. The values stated are
maximum values supplied to the motor terminals.
The cable influence has not been taken into
account. See the frequency converter data sheet
regarding the actual values and the cable
influence on the peak voltage and dU/dt.
• If the pump is an Ex-approved pump, check if the
Ex certificate of the specific pump allows the use
of a frequency converter.
• Set the frequency converter U/f ratio according to
the motor data.
• Local regulations or standards must be fulfilled.
Recommendations
Before installing a frequency converter, calculate the
lowest allowable frequency in the installation in order
to avoid zero flow.
• Do not reduce the motor speed below 30 % of
rated speed.
• Keep the flow velocity above 1 m/sec.
• Let the pump run at rated speed at least once a
day in order to prevent sedimentation in the
piping system.
• Do not exceed the frequency indicated on the
nameplate. In this case there is risk of motor
overload.
• Keep the power cable as short as possible. The
peak voltage will increase with the length of the
power cable. See data sheet for the frequency
converter used.
• Use input and output filters on the frequency
converter. See data sheet for the frequency
converter used.
• Use a screened power cable if there is a risk that
electrical noise can disturb other electrical
equipment. See data sheet for the frequency
converter used.
Consequences
When operating the pump via a frequency converter,
please be aware of these possible consequences:
• The locked-rotor torque will be lower. How much
lower will depend on the frequency converter
type. See the installation and operating
instructions for the frequency converter used for
information on the locked-rotor torque available.
• The working condition of bearings and shaft seal
may be affected. The possible effect will depend
on the application. The actual effect cannot be
predicted.
• The acoustic noise level may increase. See the
installation and operating instructions for the
frequency converter used for advice as to how to
reduce the acoustic noise.
Operating conditions
Operating pressure
All pump housings have PN 10 outlet flanges.
Operating mode
The pumps are designed for continuous operation,
S1, or intermittent operation, S3.
Operating mode S3 means that within 10 minutes the
pump must be in operation for four minutes and
stopped for six minutes.
Maximum repetitive peak
voltage
[V]
Maximum dU/dt UN
400 V
[V/μsec.]
850 2000

English (GB)
4
pH value
SE pumps in permanent installations can cope with
the following pH values:
*For fluctuating pH values, the range is pH 4-14.
Liquid temperature
0-40 °C.
For short periods (maximum 1 hour), a temperature
of up to 60 °C is permissible for non-Ex versions.
Ambient temperature
The allowed ambient temperature is -20 to + 40 °C.
Density and viscosity of the pumped liquid
When pumping liquids with a density and/or a
kinematic viscosity higher than that of water, use
motors with correspondingly higher outputs.
Flow velocity
We recommend that you keep a minimum flow
velocity to avoid sedimentations in the pipes.
Recommended flow velocities:
– in vertical pipes: 0.7 m/s
– in horizontal pipes: 1.0 m/s.
Maximum solids size
From 50 to 100 mm, depending on the pump size.
Maximum starts per hour
Maximum 20 starts per hour.
Noise emission < 70 dB(A)
• Measurements were carried out on dry-installed
pumps in a closed system.
• Sound power measurements were carried out
according to ISO 3743.
• Sound power was calculated at a distance of 1 m
according to ISO 11203.
The sound pressure level of the pump is lower than
the limiting values stated in the EC Council directive
2006/42/EC relating to machinery.
Storage temperature
Storage temperature: -30 to +60 °C.
Electrical data
Supply voltage
• 3 x 230 V - 10 %/+ 6 %, 50 Hz.
• 3 x 400 V - 10 %/+ 6 %, 50 Hz.
Enclosure class
IP68, according to IEC 60529.
Insulation class
F (155 °C).
Receiving the product
Pump
type
Material
variant Installation pH value
SE1,
SEV Standard Dry and
submerged 6.5 - 14*
SEV Q Dry and
submerged 6-14*
SEV S Submerged 5.5 - 14*
Dry 1-14
SEV R Dry and
submerged 1-14
SEV D Dry and
submerged 0-14
Explosion-proof pumps must never pump
liquids with a temperature higher than 40
°C.
For explosion-proof pumps, the ambient
temperature on the installation site must
be in the range from -20 to +40 °C.
For explosion-proof pumps with WIO
sensor, the ambient temperature at the
installation site must be in the range from
0-40 °C.
WARNING
Crushing hazard
Death or serious
personal injury
- Check that the screws
of the lifting bracket
are tightened before
attempting to lift the
pump. Tighten, if
necessary.
- Always lift the pump by
its lifting bracket or by
means of a fork-lift
truck if the pump is
fixed on a pallet.
- Never lift the pump by
the power cable or the
hose or the pipe.

