Grundig GKNM46220DZ User manual

GKNM46220DZ
Combi Fridge-Freezer
User instructions
EN

Please read these instructions first before using your ppliance
Thank you for choosing a Grundig appliance.
Please take some time to read this user manual before using your appliance,
to ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the
appliance is correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of
this user manual, and store in a safe location close to the appliance for
easy future reference.
This user manual may also be applicable for several other models.
Differences between models will be listed.
If you have any questions or concerns, please call our contact centre or
find help and information online at www.grundig.co.uk.
Explanation of symbols used throughout this User Manual
- The terminal in the plug is marked with the symbol.
- The freezer compartment is marked with the symbol.
- Important information or useful tips.
-Warning against dangerous conditions for life and property.
- Symbol for waste electrical and electronic equipment.
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which
uses a completely environmentally friendly refrigerant the R600a (flammable
only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others
than the ones recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other
than those that might have been recommended by the manufacturer.
1

CONTENTS
2
Introduction & safety arnings.......................................................................... 3
Electrical requirements................................................................................... 4
Transportation instructions............................................................................. 5
Installation instructions .................................................................................. 5
Changing the illumination Lamp …………………………………………….….. 6
Changing the door opening Direction …………………………………….……. 6
Getting to know your combi fridge freezer..................................................... 7
Suggested arrangement of food in the your combi........................................ 8
Using your refrigerator................................................................................... 9
Indicator Panel............................................................................................... 9
Dual cooling system...................................................................................... 11
Blue light....................................................................................................... 11
Compartment for keeping perishable food (low temperature ……………….. 11
Making ice cubes............................................................................................11
Using the water dispenser ……………………………………………………….12
Freezing fresh food ……………………………………………………………….14
Recommendations for preservation of frozen food ……………………………15
Defrosting.......................................................................................................15
Placing the food............................................................................................. 15
Deep-freeze information.................................................................................16
Recommendations for the fresh food compartment …………………………..16
Cleaning and care ……………………………………………………………….. 17
Troubleshooting..............................................................................................18
Grundig UK and Ireland standard manufacturer guarantee...........................21
Grundig UK and Ireland eco inverter motor guarantee..................................24
How to obtain service for your appliance........................................................25
Notes...............................................................................................................26

Congratulations on your choice of a GRUNDIG quality Appliance which has been designed to
give you service for many years.
WARNING !
IMPORTANT !
DO NOT connect your appliance to the electricity supply until all packing and transit protectors
have been removed.
Leave to stand for at least 4 hours before switching on to allow compressor oil to settle if
transported horizontally.
If you are discarding an old refrigerator with a lock or latch fitted to the door, disable the
lock/latch, ensure that it is left in a safe condition to prevent the entrapment of children.
This refrigerator-freezer must only be used for its intended purpose i.e the storing of edible
foodstuff.
Do not dispose of the appliance on a fire. At GRUNDIG, the care and protection of our
environment is an ongoing commitment. This appliance which is among the latest range
introduced is particularly environment friendly. Your appliance contains non CFC / HFC natural
substances in the cooling system (Called R600a) and in the insulation (Called cyclopentane)
which are potentially flammable if exposed to fire. Therefore, take care not to damage, the
cooling circuit / pipes of the appliance in transportation and in use. In case of a damage do not
expose the appliance to fire, potential ignition source and immediately ventilate the room
where the appliance is situated.
We suggest you contact your local authority for disposal information and facilities available.
To obtain the best possible performance and trouble free operation from your appliance it is
very important to carefully read these instructions.
On delivery, check to make sure that the product is not damaged and that all the parts and
accessories are in perfect condition.
Ensure that the plug remains readily accesible. Do not recommend the use of extension leads
and multi-way adapters.
Failure to observe these instructions may invalidate your right to free service during the
guarantee period.
WARNING- Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
WARNING- Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING- Do not damage the refrigerant circuit.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• If there is a blue light on the refrigerator, do not look at the blue light with optical tools.
We suggest you keep these instructions in a safe place for easy reference.
PERFORMANCE
Combi Fridge-Freezer
GKNM46220DZ
Energy efficiency class
A++
Energy consumption - Kwh/year
282
Net storage - vol fresh food ltrs (cu.ft.)
253 (8.9)
Net storage - vol frozen food ltrs (cu.ft.)
109 (3.8)
Total net vol - ltrs (cu.ft.)
362 (12.7
Frozen food compartment rating
4 STAR
Conservation time from failure
33 hrs
Freezing capacity fresh food - kg (lb) /24 hrs.
6 (13.2)
Climate class
SN-T
Operating noise level [ dB(A) re1pW ]
38
3

