Grundig MUSIC 85 DAB+ User manual

PORTABLE RADIO
MUSIC 85 DAB+
NL
DE
PL
EN
DA
FR
SV
IT
TR
ES
FI
RU

GRUNDIG Kundenberatungszentrum
Haben Sie Fragen?
Unser Kundenberatungszentrum steht
Ihnen werktags stets von 8.00 – 18.00
Uhr zur Verfügung.
Montag bis Freitag von 8.00 bis 18.00 Uhr
Deutschland: 0180 / 523 18 80 *
Österreich: 0820 / 220 33 22 **
* gebührenpflichtig (0,14 €/Min. aus dem Festnetz,
Mobilfunk: max. 0,42 €/Min.)
** gebührenpflichtig (0,145 €/Min. aus dem Festnetz,
Mobilfunk: max. 0,20 €/Min.)

3
TUNING
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
! "
0
+ VOLUME -
SNOOZE ON/OFF
SLEEP
ANTENNA
AC 230V ~
A
OPEN
USB
1/6 5/10
MODE/AL+5 MENU INFO SEL/ATS

4
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
DEUTSCH
6 SICHERHEIT UND INFORMATIONEN
7 AUF EINEN BLICK
8 STROMVERSORGUNG
9 EINSTELLUNGEN
12 BETRIEB
13 TIMER-BETRIEB
15 SONDERFUNKTIONEN
ENGLISH
16 SAFETY AND INFORMATION
17 OVERVIEW
18 POWER SUPPLY
19 SETTINGS
22 OPERATION
23 TIMER MODE
25 SPECIAL FUNCTIONS
FRANCAIS
26 INFORMATIONS RELATIVES A LA
SECURITE
27 APERCU
28 ALIMENTATION ELECTRIQUE
29 RÉGLAGES
32 FONCTION RADIO
33 MODE MINUTERIE
35 FONCTIONS SPÉCIALES
ITALIANO
37 SICUREZZA E INFORMAZIONI
38 PANORAMICA
39 ALIMENTAZIONE
40 IMPOSTAZIONI
43 FUNZIONAMENTO RADIO
44 MODALITÀ TIMER
46 FUNZIONI SPECIALI
РУССКИЙ
48 ИНФОРМАЦИЯ ПО ТЕХНИКЕ
БЕЗОПАСНОСТИ
49 ОБЗОРW
50 ЭЛЕКТРОПИТАНИЕ
51 НАСТРОЙКИ
54 РАБОТА РАДИОПРИЕМНИКА
55 РЕЖИМ ТАЙМЕРА
57 СПЕЦИАЛЬНЫЕ ФУНКЦИИ
ESPAÑOL
59 SEGURIDAD E INFORMACIÓN
60 VISIÓN GENERAL
61 ALIMENTACIÓN
62 CONFIGURACIÓN
65 FUNCIONAMIENTO DE LA RADIO
66 MODO TEMPORIZADOR
68 FUNCIONES ESPECIALES
NEDERLANDS
70 VEILIGHEID EN INFORMATIE
71 OVERZICHT
72 STROOMTOEVOER
73 INSTELLINGEN
76 RADIOWERKING
77 TIMERMODUS
78 SPECIALE FUNCTIES
POLSKI
80 BEZPIECZEŃSTWO I INFORMACJE
81 PRZEGLĄD
82 ZASILANIE ELEKTRYCZNE
83 USTAWIENIA
86 OBSŁUGA RADIA
87 TRYB TIMER (PROGRAMATOR CZA-
SOWY)
89 FUNKCJE SPECJALNE

5
DANSK
91 SIKKERHED OG INFORMATION
92 OVERSIGT
93 STRØMFORSYNING
94 INDSTILLINGER
97 RADIOFUNKTION
98 TIMERFUNKTION
100 SPECIALFUNKTIONER
SVENSKA
101 SÄKERHET OCH INFORMATION
102 ÖVERSIKT
103 STRÖMFÖRSÖRJNING
104 INSTÄLLNINGAR
107 RADIOANVÄNDNING
108 TIMERLÄGE
110 SPECIALFUNKTIONER
SUOMI
111 TURVALLISUUS JA TIEDOT
112 YLEISKATSAUS
113 VIRTALÄHDE
114 ASETUKSET
117 RADIOTOIMINTA
118 AJASTINTILA
120 ERIKOISTOIMINNOT
TÜRKÇE
121 GÜVENLİK VE BİLGİLER
123 GENEL BAKIŞ
124 GÜÇ KAYNAĞI
125 AYARLAR
128 RADYONUN ÇALIŞMASI
129 ZAMANLAYICI MODU
131 ÖZEL FONKSİYONLAR
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