English (GB)
5
Installing the product Mechanical installation
Pump installation in pits
must be carried out by
specially trained
persons.
Work in or near pits must
be carried out according
to local regulations.
WARNING
Crushing hazard
Death or serious
personal injury
- Do not stand near or
under the pump when it
is lifted.
Persons must not enter the installation
area when the atmosphere is explosive.
WARNING
Electric shock
Death or serious
personal injury
- It must be possible to
lock the main switch in
position 0. Type and
requirements as
specified in EN
60204-1.
WARNING
Electric shock
Death or serious
personal injury
- It must be possible to
switch off the power
supply and lock the
main switch in position
0 with a padlock to
ensure that the power
supply cannot be
accidentally switched
on.
- Any external voltage
connection to the pump
must be switched off
before working on the
pump.
The pump must not run dry. Dry running
can cause ignition hazard.
Install an independent secondary level
switch to ensure that the pump is stopped
in case the primary stop level switch is not
working.
Inspect the oil level and condition every
3000 operating hours or at least once a
year.
When the pump is new or after
replacement of the shaft seal, check the oil
level and water content after one week of
operation.
Use the lifting bracket
only for lifting the pump.
Do not use it to hold the
pump when it is in
operation.

English (GB)
6
Electrical connection
WARNING
Crushing hazard
Death or serious
personal injury
- Check that the screws
of the lifting bracket
are tightened before
attempting to lift the
pump. Tighten, if
necessary.
- Always lift the pump by
its lifting bracket or by
means of a fork-lift
truck if the pump is
fixed on a pallet.
- Never lift the pump by
the power cable or the
hose or the pipe.
WARNING
Electric shock
Death or serious
personal injury
- Never lift the pump by
the power cable.
Before beginning installation procedures,
make sure that the atmosphere in the pit is
not potentially explosive.
Do not use elastic
elements or bellows in
the pipes; never use
these elements as a
means to align the
pipes.
The guide rails must not
have any axial play as
this would cause noise
during pump operation.
WARNING
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
fuses have been
removed or the main
switch has been
switched off and locked
in position 0. Make
sure that the power
supply cannot be
accidentally switched
on.
WARNING
Electric shock
Death or serious
personal injury
- Make sure the earth
and phase conductors
are not mixed up,
follow the description
in the wiring diagram.
- Make sure the earth
conductor is connected
first.

English (GB)
7
Starting up the product
Connect the pump to an
external main switch
which ensures all-pole
disconnection with a
contact separation
according to EN
60204-1.
Make sure that the main
switch is locked in
position 0. Type and
requirements as
specified in EN 60204-1.
The electrical
connection must be
carried out in
accordance with local
regulations.
Observe the following points:
• Do not install Grundfos control boxes,
pump controllers, Ex barriers, or leave
the free end of the power cable, in
potentially explosive environments.
• The classification of the installation site
must be defined by the owner of the
site in each individual case.
• On explosion-proof pumps, make sure
that an external earth conductor is
connected to the external earth
terminal on the pump using a secure
cable clamp. Clean the surface of the
external earth connection and mount
the cable clamp.
• The cross section of the earth
conductor must be at least 4 mm2, e.g.
type H07 V2-K (PVT 90 °) yellow and
green.
• Make sure that the earth connection is
protected from corrosion.
• Make sure that all protective equipment
has been connected correctly.
• Float switches used in potentially
explosive environments must be
approved for this application. They
must be connected to the Grundfos LC,
LCD 108 or DC, DCD pump controller
via the intrinsically safe LC-Ex4 barrier
to ensure a safe circuit.
Set the motor-protective
circuit breaker to the
rated current of the
pump. The rated current
is stated on the pump
nameplate.
A damaged power cable
must be replaced by the
manufacturer, its service
agent or similarly
qualified persons.
Before installation and
the first startup of the
pump, check the
condition of the power
cable visually to avoid
short circuits.
If an RC filter is installed
to avoid any kind of
transients in the
installation, install the
RC filter between the
power supply and the
pump.
The pump must not run
dry.
Dry running can cause ignition hazard.
Do not open the clamp
while the pump is
operating.
Do not start the pump if the atmosphere in
the pit is potentially explosive.

