Thank you for purchasing this LCD projector.
Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S
MANUAL” thoroughly to ensure correct usage of this projector. After reading, store this
instruction manual in a safe place for future reference.
CONTENTS
FEATURES....................................P.2
BEFORE USE................................P.2
Contents of Package...........................P.2
Part Names .........................................P.3
Installing the Batteries.........................P.5
Attaching the Projector Handle ...........P.5
INSTALLATION.............................P.6
Installation of the projector and Screen .....P.6
Angle Adjustment................................P.6
Cabling................................................P.7
Power Connection...............................P.8
Example of System Setup...................P.8
Plug & Play..........................................P.8
OPERATIONS................................P.9
Switching the Power Supply ON/OFF ....P.9
Basic Operation.................................P.10
Setup Menu.......................................P.12
Input Menu ........................................P.13
Image Menu ......................................P.14
Options Menu....................................P.15
No Signal Menu.................................P.16
MAINTENANCE...........................P.17
Lamp .................................................P.17
Air Filter Maintenance .......................P.19
Other Maintenance............................P.19
TROUBLESHOOTING.................P.20
OSD Message...................................P.20
Indicators Message...........................P.21
Symptom...........................................P.22
SPECIFICATIONS .......................P.23
WARRANTY ................................P.24
NOTE:
•The information in this manual is subject to change without notice.
•The manufacturer assumes no responsibility for any errors that may appear in this manual
•The reproduction, transmission or use of this document or contents is not permitted without
express written authority.
TRADEMARK ACKNOWLEDGMENT:
•PS/2, VGA and XGA are registered trademark of International Business Machines Corporation.
•Apple, Mac and ADB are registered trademarks of Apple Computer, Inc.
•VESA and SVGA are trademarks of the Video Electronics Standard Association.
•Windows is a registered trademark of Microsoft Corporation.
•Carefully observe the trademarks and registered trademarks of all companies, even when not
mentioned.

ENGLISH-2
FEATURES
This multimedia LCD projector is used to project various computer signals as well as NTSC / PAL /
SECAM video signals onto a screen. Little space is required for installation and large images can
easily be realized.
• Outstanding brightness
The UHB lamp and high-efficiency optical system assure a high level of brightness.
•Partial magnification function
Interesting parts of images can be magnified for closer viewing.
•Distortion correction function
Distortion-free images are quickly available.
BEFORE USE
Contents of package
Make sure all of the following items are included in the package. If anything is missing, please
contact BOXLIGHT at 800-762-5757 or 360-779-7901.
NOTE: Keep the original packing material for future shipments.
Projector
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
NEDERLANDS
NORSK
TECHNICAL
PORTGÊS
LiquidCr ystal Projector
0000000000000
USER'S MANUAL
Pleaseread this user's manual thoroughly to ensure correct usage through understanding.
BEDIENUNGSANLEITUNG
Bittelessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung
aufmerksam.
MANUEL D'UTILISATION
Nousvous recommandons de lire attentivement ce menuel pour bien assimiler le
fonctionnementde l'appareil.
MANUALD'ISTRUZIONI
Vipreghiamo voler leggere attentamente il manuale d'sitruzioni in modo tale da poter
comprenderequanto riportato ai fini di un corretto utilizzo del proiettore.
MANUALDE USUARIO
Leacuidadosamente este manual del usuario para poder utilizar corretamente el
producto.
GEBRUIKSAANWIJZNG
Leesvoor het qebruik alstublieft deze handleiding aandachtig door, om volledig profijt te
hebben van de uitgebreide mogelijkheden.
BRUKERHÅNDBOK
Vennligstles denne bruksanvisningen grundig for å være garantert driftssikker bruk.
INSTRUÇÕES DO PROPRIETÁRIO
Paraassegurar o uso correto do equipamento, por favor leia atentamente este
manualdo usuário.
TECHNICAL
REGULATORYNOTICES
User’s Manual
(this manual)
Safety Instructions
Power Cord
US Type
RGB Cable Video/Audio Cable Mouse cable
(PS/2)
STANDBY/ON
LASER
VIDEO
BLANK
RGB
AUTO
MENU
MENU SELECT
POSITION
RESET
FREEZE
MAGNIFY
OFF
VOLUM E
MUTE
TIMER
Remote Control
Transmitter
Batteries
for Remote Control
Transmitter
Projector Handle
Power Cord
Europe Type

