GRUP ARGE RKR Series User manual

RKR Series
Reactive Power Control Relay
User Manual
Version 1.2
1
ADDRESS: İkitelli OSB Mah. Environment 14th Block Street. Telas Blok
Exterior Door No: 1 Floor: 1-2 Başakşehir/Istanbul
Phone: [phone] Fax: [phone] [email protected]
Reactive Power Control Relay
Menu
Installation
S. Recognition
Compensa
Modbus
Alarm
Generator
Target Cos
Stage
Load
Add Power

Reactive Power Control Relay User Manual
2
CONTENTS
INTRODUCTION ............................................................................................................................................................. 5
INSTALLATION (SETUP) .................................................................................................................................................. 6
GENERAL FEATURES ...............................................................................................................................................................16
TECHNICAL FEATURES............................................................................................................................................................. 17
RKR 12/18/24 RELAY TECHNICAL DRAWING ................................................................................................................. 20
RKR 12/18/24 RELAY CONNECTION DIAGRAM ............................................................................................................. 21
RKR 12/18/24 CURRENT TRANSFORMER CONNECTION DIAGRAM ................................................................................ 22
USER ACCESS LEVELS .................................................................................................................................................... 23
1. QUICK MENU ............................................................................................................................................................. 24
1.1. STAGE MENU....................................................................................................................................................... ........ 24
1.1.1. Stage Powers ......................................................................................................................................................24
1.1.2. Stage Recognition ..............................................................................................................................................24
1.1.2.1. Recognizing All Stages ...................................................................................................................................................24
1.1.2.2. Single Stage Recognition................................................................................................................................................25
1.1.3. Manual Stage Control ........................................................................................................................................25
1.2. RESPONSE TIME ..............................................................................................................................................................25
1.3. MODBUS ADDRESS .......................................................................................................................................................... 25
1.4. INSTALLATION (SETUP)..................................................................................................................................................... 25
2. PIN .............................................................................................................................................................................. 26
2.1. INPUT PIN ...................................................................................................................................................................... 26
2.2. NEW PIN.....................................................................................................................................................................26
3. EVENTS ........................................................................................................................................................................26
3.1. LIST .............................................................................................................................................................................. 27
3.2. SET VALUES .....................................................................................................................................................................27
3.2.1. Low Voltage Limit ................................................................................................................................................27
3.2.2. High Voltage Limit ............................................................................................................................................... 27
3.2.3. High Temperature Limit ........................................................................................................................................28
3.3. DELETE.............................................................................................................................................................................28
4. STAGE ............................................................................................................................................................................28
4.1. STAGE POWER ...................................................................................................................................................................28
4.2. STAGE RECOGNITION ...........................................................................................................................................................28
4.2.1. All Stages ...............................................................................................................................................................29
4.2.1.1. Intelligent (Automatic) Recognition ...................................................................................................................................29
4.2.1.2. Sequential Recognition ......................................................................................................................................................29
4.2.1.3. Series Recognition ..............................................................................................................................................................29
4.2.2. Single Stage Recognition ........................................................................................................................................ 29
4.3. STAGE CONTROL ............................................................................................................................................................30
4.4. STAGE SETTINGS .................................................................................................................................................................30
4.4.1 Discharge Time ........................................................................................................................................................ 30
4.4.2. Stage Associate ......................................................................................................................................................30
4.4.3. Simultaneous Aging ...............................................................................................................................................30
4.4.3.1. Control ...............................................................................................................................................................................31
4.4.3.2. Percentage .........................................................................................................................................................................31
4.4.4. Stage Break Period .................................................................................................................................................31
4.4.5. Automatic Stage Recognition Setting .....................................................................................................................31
5. SETTINGS .........................................................................................................................................................................31
5.1. Transformer .......................................................................................................................................................................32
5.1.1. Current Transformer Value.....................................................................................................................................32
5.1.2. Voltage - Current Matching....................................................................................................................................32
5.1.3. Current Transformer Direction .............................................................................................................................. 32
5.1.4. Line Voltage ...........................................................................................................................................................32
5.1.5. Measuring Voltage .................................................................................................................................................33
5.1.6. Current Transformer Setting Menu.........................................................................................................................33