English (GB)
8
Startup
Product introduction
Potentially explosive environments
CAUTION
Sharp element
Minor or moderate
personal injury
- Wear protective gloves
to avoid being cut by
the sharp edges of the
impeller.
Check that there is positive inlet pressure
before starting up the pump.
SE1 and SEV pumps must under no
circumstances pump combustible liquids.
The classification of the installation site
must be defined by the owner of the site in
each individual case.
Special conditions for safe use of
explosion-proof pumps:
1. Make sure the moisture switch and
thermal switches are connected in the
same circuit but have separate alarm
outputs (motor stop) in case of high
humidity or high temperature in the
motor.
2. Bolts used for replacement must be
class A2-70 or better according to
EN/ISO 3506-1.
3. Contact the manufacturer for
information on the dimensions of the
flameproof joints.
4. The level of pumped liquid must be
controlled by level switches connected
to the motor control circuit. The
minimum level depends on the
installation type and is specified in
these installation and operating
instructions.
5. Make sure the permanently attached
cable is suitably mechanically
protected and terminated in a suitable
terminal board placed outside the
potentially explosive area.
6. The pumps have an ambient
temperature range of -20 to +40 °C and
a maximum process temperature of
+40 °C. The minimum ambient
temperature for a pump with a
water-in-oil sensor is 0 °C.
7. The thermal protector in the stator
windings has a rated switch
temperature of 150 °C and must
guarantee the disconnection of the
power supply; the power supply must
be reset manually.
8. The control unit must protect the WIO
sensor against the short circuit current
of the supply to which it is connected.
The maximum current from the control
unit must be limited to 350 mA.
9. For painted pumps, minimise the risk of
electrostatic discharge in the following
ways:
– Earthing is mandatory.
– In dry installations, keep a safety
distance between pumps and
walking paths.
– Use wet cloths for cleaning.
10. The WIO sensor is intended for use
only with a galvanically isolated circuit.
11. The lock nut of the cable connector
must only be replaced with an identical
one.

English (GB)
9
Identification
Nameplate
Type key
1 Maximum frequency in case of
frequency-converter operation.
2 The generation code distinguishes between
pumps of different design, but with the same
power rating.
TM02 8398 2417
Pos. Description
1Notified body and explosion protection
classification
2 Explosion protection mark
3 Type designation
4 Product number and serial number
5 Maximum head [m]
6 Enclosure class to IEC 60529
7 Maximum installation depth [m]
8 Number of phases
9 Frequency [Hz]
10 Speed [min-1]
11 Motor input power P1 [kW]
12 Motor output power P2 [kW]
13 Country of production
14 Explosion protection certificate number
15 Standard for wastewater lifting stations for
buildings and installation sites
16 Maximum flow rate [m3/h]
17 Production code (year/week)
18 Maximum liquid temperature [°C]
19 Insulation class
20 Power factor
21 Rated current 1
22 Rated voltage 1
23 Rated current 2
24 Rated voltage 2
25 Weight without cable [kg]
12 1311 19 6
2
1
3
4
5
7
8
9
10
18
17
16
15
20
21
22
23
24
25
14
Tmax: °C
Type: P.c.
Hmax: Qmax:m
VA
A
mh
/
3
V
Model:
m Insul.class: &RVij
Motor: Hz
0197
~
n: min-1
kgWeight:IP68P1/P2：/ kW
Made in Tatabánya
Hungary DK-8850 Bjerringbro, Denmark
DOP 98948763 98807641
Code Explanation Designation
SE Grundfos sewage and
wastewater pumps Pump type
1 S-tube®impeller Impeller type
V SuperVortex impeller
80 Maximum solids size [mm] Pump
passage
80 Nominal diameter of pump
outlet port [mm] Pump outlet
40 Output power P2/10 Power [kW]
[ ] Standard (without sensor) Sensor
version
A Sensor version
[ ] Non-explosion-proof
pump (standard) Pump version
Ex Explosion-proof pump
2 2-pole Number of
poles
4 4-pole
50 50 Hz Frequency
[Hz] 1
0B 400-415 V, DOL
Voltage and
starting
method
0D 380-415 V, DOL
1D 380-415 V, Y/D
0E 220-240 V, DOL
1E 220-240 V, Y/D
[ ] First generation Generation (2
B Second generation
[ ] Cast iron impeller, pump
housing and top cover
Pump
materials
Q
Stainless steel impeller,
cast iron pump housing
and top cover
REntire pump of stainless
steel
S
Stainless steel pump
housing, impeller and
intermediate flange and
cast iron top cover (on
request)
D Stainless steel
Z Custom-built products Customisation

English (GB)
10
Installation types
SE1 and SEV pumps are designed for two
installation types:
• submerged installation:
– vertically on an auto coupling
– vertically, free-standing on a ring stand.
• dry installation:
– vertically on a base stand
– horizontally with brackets secured to a
concrete floor or foundation. For WIO-sensor
versions the outlet pipe must be directed
upwards to ensure proper operation of the
WIO sensor.
Protection and control functions
Level controllers
To prevent air intake, dry running and vibrations,
install the stop level switch in such a way that the
pump is stopped before the liquid level falls below
the upper edge of the clamp of the pump.
IO 113
Switches and sensors
Every explosion-proof pump is assembled with a
WIO sensor.
The sensor measures the water content from 0 to 20
%. It also sends a signal if the water content is
outside the normal range (warning), or if there is air
in the oil chamber (alarm).
Servicing the product
All the EX pumps are
equipped with a WIO
sensor.
In case of dry, horizontal
installation, the outlet
pipe must be directed
upwards to ensure the
proper operation of the
WIO sensor.
TM06 5988 0216
Max.
Min.
Float switches used in potentially
explosive environments must be approved
for this application. They must be
connected to the Grundfos LC, LCD 108
pump controller via the intrinsically safe
LC-Ex4 barrier to ensure a safe circuit.
Do not use IO 113 for
other purposes than
those mentioned in the
installation and
operating instructions for
IO 113.
The IO 113 module must be configured to
stop explosion-proof pumps in case the
WIO sensor sends an alarm signal.
The pump must not restart automatically.
The thermal protection of explosion-proof
pumps must not restart the pump
automatically. This ensures protection
against overtemperature in potentially
explosive environments. In pumps with
sensor this is done by removing the
short-circuit between terminals R1 and R2
in the IO 113.
Do not install the separate
motor-protective circuit breaker or control
box installed in potentially explosive
environments.
WARNING
Crushing hazard
Death or serious
personal injury
- Do not stand near or
under the pump when it
is lifted.

