Grundig GCH-K0323V User manual

GCH-K0323V.67.1.24.07.2012
Owner's Manual
EN
© ASP AG
HD-SDI Cameras & Domes
GCH-K0323V 2 Megapixel Full HD CMOS V-Fixed Dome HD-SDI
Camera ICR
GCH-K0326V 2 Megapixel Full HD CMOS V-Fixed Dome HD-SDI
Camera IR 28 LED

Content:
1. Introduction 2
2. Important Safety Instructions 2
3. Package Contents 2
4. Installation 2
1. Installation Remarks
2. Part Names 3
3. Zoom & Focus Adjustment
4. 3-Axis Gimbal Adjustment 6
5. Operation and Configuration 7
1. OSD Menu Tree
2. OSD Control Key
3. OSD Menu Configuration 9
6. OSD Menu 9
1. Lens 9
2. Exposure 10
3. Backlight 11
4. Day&Night 12
5. White Balance 13
6. DNR (Digital Noise Reduction) 14
7. Image 14
8. Motion 16
9. System 16
1
English

1. Introduction
Based on the Television Standard for Full HD Television, HD-SDI products feature 2
Megapixel (1920x1080) pictures in real-time (30fps) transmitted over coax cabling.
Get the advantages of an IP technology without their drawbacks. Get 16:9 megapixel
pictures without network configuration, bandwidth problems and network security risks.
Use existing coax cables and only exchange the cameras and recorders. Get a “real” live
picture and see the things that happen in the now, not a few seconds later. Connect a
monitor directly to a camera using only a HD-SDI-to-HDMI converter.
HD-SDI products are easy to handle, easy to install and produce amazing high quality
pictures.
2. Important Safety Instructions
Be sure to use only the standard adapter that is specified in the specification sheet.
Using any other adapter could cause fire, electrical shock, or damage to the product.
Incorrectly connecting the power supply may cause explosion, fire, electric shock, or
damage to the product. Do not connect multiple products to one single adapter.
Exceeding the capacity may cause abnormal heat generation or fire.
Do not place conductive objects (e.g. screwdrivers, coins or any metal items) or
containers filled with water on top of the product. Doing so may cause personal injury
due to fire, electric shock, or falling objects.
If any unusual smells or smoke comes out of the unit, stop using the product. In this
case, immediately disconnect the power source and contact the service center.
Continued use in such a condition may cause fire or electric shock.
If this product fails to operate normally, contact the nearest service center. Never
disassemble or modify this product in any way. (GRUNDIG is not liable for problems
caused by unauthorised modifications or attempted repair.)
To prevent fire or electric shock, do not expose the inside of this device to rain or
moisture.
3. Package Contents
These parts are included:
HD-SDI Camera, Installation Material, Video Test Cable, User's Manual
4. Installation
4.1. Installation Remarks
Do not install the product in a location subject to high temperature (over 50°C), low
temperature (below -10°C), or high humidity. Doing so may cause fire or electric shock.
Keep out of direct sunlight and heat radiation sources. This may cause fire. Avoid aiming
the camera directly towards extremely bright objects such as the sun, as this may
damage the image sensor.
Do not install the unit in humid, dusty or sooty locations. Doing so may cause fire or
electric shock. Install it in a place with good ventilation.
2English

When installing the unit, fasten it securely and firmly. A falling unit may cause personal
injury.
If you want to relocate the already installed product, be sure to turn the power off and
then move or reinstall it.
Connect the HD-SDI Camera to other devices as shown in the diagram to complete a
video surveillance solution. HD-SDI products can be connected through BNC cables.
The installation is Plug & Play. There is no further configuration necessary.
If you do not get a signal, please check whether all cables are connected correctly. The
distance of HD-SDI signals is limited to approx. 100-120m when using a RG59 cable. If
you want to use HD-SDI for further distances, please use either a higher quality cable
(RG6 approx. 300m) or the Grundig HD-SDI repeater GTH-K0011E that will extend the
transmitting distance to 200-240m.
3English

4.2. Part Names
4English

4.3. Zoom & Focus Adjustment
1. Flip over the Cover of the Camera.
2. Adjust the Viewing Angle by using the lever located in the back. Adjust the Focus by
using the lever in the front.
5English