Reactive Power Control Relay User Manual
3
5.2. PROGRAM ...................................................................................................................................................................33
5.2.1. Penalty Limits .................................................................................................................................................... 33
5.2.1.1. Inductive Limit Value....................................................................................................................................................33
5.2.1.2. Capacitive Limit Value....................................................................................................................................................34
5.2.2. Response Time................................................................................................................................................... 34
5.2.2.1. Inductive Response Time .............................................................................................................................................34
5.2.2.2. Capacitive Response Time .............................................................................................................................................34
5.2.2.3. Normal Response Time.................................................................................................................................................34
5.2.3. Additional Power............................................................................................................................................... 35
5.2.3.1. Power............................................................................................................................................................................35
5.2.3.2. Duration........................................................................................................................................................................35
5.2.4. Target Cos(φ)..................................................................................................................................................... 3 5
5.2.5. Generator .......................................................................................................................................................... 35
5.2.5.1. Program .......................................................................................................................................................................36
5.2.5.2. Generator Cos(φ) .........................................................................................................................................................36
5.2.6. Hysteresis .......................................................................................................................................................... 36
5.2.6.1. Inductive Hysteresis Rate.............................................................................................................................................36
5.2.6.2. Capacitive Hysteresis Rate ..........................................................................................................................................36
5.2.6.3. Normal Hysteresis Rate...............................................................................................................................................37
5.2.7. Compensation Hysteresis ..................................................................................................................................37
5.3. MODBUS...................................................................................................................................................................37
5.3.1.Modbus Address ................................................................................................................................................ 37
5.3.2.Baud Rate Speed ................................................................................................................................................ 38
5.4. DISPLAY SETTINGS ..........................................................................................................................................................38
5.4.2. Language Menu ................................................................................................................................................40
5.4.3. Screen Type Selection........................................................................................................................................ 40
5.4.4. Display Cycle ....................................................................................................................................................40
5.4.3.1. Automatic....................................................................................................................................................................40
5.4.3.3. Duration.......................................................................................................................................................................40
5.5. PROFESSIONAL SETTINGS................................................................................................................................................. 38
5.5.1. Device Off-On .................................................................................................................................................... 41
5.5.2. Factory Settings ................................................................................................................................................ 41
5.5.3. Device Reset ...................................................................................................................................................... 41
5.5.4. Earnings Multiplier............................................................................................................................................ 41
5.5.5. Reset Response Time .......................................................................................................................................... 41
5.5.6. Next Response Time .......................................................................................................................................... 42
5.5.7. New Response Time ......................................................................................................................................... 42
5.5.8. Developer Menu .................................................................................................................................................42
5.6. INFORMATION ............................................................................................................................................................... 42
6. POWER FLOW PROFILE ............................................................................................................................................. 42
6.1. EXAMPLE .....................................................................................................................................................................43
6.2. DELETE........................................................................................................................................................................43
6.3. PERCENTAGE LIMIT ........................................................................................................................................................43
7. ANALYZER ................................................................................................................................................................ 43
7.1. DELETE ENERGY VALUES.................................................................................................................................................. 43
7.3. DELETE PEAK VALUES ....................................................................................................................................................44
7.4. DELETE DEMAND VALUES ..............................................................................................................................................44
8. INSTALLATION (SETUP)............................................................................................................................................. 44
8.1. START SETUP ............................................................................................................................................................... 45
8.2. SETUP SETTINGS ...........................................................................................................................................................45
8.2.1. Type.................................................................................................................................................................. 45
8.2.2. Automatic Voltage - Current Matching ............................................................................................................45
8.2.3. Number of Tests .............................................................................................................................................. 45
8.2.4. Automatic Control............................................................................................................................................46
8.3. SETUP PROFESSIONAL SETTINGS .......................................................................................................................................46
EVENT CODES AND DESCRIPTIONS ............................................................................................................................. 48
MODBUS MAP ............................................................................................................................................................ 49
TABLES ........................................................................................................................................................................ 50