English (GB)
11
WARNING
Electric shock
Death or serious
personal injury
- Make sure the earth
and phase conductors
are not mixed up,
follow the description
in the wiring diagram.
- Make sure the earth
conductor is connected
first.
WARNING
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
fuses have been
removed or the main
switch has been
switched off and locked
in position 0. Make
sure that the power
supply cannot be
accidentally switched
on.
WARNING
Crushing of hands
Death or serious
personal injury
- Make sure that all
rotating parts have
stopped moving.
CAUTION
Sharp element
Minor or moderate
personal injury
- Wear protective gloves
to avoid being cut by
the sharp edges of the
impeller.
Inspect the oil level and condition every
3000 operating hours or at least once a
year.
When the pump is new or after
replacement of the shaft seal, check the oil
level and water content after one week of
operation.
Maintenance work on explosion-proof
pumps must be carried out by Grundfos or
a service workshop authorised by
Grundfos.
However, this does not apply to the
hydraulic components, such as pump
housing and impeller.
Observe all regulations applying to pumps
installed in potentially explosive
environments.
Make sure that no work is carried out in
potentially explosive environment.

English (GB)
12
Maintenance schedule
Checking and changing the oil
Explosion-proof pumps must be checked
by an authorised Ex workshop after 3000
working hours or at least once a year.
When the pump is new or after
replacement of the shaft seal, check the oil
level and water content after one week of
operation.
If the pump has not been in operation for
some time, vent it to let any explosive
gasses gathered in the pump escape.
The cable must be
replaced by Grundfos or
a service workshop
authorised by Grundfos.
Defective bearings may reduce the Ex
safety.
Pumps running normal operation must be
inspected every 3000 operating hours or at
least once a year. If the pumped liquid is
very muddy or sandy, inspect the pump at
shorter intervals.
Pumps with sensor offer the possibility of
constant monitoring of key components in
the pump, such as shaft seal condition,
bearing temperature, winding temperature,
insulation resistance and moisture in the
motor.
Check the shaft for noisy or heavy
operation (turn the shaft by hand). Replace
defective bearings.
Do not reuse used
rubber parts.
Use Shell Ondina X420
oil or similar type.
Inspect the oil level and condition every
3000 operating hours or at least once a
year.
When the pump is new or after
replacement of the shaft seal, check the oil
level and water content after one week of
operation.
WARNING
Pressurised system
Death or serious
personal injury
- As pressure may have
built up in the oil
chamber, loosen the
screws slowly, and do
not remove the screws
until the pressure has
been fully relieved.

English (GB)
13
Repairing the product
Contaminated pumps
Dispose of used oil in
accordance with local
regulations.
DANGER
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
fuses have been
removed or the main
switch has been
switched off and locked
in position 0. Make
sure that the power
supply cannot be
accidentally switched
on.
WARNING
Crushing hazard
Death or serious
personal injury
- Do not stand near or
under the pump when it
is lifted.
Inspect the oil level and condition every
3000 operating hours or at least once a
year.
When the pump is new or after
replacement of the shaft seal, check the oil
level and water content after one week of
operation.
CAUTION
Sharp element
Minor or moderate
personal injury
- Wear protective gloves
to avoid being cut by
the sharp edges of the
impeller.
WARNING
Infection caused by
wastewater
Minor or moderate
personal injury
- Wear appropriate
personal protective
equipment and
clothing.
- Observe the local
hygiene regulations in
force.
WARNING
Biological hazard
Death or serious
personal injury
- Flush the pump
thoroughly with clean
water and rinse the
pump parts in water
after dismantling.

English (GB)
14
Fault finding the product
Disposing of the product
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin symbol on
a product means that it must be
disposed of separately from household
waste. When a product marked with this
symbol reaches its end of life, take it to a
collection point designated by the local
waste disposal authorities. The separate collection
and recycling of such products will help protect the
environment and human health.
See also end-of-life information at
www.grundfos.com/product-recycling.
DANGER
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
fuses have been
removed or the main
switch has been
switched off and locked
in position 0. Make
sure that the power
supply cannot be
accidentally switched
on.