ENGLISH-3
BBEEFFOORREEUUSSEE((ccoonnttiinnuueedd))
ENGLISH
Part Names
Control Panel (Refer to P.9 "OPERATIONS")
Power Switch
AC Inlet
(to the Power Cord)
Ventilation Openings
(Intake)
Zoom Knob
Focus Ring
Remote Control Sensor
Lens
Slide Lens door
Foot Adjuster
FRONT/LEFT VIEW OF
THE PROJECTOR
Speaker
Handle Hook
STANDBY/ON Button
MUTE Button
Foot Adjuster Button
Air Filter and Intake
(for the Cooling Fan)
Rear Foot Adjuster
INPUT Button
LAMP Indicator
TEMP Indicator
POWER Indicator
RESET Button
MENU Button
Ventilation Openings
(exhaust)
REAR/RIGHT VIEW OF
THE PROJECTOR Terminal Panel
(Refer below)
TERMINAL PANEL
S-VIDEO Terminal
VIDEO IN Terminal
AUDIO IN L Terminal
AUDIO IN R Terminal
AUDIO IN 1 Terminal
AUDIO IN 2 Terminal
AUDIO OUT Terminal
Remote Control Sensor
RGB IN 1 Terminal
RGB IN 2 Terminal
CONTROL Terminal
RGB OUT Terminal
USB Terminal
AUDIO IN VIDEO IN S-VIDEO IN
AUDIO
IN
AUDIO OUT
1
12
2 USB
RGB IN
RGB OUT CONTROL

ENGLISH-4
BBEEFFOORREEUUSSEE((ccoonnttiinnuueedd))
Part Names (continued)
WARNING
Never look directly into the laser beam outlet or point the laser beam at other people.
The laser beam can cause vision problems.
ST
ANDBY/ON
LASER
VIDEO
BLANK
RGB
AUTO
MENU
MENU SELECT
POSITION
RESET
FREEZE
MAGNIFY
OFF
VOLUME
MUTE
TIMER
REMOTE CONTROL TRANSMITTER
(Refer to P.9 "OPERATIONS")
NOTE:To prevent any malfunction;
•Do not give the remote control transmitter any physical impact. Do not drop.
•Do not place heavy objects on the remote control transmitter.
•Do not wet the remote control transmitter or place it on any wet object.
•Do not place the remote control transmitter close to the cooling fan of the projector.
•Do not disassemble the remote control transmitter if it malfunctions. Please contact BOXLIGHT.
CAUTION
LASER RADIATION-
DO NOT STARE INTO BEAM

WAVE LENGTH: 650nm
MAX . OUTPUT: 1mW

CLASS 2 LASER PRODUCT
RADIAZIONI LASER
NON GUARDARE NEL RAGGIO LUCE
APPARECCHIO LASER DI CLASSE 2
RAYONNEMENT LASER
NE PAS REGARDER DANS
LE FAISCEAU APPAREIL
A LASER DE CLASSE 2
LASER-STRAHLUNG
NICHT IN DEN STRAHL
BLICKEN LASER KLASSE2
MANUFACTURED
PLACE OF
MANUFACTURER:A
MADE IN JAPAN
IEC60825-1:1993+A1:1997
STANDBY/ON button LASER button
BLANK button
DISK PAD
Used to operate the
mouse shift function
and left click function.
AUTO button
MENU button
MENU SELECT button
Used to click the left
mouse button.
, , , button
Used to operate the
mouse shift function.
MAGNIFY button
VIDEO button
RGB button
MOUSE / RIGHT button
Used to click the right
mouse button.
RESET button
Used to click the right
mouse button.
VOLUME button
FREEZE button
MUTE button
POSITION button
TIMER button
: These functions work when the mouse control function is activated. Remember, the POSITION,
BLANK ON and MENU ON functions disable the mouse control function.

ENGLISH-5
BBEEFFOORREEUUSSEE((ccoonnttiinnuueedd))
ENGLISH
Installing the Batteries
Install the AA batteries into the remote control
transmitter.
1. Remove the battery cover.
Push the knob while lifting up the battery cover.
2. Load the batteries.
Make sure the plus and minus poles are correctly
oriented.
3. Close the battery cover.
12
CAUTION
•Use only the specified batteries with this remote control transmitter. Also, do not mix
new and old batteries. This could cause battery cracking or leakage, which could result
in fire or personal injury.
•When loading the batteries, make sure the plus and minus terminals are correctly
oriented as indicated in the remote control transmitter. Incorrect orientation could cause
battery cracking or leakage, which could result in personal injury or pollution of the
surrounding environment.
•When you dispose of the battery, follow the law in your area or country.
•Keep the battery away from children and pets.
•When not using the remote for an extended period, remove the batteries from the remote
control transmitter.
NOTE:Replace the batteries when remote control transmitter operation becomes difficult.
Attaching the Projector Handle
Attaching the enclosed handle needed.
1. Raise up the handle hook, and pass one end of the
handle through the hole of handle hook.
2. Buckle the end of the handle, per diagram at right.
3. Fix the other end of the handle to the other handle
hook in the same way.
CAUTION
Make sure the handle is firmly attached before carrying the projector with the handle. If
the projector is dropped , it could result in an injury, and continued use could result in fire
or electrical shock.
1
2