4
Reactive Power Control Relay User Manual
PROPER USE AND SAFETY REQUIREMENTS
Cihaz panoya bağlanırken ve panodan sökülürken tüm enerjiyi kesiniz.
Cut all the power when connecting and disconnecting the device
to a panel.
Do not clean the device with a solvent or similar material. Only use a dry
cloth.
Please do not intervene to the device when a technical problem is
encountered and get in contact with a technical service within the shortest
time.
If the warnings are not taken into account, our company or the authorized
dealer shall not be held responsible for the negative consequences.
Do not dispose in the trash, the device must be delivered to the collection
centers (electronic device recycling centers). It should be recycled or
disposed of without harming human health and environment.
(See: RKR 12/18/24 current transformer connection diagram, sf:22)
The installation, assembly, activation and operation of the device should be done
and used by only expert professionals and in accordance with safety
regulations and instructions.
The device operates with current transformers. Do not strictly leave current
transformer tips unattached. Dangerous high voltage can occur.
The common supplies of the stage terminals must be connected to any phase
with a 6 Ampere fuse separately. We absolutely do not recommend parallel
connection! When separate fuses are connected to the partners, the fuse
protection will be activated in the event of a short circuit in the contactors
over time, and only the relevant stage blocks will be deactivated, allowing the
device to continue compensation with other blocks. Otherwise (when a single
fuse is used with parallel connection), all stages will be deactivated due to a
problem occurring in one contactor!
Current transformers should be placed immediately at the output of the main
switch of the enterprise.

5
Reactive Power Control Relay User Manual
INTRODUCTION
Preliminary information
main menu by pressing the Input Button.
can change the flashing selections using the Ok Buttons.
Enter the
The user
You can
The Exit
enter a desired sub-menu with the Enter button.
button is used to return to the next menu.
In order to follow the sub-menus, the numbering at the top of the screen is used.
oFor example, when the Input Button is pressed immediately after the
device is switched on, the numbering 1.--- will appear at the top of the screen.
arrow button is pressed, the top line will change to 2.---
oWhen the up
oWhen the Enter Button is pressed, 2.1--will appear on the top line,
oPress the exit button to return to the top menu in the form of 2.---
oThe numbering at the top of the screen can be followed in the user manual
to make it easier to understand the manual.
For example; if you want to recognize all stages sequentially with
the help of the submenu in 4.2.1.2’ it will be enough to follow the
path 4.2.1.2. yfrom the device screen.
IMPORTANT NOTE: Each heading number in the manual also refers to the
menu numbering in the device.
Recommendations for Installation with Capacitors:
In order to get results in a shorter
time during installation with
capacitors, it is recommended to
connect capacitors to the first stages
starting with three-phase large power
capacitors and reactors to the last
stages.
If compensators (capacitor or
reactor) are placed in stages in a
complex way, without taking into
account their characteristics, it is
recommended to switch off the
supply fuses of the reactors before
installation with capacitors.
Recommendations for Installation with Reactors:
During installation with reactors, it is
recommended to connect the reactors
to the first stages, starting with the
three-phase high power reactors, and
the capacitors to the last stages, in
order to obtain results in a shorter
time.
If compensators (capacitor or reactor)
are placed in a complex way in
stages, without taking into account
their characteristics, it is
recommended to switch off the
supply fuses of the capacitors before
the installation with reactors.
The factory default installation setting is set as installation with capacitors.
indicating that a sub-menu has been entered.

6
Reactive Power Control Relay User Manual
We are Starting the Installation (Setup)
After the device connections are made in accordance with the connection diagram, the device is
energized.
When the device is energized, the "Serial Number" screen shown in Figure 1 appears. By pressing
the Enter Button or after 3 seconds, it automatically switches to the next screen. "Current
Transformer" screen appears as shown in Figure 2. Select the current transformer value
using the Up/Down Ok Buttons and press the Enter Button.
The device then automatically starts setup, the flashing red "Setup" LED positioned on the left
side of the device lights up steadily after the setup starts. During the setup, the device checks
the line parameters such as current control, voltage control, voltage-current matching and
current directions as shown in Figure 3 and Figure 4. If no faulty situation is encountered, the
"StupxbAsArili" text appears on the screen and the relay automatically switches to stage
recognition.
When the device automatically moves to the stage recognition test after the installation is
complete
The "Setup" LED turns off and the red " Stage Recognition" LED lights up as shown in Figure 6.
Figure 1. The first opening screen
showing the "Serial Number" of
the device
Figure 2. Screen display that shows
the current transformer value
(Current Transformer Value) in X/5
format
Figure 4. Screenshot of "Current
Transformer Secondary Directions"
detected by the device during
installation
Figure 3. Matching during installation
Screenshot showing “Voltage-Current
Pairs”

