Grundig DRP5100 User manual

4 BAND DYNAMO RADIO
WITH LEATHER HANDLE
Grundig Helpline: 1800 509 394 Australia
Grundig Helpline: 0800 450 259 New Zealand
DRP5100
ENGLISH

2
MW
OWNER’S MANUAL
Please read before using the equipment.
Your MW/FM/SW1/SW2 Radio is ideal for aviation enthusiasts – you can tune
to the MW or FM or SW radio band. Its portable design with a fixed handle
strap lets which you enjoy news, sports, talk shows and weather reports
almost any where.
POWER SOURCES
You can power your radio with:
•Three AA batteries (not supplied), External
AC/DC adapter or Dynamo power.
Using Batteries
Install three new AA batteries into the compartment
as indicated by the polarity symbols (+ and -) inside
the compartment. For easy replacement, always
install the batteries over the tab in the battery compartment.
Cautions:
•Use only new batteries of the required size and type. Never mix new and
old batteries, or different battery types (Alkaline batteries with other types).
•To protect the radio from battery leakage, never leave dead, weak or old
batteries in the radio. If you do not plan to use the radio for a month or
3.6V
RECHARGEABLE
BATTERY

3
more, remove the batteries. Batteries can leak chemicals that can destroy
electronics parts.
•Always dispose of old batteries promptly and properly.
Note: When the radio does not operate properly or the sound weakens or
distorts, replace the batteries.
Important: This radio can use Ni-MH rechargeable batteries. At the end of a
nickel-metal hydride battery’s useful life, it must be recycled or disposed of
property. Contact your local hazardous waste management authorities for
information on recycling or disposal programs in your area.
Using an AC adaptor
You can power your radio with a 6V AC adaptor (not supplied).
Insert the barrel plug into your radio’s DC 6V jack.
Plug the other end of the adaptor into a standard AC outlet.
Note: your must use a Class 2 power source that supplies 6V DC and delivers
at least 300mA. Its center tip must be set to positive and its plug must fit your
radio’s 6V jack. Using an adaptor that does not meet these specifications
could damage your radio or adaptor.
Using a DC adaptor
1. Insert one end of the DC adaptor into the DC jack.
2. Plug the other end into the cigarette lighter in your vehicle.
Using Dynamo Power
The radio has a internal rechargeable battery pack that can be recharged by
the dynamo-crank.
1. Switch BATTERY/DYNAMO to DYNAMO position.
2. Lift the crank and rotate it either clockwise or counter-
clockwise to charge the radio. The charging LED light will be
lit when in charge.
3. Return the crank to the folded position.
Note:
•Radio operation time depends on the number of the turns and
time per turn. For example, approximately 2 turns per second for 90

4
seconds will provide about 40-60 minutes of radio operation.
•If turning the crank at about 2 turns per second for about 90 seconds does
not power the radio for at least 15 minutes, replace the rechargeable
battery pack.
Replacing the Rechargeable Battery Pack and bulb
Replacing the rechargeable battery pack (Ni-MH, 3.6V,
600 mAh or equivalent).
1. Remove the battery pack. Then, unplug the battery
pack connecter.
2. Insert the new battery pack plug into the connector;
then, place the battery into the slot.
If the bulb of the light burns out, replace with a new E-5 base, 2.4V 360mA
bulb (not supplied) as follows:
1. Remove the lens cap and reflector and unscrew the bulb gently.
2. Screw a new bulb (not supplied). Align the reflector with the lens cap
groove and replace the lens cap.
Charging your mobile phone
Connect your mobile phone to the USB female jack on the back of your radio,
using the USB cable (supplied) with one of four tips for Samsung, Siemens,
Sony Ericsson or Nokia mobile phones with max. charging voltage and
current 5.7V/500mA.
CONNECTING TO THE EARPHONE
For private listening, insert the 1/8-inch (3.5 mm) plug into the stereo
earphone jack (mono ouput) on the bottom of the radio.
Note: Connecting the earphone automatically disconnects the built-in speaker.
Safe Listening
To protect your hearing, follow these guidelines when you use the earphone.
•Do not listen at extremely high volume levels. High-volume listening can
3.6V
RECHARGEABLE
BATTERY
3.6 V
RECHARGEABLE
BATTERY