ENGLISH-6
INSTALLATION
Installation of the Projector and Screen
CAUTION
•Install the projector in a suitable environment according to instructions of the
accompanying manual “SAFETY INSTRUCTIONS”and this manual.
•Use the liquid crystal projector at the horizontal position only.
If you use this projector by
the lens up position, the lens down position or the side up position, this may cause the heat
inside to build up and cause damage.
Be especially careful not to install it with ventilation
holes blocked.
Refer to the drawing and table below to determine the screen size and projection distance.
TOP VIEW
SIDE VIEW
a: Distance from the LCD projector to the screen.
The projection distance shown in the table below
are for full size (1024 x 768 dots) images.
Table 1. Installation Reference
Screen size
(inches)
a (inches)
Min. Max.
40 65 78
60 98 117
80 131 157
100 163 196
120 196 236
150 246 295
200 328 394
a
Angle Adjustment
Use the foot adjuster on the bottom of the projector to adjust the projection angle. It is variable
within 0˚to 9˚approximately.
1. Lift up the front side of the projector, and pressing
the foot adjuster button, adjust the projection angle.
2. Release the button to lock at the angle to be fixed.
3. Turn the rear foot adjuster to adjust the left-right slope.
CAUTION
Do not release the foot adjuster button unless the projector is being held; otherwise, the
projector could overturn or the fingers could get caught and cause personal injury.
Foot Adjuster Press the foot adjuster button
Rear Foot Adjuster

ENGLISH-7
ENGLISH
IINNSSTTAALLLLAATTIIOONN((ccoonnttiinnuueedd))
Cabling
RGB signal input:
Connect the RGB IN 1 or 2 terminal of the projector to the RGB signal output of the computer by the enclosed
RGB cable.
For some modes, the optional Mac adapter is necessary. Consult BOXLIGHT if you have any questions
regarding connection to an Apple computer.
Some computers may have multiple display screen modes. Use of some of these modes will not be possible with
this projector.
Audio signal input (from computer) :
Connect the AUDIO IN 1 or 2 terminal of the projector to the audio signal output of the computer by the
optional audio cable.
Video signal input:
Connect the VIDEO IN terminal of the projector to the video signal output of the video tape recorder by the
enclosed video/audio cable.
For S-Video signal, use the S-VIDEO IN terminal of the projector and the optional S-Video cable with Mini DIN
4-pin jack.
Audio signal input (from video tape recorder) :
Connect the AUDIO IN R and L terminals of the projector to the audio output of the video tape recorder by the
enclosed video/audio cable with RCA jack.
RGB signal output:
Connect the RGB OUT terminal of the projector to the RGB signal input terminal of the monitor by the optional
RGB cable with D-sub 15-pin shrink jack.
Audio signal output:
Connect the AUDIO OUT terminal of the projector to the audio signal input terminal of the speaker by the
optional audio cable with stereo mini jack.
PS/2, ADB , Serial or RS-232C communication:
Connect the CONTROL terminal of the projector to the computer by an appropriate cable.
For PS/2 mouse control (for IBM and compatible) use the enclosed mouse cable. For others, contact
BOXLIGHT to purchase optional cables.
USB communication (mouse control only):
Connect the USB jack (B type) of the projector to the USB jack (A type) of the computer by optional USB cable.
CAUTION
•Incorrect connecting could result in fire or
electrical shock. Please read this manual and the
separate “SAFETY INSTRUCTIONS”.
•Before connecting, turn off power to all devices
to be connected, except when connecting the
USB cable.
•The cables (Power cord, RGB cable and other
cables) may have to be used with the core set to
the projector side. Use the cables which are included with the projector or specified.
Core
NOTE:
•Before connecting, read the instruction manuals of the devices to be connected, and make sure that
the projector is compatible with the device.
•Secure the screws on the D-sub connectors and tighten.
•Refer to the TECHNICAL section for the pin assign of connectors and RS-232C communication
data.