ELECTRICAL REQUIREMENTS
Before you insert the plug into the wall socket make sure that the voltage and the
frequency shown in the rating plate inside the appliance corresponds to your
electricity supply.
Rating label is on the left hand side of fridge inner liner.
We recommend that this appliance is connected to the mains supply via a suitable
switched and fused socket in a readily accessible position.
WARNING: When positioning the appliance ensure the supply cord is not trapped or
damaged.
Should the mains lead of the appliance become damaged or should it need
replacing at any time, it must be replaced by a special purpose made mains lead
which can only be obtained from a BEKO Authorised Service Agent.
WARNING! THIS APPLIANCE MUST BE EARTHED
If the fitted moulded plug is not suitable for your socket, then the plug should be cut
off and an appropriate plug fitted. Destroy the old plug which is cut off as a plug with
bared cord could cause a shock hazard if inserted into a socket elsewhere in the
house.
The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse need
to be replaced an ASTA approved BS 1362 fuse of the same rating must be used.
Do not forget to refit the fuse cover. In the event of losing the fuse cover the plug
must not be used until a replacement fuse cover has been fitted. Colour of the
replacement fuse cover must be the same colour as that visible on the pin face of
the plug. Fuse covers are available from any good electrical store.
WARNING: Do not locate extension sockets or charging transformers/power
supplies or Lithium-Iron battery operated products adjacent to the compressor as
they could overheat.
IMPORTANT! FITTING A DIFFERENT PLUG
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals in your plug proceed as follows:
(See diagram).
1. Connect the green-yellow or green
(Earth) wire to the terminal in the plug
marked 'E' or with the symbol or coloured
green and yellow or green.
2. Connect the blue (Neutral) wire to the
terminal in the plug marked 'N' or coloured
black.
3. Connect the brown (Live) wire to the
terminal in the plug marked 'L' or coloured red.
With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor or
in the main fuse box.
If in doubt contact a qualified electrician.
WARNING: Do not locate extension sockets or charging transformers/power
supplies or Lithium-Iron battery operated products adjacent to the compressor as
they could overheat.
4

TRANSPORTATION INSTRUCTIONS
1. The appliance should be transported only in an upright position. The packing as
supplied must be intact during transportation.
2. If during the course of transport the appliance has to be transported horizontally,
it must only be laid on its left hand side when standing in the front of the appliance.
After bringing it to upright position,it must not be operated for at least 4 hours to
allow the system to settle.
3. Failure to comply with the above instructions could result in damage to the
appliance, for which the manufacturer will not be held liable.
4. The appliance must be protected against rain, moisture and other atmospheric
influences.
5. When positioning your appliance take care not to damage your flooring, pipes,
wall coverings etc. Do not move the appliance by pulling by the door or handle.
6. Empty any water in the drain tray before moving. See section „Defrosting” and
„Care & Cleaning” for further information.
7. Make sure that the defrost water pipe at the back of the product is fixed to the
plastic evaporating pan on the top of the compressor, to avoid defrost water spillage
on the floor.
Important!
Care must be taken while cleaning/carrying the appliance not to touch the bottom
of the condenser metal wires at the back of the appliance, as this could cause injury
to fingers and hands.
Do not attempt to sit or stand on top of your appliance as it is not designed for
such use. You could injure yourself or damage the appliance.
Make sure that the mains cable is not caught under the appliance during and after
moving, as this could damage the cable.
Do not allow children to play with the appliance or tamper with the controls.
GRUNDIG plc declines to accept any liability should the instructions not be
followed.
INSTALLATION INSTRUCTIONS
1. The space in the room where the appliance is installed must not be smaller than
10 cubic metres.
2. If the ambient temperature is below 0°C, the food in the fridge compartment will
freeze. So, we recommend you don't use the fridge compartment in such low
ambient conditions.
You can continue using the freezer compartment as usual.
3. Do not place the appliance near cookers, radiators or in direct sunlight as this
will cause your appliance to work harder. If installed next to a source of heat or
freezer, maintain the following minimum side clearances:
From Cookers
2" (50 mm)
From Radiators
12" (300 mm)
From Refrigerators or Larder Fridge
1" (25 mm)
5