ENGLISH
16
SAFETY AND INFORMATION ----------------------------------------------------------------
7
This device is designed for the playback of au-
dio signals.
Any other use is expressly prohibited.
7
Make sure the device is protected from drip-
ping or splashing water.
7
Do not place any vessels such as vases on the
device. These may be knocked over and spill
fluid on the electrical components, thus present-
ing a safety risk.
7
Do not place any naked flames such as candles
on the device.
7
Only use the device in a moderate climate.
7
Ensure that the device is adequately ventilated
by placing it at least 10 cm from any other ob-
ject. Do not cover the device with newspapers,
table cloths, curtains, etc.
7
If malfunctions occur due to static electricity
charges or fast transient (burst), reset the de-
vice. To do this, pull out the power plug and
connect it again after a few seconds.
7
When deciding where to place the device,
please note that furniture surfaces are covered
by various types of varnish and plastic, most of
which contain chemical additives. These addi-
tives can corrode the device supports, leaving
residues on the furniture surfaces which can be
difficult or impossible to remove.
7
Do not use any cleaning agent, as this may
damage the casing. Clean the device with a
clean, dry cloth.
7
Never open the device casing. The manufac-
turer will not accept any liability for damage
resulting from improper handling.
7
Make sure the power plug is freely accessible.
7
Note, prolonged listening at loud
volumes with the earphones can
damage your hearing.
Technical data
This device is noise-suppressed
according to the applicable EU
directives. This product fulfils the
European directives 2004/108/
EC, 2006/95/EC and 2009/125/EC.
The type plate is located on the bottom of the
device.
Power supply: 230 V~, 50/60 Hz
Max. power consumtion:
Operating < 6 W, Stand-by < 1 W
Output:
DIN 45324, 10% THD 1 W
Frequency band:
DAB/DAB+ 174.928 ... 239.200 MHz
FM 87.5 ... 108.0 MHz
Dimension and weight:
B x H x T 293 x 160 x 95 mm
Weight approx. 1.1 kg
Technical and design modifications reserved.
Environmental note
This product has been manufac-
tured with high quality parts and
materials which can be reused
and are suitable for recycling.
Therefore, do not dispose the
product with normal domestic waste at the end of
its service life. Take it to a collection point for the
recycling of electrical and electronic equipment.
This is indicated by this symbol on the product,
in the operating manual and on the packaging.
Please consult your local authorities to learn the
nearest collection point.
Help protect the environment by recycling used
products.

17
ENGLISH
OVERVIEW
---------------------------------------------------------------------------------------------------------------------------------
See the figure on page 3.
Controls on the top
SLEEP Sets the sleep timer.
SNOOZE Interrupts the alarm function.
ON/OFF Switches the device on and
off.
1/6 ... 5/10 Preset buttons for storing
and selecting radio stations.
+5 Activates the second level of
preset buttons 6 to 10.
MODE/AL In DAB/FM mode: switches
between DAB and FM input
sources.
In standby mode: activates
the alarm function;
ends alarm stand-by.
MENU Opens the menu.
INFO Displays DAB station infor-
mation and RDS station in-
formation.
SEL/ATS In the menus: confirms set-
tings.
In DAB/FM mode: press
and hold down, starts the
auto tuning for DAB/FM ra-
dio stations.
ANTENNA Telescopic antenna.
Controls on the sides and on the back
A Handle.
– VOLUME + Adjusts the volume.
" ! Adjusts the tone.
0 Earphone socket (3.5 mm
stereo plug).
Mono playback via ear-
phones.
Caution:
Excessive sound pressure
from the earphones can
cause hearing loss.
AC 230V ~ Connection socket for power
cable supplied.
OPEN Battery compartment cover.
USB USB socket for upgrading
the software of the device (in
the battery compartment).
TUNING In DAB mode: selects DAB
radio stations from the pro-
gram list.
In FM mode: tunes FM radio
stations.
Selects menu options.