AUDIO IN VIDEO IN S-VIDEO IN
AUDIO
IN
AUDIO OUT
1
12
2 USB
RGB IN
RGB OUT CONTROL
Example of system setup
Video tape recorder
with S jack
Video tape recorder
Computer
(desktop type)
Computer
(notebook type)
NOTE:
When connecting with notebook computer, set to valid the RGB external image output (setting
CRT display or simultaneous display of LCD and CRT).Please read instruction manual of the
notebook for more information.
Plug & Play
This projector is VESA DDC 1/2B compatible. Plug & play is possible by connecting to a computer
that is VESA DDC (Display Data Channel) compatible.
(Plug & play is a system configured with peripheral equipment including a computer and display,
and an operating system.
NOTE:
•Use the RGB cable included with this projector when using plug & play. With other cables, pins
(12) (14) (15) are sometimes not connected.
•Plug & play is available only when the RGB cable is connected to the RGB IN 1 terminal.
RGB Cable
RS-232C
Cable
ENGLISH-8
IINNSSTTAALLLLAATTIIOONN((ccoonnttiinnuueedd))
Power Connection
Use the correct one of the enclosed power cords depending on the power outlet to be used.
Connect the AC inlet of the projector to the power outlet firmly by the power cord.
WARNING
•Handle the power cord according to instructions of the
accompanying manual "SAFETY INSTRUCTIONS"
and this manual.
•Connect the power cord firmly. Avoid using a loose,
unsound outlet or contact failure.
AC Inlet
Power Cord
Power outlet
Speaker (with built-in amp) Display monitor

ENGLISH-9
ENGLISH
OPERATIONS
Switching the Power Supply ON/OFF
Switching Power ON
1. Check that the power cord is connected correctly.
2. Set the power switch to [ | ]. The standby mode is selected, and the Power indicator is turned to
orange.
3. Press the STANDBY/ON button on the control panel or the remote control transmitter.
Warm-up begins and the Power indicator blinks in green.
4. The Power indicator ceases blinking and turns to green when power is on. Open the slide lens
door.
5. Adjust picture size using the projection lens Zoom Knob.
6. Adjust focus using the projection lens Focus Ring.
Switching Power OFF
1. Press the STANDBY/ON button on the control panel or the remote control transmitter for
approximately two seconds. The projector lamp is extinguished and lamp cooling begins. The
Power indicator blinks orange during lamp cooling. Pressing the STANDBY/ON button has
no effect while the Power indicator is blinking.
2. The system assumes the Standby mode when cooling is complete, and the Power indicator ceases
blinking and changes to orange. When the indicator is orange, set the Power switch to [
O ].
3. The Power indicator is extinguished when power is off. Do not forget to close the lens door.
WARNING
Please read this manual, and the separate “SAFETY INSTRUCTIONS”thoroughly before
using the equipment. Always ensure that the equipment is used safely.
Power Switch Slide Lens door
STANDBY/ON Button
POWER Indicator
STANDBY/ON
LASER
VIDEO
BLANK
RGB
AUTO
MENU
MENU SELECT
POSITION
RESET
FREEZE
MAGNIFY
OFF
VOLUME
MUTE
STANDBY/
ON Button
ZOOM knob
FOCUS ring
NOTE:
•Except in emergencies, do not turn off unless the Power indicator is orange as it will reduce the
life of the projector lamp.
•To prevent problems, turn on/off the projector when the computer or video tape recorder is OFF.
Providing a RS-232C cable is connected, turn on the computer before the projector.