4.4. 3-Axis Gimbal Adjustment
1. Turn the Module Base left or right to adjust the Pan.
2. Move the Cover of the Camera up or down to adjust the Tilt.
3. Rotate the Camera Module to set the camera to the desired angle.
6English

5. Operation and Configuration
5.1. OSD Menu Tree
The OSD setup menu structure is listed in the following section. The star symbol
indicates the factory default. For detailed function description, please refer to 6. OSD
Menu.
7English

5.2. OSD Control Key
SET and Direction (RIGHT/LEFT/UP/DOWN) Key:
Press this key to enter the Setup menu. Push the key up, down, left and right to move
around in the OSD.
VIDEO TEST Output:
Connect the Video Test Cable with this connection to receive an analogue video signal
for an easy installation.
LED VOLUME LEVEL:
Control herewith the intensity of the IR LEDs.
8English

5.3. OSD Menu Configuration
1. Press the SET key to access the menu mode.
2. Select the desired feature by using the UP/DOWN direction (/\ \/) of the SET key. If an
ENTER arrow (↵) is displayed next to the feature, press the SET key to access the
feature's menu.
3. If there is a setting for this feature on the right side of the screen, use the
LEFT/RIGHT direction to switch between the settings and confirm your choice by
pressing the SET key.
4. When the settings are completed, go to EXIT to save and leave the OSD.
6. OSD Menu
6.1. Lens
Here you can configure the lens setting.
LENS [DC, MANUAL] :
If you are using a lens with manual Iris, set this item to MANUAL. If you are using a DC
controlled lens, set it to DC.
9English

If you choose DC, you will be able to select
if the camera is used indoors or outdoors.
The lens and shutter control will be
automatically optimised according the
present situation.
- MODE [INDOOR, OUTDOOR] :
If you choose INDOOR, the Iris and the
shutter are set to fixed values. This will
prevent a “rolling effect” of the image. If you
choose OUTDOOR, the Iris and shutter
settings are flexible and will adjust
accordingly to the current brightness
situation.
6.2. Exposure
When selecting ↵, the following submenu will appear.
The exposure is the amount of light
received by the image sensor and is
determined by the width of lens diaphragm
opening, the amount of exposure by the
sensor (shutter speed) and other exposure
parameters. With this item, users can
define how the Auto Exposure function
BRIGHTNESS [0 ~20] :
This function is used to adjust the brightness of the camera picture.
SHUTTER [OFF, AUTO, 1/25, 1/50, 1/FLK, 1/240, 1/500, 1/1000,1/2000, 1/4000,
1/8000, 1/16000, 1/30000, 1/60000] :
You can select one of 14 options from 1/25 to 1/60000K for the fixed high speed
electronic shutter, which is mostly used for imaging a fast moving object.
SENS-UP [OFF, AUTO, x2~x64] :
Automatically detects the ambient level of darkness in a dark or low contrast scene to
extend the accumulated time, keeping the image bright and sharp.
AGC (Automatic Gain Control) [0-20] :
The AGC (Auto Gain Control) function is used to amplify the video signal when it falls
below the set parameter. As the AGC level increases, the overall screen gets brighter
but the level of noise will also increase at the same time.
10 English

6.3. Backlight
To overcome difficult light situations, the GRUNDIG HD-SDI cameras feature different
options to improve the image quality.
HLC (High Light Compensation):
This function is used to surpress or mask a
strong light source (for example, headlights
of cars during night-time) so that other
subjects can be seen in more detail. If you
select HLC, a submenu appears where you
can make finer adjustments.
- HLC LEVEL: Adjust the brightness level
from which on the light source is to be
masked out.
BLC (Back Light Compensation):
This function is used to counterbalance the
screen image by increasing the brightness
so that a subject which appears dark due to
a strong backlight can be displayed in more
detail. If you select BLC, a submenu
appears where you can make finer
adjustments.
- H-POS/ V-POS/ H-SIZE/ V-SIZE: Define
the position and size of the area of interest
by changing the position & size.
WDR:
The WDR (Wide Dynamic Range) function
works to correct excessive light within the
frame to produce a usable image. When the
image has simultaneous bright and dark
areas, it makes both areas distinct. If you
select WDR, a submenu appears where you
can make finer adjustments.
- WEIGHT [MIDDLE, HIGH, LOW]: Select
the WDR level of the camera.
11
English