Declaration of conformity
15
Declaration of conformity 1
GB: EC/EU declaration of conformity
We, Grundfos, declare under our sole responsibility
that the product SE1 50, 80, 100, SEV 65, 80, 100,
to which the declaration below relates, is in
conformity with the Council Directives listed below
on the approximation of the laws of the EC/EU
member states.
BG:   
 /EO
,  Grundfos,  
,   SE1 50, 80, 100, SEV
65, 80, 100,     
,     
    
  -  /EO.
CZ: Prohlášení o shodEU
My firma Grundfos prohlašujeme na svou plnou
odpovdnost, že výrobek SE1 50, 80, 100, SEV 65,
80, 100, na který se toto prohlášení vztahuje, je v
souladu s níže uvedenými ustanoveními smrnice
Rady pro sblížení právních pedpislenských
státEvropského spoleenství.
DE: EG-/EU-Konformitätserklärung
Wir, Grundfos, erklären in alleiniger Verantwortung,
dass das Produkt SE1 50, 80, 100, SEV 65, 80,
100, auf das sich diese Erklärung bezieht, mit den
folgenden Richtlinien des Rates zur Angleichung
der Rechtsvorschriften der
EG-/EU-Mitgliedsstaaten übereinstimmt.
DK: EF/EU-
overensstemmelseserklæring
Vi, Grundfos, erklærer under ansvar at produktet
SE1 50, 80, 100, SEV 65, 80, 100 som erklæringen
nedenfor omhandler, er i overensstemmelse med
Rådets direktiver der er nævnt nedenfor, om
indbyrdes tilnærmelse til EF/EU-medlemsstaternes
lovgivning.
EE: EÜ/ELi vastavusdeklaratsioon
Meie, Grundfos, kinnitame ja kanname ainuisikulist
vastutust selle eest, et toode SE1 50, 80, 100, SEV
65, 80, 100, mille kohta all olev deklaratsioon käib,
on kooskõlas Nõukogu Direktiividega, mis on
nimetatud all pool vastavalt vastuvõetud
õigusaktidele ühtlustamise kohta EÜ / EL
liikmesriikides.
ES: Declaración de conformidad de
la CE/UE
Grundfos declara, bajo su exclusiva
responsabilidad, que el producto SE1 50, 80, 100,
SEV 65, 80, 100 al que hace referencia la siguiente
declaración cumple lo establecido por las
siguientes Directivas del Consejo sobre la
aproximación de las legislaciones de los Estados
miembros de la CE/UE.
FI: EY/EU-
vaatimustenmukaisuusvakuutus
Grundfos vakuuttaa omalla vastuullaan, että tuote
SE1 50, 80, 100, SEV 65, 80, 100, jota tämä
vakuutus koskee, on EY/EU:n jäsenvaltioiden
lainsäädännön lähentämiseen tähtäävien
Euroopan neuvoston direktiivien vaatimusten
mukainen seuraavasti.
FR: Déclaration de conformité CE/UE
Nous, Grundfos, déclarons sous notre seule
responsabilité, que le produit SE1 50, 80, 100, SEV
65, 80, 100, auquel se réfère cette déclaration, est
conforme aux Directives du Conseil concernant le
rapprochement des législations des États membres
CE/UE relatives aux normes énoncées ci-dessous.
GR:   /
, Grundfos,    
     SE1 50, 80, 100, SEV 65,
80, 100,    
,     
     
    /.
HR: EC/EU deklaracija sukladnosti
Mi, Grundfos, izjavljujemo s punom odgovornošu
da je proizvod SE1 50, 80, 100, SEV 65, 80, 100, na
koja se izjava odnosi u nastavku, u skladu s
direktivama Vijea dolje navedenih o usklaivanju
zakona država lanica EZ-a / EU-a.
HU: EC/EU megfelelségi nyilatkozat
Mi, a Grundfos vállalat, teljes felelsséggel
kijelentjük, hogy a(z) SE1 50, 80, 100, SEV 65, 80,
100 termék, amelyre az alábbi nyilatkozat
vonatkozik, megfelel az Európai Közösség/Európai
Unió tagállamainak jogi irányelveit összehangoló
tanács alábbi elírásainak.
IT: Dichiarazione di conformità
CE/UE
Grundfos dichiara sotto la sua esclusiva
responsabilità che il prodotto SE1 50, 80, 100, SEV
65, 80, 100, al quale si riferisce questa
dichiarazione, è conforme alle seguenti direttive del
Consiglio riguardanti il riavvicinamento delle
legislazioni degli Stati membri CE/UE.
LT: EB/ES atitikties deklaracija
Mes, Grundfos, su visa atsakomybe pareiškiame,
kad produktas SE1 50, 80, 100, SEV 65, 80, 100,
kuriam skirta ši deklaracija, atitinka žemiau
nurodytas Tarybos Direktyvas dl EB/ES šalinari
statymsuderinimo.