ENGLISH-10
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Basic Operation
The Basic operations shown in Table 2 can be controlled from the projector control panel or the
supplied remote control transmitter. (items indicated by * may be used from the control panel)
NOTE: Use the remote control transmitter at a distance of approximately 3m from the sensor on the
front of the projector, and within a range of 30°left-right. Strong light and obstacles will
interfere with operation of the remote control transmitter.
Table 2 . Basic Operation
Item Description
INPUT
SELECT
Changes in input signal in sequence: Press INPUT button.*
RGB1 →RGB2 →VIDEO →S-VIDEO (→RGB1)
Select RGB input: Press RGB button.
VIDEO/S-VIDEO →RGB1/RGB2 RGB2 ↔RGB1
Select VIDEO/S-VIDEO input: Press VIDEO button.
RGB1/RGB2 →VIDEO/S-VIDEO S-VIDEO ↔VIDEO
•The selected signal name is displayed for approximately three seconds
when the input signal is changed.
POSITION
Set/Clear position adjustment mode: Press POSITION button.
The [ ] icon is displayed in the POSITION mode.
Image position adjustment: Press the , , and buttons in the
position adjustment mode.
•Valid only in the MAGNIFY mode with VIDEO/S-VIDEO input.
•The [ ] icon is extinguished, and the position adjustment mode cleared
automatically, after approximately ten seconds of inactivity.
, , and buttons may operate as the mouse control button.
Refer to P.4.
RESET *
Initialize menu items: Select an item and press the RESET button.
Initialize position adjustment: Press the RESET button
and the POSITION mode.Valid only when RGB signal is input.
•Valid except for VOLUME, LANGUAGE and H PHASE.
•RESET button may operate as the mouse control button. Refer to P.4.
MAGNIFY
Set MAGNIFY mode: Press the MAGNIFY button.
Move magnified area: Run Position Adjustment in MAGNIFY mode.
Adjust magnification: Press MAGNIFY / in MAGNIFY mode.
Clear MAGNIFY mode: Press MAGNIFY button.
•MAGNIFY is cleared by running or setting AUTO, ASPECT, INPUT
SELECT or VIDEO, or by changing the input signal.
OFF
FREEZE
Set/Clear FREEZE mode: Press FREEZE button.
The [
II ] icon is displayed, and the image frozen, in the FREEZE mode.
•FREEZE is cleared by running or setting POSITION, VOLUME, MUTE,
Auto Adjust, BLANK ON/OFF, or MENU ON/OFF, or by changing the
input signal.
•Do not forget to clear frozen static images.

ENGLISH-11
ENGLISH
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Table 2. Basic Operation (continued)
Item Description
VOLUME Volume adjustment : Reduce VOLUME ↔Increase VOLUME
MUTE *Set/Clear Mute mode: Press the MUTE button.
No sound is heard in the MUTE mode.
AUTO
Automatic adjustment at RGB input: Press the AUTO button.
Horizontal position(H.POSIT), vertical position (V.POSIT),clock phase
(H.PHASE), and horizontal size(H.SIZE) are automatically adjusted. Use
with the window at maximum size in the application display.
Automatic adjustment at VIDEO/S-VIDEO input:
Press the AUTO button.
A signal type appropriate for the input signal is selected automatically.
Valid only when AUTO is set for VIDEO on the menu.
•This operation requires approximately ten seconds. It may not function
correctly with some input signals.
TIMER
ON/OFF
Timer start/stop: Press the TIMER button.
Count-down and display by the minute from the initial value (1~99) set in
TIMER on the Options menu to 0.
•The timer is not displayed in the BLANK MODE or FREEZE MODE.
BLANK
ON/OFF
Set/Clear Blank mode: Press the BLANK button.
No image is displayed in the Blank mode. The screen color is as set in
BLANK on the Image menu.
MENU
ON/OFF *
Menu display start/stop: Press the MENU button.
•The menu display is terminated automatically after approximately ten
seconds of inactivity.
MENU
SELECT
Select menu type: Press the MENU SELECT button.
Allows the user to select the normal menu or the single menu. Only the
selected item is displayed on the single menu, and other items are
displayed with the and buttons as with the normal menu.
•Valid only when the Setup menu is used. Push the MENU SELECT button
after selecting items such as "BRIGHTNESS".
•MENU SELECT button may operate as the mouse control button.
Refer to P.4.
Normal menu Single menu
CONTRAST -2
BRIGHT
CONTRAST
V POSIT
H POSIT
H PHASE
H SIZE
COLOR BAL R
COLOR BAL B
ASPECT
0
-2
+1
0
0
100
100
800
SETUP INPUT OPT.IMAGE
(MENU SELECT)