ENGLISH
18
Mains operation
Check that the mains voltage on the type plate
(on the bottom of the device) corresponds to your
local mains supply. If this is not the case, contact
your specialist dealer.
1 Plug the mains cable supplied into the »AC ~«
socket on the device.
2 Plug the mains cable into the socket (230V~,
50/60 Hz).
Note:
7
If there are batteries in the device, these are
switched off automatically during mains op-
eration.
Caution:
7
The device is connected to the mains with
the power cable. Pull out the power cable
when you want to completely disconnect the
device from the mains.
7
Unplug the mains plug to disconnect the de-
vice from the mains. Make sure the power
plug is easily accessible during operation
and not hindered by other objects.
POWER SUPPLY
---------------------------------------------------------------------------------------------------------------
Battery operation
You can also operate the device using standard
batteries (not supplied). In this case, you must dis-
connect the mains power cable.
Time indication and alarm time function are not
available in battery operation.
1 Open the battery compartment by pressing the
marked area and pushing sidewards the cover.
2 Insert four batteries (4 x 1,5V, Typ IEC, AM 1,
LR 20, D-Size) according to the polarity
marked on the battery compartment.
3 Close the battery compartment.
Notes:
7
»Ä« flash in the display, if the batteries
are weak.
7
Do not expose the batteries to extreme heat,
caused for example by direct sunlight, heat-
ers or fire.
7
Remove the batteries when they are flat or
when you know that the device will not be
used for a long period of time. When the bat-
teries are low, a battery symbol appears and
flashes in the display. This function does not
work when the power cable is plugged into
the device.
7
No liability is accepted for damage resulting
from leaking batteries.
Environmental note:
7
Batteries, including those which contain no
heavy metal, must not be disposed of with
household waste. Please dispose of used
batteries in an environmentally sound man-
ner. Observe the legal regulations which ap-
ply in your area.

19
ENGLISH
Tuning and storing radio stations
(DAB and FM) – first installation
When the device is switched on for the first time
or after factory reset, the Auto Tuning System will
start to scan the whole DAB bandwidth and store
in the program list.
The device will then scan the FM waveband and
store the first 10 radio stations as presets 1 to 10.
The time is updated automatically.
1 Press »ON/OFF« to switch on the device.
– Display: »WELCOME« and then »SCAN«.
– The automatic station search starts, searches
and stores the radio stations.
– »FULL« displays that 10 FM radio stations
are stored at the presets.
– After the automatic scan, the device switches
to standby, the current time lights up.
Tuning and storing DAB and FM
radio stations – after a removal
You can activate the Auto Tuning System again.
That is reasonable, if you will use the device in
another place or search new DAB radio stations.
1 Press »ON/OFF« to switch on the device.
– Display: the name of the radio station, e.g.
»B5 AKT«.
2 Start the automatic station search by pressing
and holding down »SEL/ATS«.
– Display: »SCAN«.
– The automatic station search starts, searches
and stores the radio stations.
– After the automatic scan, the device switches
to standby, the current time lights up.
Note:
7
You can also activate the automatic scan
from the menu.
Open the menu with »MENU« and press
»SEL/ATS« to confirm.
Select the option »SYSTEM« with »TUN-
ING« and confirm by pressing »SEL/ATS«.
Select the option »ATS« with »TUNING«
and confirm by pressing »SEL/ATS« (dis-
play: »N«).
Select »Y« with »TUNING« and start the
automatic station search by pressing »SEL/
ATS«.
SETTINGS
---------------------------------------------------------------------------------------------------------------------------------------
Storing DAB radio stations to
presets
After the automatic station search, all radio sta-
tions will be stored in the program list. You can
store your favored DAB radio stations on presets
1 to 10.
1 Select DAB radio stations with »TUNING«.
– Display: the name of the radio station, the
radio station will be activated in 1 second.
2 For storing the DAB radio station on a preset,
press and hold down the required preset but-
ton »1/6« to »5/10«, until »STORED« appears.
Note:
7
Press »+5« and the required preset button
»1/6« to »5/10« for presets 6 to 10.
Programming DAB radio stations
– manually
1 Select the input source DAB with »MODE/
AL«.
– Display: »DAB«.
2 Open the menu with »MENU«.
– Display: »MANUAL«.
3 Press »SEL/ATS«.
– Display: e.g. »I74.9 SA« (frequency and
channel of a DAB radio station).
4 Select the desired frequency/channel with
»TUNING«.
5 Press »SEL/ATS« to confirm the frequency/
channel.
– Display: the signal strength.
6 Press »SEL/ATS« to confirm the setting.
– The DAB radio stations will be stored in the
program list.

