Grundig GD-CI-AP2647P User manual

1
Quick Guide
About this guide
The guide includes instructions for using and managing the product.
Pictures, charts, images and all other information hereinafter are for
description and explanation only. The information contained in the
guide is subject to change, without notice, due to firmware updates
or other reasons.
Please find the latest version at WWW.GRUNDIG-SECURITY.COM
Limitation of Liability / Legal Disclaimer
Abetechs GmbH (Grundig Security) undertakes all reasonable efforts
to verify the integrity and correctness of the contents in this
document, but no formal guarantee shall be provided. Use of this
document and the subsequent results shall be entirely on the user’s
own responsibility. Abetechs GmbH (Grundig Security) reserves the
right to change the contents of this document without prior notice.
Design and specifications are subject to change without prior notice.
The product described herein, with its hardware, software and
documentation is provided “as is”, without any warranty, expressed
or implies, including without limitation, merchantability, satisfactory
quality, fitness for a particular purpose, and non-infringement of a
third party.
In no event will our company and its employees or agents be liable
to you for any special, consequential, incidental, or indirect damages,
including among others, damages for loss of business profits,
business interruption, or loss of data or documentation, in
QG-GD-CI-AP2647P-2018-01-06-V2-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY

2
connection with the use of this product, even if our company has
been advised of the possibility of such damages.
Regarding to products with internet access, the use of the product
shall be wholly at your own risks. Our company shall not take any
responsibilities for abnormal operation, privacy leakage or other
damages resulting from cyber-attack, hacker attack, virus inspection,
or other internet security risks; however our company will provide
timely technical support if required. Surveillance laws vary by
jurisdiction before using this product in order to ensure that your
use conforms to the applicable law. Our company shall not be liable
in the event that this product is used with illegitimate purposes.
In the event of any conflicts between this manual and the applicable
law, the later prevails.
Trademark:
Each of trademarks herein is registered. The name of this product
and other trademarks mentioned in this manual are the registered
trademark of their respective company.
Copyright of this document is reserved. This document shall not be
reproduced, distributed or changed, partially or wholly, without
formal authorization.
OPEN SOURCE SOFTWARE LICENSE INFORMATION
The software components provided with Grundig products may
contain copyrighted software that is licensed under various open
source software licenses. For detailed information about the
contained open source software packages, the used package
versions, license information and complete license terms, please

3
refer to the product detail pages on our website. The complete open
source software license information is also included in firmware files
of affected products. Please also check your product’s CD-ROM and
manuals for additional information.
You may obtain the complete corresponding open source part of a
specific product from us for a period of three years after our last
shipment of this product by sending an email to:
[e-mail]
Safety Instruction
Make sure that you only use the power adapter that is specified in
the specifications sheet of the product. If you use any other adapter
or connect the power supply incorrectly, this may cause explosion,
fire, electric shocks or damage the product. Do not connect several
devices to one power adapter as this may cause an adapter overload
and can lead to over-heating and fire. Make sure that the plug of the
power adapter is firmly connected to the power socket.
Do not place containers with liquids on the product. Do not place
conducting items like tools, screws, coins or other metal items on
the product. These may fall from the product or can cause fire or
electric shocks or other physical injuries.
Do not push or insert any sharp items or any objects into the device
as this may cause damage to the product, fire, electric shocks and/or
physical injuries.
Do not block any ventilation openings, if there are any. Ensure that
the product is well ventilated to prevent any over-heating.
Do not subject the device to physical shock or drop the product.

4
If the product uses batteries, please use a battery type that is
recommended by the manufacturer. Improper use or replacement of
the battery may result in the hazard of explosion.
Do not use any accessories that are not recommended by GRUNDIG.
Do not modify the product in any way.
If the product starts to smell or smoke comes out of the device,
immediately stop using the product and disconnect it from the
power supply to prevent fire or electric shocks. Then contact your
dealer or the nearest service center.
If the product does not work correctly, contact your dealer or
nearest service center. Never open, disassemble or alter the product
yourself. GRUNDIG cannot accept any liability or responsibility for
problems caused by attempted and unauthorized repair and
maintenance.
Special Installation Instructions for IP Cameras
Make sure that the latest firmware is installed on the IP Device. You
may get the latest firmware from grundig-security.com website or
from [e-mail].
Do not touch the sensor module with your fingers.
Do not aim the camera or camera lens at a strong light such as the
sun or a bright lamp. Irreversible damage to the camera can be
caused by a strong light.