Declaration of conformity
16
LV: EK/ES atbilstbas deklarcija
Sabiedrba Grundfos ar pilnu atbildbu pazio, ka
produkts SE1 50, 80, 100, SEV 65, 80, 100, uz kuru
attiecas tlk redzamdeklarcija, atbilst tlk
nordtajm Padomes direktvm par EK/ES
dalbvalstu normatvo aktu tuvinšanu.
NL: EG/EU-conformiteitsverklaring
Wij, Grundfos, verklaren geheel onder eigen
verantwoordelijkheid dat product SE1 50, 80, 100,
SEV 65, 80, 100, waarop de onderstaande
verklaring betrekking heeft, in overeenstemming is
met de onderstaande Richtlijnen van de Raad
inzake de onderlinge aanpassing van de wetgeving
van de EG-/EU-lidstaten.
PL: Deklaracja zgodnoci WE/UE
My, Grundfos, owiadczamy z pen
odpowiedzialnoci, e nasz produkt SE1 50, 80,
100, SEV 65, 80, 100, którego deklaracja niniejsza
dotyczy, jest zgodny z nastpujcymi dyrektywami
Rady w sprawie zblienia przepisów prawnych
pastw czonkowskich.
PT: Declaração de conformidade
CE/UE
A Grundfos declara sob sua única responsabilidade
que o produto SE1 50, 80, 100, SEV 65, 80, 100, ao
qual diz respeito a declaração abaixo, está em
conformidade com as Directivas do Conselho sobre
a aproximação das legislações dos Estados
Membros da CE/UE.
RO: Declaraia de conformitate
CE/UE
Noi Grundfos declarm pe propria rspundere c
produsul SE1 50, 80, 100, SEV 65, 80, 100, la care
se referaceastdeclaraie, este în conformitate
cu Directivele de Consiliu specificate mai jos privind
armonizarea legilor statelor membre CE/UE.
RS: Deklaracija o usklaenosti
EC/EU
Mi, kompanija Grundfos, izjavljujemo pod punom
vlastitom odgovornošu da je proizvod SE1 50, 80,
100, SEV 65, 80, 100, na koji se odnosi deklaracija
ispod, u skladu sa dole prikazanim direktivama
Saveta za usklaivanje zakona država lanica
EC/EU.
SE: EG/EU-försäkran om
överensstämmelse
Vi, Grundfos, försäkrar under ansvar att produkten
, som omfattas av nedanstående försäkran, är i
överensstämmelse med de rådsdirektiv om
inbördes närmande till EG/EU-medlemsstaternas
lagstiftning som listas nedan.
SI: Izjava o skladnosti ES/EU
V Grundfosu s polno odgovornostjo izjavljamo, da
je izdelek SE1 50, 80, 100, SEV 65, 80, 100, na
katerega se spodnja izjava nanaša, v skladu s
spodnjimi direktivami Sveta o približevanju
zakonodaje za izenaevanje pravnih predpisov
držav lanic ES/EU.
SK: ES vyhlásenie o zhode
My, spolonosGrundfos, vyhlasujeme na svoju
plnú zodpovednos, že produkt SE1 50, 80, 100,
SEV 65, 80, 100, na ktorý sa vyhlásenie uvedené
nižšie vzahuje, je v súlade s ustanoveniami nižšie
uvedených smerníc Rady pre zblíženie právnych
predpisov lenských štátov Európskeho
spoloenstva/EÚ.
TR: EC/AB uygunluk bildirgesi
Grundfos olarak, aaıdaki bildirim konusu olan
SE1 50, 80, 100, SEV 65, 80, 100 ürünlerinin,
EC/AB üye ülkelerinin direktiflerinin
yakınlatırılmasıyla ilgili durumun aaıdaki
Konsey Direktifleriyle uyumlu olduunu ve bununla
ilgili olarak tüm sorumluluun bize ait olduunu
beyan ederiz.
UA:  
 EC/EU
,  Grundfos,   
 ,   SE1 50,
80, 100, SEV 65, 80, 100,   
 , 
 EC/EU,  , 
  - .
CN: 欧盟符合性声明
我们，格兰富，在我们的全权责任下声明，产品
SE1 50, 80, 100, SEV 65, 80, 100 系列，其制造和性
能完全符合以下所列欧盟委员会指令。
KZ:   EK/

, Grundfos, EK/   
   
  
  SE1 50, 80, 100, SEV 65,
80, 100,    
 .
AR    :
(EC/EU)
     
 SE1 50, 80, 100, SEV 65, 80, 100 
       
       
 .(EC/EU)