4. Refer to cleaning and care section to prepare your appliance for use.
5. A special receptacle is supplied to store the mains plug during transit.
The receptacle is fixed at the back of the cabinet,
on the side of the compressor (see diagram).
Gently remove the plug from the receptacle.
Never pull the mains cord, you may
damage the appliance. In the case of
transportation, ensure you locate the plug in
the receptacle provided to avoid transit
damage.
6. If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction of
black arrow and raised when you turn in the
opposite direction. Taking help from someone
to slightly lift the refrigerator will facilitate this process.
Changing the illumination Lamp
To change the Bulb/LED used for illumination of your refrigerator, call your
Authorized Service.
The lamp(s) used in this appliance is not suitable for household room illumination.
The intended purpose of this lamp is to assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable way.
The lamps used in this appliance have to withstand extreme physical conditions
such as temperatures below -20°C.
Changing the door opening Direction
Door opening direction of your refrigerator can be changed according to the place
you are using it. If this is necessary, please call your nearest Authorized Service.
6

GETTING TO KNOW YOUR COMBI FRIDGE FREEZER
1. Control panel
2. Interior light
3. Fresh Food fan
4. Adjustable Cabinet shelves
5. Wine bottles support
6. Zero degree compartment
7. Cover glass
8. Salad crispers
9. Ice tray
10.Compartment for quickly freezing
11. Compartments for frozen froods keeping
12. Adjustable front feet
13. Shelf for jars
14. Water dispenser reservoir
15. Shelf for bottles
16. Freezer fan
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
7

2
Arrangement Examples (See diagram)
1. Baked, chilled cooked food,
dairy products, cans.
2. Wine bottles
3. Chesse, butter, meat or chicken
4. Fruit, vegetables, salads
5. Making, storing ice cubes.
6. Frozen food and freezing of fresh food.
7. Frozen food.
8. Butter, cheese, eggs, small bottles,
cans, tubes.
9. Tall, large bottles, beverages.
The following guidelines and recommendations are suggested to obtain the best
results and storage hygiene.
1. The fridge compartment is for the short term storage of fresh food and drinks.
2. The freezer compartment is rated and suitable for the freezing and
storage of pre frozen food. The recommendation for storage as stated on
the food packaging should be observed at all times.
3. Cooked dishes must be stored in airtight covered containers.
4. Fresh wrapped produce can be placed on the shelf. Fresh fruit and vegetables
should be cleaned and stored in the crisper bins.
5. Bottles can be placed in the door section.
6. To store raw meat, wrap in polythene bags and place on biofresh box. Do not
allow to come into contact with cooked food to avoid contamination. For safety,
only store raw meat for two to three days.
7. Keep the food packed wrapped or covered. Allow hot food and beverages to
cool before placing them in the fridge. Do not store explosive substances. High
proof alcohol must be stored upright in sealed containers. Left over canned food
should not be stored in the can.
8. Fizzy drinks should not be frozen and products such as flavoured water ices
should not be consumed too cold.
9. Some fruit and vegetables suffer damage if kept at temperatures near 0°C
(biofresh box). Therefore wrap pineapples, melons, cucumbers, tomatoes and
similar produce in polythene bags.
10. Place chilled cooked food and similar food near the rear of the fridge inner liner
where the cold wall is located.
11. Shelves, racks, crisper bins, drawers, flaps, bottle grippers are all removable.
12. Do not leave frozen food at room temperature to thaw; the best way to defrost
food is to put it in the fridge to thaw slowly. Make sure you avoid defrosting food or
food juices drip onto other food.
13. For hygiene reasons, always wrap food using a suitable packaging material
before storing in your appliance to avoid contact with the appliance surface.
SUGGESTED ARRANGEMENT OF FOOD IN THE YOUR COMBI
8