5
Do not expose the sensor of the product to laser beams as this may
damage the sensor.
If the product supports IR, you need to take some precautions to
prevent IR reflection. Do not install the product close to reflective
surfaces of objects as this may cause reflection. If the product has a
dome cover, please remove the protection film only after installation
to prevent dust or grease on the camera which can cause reflection.
The foam ring around the lens must be seated flush against the inner
surface of the bubble to isolate the lens from the IR LEDS. Fasten the
dome cover to the camera body so that the foam ring and the dome
cover are attached seamlessly.
For cleaning, use a clean cloth with a bit of ethanol and wipe it
carefully and gently. In any case, do not use alkaline detergents.
If a glove is provided in the package, please use it to open the
product cover. Never touch the product cover directly with fingers,
because the acidic sweat of the fingers may damage the surface
coating of the product cover.

6
Table of Contents
1 Overview......................................................................................... 8
1.1 Cable Descriptions .................................................................... 8
1.2 Alarm Output............................................................................ 9
2 Installation.................................................................................... 10
2.1 Installing the Memory Card .................................................... 10
2.1.1 DE2xxx Series & DE2xxxI Series (IR) PTZ Camera.............. 10
2.1.2 DE3xxx Series PTZ Camera............................................... 12
2.1.3 DY3xxx Series PTZ Bullet Camera..................................... 12
2.1.4 DE4AxxxI Series (IR) PTZ camera...................................... 13
2.2 Installing DE2xxx Series & DE2xxxI Series (IR) PTZ Camera...... 15
2.2.1 Wall Mounting................................................................. 15
2.2.2 Ceiling Mounting ............................................................. 19
2.2.3 Installing with Junction Box ............................................. 24
2.3 Installing DE3xxx Series PTZ Camera....................................... 27
2.3.1 Ceiling Mounting ............................................................. 27
2.3.2 In-ceiling Mounting ......................................................... 29
2.4 Installing DY3xxx Series PTZ Bullet Camera ............................. 32
2.4.1 Dimensions of DY3xxx Series PTZ Bullet Camera.............. 32
2.4.2 Wall Mounting................................................................. 33
2.4.3 Base Mounting ................................................................ 35
2.5 Installing DE4AxxxI Series (IR) PTZ Camera ............................. 36
2.5.1 Ceiling Mounting ............................................................. 36
2.5.2 In-ceiling Mounting ......................................................... 37
3 Setting the PTZ Camera over the LAN........................................... 40
3.1 Wiring .................................................................................... 40
3.2 Activating the Camera ............................................................ 41
3.2.1 Activation via Web Browser............................................. 41

7
3.2.2 Activation via SADP Software .......................................... 43
3.3 Modifying the IP Address........................................................ 44
4 Accessing via Web Browser .......................................................... 47
4.2 Initializing the Memory Card .................................................. 50

8
1Overview
1.1 Cable Descriptions
The cable interfaces of network PTZ camera are shown in Figure 1-1.
The cables are distinguished by different colors. Refer to the labels
attached on the cables for identification.
Notes:
The cables vary depending on different camera models.
Make sure the camera is power-off before you connect the
cables.
Network Cable
Audio Cable
Alarm Cable
Video Cable
RS-485 Cable
Power Cord

9
Figure 1-1 Cables of PTZ Camera
Power Cord: Supports 12 VDC power supply.
Video Cable: Connect BNC Cable to test the video output.
Alarm Cable: Connect terminal ALARM-IN with GND interface,
and connect terminal ALARM-OUT with ALARM-COM interface.
Audio Cable: Connect terminal AUDIO-IN with GND interface.
Network Cable: Connect the network interface with network
cable.
1.2 Alarm Output
Alarm output is shown in Figure 1-2.
Relay Output
OUT (n) DC
OUT (n)
Direct load
+
-
Relay Output
OUT (n)
OUT (n)
DC 30V
1A
Power Supply
GND Output
~220V AC
FireWire
Zero
Line
JQC-3FG
Relay
(10A 250VAC)
Figure 1-2 Alarm Output

10
2Installation
Before you start:
Check the package contents and make sure that the device in the
package is in good condition and all the assembly parts are included.
Notes:
Do not drag the PTZ camera with its waterproof cables;
otherwise the waterproof performance is affected.
Do not touch the bubble directly by hand. The image blurs
otherwise.
Do not power up the camera until the installation is finished. To
ensure the safety of personnel and equipment, all the
installation steps should be done with power supply off.
2.1 Installing the Memory Card
You can install the memory card for local storage.
2.1.1 DE2xxx Series & DE2xxxI Series (IR) PTZ Camera
Steps:
1. Open the memory card cover.