NOTE: The WDR function might lead to a reduced framerate and “ghost” effects in areas
with very bright background.
6.4. Day&Night
Here you can choose different settings to control the DAY&NIGHT function.
COLOUR: The camera is always in colour mode regardless of the ambient conditions.
B/W: The camera is always in Black & White mode regardless of the ambient conditions.
EXTERN:
Here you can activate the EXTERN function to activate the external Day & Night
connector on the rear panel of the camera. If you select EXTERN, a submenu appears
where you can make finer adjustments.
- DELAY [MIDDLE, HIGH, LOW]: Set the delay time for switching between COLOUR
and B/W.
AUTO:
The camera will automatically switch between DAY and NIGHT mode, according to the
lighting condition. If you press the SET key, the AUTO sub-menu is selected.
- AGC THRES [0-20]: Execute the
Day/Night switch depending on the AGC
level that is used to increase the brightness
of the image. Higher values require a darker
illumination to execute the switch.
- MARGIN [0-20]: Define the difference
between the Day/Night & Night/Day switch
based on AGC THRES. Higher values will
increase this distance and can help to
prevent continuous switching between Day
& Night mode.
12 English

- DELAY [MIDDLE, HIGH, LOW]: Set the delay time for switching between COLOUR
and B/W.
6.5. White Balance
The camera needs to find a reference colour temperature, which is a way of measuring
the colour of a light source, for calculating all the other colours. The unit for measuring
this ratio is in degree Kelvin (K). You can select one of the White Balance Control modes
according to the installation condition.
ATW (Auto Tracking White Balance):
With the Auto Tracking White Balance function, the white balance in a scene will be
automatically adjusted while temperature colour is changing. The ATW Mode is suitable
for environments with a light source having a colour temperature in the range roughly
from 1800 ~ 10500K.
AWB (Auto White Balance):
In this mode, white balance works within its colour temperature range. This mode
computes the white balance value output using the colour information from the entire
screen. It outputs the proper value using the colour temperature radiating from a black
subject.
PRESET:
This mode is set to the current white balance condition and keeps its value. Select this
mode and then press the SET key. If there is a change in location or light source, please
repeat this procedure.
13
English

MANUAL:
Can be used for fine adjustment. Set the
White Balance by first using ATW or AWC
and then change to MANUAL and press the
SET key. Increase or decrease the value of
R-Gain (Red) and B-Gain (Blue) while
monitoring the colour of the image.
- R-GAIN: Adjusts the White Balance for the
colour Red.
- B-GAIN: Adjusts the White Balance for the
colour Blue.
6.6. DNR (Digital Noise Reduction)
This function is used to improve the picture quality by filtering the noise which is
generated under low bright light conditions. You can set different levels here.
6.7. Image
When selecting ↵, the following submenu will appear.
Here you can optimise the image quality by
adjusting different options.
SHARPNESS [1 ~ 10] :
Adjusts the image sharpness. If the level
goes up excessively, it may affect the video
image and generate a noise.
GAMMA [0.45 ~ 0.65] :
Changes the gamma curve of the camera.
COLOR GAIN [0 ~ 20] :
Kontrollieren Sie die Farbsättigung des Video-Bildes.
MIRROR [ON, OFF] :
Mirrors the image horizontally on the screen.
FLIP [ON, OFF] :
Flips the image vertically on the screen.
D-ZOOM [1.0x~8.0x] :
You can use the up to x8 bi-cubic linear digital zoom.
14 English