USING YOUR REFRIGERATOR
*Optional: The figures in this user guide are intended as drafts and may not
perfectly match your product. If your product does not comprise the relevant
parts, the information pertains to other models.
Indicator Panel
Indicator panel allows you to set the
temperature and control the other
functions related to the product without
opening the door of the product. Just
press the inscriptions on relevant
buttons for function settings.
1. Quick Fridge Function:
Quick Fridge indicator turns on when
the Quick Fridge function is on. Press
Quick Fridge button again to cancel
this function.
Quick Fridge indicator will turn o and
normal settings will be resumed. Quick
Fridge function will be cancelled
automatically 1 hour later if you do not
cancel it manually. If you want to cool
plenty amount of fresh food, press
Quick Fridge button before you place
the food into the fridge compartment.
2. Quick Fridge Indicator:
This icon comes on when the Quick
Fridge function is on.
3. Quick Freeze Function:
Quick Freeze indicator turns on when
the Quick Freeze function is on. Press
Quick Freeze button again to cancel
this function.
Quick Freeze indicator will turn o and
normal settings will be resumed. Quick
Freeze function will be cancelled
automatically 25 hours later if you do
not cancel it manually. If you want to
freeze plenty amount food, press
Quick Freeze button before you place
the food into the freezer compartment.
4. Quick Freeze Indicator:
This icon comes on when the Quick
Freeze function is on.
9

5. Fridge Set Function:
This function allows you to make the
Fridge compartment temperature
setting. Press this button to set the
temperature of the fridge compartment
to 8,7,6,5,4,3 and 2 respectively.
6. Fridge Compartment
Temperature Setting Indicator:
Indicates the temperature set for the
Fridge Compartment.
7. Eco Extra Function:
Press the Eco Extra button to activate
the Eco Extra Function. Freezer will
start operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn on
when the function is active.
Press the Eco Extra button for 3
seconds again to deactivate the Eco
Extra Function.
8. Eco Extra Indicator:
This icon lights when the Eco Extra
Function is active.
9. High Temperature/Error
Warning Indicator:
This light comes on during high
temperature failures and error
warnings. If you see this light is on,
please check the “Recommended
Solutions for the Problems” part from
you manual.
10. Economic Usage Indicator:
This icon comes on when the Fridge
Compartment is set to 8°C and
Freezer Compartment is set to -18°C
which are the most economical set
values. Economic Usage Indicator
turns off when the Quick Fridge or
Quick Freeze function is selected.
11. Energy saving Function
(Display Off):
Energy saving icon will light up and
Energy Saving Function will be
activated automatically after 1 minute.
If energy saving function is active, all
icons on the display other than energy
saving icon will turn off.
When the Energy Saving Function is
active, if any button is pressed or the
door is opened, Energy Saving
Function will be exited for a minute
and the icons on display will return to
normal.
12. Energy Saving Indicator :
This icon (“-“) lights up when the
Energy Saving Function is selected.
13. Key Lock Mode:
Press Key Lock button concurrently for
3 seconds. Key lock icon will light up
and key lock mode will be activated.
Buttons will not function if the Key
Lock mode is active. Press Key Lock
button con-currently for 3 seconds
again.
Key lock icon will turn off and the key
lock mode will be exited.
14. Key Lock Indicator:
This icon lights up when the Key Lock
mode is activated.
15. Freezer Set Function:
This function allows you to make the
Freezer compartment temperature
setting. Press this button to set the
temperature of the freezer
compartment to -18,-19,-20, -21,-22,
-23 and -24, respectively.
16. Freezer Compartment Setting
Indicator:
Indicates the temperature set for the
Freezer Compartment.
10

17. Vacation Function:
When you press for 3 sec. the
Vacation button, vacation function is
activated and vacation indicator lights.
You can use this function when you
will not use your fridge for a long time.
Note that there should be no food
inside your fridge, otherwise fridge can
not preserve your food at Vacation
mode. If this function is activated,
fridge compartment temperature is
kept at 15 C° in order to prevent bad
smelling.
Press Vacation button again to
deactivate vacation function.
18. Vacation Indicator:
This icon lights up when the Vacation
Function is active.
Dual cooling system
Your refrigerator is equipped with
two separate cooling systems to cool
the fresh food compartment and
freezer compartment. Thus, air in the
fresh food compartment and freezer
compartment do not get mixed.
Thanks to these two separate cooling
systems, cooling speed is much higher
than other refrigerators. Odors in the
compartments do not get mixed. Also
additional power saving is provided
since the defrosting is performed
individually.
Blue light
Fruits and vegetables stored in the
crispers that are illuminated with a
blue light continue their
photosynthesis by means of the
wavelength effect of blue light and
thus preserve their vitamin C content
longer.
Compartment for keeping
perishable food (low
temperature /-20C - +30C).
This compartment was designed to
store frozen food, which can be
defrosted slowly (meat, fish,
chicken,etc) as needed. Low
temperature compartment is the
coldest place in refrigerator where
dairy products (cheese,butter), meat
fish or chicken can be kept in ideal
conditions storage.
Vegetables and/or fruits should not be
placed in this compartment.
Making ice cubes
Fill the ice - cube tray 3/4 full with
water and place it in the Ice Bank.
Loosen frozen trays with the handle of
a spoon, never use sharp edged
objects such as knives, forks. Store
ice-cubes in the Ice Bank.
Note: If freshly made ice cubes are
not consumed for several weeks and
stored in Ice Bank, they will slowly
reduce in size and eventually
disappear completely.
11