5
lead to permanent hearing loss.
•Set the volume to the lowest setting before you begin listening. After you
begin listening, adjust the volume to a comfortable level.
•Once you set the volume, do not increase it. Over time, your ears adapt to
the volume level, so a volume level that does not cause discomfort might
still damage your hearing.
Traffic Safety
Do not wear earphone while operating a motor vehicle or riding a bicycle. This
can create a traffic hazard and is illegal in some areas.
Even though some earphones are designed to let you hear some outside
sounds when listening at normal volume levels, they still present a traffic
hazard.
OPERATION
The portable radio lets you listen to MW, FM and SW band radio broadcasts.
Playing the Radio
1. Switch BATTERY/DYNAMO to BATTERY or DYNAMO.
Or, you can use the AC/DC adaptor (not supplied).
2. Rotate the VOLUME until it clicks to turn on the radio and adjust to the
desired listening level.
3. Set the FM/MW/SW1/SW2 switch.
4. Turn the TUNING knob to select the desired station.
5. To turn off, turn VOLUME the opposite direction to turn off the radio.
•For best FM/SW reception, fully extend the telescopic antenna.
•The radio has a built-in MW antenna. For the best reception, rotate your
radio.
•Rotate SW FINE TUNING for better SW tuning.
•For best reception, do not charge your mobile phone while listening to
radio.
To use the light, switch OFF/ON/LIGHT to ON to turn on the light.

6
MAINTENANCE
Your MW / FM / SW1-2 Radio is an example of superior design and
craftsmanship. The following suggestions will help you care for the radio so
you can enjoy it for years.
•Keep the radio dry. If it gets wet, wipe it dry immediately. Liquids might
contain minerals that can corrode the electronic circuits.
•Use and store the radio only in normal temperature environment.
Temperature extremes can shorten the life of electronic devices, damage
batteries, and distort or melt plastic parts.
•Handle the radio gently and carefully. Dropping it can damage the circuit
boards and can cause the radio to work improperly.
•Keep the radio away from dust and dirt, which can cause premature wear
of parts.
•Wipe the radio with a damp cloth occasionally to keep it look new. Do not
use harsh chemicals, cleaning solvents, or strong detergents to clean the
radio.
Modifying or tampering with the radio’s internal components can cause a
malfunction and will void the warranty.
SPECIFICATIONS
Frequency Range
MW……………………………………..………………….…….… 530-1620 kHz
FM…………………………………………………………….….…… 88-108 MHz
SW1………………………………………………………………..….. 3.2-7.6 MHz
SW2……………………….……………………………………..… 9.2-22.0 MHz
Power Output (at 10% THD)… ………………………………………..100 mW
Power Requirement……………………………….…… DC 4.5V (3 AA batteries)
Dimensions (HWD)………………………………….……...…… 115x78x25mm
Weight (without batteries)………………………………………………… 600 g
Antenna………………………………………………... FM: Telescoping Antenna
MW: Built-In Antenna
Speaker………………………………..………………………..3 inches (76 mm)
8 Ohm Impedance
Specifications are typical; individual units might vary. Specifications are

7
subject to change and improvement without notice.
INFORMATION
Environmental note
This product has been made from high-quality parts and materials which can
be re-used and recycled.
Therefore, do not throw the product away with normal household
waste at the end of its life. Take it to a collection point for
recycling electrical and electronic devices. This is indicated by
this symbol on the product, in the operating manual and on the
packing.
Please find out about collection points operated by your local authority.
Help protect the environment by recycling used products.

8
GUARANTEE
Please keep your receipt as proof of purchase. This product is warranted for
any defect in materials or workmanship for one year after the original date of
purchase. This product is for normal domestic and office use only. This
warranty does not cover damage from misuse or neglect, accidental damage,
vermin infestation, excessive voltages such us lightning or power surges or
any alteration that affects the performance or reliability of the product.
If guarantee is required please contact the Grundig Helpline 1800 509 394
within Australia or the 0800 450 259 within New Zealand.
Have your receipt of purchase on hand.
This guarantee is subject to the following provisions:
•It is only valid within boundaries of the country of purchase;
•The product must be correctly assembled and operated in accordance
with the instructions contained in this manual;
•This product must be used solely for domestic purposes;
•The guarantee does not cover accidental damage;
•The guarantee will be rendered invalid if the product is resold or has been
damaged by inexpert repair;
•The manufacturer disclaims any liability for incidental or consequential
damaged.
This guarantee is in addition to, and does not diminish, your statutory or
legal rights.