Reactive Power Control Relay User Manual
7
Installation
S.. Recogniti Installation in progress
Relay Recognises
Stages
Weight
Compensa
Modbus
Alarm Relay
In Compensation
Generator
Target Cos
Inductive
Capacitive
Menu
Figure 5. Stage LEDs at the top of the device showing the status of the stages
The stage recognition process as shown in Figure 7 continues with the display of each
recognized stage value on the screen, while the information of which stage is activated can be
followed from the green colored Stage LEDs bar at the top of the device as shown in Figure 5,
and after the recognition process of the last stage is completed, the "Stage Recognition" LED
turns off and the green "Compensate" LED lights up. The device now starts to compensate with
the stages it recognizes.
If the compensator connected to the recognized stage is a capacitor, the capacitive red LED on
the left side of the device (as in Figure 7) and if it is a shunt reactor, the inductive blue LED on
the left side of the device lights up.
NOTE: During setup and stage recognition operations, if the Exit Key is held
down for 4 seconds, the current operation is canceled and terminated.
If an incorrect situation is encountered during installation; The device automatically
corrects some errors (e.g. voltage-current mismatch). In cases of incorrect connections that the
device cannot correct, the device stops the installation without completing the installation by
reporting the incorrect status as shown in Figure 8.
Example Error 4. The screenshot showing that the
voltage input of the first phase is empty
(Check the voltage connection of the first phase.)
Figure 7. The value of a stage
containing a capacitive characteristic
load screenshot showing
Figure 6. From the Status LEDs on
the left side of the device, the
"K.Recognition" LED is set to lights
up continuously during recognition.

8
Reactive Power Control Relay User Manual
Some Faulty Situations During Installation
Example Error 1. Screenshot showing
that the current of the third phase is
high
(Check the third phase current input
and current transformer value).
Example Error 2. Screenshot showing
that the currents of the second and third
phases are high
(Check the current inputs of the second
and third phases and the current
transformer value).
Example Error 3. Screenshot showing
that the currents of all phases are high
(Check the current inputs of all phases
and all current transformer values).
Example Error 4. Screenshot showing
that the voltage input of the first phase
is empty
(Check the voltage connection of the
first phase.)
Example Error 5. Screenshot showing
that the voltage inputs of the second
and third phases are empty
(Check the voltage connections of the
second and third phases).
Example Error 6. Screenshot showing
that the voltage inputs of the first and
third phases are empty
(Check the voltage connections of the
first and third phases.)
Example Error 7. Screenshot showing
that the voltage of the first phase is
low
(Check the voltage of the first phase.)
Example Error 8. Screenshot showing
that the voltages of the second and
third phases are low
(Check the voltages of the second and
third phases).
Example Error 9. Screenshot showing
that the voltages of the first and third
phases are low
(Check the voltages of the first and
third phases.)

Reactive Power Control Relay User Manual
9
Example Error 10. Screen display
showing that the current input of the
second phase is empty
(Check the current connection of the
second phase.)
Example Error 11. Screenshot
showing that the current inputs of the
first and third phases are empty
(Check the current connections of the
first and third phases.)
Example Error 12. Screenshot showing
that the current inputs of all phases are
empty
(Check the current connections of all
phases.)
Example Error 16. Screenshot showing
that the current transformer terminals of
the first and second phases are
connected by mixing them to form a loop
(Check the terminals of the current
transformers of the first and second
phases).
Example Error 17. Screenshot showing
that the current transformer terminals
of all phases are connected by mixing
them to form a loop among themselves
(Check the terminals of the current
transformers of all phases.)
Example Error 18. Screenshot
indicating that the installation could
not be completed with the available
stages
(Check the connections and steps and
repeat the installation).
Example additional Error 13.
Screen display showing Phase/
Neutral connection error
(Check phase inputs and neutral
connection.)
Example Error 14. Screenshot showing
stage connection error
(Check the stage connections.)
Example Error 15. Screen display
showing that the current transformer
is not connected
(Please connect the current
transformer.)