ENGLISH-12
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Setup Menu
The following adjustments and settings are
possible when SETUP is selected at the top of
the menu. Part of the Setup menu differs
between RGB input and VIDEO/S-VIDEO
input. Select an item with the and
buttons, and start operation. Use the Single
menu to reduce menu size (see Table 2 MENU
SELECT on page 11).
Table 3. Setup Menu
VIDEO/S-VIDEO
RGB
BRIGHT
CONTRAST
V POSIT
H POSIT
H PHASE
H SIZE
COLOR BAL R
COLOR BAL B
ASPECT
0
-2
+1
0
0
100
100
800
SETUP INPUT OPT.IMAGE
BRIGHT
CONTRAST
SHARPNESS
COLOR
TINT
COLOR BAL R
COLOR BAL B
ASPECT
0
+1
+1
0
0
0
0
SETUP INPUT OPT.IMAGE
Item Description
RGB VIDEO
S-VIDEO
BRIGHT
Adjustment: Dark ↔Light ✔ ✔
CONTRAST Adjustment: Weak ↔Strong ✔ ✔
V POSIT Adjustment: Down ↔Up ✔-
H POSIT Adjustment: Left ↔Right ✔-
H PHASE Adjustment: Left ↔Right
• Adjust to eliminate flicker. ✔-
H SIZE
Adjustment: Small ↔Large
• The image may not be displayed correctly if the horizontal
size is excessive. In such cases, press the RESET
button, and initialize the horizontal size.
✔-
SHARPNESS Adjustment: Soft ↔Clear -✔
COLOR Adjustment: Light ↔Dark -✔
TINT Adjustment: Red ↔Green
• Valid only when NTSC or NTSC 4.43 signal is received. -✔
COLOR BAL R
Adjustment: Light ↔Dark ✔ ✔
COLOR BAL B
Adjustment: Light ↔Dark ✔ ✔
ASPECT
Select image aspect ratio:
4:3[ ] ↔16:9[ ]
Select position of 16:9:[ ] image:
Press button while 16:9[ ] is selected.
Center →Down →Up ( →Center )
✔-
Select image aspect ratio:
4:3[ ] ↔16:9[ ] ↔4:3 small[ ]
Select position of 16:9:[ ]/4:3 small[ ] image:
Press button while 16:9[ ]/4:3 small[ ] is selected.
Center →Down →Up ( →Center )
•
4:3 small may not be displayed correctly with some input signals.
-✔

ENGLISH-13
ENGLISH
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Input Menu
The following functions are available when INPUT is selected on the
menu. Select an item with the and buttons, and start or stop
operation with the and buttons.
Table 4. Input Menu
fH:38kHz
fV:60Hz
RGB
VIDEO
AUTO
SETUP INPUT OPT.IMAGE
Item Description
RGB
Displays RGB input frequency: Displays the horizontal and vertical sync
signal frequency for RGB input.
• Valid only at RGB input.
VIDEO
Select video signal type:
Select the signal type with the and buttons.
Select NTSC, PAL, SECAM, NTSC4.43, M-PAL, or N-PAL as appropriate
for the input signal.
Auto Adjust is valid at VIDEO/S-VIDEO input when AUTO is selected,
and is then used for automatic selection of the signal type.
• Use this function when the image becomes unstable (eg. the image
becomes irregular, or lacks color).
• Auto Adjust requires approximately ten seconds. It may not function
correctly with some input signals. Pressing the AUTO button in this case
may correct this problem.
AUTO
Automatic adjustment at RGB input: Select EXECUTE with the button.
Horizontal position, vertical position, clock phase, and horizontal size are
automatically adjusted when
EXECUTE is selected. Use with the window
at maximum size in the application display.
Automatic adjustment at VIDEO/S-VIDEO input:
Select EXECUTE with the button.
A signal type appropriate for the input signal is selected automatically
when
EXECUTE is selected. Valid only if AUTO is selected in VIDEO (see
above).
• This operation requires approximately ten seconds. It may not function
correctly with some input signals. Pressing the AUTO button in this case
may correct this problem.
• This function is the same as for Auto Adjust in Basic operation.

ENGLISH-14
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Image Menu
The following adjustments and settings are available when IMAGE is
selected on the menu. Select an item with the and buttons, and
start operation.
Table 5. Image Menu
KEYSTONE
BLANK
MIRROR
START UP
+1
SETUP INPUT OPT.IMAGE
Item Description
KEYSTONE
Adjustment:
Reduce size of bottom of image ↔Reduce size of top of image
• When this function is activated, the image may not be displayed correctly
with some input signals.
BLANK
Select blank screen color: Select color with the and buttons.
• The image is cleared when the BLANK mode is set with BLANK ON, or
when there is no signal, and the entire screen is displayed in the selected
color.
MIRROR Operation start/stop: Press the or button.
Select Mirror status: Select mirror status with and buttons.
START UP
Operation start/stop: Press the or button.
Setup initial screen display: Select TURN ON with the button.
Clear initial screen display: Select TURN OFF with the button.
• Note that if TURN OFF is selected the screen is displayed in blue when
there is no signal.