ENGLISH
20
SETTINGS
---------------------------------------------------------------------------------------------------------------------------------------
Programming FM radio stations –
manually
1 Select the input source FM with »MODE/AL«.
2 Press and hold down »SEL/ATS« to start the
automatic station search.
– The automatic station search starts, and stops
at the next station with a strong signal;
or
turn »TUNING« until you have found the
frequency you want.
– The frequency changes in steps of 50 kHz.
3 To store the FM radio station on a preset, press
and hold down the required preset button
»1/6« to »5/10«, until »STORED« appears.
Press »+5« and the required preset button
»1/6« to »5/10« for presets 6 to 10.
Note:
7
The device normally scans for FM radio
stations which are strong enough to get
good reception. To scan radio stations with
weak signal:
Open the menu »SCAN« with »MENU« and
confirm with »SEL/ATS«.
Select the option »DX« with »TUNING«
and confirm by pressing »SEL/ATS«.
7
Switch back to normal sensitivity by repeat-
ing the setting and choosing the option
»LOCAL«.
Setting the clock format
(12 or 24 hours)
1 Press »ON/OFF« to switch on the device.
– Display: e.g. »B5 AKT«.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »TIME« with »TUNING« and
confirm by pressing »SEL/ATS«.
– Display: »12/24 HR«.
5 Press »SEL/ATS« again and select the desired
clock format (12 or 24 hours) by pressing
»TUNING«.
6 Press »SEL/ATS« to confirm the setting.
7 Press »MENU« to end the setting.
Updating the time – automatically
The device will normally update the time automat-
ically, when a time signal is received. You can
select from which source (DAB or FM) the update
starts or you can disable this function.
1 Press »ON/OFF« to switch on the device.
– Display: e.g. »B5 AKT«.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »TIME« with »TUNING« and
confirm by pressing »SEL/ATS«.
– Display: »12/24 HR«.
5 Select the option »UPDATE« with »TUNING«
and confirm by pressing »SEL/ATS«.
– Display: »ANY«.
6 Select the desired option (Any, DAB or FM)
with »TUNING«; or select the option »NONE«,
if you want to disable the update.
7 Press »SEL/ATS« to confirm the setting.
8 Press »MENU« to end the setting.

21
ENGLISH
SETTINGS
---------------------------------------------------------------------------------------------------------------------------------------
Updating the time – manually
1 Press »ON/OFF« to switch on the device.
– Display: e.g. »B5 AKT«.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »TIME« with »TUNING« and
confirm by pressing »SEL/ATS«.
– Display: »12/24 HR«.
5 Select the option »SET TIME« with »TUNING«
and confirm by pressing »SEL/ATS«.
– Display: e.g. »I : I6 PM«.
6 Set the hours with »TUNING« and confirm by
pressing »SEL/ATS«.
7 Set the minutes with »TUNING« and confirm
by pressing »SEL/ATS«.
8 Set the day with »TUNING« and confirm by
pressing »SEL/ATS«.
9 Set the month with »TUNING« and confirm by
pressing »SEL/ATS«.
10 Set the year with »TUNING«.
11 Press »SEL/ATS« to confirm the setting.
– Display: »SAVED«.
12 Press »MENU« to end the setting.