Reactive Power Control Relay User Manual
10
In cases of faulty connections that the device cannot correct automatically, the operator corrects
these errors by taking into account the warnings of the device and when the device is re-
energized, the device automatically starts the installation and automatically switches to the
stage recognition step if it does not encounter any errors.
NOTE: During setup and stage recognition operations, pressing and holding the Exit Key
for 4 seconds will cancel and terminate the operation.
Example Error 20. Screenshot
showing that the operating load is not
stable
(Perform your test when the
operating load is more stable.)
Example Error 21. Screenshot
showing that all stage partners are
empty
(Check the commonality of the
stages to be used.)
Example Error 24. Screenshot indicating
that the stage has exceeded the pull-up/
release limit
(Check the connections and repeat the
process at more stable current).
Example Error 22. Screen display
showing that the voltage-current
terminals of the 1st and 2nd phases are
not matched when automatic voltage-
current matching is off
(Make sure that the voltage and
current terminals of the 1st and 2nd
phases are connected in the correct
order).
Example Error 23. When automatic
current-voltage matching is off;
screenshot showing that the voltage-
current terminals of all phases are not
matched
(Make sure that the voltage and
current terminals of all phases are
connected in the correct order).
Example Error 19. Screenshot showing
that the voltages connected for the first
and second phases are in the same
phase
(Make the correct voltage connection to
the first and second phases.)

11
1 - Stage LEDs: These are the LEDs where all stage states are monitored. The LED of
the tapped stage is switched on. The blinking LED indicates that the discharge time of
the relevant stage is running. When the LED of the relevant stage turns off, the stage
is ready to be activated.
2 - Inductive Load LED: When this LED is on, it means that the load drawn from the
network is inductive.
3 - Capacitive Load LED: When this LED is on, it means that the load drawn from
the network is capacitive.
4 - Seven Segment Display: All powers, ratios, values, warnings and menu
parameters are monitored from this screen.
5 - K (x1000) LED: When this LED is lit, the values shown on the display must be
multiplied by 1000. (kWatt, kVAr, kA...)
Reactive Power Control Relay User Manual
Reactive Power Control Relay Front Panel View
Reactive Power Control Relay
Installation
S. Recognition
Compensa
Modbus
Alarm
Generator
Target Cos
Stage
Menu
Load

12
Reactive Power Control Relay User Manual
6 - Capacitive LED: It is the LED indicated by the sign on the lexan . If the ratio of
the reactive power drawn from any phase to the active power exceeds the determined
capacitive limit, this red LED lights up.
7 - Normal LED: It is the LED indicated with its sign on the lexan . If the ratio of
the reactive power drawn from all three phases to the active power is between the
End / Close limits of the relay, the green colored normal LED lights up.
8 - Inductive LED: It is the LED indicated by the sign on the lexan . If the ratio of
the reactive power drawn from any phase to the active power exceeds the determined
inductive limit, this blue LED lights up.
9 - Exit Key: It allows to return to a previous operation in the menu and return to a
sub-menu.
10 - Down OK Key: Allows downward movement on the operation screen and in the
menu.
11 - Up OK Key: Allows upward movement on the operation screen and in the menu.
12 - Enter Key: Allows to enter the menu and move to a sub-menu.
13 - Status LEDs:
Setup: Indicates that the device is in the setup state. If this LED flashes, it means that
the device needs to be set up.
Stage Recognition: Indicates that the device is in stage recognition. If this LED
flashes, it is understood that the stage recognition process of the device should be
done.
Compensation: This LED indicates that the device is in compensation state and the
best response is produced.
Modbus: This LED flashes when communication via Modbus occurs.
Alarm: This is the red LED that informs the user about warnings or problems occurring
in the system. This LED turns off when alarms are deleted from the alarm menu.
Generator: This LED indicates that the system is fed from the generator.
Target Cos(φ): This LED lights when the default value of target cos(φ) of 1.00 is changed.
Common Feeding 1-7 Stage Terminal: Indicates that stages 1 to 7 are suitable to be
used for compensation response. If this LED is not on, the stages in this group cannot
be used.
Common Supply 8-12 Stage Terminal: Indicates that stages 8 through 12 are
available for compensation response. If this LED is not lit, the stages in this group
cannot be used.
Common Supply 13-18 Stage Terminal (for RKR18 and RKR24 devices):Indicates
that steps 13 to 18 are available for compensation response. If this LED is not on, the
stages in this group cannot be used.