Declaration of conformity
17
VI: Tuyên btuân thEC/EU
Chúng tôi, Grundfos, tuyên btrong phm vi trách
nhim duy nht ca mình rng sn phm SE1 50,
80, 100, SEV 65, 80, 100 mà tuyên bdi ây có
liên quan tuân thcác ChthHi ng sau vvic
áp dng lut pháp ca các nc thành viên EC/EU.
– Machinery Directive (2006/42/EC)
Standards used:
EN 809: 1998 + A1:2009
– Low Voltage Directive (2014/35/EU)
Standards used:
EN 60335-1:2012 + A11:2014
EN 60335-2-41:2003, +A1:2004, A2:2010
– EMC Directive (2014/30/EU)
Standards used:
EN 61326-1:2013
– RoHS Directives (2011/65/EU and 2015/863/EU)
Standard used:
EN 50581:2012
– ATEX Directive (2014/34/EU)
Applies only to products intended for use
potentially explosive environments, Ex II 2GD,
equipped with the separate ATEX approval plate
and EC-type examination certificate. Further
information, see below.
This EC/EU declaration of conformity is only valid
when published as part of the Grundfos safety
instructions (publication number 98948763).
Székesfehérvár, 30 August 2018
Róbert Kis
Senior Manager
GRUNDFOS Holding A/S
Poul Due Jensens Vej 7
8850 Bjerringbro, Denmark
Person authorised to compile the technical file and
empowered to sign the EC/EU declaration of
conformity.
Certificate No. Standards used
KEMA 04ATEX2201X EN 60079-0:2012 + A11:2013, EN 60079-1:2014,
EN 60079-31:2014, EN 60079-18:2015 + A1:2017,
EN ISO 80079-36:2016, EN ISO 80079-37:2016
Notified body: DEKRA Certification B.V. Meander 1051, 6825 MJ Arnhem, The Netherlands
Manufacturer: Grundfos Holding A/S, Poul Due Jensens Vej 7, 8850 Bjerringbro, Denmark

   
18
    2
RUS
SE1, SEV 1,1 – 11 кВт
Руководство по эксплуатации
Руководство по эксплуатации на данное изделие является составным и включает в себя несколько частей:
Часть 1: настоящее «Руководство по эксплуатации».
Часть 2: электронная часть «Паспорт. Руководство по монтажу и эксплуатации» размещенная на сайте
компании Грундфос. Перейдите по ссылке, указанной в конце документа.
Часть 3: информация о сроке изготовления, размещенная на фирменной табличке изделия.
Сведения о сертификации:
Насосы типа SE1, SEV 1,1 – 11 кВт сертифицированы на соответствие требованиям Технических регламентов
Таможенного союза: ТР ТС 004/2011 «О безопасности низковольтного оборудования»; ТР ТС 010/2011 «О
безопасности машин и оборудования»; ТР ТС 020/2011 «Электромагнитная совместимость технических
средств».
KAZ
SE1, SEV 1,1 – 11 кВт
Пайдалану бойынша нұсқаулық
Атаулы өнімге арналған пайдалану бойынша нұсқаулық құрамалы болып келеді және келесі бөлімдерден
тұрады:
1 бөлім: атаулы «Пайдалану бойынша нұсқаулық»
2 бөлім: Грундфос компаниясының сайтында орналасқан электронды бөлім «Төлқұжат, Құрастыру жəне
пайдалану бойынша нұсқаулық». Құжат соңында көрсетілген сілтеме арқылы өтіңіз.
3 бөлім: өнімнің фирмалық тақташасында орналасқан шығарылған уақыты жөніндегі мәлімет
Сертификаттау туралы ақпарат:
SE1, SEV 1,1 – 11 кВт типті сорғылары «Төмен вольтты жабдықтардың қауіпсіздігі туралы» (ТР ТС 004/2011),
«Машиналар және жабдықтар қауіпсіздігі туралы» (ТР ТС 010/2011) «Техникалық заттардың электрлі магниттік
сәйкестілігі» (ТР ТС 020/2011) Кеден Одағының техникалық регламенттерінің талаптарына сәйкес
сертификатталды.
KG
SE1, SEV 1,1 – 11 токтун
Пайдалануу боюнча колдонмо
Аталган жабдууну пайдалануу боюнча колдонмо курамдык жана өзүнө бир нече бөлүкчөнү камтыйт:
1-Бөлүк: «Пайдалануу боюнча колдонмо»
2-Бөлүк: «Паспорт. Пайдалануу жана монтаж боюнча колдонмо» электрондук бөлүгү Грундфос компаниянын
сайтында жайгашкан. Документтин аягында көрсөтүлгөн шилтемеге кайрылыңыз.
3-Бөлүк: жабдуунун фирмалык тактасында жайгашкан даярдоо мөөнөтү тууралуу маалымат.
Шайкештик жөнүндө декларация
SE1, SEV 1,1 – 11 токтун түрүндөгү соргучтар Бажы Биримдиктин Техникалык регламенттин талаптарына
ылайыктуу тастыкталган: ТР ТБ 004/2011 «Төмөн вольттук жабдуунун коопсуздугу жөнүндө»; ТР ТБ 010/2011
«Жабдуу жана машиналардын коопсуздугу жөнүндө»; ТР ТБ 020/2011 «Техникалык каражаттардын
электрмагниттик шайкештиги».