ENGLISH
22
OPERATION
------------------------------------------------------------------------------------------------------------------------------
General functions
Switching on and off
1 Press »ON/OFF« to switch the device on and
off.
Adjusting the volume
1 Adjust the volume using »– VOLUME +«.
Adjusting the tone
1 Adjust the tone using »! "«.
DAB mode
For the best DAB reception, it is sufficient to extend
the telescopic antenna and direct it accordingly.
Selecting the input source DAB
1 Select the input source DAB with »MODE/
AL«.
– Display: »DAB«, then the name of a DAB ra-
dio station.
Selecting stored stations
1 Select the station you want using the preset but-
tons »1/6« to »5/10« (presets 1 to 5) or using
»+ 5« and the preset buttons »1/6« to »5/10«
(presets 6 to 10);
or
select the desired station step by step by press-
ing »TUNING«.
Displaying DAB station information
1 To display information on the current DAB sta-
tion, press »INFO« repeatedly.
– The following display appears in succession:
Information from the provider (e.g. the title
of the song, the e-mail address), the signal
strength, the genre, the Ensemble (e.g. BR for
Bayern), the current frequency, reference to
signal interference (at optimum signal display
»ERR: 0«) the bit rate, the broadcasting format,
the current time and date.
Setting Dynamic Range Control
(DRC) for DAB stations
When you activate Dynamic Range Control, you
can hear lower sounds better in a loud environ-
ment.
1 Open the menu with »MENU«.
2 Select the option »DRC« with »TUNING« and
confirm by pressing »SEL/ATS«.
– Display: »DRC OFF«.
3 Select the option “DRC LOW” or “DRC HIGH”
with »TUNING« and confirm by pressing
»SEL/ATS«.
4 Press »MENU« to end the display.
Note:
7
The DAB station must support DRC.
FM mode
For the best FM reception, it is sufficient to extend
the telescopic antenna and direct it accordingly.
Selecting the input source FM
1 Select the input source FM with »MODE/AL«.
– Display: »FM«, then the frequency of a FM
radio station.
Selecting stored stations
1 Select the station you want using the preset but-
tons »1/6« to »5/10« (presets 1 to 5) or using
»+ 5« and the preset buttons »1/6« to »5/10«
(presets 6 to 10).
Displaying RDS station informations
RDS (Radio Data System) is an information sys-
tem which is transmitted additionally by most FM
stations.
Notes:
7 It may take some time before all RDS infor-
mation is available.
7 GRUNDIG has no influence on the correct-
ness of such information.
1 Press »INFO« repeatedly.
– The following display appears in succesion:
The name of the radio station, radio text (if
offered), station type (PTY), the current time
and date.

23
ENGLISH
TIMER MODE
--------------------------------------------------------------------------------------------------------------------------
Notes:
7
The alarm function is only available during
mains operation, it is disabled during battery
use.
7
You can select directly the option »ALARM«
also with »MODE/AL« in standby mode.
Setting the alarm times
1 Press »ON/OFF« to switch on the device.
– Display: e.g. »B5 AKT«.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »ALARM« with »TUNING«
and confirm by pressing »SEL/ATS«.
– Display: »ALARM« flash.
5 Press »SEL/ATS«, select Timer On (»ON«) with
»TUNING« and confirm by pressing »SEL/
ATS«.
– Display: e.g. »6 : 00 AM«.
6 Set the hours with »TUNING« and confirm by
pressing »SEL/ATS«.
7 Set the minutes with »TUNING« and confirm
by pressing »SEL/ATS«.
8 Select the desired alarm mode (signal sound/
buzzer, DAB radio station or FM radio sta-
tion) with »TUNING« and confirm by pressing
»SEL/ATS«.
Note:
7 If DAB/ or FM program has been selected
as the alarm signal, a program must be se-
lected with »TUNING« and confirmed with
»SEL/ATS«.
9 Select the desired alarm day (Daily, Once,
Weekends or Weekdays) with »TUNING«.
Notes:
7
If the alarm is set to “Once“ continue with
step 10.
7
Otherwise, end settings with step 13.
10 Set the day with »TUNING« and confirm by
pressing »SEL/ATS«.
11 Set the month with »TUNING« and confirm
by pressing »SEL/ATS«.
12 Set the year with »TUNING«.
13 Press »SEL/ATS« to end the setting.
– Display: »SAVED«.
Interrupting the alarm
1 Press »SNOOZE« while the alarm is sounding.
– Display: »e« or »§« flash.
– The alarm (signal tone or radio) stops.
– The alarm goes on again in 5-minute inter-
vals (the total alarm time is 90 minutes).
Cancelling alarm stand-by
1 Press »ON/OFF« while the alarm is sounding.
– Display: the current time and »e« or »§«.
– The alarm (signal tone or radio) stops, but
the alarm function remains activated for the
next day at the same time.
Activating and deactivating the
alarm
1 Press »ON/OFF« to switch off the device.
2 Press »MODE/AL« to deactivate the alarm
stand-by.
– Display: »OFF« and »e« or »§« disap-
pears.
– The set alarm time is saved
3 Press »MODE/AL« to reactivate the alarm
stand-by.
– Display: »ON« and »e« or »§«.