11
Memory Card Cover
Figure 2-1 DE2xxx Series PTZ Camera
Memory Card Cover
Figure 2-2 DE2xxxI Series (IR) PTZ Camera
2. Rotate the cover to a proper position, align the memory card with
the memory card slot and insert it.
Figure 2-3 Insert the Memory Card

12
3. Rotate the cover and push it back.
2.1.2 DE3xxx Series PTZ Camera
Steps:
1. Loosen three screws on the bottom of camera to reveal the
memory card slot, as shown in Figure 2-4.
ResetDebug Memory Card
Figure 2-4 DE3xxx Series PTZ Camera
2. Align the memory card with the memory card slot and insert it.
3. Fix the screws and assemble the PTZ camera.
2.1.3 DY3xxx Series PTZ Bullet Camera
For DY3xxx series PTZ bullet camera, the memory card slot is in the
camera module and if you need, the memory card can be installed
before the camera leaves the factory. In order to prevent damage,
we highly recommend that you do not disassemble the PTZ bullet
camera by yourself.

13
2.1.4 DE4AxxxI Series (IR) PTZ camera
Steps:
1. Remove the four silicone plugs on the decorative rim as shown in
Figure 2-5, and you can see four flange screws in the decorative
rim.
Silicone Plug
Decorative Rim
Figure 2-5 Remove the Silicone Plugs
2. Loosen four flange screws with a screwdriver. Remove the bubble
and the decorative rim as shown in Figure 2-6.
Bubble Flange Srews
Decorative Rim
Figure 2-6 Remove the Bubble and the Decorative Rim

14
3. Open the memory card cover and insert the memory card into the
card slot as shown in Figure 2-7 and Figure 2-8.
Memory Card Slot
Memory Card Cover
Figure 2-7 For 20× Camera Module
Memory Card Slot
Memory Card Cover
Figure 2-8 For 4× Camera Module
4. Close the memory card cover. Fix the four flange screws and push
four silicone plugs back to assemble the PTZ camera.

15
2.2 Installing DE2xxx Series & DE2xxxI Series (IR) PTZ
Camera
DE2xxx series PTZ camera supports wall mounting, ceiling mounting,
and installing with junction box. DE2xxxI Series (IR) PTZ camera
supports wall mounting and ceiling mounting.
2.2.1 Wall Mounting
Before you start:
Make sure the camera is power-off before you install the camera.
Notes:
For cement wall, you need to use the expansion screw to fix the
bracket. The mounting hole of the expansion pipe on the wall
should align with the mounting hole on the bracket.
For wooden wall, you can just use the self-tapping screw to fix
the bracket.
Make sure that the wall is strong enough to withstand more
than eight times the weight of the PTZ camera and its
accessories.
Steps:
1. Rotate the base plate counterclockwise to separate it from the PTZ
camera.

16
Front View of Base Plate
OPEN
Base Plate on the Bottom of the Dome
Figure 2-9 Base Plate for DE2xxx Series PTZ Camera
Front View of Base PlateBase Plate on the Bottom of the Dome
OPEN
Figure 2-10 Base Plate for DE2xxxI Series (IR) PTZ Camera
2. Align the cable hole on the base plate with the hole on the bracket
for wiring. And install the base plate to the bracket by fixing three
PM4*10 screws (supplied) to the holes marked with digit “2”on
the bracket.

17
Figure 2-11 For DE2xxx Series PTZ Camera
Figure 2-12 For DE2xxxI Series (IR) PTZ Camera
3. Route the cables through the cable hole.
4. Align the PTZ camera with the base plate. Rotate the PTZ camera
clockwise to the base plate, and the PTZ camera is secured with
the base plate by three locks on the plate.

18
LOCKOPEN
Figure 2-13 Secure DE2xxx Series PTZ Camera
LOCK
OPEN
Figure 2-14 Secure DE2xxxI Series (IR) PTZ Camera
5. Secure the mounting base to the wall with four PA4*25 screws
(supplied).

19
Figure 2-15 Install the Mounting Base
6. Install the PTZ camera to the bracket.
1). Route the cables of the PTZ camera through the wall bracket.
2). Connect the corresponding cables.
3). Hang the bracket together with the PTZ camera on the
mounting base.
4). Fix the mounting base with a PM4*10 screw.
Figure 2-16 Secure the Mounting Base
2.2.2 Ceiling Mounting
Purpose:
There are two ceiling mounting types provided for the camera, and
we take the mounting without the junction box as the example.