Using the water dispenser
*optional
It is normal for the first few glasses of
water taken from the dispenser to be
warm.
If the water dispenser is not used for
a long period of time, dispose of first few
glasses of water to obtain fresh water.
1. Push in the lever of the water
dispenser with your glass. If you are
using a soft plastic cup, pushing the lever
with your hand will be easier.
2. After filling the cup up to the level you
want, release the lever.
Please note, how much water flows
from the dispenser depends on how far
you depress the lever. As the level of
water in your cup / glass rises, gently
reduce the amount of pressure on the
lever to avoid overflow.
If you slightly press the arm, the water
will drip; this is quite normal and not a
failure.
Filling the water dispenser's tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking water.
3. Close the cover.
Do not fill the water tank with any
other liquid except for water such as fruit
juices, carbonated beverages or
alcoholic drinks which are not suitable to
use in the water dispenser. Water
dispenser will be irreparably damaged if
these kinds of liquids are used. Warranty
does not cover such usages.
Some chemical substances and
additives contained in these kinds of
drinks/liquids may damage the water
tank.
Use clean drinking water only.
12

Capacity of the water tank is 3 liters;
do not overfill.
Cleaning the water tank
1. Remove the water filling reservoir
inside the door rack.
2. Remove the door rack by holding from
both sides.
3. Grab the water tank from both sides
and remove it with an angle of 45°C.
4. Remove the cover of the water tank
and clean the tank.
Components of the water tank and
water dispenser should not be washed in
dishwasher.
Drip tray
Water that dripped while using the water
dispenser accumulates in the spillage
tray.
Remove the plastic filter as shown in the
figure.
With a clean and dry cloth, remove the
water that has accumulated.
13

3. Make sure raw foods are not in
contact with cooked foods in the
fridge.
4. Maximum frozen food storage
volume is achieved without using the
drawers provided in the freezer
compartment. Energy consumption of
your appliance is declared while the
freezer compartment is fully loaded on
shelves without the use of the
drawers.
5. It is recommended that you place
foodstuffs on top shelf of freezer for
initial freezing.
Freezing fresh food
Wrap or cover the food before
placing them in the refrigerator.
Hot food must cool down to the room
temperature before putting them in the
refrigerator.
The foodstuff that you want to freeze
must be fresh and in good quality.
Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
Foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be
kept for a short time.
Materials to be used for packagings
must be resistant to cold and humidity
and they must be airtight. The
packaging material of the food must
be at a sufficient thickness and
durability. Otherwise the food
hardened due to freezing may
puncture the packaging. It is important
for the packaging to be closed
securely for safe storage of the food.
Frozen food must be used
immediately after they are thawed and
they should never be re-frozen.
Placing warm food into the freezer
compartment causes the cooling
system to operate continuously until
the food is frozen solid.
Please observe the following
instructions to obtain the best results.
1. Do not freeze too large quantities of
food at one time. The quality of the
food is best preserved when it is
frozen right through to the core as
quickly as possible.
2. Take special care not to mix already
frozen food and fresh food.
14