ENGLISH
24
Sleep Timer
The device has a sleep timer which switches off
in radio mode at a preset time. It is possible to
adjust the sleep time between 90 and 10 minutes
in 10 minute increments.
Select the switch-off time for the
sleep timer
1 Press »ON/OFF« to switch on the device.
– Display: e.g. »B5 AKT«.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »SLEEP« with »TUNING«
and confirm by pressing »SEL/ATS«.
– Display: »OFF«.
5 Set the switch-off time with »TUNING« and
confirm by pressing »SEL/ATS«.
– Display: » ≤« and the switch-off time.
6 Press »MENU« to end the setting.
Notes:
7
To check the remaining switch-off time press
briefly »SLEEP«.
7
You can set the switch-off time also by press-
ing »SLEEP« (in 10 minutes increments).
Switch off the sleep timer
1 To switch off the sleep timer earlier, select in the
option »SLEEP« the option »OFF« by pressing
»TUNING« and confirm by pressing »SEL/
ATS«.
– Display: » ≤« disappears.
TIMER MODE
--------------------------------------------------------------------------------------------------------------------------

25
ENGLISH
Call up the software version
1 Open the menu with »MENU«.
2 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
3 Select the option »SW VER« with »TUNING«
and confirm by pressing »SEL/ATS«.
– Display: actual software version.
4 Press »MENU« to end the display.
Deleting all settings (Reset)
This function enables you to reset all the custom
settings back to the default settings. All setings are
lost when you do this.
1 Open the menu with »MENU«.
2 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
3 Select the option »RESET« with »TUNING«
and confirm by pressing »SEL/ATS«.
– A safety confirmation is displayed.
4 Select the option »Y« (Yes) with »TUNING«.
Note:
7
To cancel the function select the option »N«
(No) by pressing »TUNING«.
5 Press »SEL/ATS« to confirm setting.
– Display: »RESTART«.
Set the display illumination
You can choose to illuminate the display either
permanently or only for 10 seconds.
1 Open the menu with »MENU«.
2 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
3 Select the option »BACKLITE« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the desired option (»10 SEC« or »ON«)
with »TUNING« and confirm by pressing
»SEL/ATS«.
5 Press »MENU« to end the setting.
Removing DAB radio stations
from the program list
If you move to a different part of the country, you
should remove DAB radio stations, which are no
longer available from the program list.
These DAB radio stations are marked with “?“.
1 Open the menu with »MENU«.
2 Select the option »PRUNE« with »TUNING« and
confirm by pressing »SEL/ATS«.
– A confirmation message is displayed.
3 Select the option »Y« (Yes) with »TUNING«.
Note:
7
To cancel the function select the option »N«
(No) with »TUNING«.
4 Press »SEL/ATS« to confirm setting.
– Display: »RESTART«.
5 Press »MENU« to end the setting.
– In the program list you will find only avail-
able radio stations.
Software Update
You can install the latest version of the software,
if available.
1 Connect the device to a PC by means of the
socket located in the battery compartment.
2 Open the menu with »MENU«.
3 Select the option »SYSTEM« with »TUNING«
and confirm by pressing »SEL/ATS«.
4 Select the option »UPGRADE« with »TUNING«
and confirm by pressing »SEL/ATS«.
– A confirmation message is displayed.
5 Select the option »Y« (Yes) with »TUNING«.
– Display: »WAITING«.
Note:
7
To cancel the function select the option »N«
(No) with »TUNING«.
6 Start the update program on the PC.
7 Once the software is updated successfully, re-
move the device from the PC.
SPECIAL FUNCTIONS
--------------------------------------------------------------------------------------------

Grundig Intermedia GmbH
Beuthener Strasse 41
90471 Nürnberg
www.grundig.com
72011 411 7600 12/49