ENGLISH-15
ENGLISH
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
Options Menu
The following adjustments and settings are available when OPT. is
selected on the menu. Select an item with the and buttons, and
start operation.
Table 6. Options Menu
VOLUME
MENU COLOR
TIMER
LANGUAGE
AUTO OFF
SYNC ON G
128
SETUP INPUT OPT.IMAGE
Item Description
VOLUME Volume adjustment: Reduce VOLUME ↔Increase VOLUME
MENU COLOR Select menu background color: Select with the and buttons.
TIMER
Operation start/stop: Press the or button.
Setup initial timer value:
Set 1~99 minutes with the and buttons.
LANGUAGE Operation start/stop: Press the or button.
Select menu display language: Select with the and buttons.
AUTO OFF
Operation start/stop: Press the or button.
Set AUTO OFF: Set 1~99 minutes with the and buttons.
The system automatically enters the standby mode when a signal is
not received for the set time.
Clear AUTO OFF: Select STOP (0 min.) with the button.
When STOP is selected the system does not enter the standby mode
even if no signal is received.
SYNC ON G
Operation start/stop: Press the or button.
SYNC ON G valid: Select TURN ON with the button.
SYNC ON G invalid: Select TURN OFF with the button.
• May not be displayed correctly with some input signals when SYNC
ON G is valid. In such cases, remove the signal connector so that no
signal is received, set SYNC ON G to invalid, and reconnect the
signal.

ENGLISH-16
OOPPEERRAATTIIOONNSS((ccoonnttiinnuueedd))
No Signal Menu
The same adjustments and settings are available as with the Image and
Options menus when the MENU button is pressed during display of the
“NO INPUT IS DETECTED ON ***”or “SYNC IS OUT OF RANGE
ON ***”message while no signal is received.
Table 7. No Signal Menu
VOLUME
KEYSTONE
BLANK
MIRROR
START UP
MENU COLOR
TIMER
LANGUAGE
AUTO OFF
SYNC ON G
40
+1
Item Description
VOLUME Volume adjustment: Reduce VOLUME ↔Increase VOLUME
KEYSTONE Adjustment:
Reduce size of bottom of image ↔Reduce size of top of image
BLANK
Select blank screen color: Select color with the and buttons.
• When the blank mode is set with BLANK ON, by absence of a signal, or by
input of a non-standard signal, the image is cleared and the complete screen is
displayed in the selected colour.
MIRROR Operation start/stop: Press the or button.
Select Mirror status: Select mirror status with and buttons.
START UP
Operation start/stop: Press the or button.
Setup initial screen display: Select TURN ON with the button.
Clear initial screen display: Select TURN OFF with the button.
• Note that if TURN OFF is selected the screen is displayed in blue
when there is no signal.
MENU COLOR Select menu background color: Select with the and buttons.
TIMER Operation start/stop: Press the or button.
Setup initial timer value: Set 1~99 minutes with the and buttons.
LANGUAGE Operation start/stop: Press the or button.
Select menu display language: Select with the and buttons.
AUTO OFF
Operation start/stop: Press the or button.
Set AUTO OFF: Set 1~99 minutes with the and buttons.
The system automatically enters the standby mode when a signal is
not received for the set time.
Clear AUTO OFF: Select STOP (0 min.) with the button.
When STOP is selected the system does not enter the standby mode
even if no signal is received.
SYNC ON G
Operation start/stop: Press the or button.
SYNC ON G valid: Select TURN ON with the button.
SYNC ON G invalid: Select TURN OFF with the button.
• May not be displayed correctly with some input signals when SYNC ON G is
valid. In such cases, remove the signal connector so that no signal is received,
set SYNC ON G to invalid, and reconnect the signal.