Freezer
Compartment
Setting
Fridge
Compartment
Setting
Explanations
-18°C
4°C
This is the normal recommended
setting.
-20, -22 or -24°C
4°C
These settings are recommended when
the ambient temperature exceeds 30°C.
Quick Freeze
4°C
Use when you wish to freeze your food
in a short time. If is recommended to be
used to maintain the quality of meat
and fish products.
-18°C or colder
2°C
If you think that your fridge
compartment is not cold enough
because of the hot conditions or
frequent opening and closing of the
door.
-18°C or colder
Quick Fridge
You can use it when your fridge
compartment is overloaded or if you
wish to cool down your food rapidly. It is
recommended that you activate quick
fridge function 4-8 hours before placing
the food.
Freezer
compartment
shelves
Various frozen food
such as meat, fish, ice
cream, vegetables and
etc.
Egg holder
Egg
Fridge
compartment
shelves
Food in pans, covered
plates and closed
containers
Fridge
compartment
door shelves
Small and packaged
food or drinks (such as
milk, fruit juice and
beer)
Crisper
Vegetables and fruits
Fresh zone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)
Placing the food
Recommendations for
preservation of frozen food
Pre-packed commercially frozen
food should be stored in accordance
with the frozen food manufacturer's
instructions in a frozen food storage
compartment.
To ensure that the high quality
supplied by the frozen food
manufacturer and the food retailer is
maintained, following points should be
noted:
1. Put packages in the freezer as
quickly as possible after purchase.
2. Ensure that contents of the
package are labeled and dated.
3. Do not exceed "Use By", "Best
Before" dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
15

Recommendations for the
fresh food compartment
*optional
Do not allow the food to touch the
temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be
hindered by food.
Do not place hot foods in the
product.
Deep-freeze information
Food must be frozen as rapidly as
possible when they are put in the
freezer in order to keep them in good
quality.
The TSE norm requires (according
to certain measurement conditions) the
refrigerator to freeze at least 4.5 kg of
foodstuff at 32°C ambient temperature
to -18°C or lower within 24 hours for
every 100-liters of freezer volume.
It is possible to preserve the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING!
Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
Foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be kept
for a short time.
Materials necessary for packaging:
Cold resistant adhesive tape
Self-adhesive label
Rubber rings
Pen
Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, dour, oils
and acids.
Foodstuff to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent their
partial thawing. Thawed out food must
be consumed and must not be frozen
again.
16

CLEANING AND CARE
1. We recommend that you switch off the appliance at the socket outlet and
pull out the mains plug before cleaning.
2. Never use any sharp instruments or abrasive substances, soap, household
cleaner, detergent or wax polish for cleaning.
3. Use luke warm water to clean the cabinet of the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of one teaspoon of bicarbonate of
soda to one pint of water to clean the interior and wipe it dry.
5. Make sure that no water enters the temperature control box.
6. If the appliance is not going to be used for a long period of time, switch it
off, remove all food, clean it and leave the door ajar.
7. Any dust that gathers on the condenser, which is located at the back of the
appliance, should be removed once a year with a vacuum cleaner.
8. Check door seals regularly to ensure they areclean and free from food
particles.
9. Never:
Clean the appliance with unsuitable material; eg petroleum based
products.
Subject it to high temperatures in any way, Scour, rub etc., with abrasive
material.
10. Removal of door tray :
To remove a door tray, remove all the contents and then simply push the
door tray upwards from the base.
11. Make sure that the special plastic container (drain tray) at the back of the
appliance which collects defrost water is clean at all times. If you want to
remove the tray to clean it follow the instructions below:
Switch off at the socket outlet and pull out the mains plug.
Push the lug down with the tip of a screw driver & pull out with a jerk
movement.
Clean the drain tray and wipe it dry.
Reassemble, reversing the sequence and operations
12. To remove a freezer drawer, pull it as far as possible, tilt it upwards and
then pull it out completely.
13. To remove the freezer flap door, first open the door 3” and then gently pull
it off. Make sure that the flap is in place before closing the freezer door.
14. Avoid spillage of food particularly small items like rice, peas, beans through
the fan guard as they mai cause the cooling system to block and therefore
operate less efficiently.
17

TROUBLESHOOTING
Please review this list before calling the service. It will save your time and money.
This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not exist
in your product.
18
The refrigerator does not operate.
• The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
• The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE,
COOL CONTROL and FLEXI ZONE).
• Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10°C.
• Door has been opened frequently. >>>Do not open and close the door of
refrigerator frequently.
• Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
• Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
• Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
• Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running
• Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
• The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit
into the socket.
• Temperature settings are not made correctly. >>>Select the suitable temperature
value.
• There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
The operation noise increases when the refrigerator is running.
• The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.
18