   
19
ARM
SE1, SEV 1,1 – 11 կկՎտ
Շահագործման ձեռնարկ
Տվյալ սարքավորման շահագործման ձեռնարկը բաղկացած է մի քանի մասերից.
Մաս 1. սույն «Շահագործման ձեռնարկ»:
Մաս 2. էլեկտրոնային մաս. այն է՝ «Անձնագիր: Մոնտաժման և
շահագործման ձեռնարկ» տեղադրված «Գրունդֆոս». Անցեք փաստաթղթի վերջում նշված հղումով.
Մաս 3. տեղեկություն արտադրման ամսաթվի վերաբերյալ՝ նշված սարքավորման պիտակի վրա:
Տեղեկություններ հավաստագրման մասին՝
SE1, SEV 1,1 – 11 կՎտ տիպի պոմպերը սերտիֆիկացված են համաձայն Մաքսային Միության
տեխնիկական կանոնակարգի պահանջների՝ ТР ТС 004/2011 «Ցածրավոլտ սարքավորումների
վերաբերյալ», ТР ТС 010/2011«Մեքենաների և սարքավորումների անվտանգության վերաբերյալ» ; ТР ТС
020/2011 «Տեխնիկական միջոցների էլեկտրամագնիսական համատեղելիության վերաբերյալ»:
http://net.grundfos.com/qr/i/98947336
10000096682
0617
ECM: 1211677

Declaration of performance
20
Declaration of performance 3
GB:
EU declaration of performance in accordance
with Annex III of Regulation (EU) No 305/2011
(Construction Product Regulation)
1. Unique identification code of the product type:
– EN 12050-1 or EN 12050-2 (SE1.50).
2. Type, batch or serial number or any other element allowing
identification of the construction product as required pursuant to
Article 11(4):
– SE1, SEV pumps marked with EN 12050-1 or EN 12050-2
(SE1.50) on the nameplate.
3. Intended use or uses of the construction product, in accordance
with the applicable harmonised technical specification, as
foreseen by the manufacturer:
– Pumps for pumping of wastewater containing faecal matter
marked with EN 12050-1 on the nameplate.
– SE1.50 pumps for pumping of faecal-free wastewater marked
with EN 12050-2 on the nameplate.
4. Name, registered trade name or registered trade mark and
contact address of the manufacturer as required pursuant to
Article 11(5):
– Grundfos Holding A/S
Poul Due Jensens Vej 7
8850 Bjerringbro
Denmark.
5. NOT RELEVANT.
6. System or systems of assessment and verification of constancy
of performance of the construction product as set out in Annex V:
– System 3.
7. In case of the declaration of performance concerning a
construction product covered by a harmonised standard:
– TÜV Rheinland LGA Products GmbH, identification number:
0197.
Performed test according to EN 12050-1 or EN 12050-2
(SE1.50) under system 3.
(description of the third party tasks as set out in Annex V)
– Certificate number: LGA-Certificate No 7381115. Type-tested
and monitored.
8. NOT RELEVANT.
9. Declared performance:
The products covered by this declaration of performance are in
compliance with the essential characteristics and the
performance requirements as described in the following:
– Standards used: EN 12050-1:2001 or EN 12050-2:2000
(SE1.50).
10. The performance of the product identified in points 1 and 2 is in
conformity with the declared performance in point 9.
BG:
  C   
 III   () 305/2011
(   )
1.      :
– EN 12050-1  EN 12050-2 (SE1.50).
2. ,        ,
    ,
   11(4):
– SE1, SEV,  EN 12050-1  EN 12050-2
(SE1.50)   .
3.       
,   
 ,   
:
–     , 
 ,  EN 12050-1   
.
– SE1.50       
,  EN 12050-2   .
4. ,        
    ,   
  11(5):
– Grundfos Holding A/S
Poul Due Jensens Vej 7
8850 Bjerringbro
.
5.     .
6.        
    ,   
 V:
– 3.
7.     ,   
 ,     
:
– TÜV Rheinland LGA Products GmbH, 
: 0197.
   EN 12050-1  EN 12050-
2 (SE1.50)   3.
(     ,   
 V)
–  : LGA  7381115.
   .
8.     .
9.  :
,      ,  
    
,  -:
– : EN 12050-1:2001  EN 12050-
2:2000.
10.   ,   1 2, 
    9.