ENGLISH-17
ENGLISH
WARNING
•Dispose of used lamp, according to the instruction of community
authorities.
•Since the lamp is made of glass, do not apply shock to it and do
not scratch it.
•Also, do not use old lamp. This could also cause explosion of the
lamp.
•If it is probable that the lamp has exploded (explosive sound is
heard), disconnect the power plug from the power outlet and
contact BOXLIGHT.
The lamp is covered by front glass , but, in rare cases, the
reflector and the inside of the projector may be damaged by scattered broken pieces of
glass, and broken pieces could cause injury when being handled.
•Do not use the projector with the lamp cover removed.
MAINTENANCE
Lamp
HIGH VOLTAGE
HIGH TEMPERATURE
HIGH PRESSURE
Contact BOXLIGHT before replacing the lamp.
Before replacing the lamp switch power OFF, remove the power cord from the power outlet, and
wait approximately 45 minutes until the lamp has cooled. The lamp may explode if handled at high
temperatures.
Lamp Life
Projector lamps have a finite life. The image will become darker, and hues will become weaker,
after a lamp has been used for a long period of time.
Replace the lamp if the LAMP indicator is red, or the CHANGE THE LAMP message (see P.20
Table 8) appears when the projector is switched ON.
NOTE:
The LAMP indicator is also red when the lamp unit reaches high temperature. Before replacing the
lamp, switch power OFF, wait approximately 20 minutes, and switch power ON again. If the LAMP
indicator is still red, replace the lamp.
Lamp
Front
glasss
Reflector

ENGLISH-18
MMAAIINNTTEENNAANNCCEE((ccoonnttiinnuueedd))
Replacing the Lamp
1. Switch the projector OFF, remove the power cord from the
power outlet, and wait at least 45 minutes for the unit to cool.
2. Prepare a new lamp.
3. Check that the projector has cooled sufficiently, and gently
turn it upside down.
4. Loosen the two screws as shown in the diagram, and remove
the lamp cover.
5. Loosen the three screws, and gently remove the lamp while
holding the grips. Touching the inside of the lamp case may
result in uneven coloring of the projected image.
6. Install the new lamp and tighten the three screws firmly.
7. Replace the lamp cover in position and tighten the two
screws firmly.
8. Gently turn the projector right-side up.
CAUTION
•Ensure that screws are tightened properly. Screws not
tightened fully may result in injury or accidents.
•Do not use the projector with the lamp cover removed.
Resetting the Lamp Timer
Reset the lamp timer after replacing the lamp. When the lamp has been replaced after the LAMP
indicator is red, or the CHANGE THE LAMP message is displayed, complete the following
operation within ten minutes of switching power ON. The power will be turned off automatically in
10 minutes.
1. Switch power ON, and press the TIMER button on the remote control transmitter, or the RESET
button on the control panel, for approximately three seconds. The ‘LAMP xxxx hr’message
will appear on the lamp timer on the bottom of the screen.
2. Press the MENU button on the remote control transmitter, or the RESET button on the control
panel, while the lamp timer is displayed. The ‘LAMP xxxx →0 ■CANCEL’message will
then appear.
3. Press the and select 0, and wait until the timer display is cleared.
NOTE:
Do not reset the lamp timer without replacing the lamp. Reset the lamp timer always when replacing
the lamp. The message functions will not operate properly if the lamp timer is not reset correctly.

ENGLISH-19
ENGLISH
MMAAIINNTTEENNAANNCCEE((ccoonnttiinnuueedd))
Air Filter Maintenance
The air filter should be cleaned as described below at intervals of approximately 100 hours.
1. Switch the projector power supply OFF, and remove the power cord from the power outlet.
2. Clean the air filter with a vacuum cleaner.
Other Maintenance
Maintenance Inside the Equipment
For safety reasons, ensure that the equipment is cleaned and checked by BOXLIGHT once every
two years. Maintaining the equipment by yourself is dangerous.
Cleaning the Lens
Gently wipe the lens with lens cleaning paper. Do not touch the lens with your hands.
Cleaning the Cabinet and Remote control transmitter
Gently wipe with a soft cloth. If dirt and stain etc. are not easily removed, use a soft cloth dampened
with water, or water and a neutral detergent, and wipe dry with a soft, dry cloth.
CAUTION
•Switch power OFF and remove the power cord from the power outlet before beginning
maintenance work. Please read the separate “SAFETY INSTRUCTIONS”thoroughly to
ensure that maintenance is performed correctly.
•Replace the air filter if contamination cannot be removed, or if it is damaged. Contact
BOXLIGHT for service.
•Do not use the equipment with the air filter removed.
•When the air filter is clogged with dust etc. the CHECK AIR FLOW message appears on
the screen and the power supply is switched OFF automatically to prevent the
temperature rising inside the projector.
CAUTION
•Switch power OFF and remove the power cord from the power outlet before beginning
maintenance work. Please read the separate “SAFETY INSTRUCTIONS”thoroughly to
ensure that maintenance is performed correctly.
•Do not use detergents or chemicals other than those noted above (e.g. benzene or
thinners).
•Do not use cleaning sprays.
•Do not rub with hard materials, or tap the equipment.