D-WDR [LOW, MIDDLE, HIGH, OFF] :
The WDR (Wide Dynamic Range) function works to correct excessive light within the
frame to produce a usable image. When the image has simultaneous bright and dark
areas, it makes both areas distinct.
SHADING [ON, OFF] :
Compensates the shading effects of lenses
when the lens is set to a very wide angle.
This function will reduce the brightness
difference between the centre and the
edges. If you select ON, a submenu
appears where you can make finer
adjustments.
- WEIGHT [1%~100%] : You can set
different levels here.
PRIVACY [ON, OFF] :
Masks areas that you want to hide on the
screen. The camera can activate up to 32
privacy masks. Switch between ON and
OFF to activate or deactivate this function.
- ZONE NUM [0 ~ 32]: Select a mask out of the 32 mask areas and set the options
below for the selected mask.
- ZONE DISP [ON, OFF]: Choose ON to activate privacy masks and press OFF to
deactivate masks.
- H-POS [0 ~ 60]: Define the horizontal start position of the privacy mask.
- V-POS [0 ~ 40]: Define the vertical start position of the privacy mask.
- H-SIZE [0 ~ 40]: Define the horizontal size of the privacy mask.
- V-SIZE [0 ~ 40]: Define the vertical size of the privacy mask.
- Y LEVEL [0 ~ 20]: Define the brightness of the mask colour.
- CR LEVEL [0 ~ 20]: Define the red amount of the mask colour.
- CB LEVEL [0 ~ 20]: Define the blue amount of the mask colour.
15
English

6.8. Motion
This function is used to detect moving
objects in the monitored area. When
choosing ON, the following submenu will
appear where you can adjust the settings
for the MOTION function.
SENSITIVITY [1 ~ 20] :
Set the sensitivity of the motion detection.
DET H-PS [0 ~ 60] :
Define the horizontal start position of the monitoring area.
DET V-PS [0 ~ 40] :
Define the vertical start position of the monitoring area.
DET H-SIZE [0 ~ 60] :
Define the horizontal size of the monitoring area.
DET V-SIZE [0 ~ 40] :
Define the vertical size of the monitoring area.
MOTION OSD [ON, OFF] :
Controls the ON/OFF status of the motion detection block display.
ALARM [ON, OFF] :
When the ALARM function is activated, the camera will detect movement within a
monitoring area and then send an alarm signal automatically. The flash warning notice
"MOTION !!!" will be displayed in the upper left corner of the screen. When the camera is
moved, the flash warning notice "MOVING !!!" will be displayed in the upper left corner of
the screen.
6.9. System
When selecting ↵, the following submenu will appear.
16 English

COLOR SPACE [COLOR1~3] :
Select different colour settings for a warmer
or a colder image.
FRAME RATE [25 FPS, 30 FPS] :
Choose a frame rate.
CVBS [PAL, NTSC] :
Select the video format that matches the
present TV system
RESET [ON↓] :
All settings will be restored to factory default.
17
English

Specifications GCH-K0323V
Image Sensor 1/2.8" CMOS Sony Exmor, 2.4 Megapixel
Pixels - Total 2000(H) x 1121(V)
Pixels - Effective 1984(H) x 1105(V), 2.19M pixels
Scanning System Progressive
Image Size 1920x1080
Frame Rate 30, 25 fps at 1080p
Sensitivity Colour 0.5 Lux @ F1.2 (IRE50)
Sensitivity B&W 0.3 Lux @ F1.2 (IRE50)
Sens Up Off ~ x64
S/N Ratio 50 dB
Video Outputs 1 Ch HD-SDI BNC or 1 Ch Composite BNC
Focal Length 2.8 ~ 10 mm
Lens Drive Type DC Auto Iris
High Speed Shutter 1/25 ~ 1/60.000 sec
Shutter Mode Auto / Fix
Col/B&W On/Off/Auto, IR-cut filter removable (ICR)
OSD Yes
Number of Privacy Zones 32
BLC WDR / BLC / HLC / OFF
Digital Noise Reduction (DNR) Off/Low/Mid/High (Adaptive 3D + 2D)
Motion Detection On/ Off/ Sensitivity/ Area setting
White Balance ATW, AWB, Manual, Preset
Protection Rating IP66 / IK10
Operating Temperature -10°C ~ +50°C
Storage Temperature -20°C ~ +60°C
Humidity less than 85%
Supply Voltage 12 VDC/24 VAC
3 WPower Consumption
1.4 kgWeight
Ø150 x 99 mmDimensions (wxhxd)
Specifications GCH-K0326V
Sensitivity Colour 0.5 Lux @ F1.2 (IRE50)
Sensitivity B&W 0 Lux LED IR on
IR LED 28 pcs.
6 WPower Consumption
1.4 kgWeight
Ø150 x 99 mmDimensions (wxhxd)
18 English