13
Reactive Power Control Relay User Manual
Common Supply of 19-24 Stage Terminals (RKR24 only): Indicates that
stages 19 to 24 are available to be used for compensation response. If this LED is not
on, the stages in this group cannot be used.
Menu: This LED is on when you are in a menu. It flashes during editing.
Additional Power (RKR12 and RKR18 devices): This LED lights when the
device adds additional reactive power in the compensation response.
Add Step (RKR12 only): Indicates that the total stage power is insufficient for
the compensation response of the device and indicates that a stage should be added.
14 - Value LEDs:
VLN: Phase-neutral voltage values of L1, L2 and L3 phases are displayed.
VLL: Phase-phase (L-L) voltage values of L1-L2, L2-L3 and L3-L1 phases are
displayed.
VLN and VLL (F): Frequency values for L1, L2 and L3 phases are shown.
I: Current values of L1, L2 and L3 phases are shown.
Cos(φ): Cos(φ) values of L1, L2 and L3 phases are shown.
P: Active power values of L1, L2 and L3 phases are shown.
Q: Reactive power values of L1, L2 and L3 phases are shown.
Q and Load: When these LEDs are on at the same time, the total reactive load
drawn by the operation is displayed on the screen.
Q, ∑ and Step: It shows the total reactive power of the stages activated by the
relay.
VLN, VLL, I, Max and Min: Top to bottom;
Line 1: Average voltage values of L1, L2 and L3 phases are shown.
Line 2: Average current values of L1, L2 and L3 phases are shown.
Row 3: Average frequency values of L1, L2 and L3 phases are shown.
P, Q, Max and Min: Top to bottom;
Line 1: Average active power values of L1, L2 and L3 phases are shown.
2nd Line: Average reactive power values of L1, L2 and L3 phases are
shown.

Reactive Power Control Relay User Manual
14
Line 3: Average apparent power values of L1, L2 and L3 phases are shown.
P and Q: These LEDs turn on when the capacitive/inductive instantaneous ratios of
each phase are shown on the display.
P, Q and ∑: Top-down;
Line 1: Inductive percentage ratio value is displayed.
Line 2: "%"
Line 3: The capacitive percentage ratio value is displayed.
P, ∑: The first line shows the total active energy A.Enj The lines
below this line show the total active energy values.
NOTE: Since the lines have 4 characters, the digits after the first 4
digits of the active energy values will be displayed on the bottom
line to avoid overflowing the bottom line.
If the active energy value is greater than an 8-digit number, the
K(x1000) LEDs on the left side of the display will light up. For
example, if a display like the one in Figure 2.1 appears, it should
be understood that the active energy value is 435410 W.
Q, ∑: This index shows the total reactive energies (capacitive and inductive).
Firstly, in the first line, E.Enj is shown. In the lines below this text, total inductive
energies are displayed. To display the total capacitive energies, press the down arrow
key. When this is done, C.Enj is displayed on the first line. In the lines below this text,
total capacitive energy values are read.
NOTE: The display of total reactive energy values on the screen is the same as
the display of total active energy values.
I and Cos(φ) (oC): When these two LEDs are lighted together, the approximate temperature of the
panel is displayed instantaneously.
VLN and Demand: Voltage demand values of L1, L2 and L3 phases are displayed.
NOTE: If the Export LEDs are blinking, then the values shown on the display are Export values.
I and Demand: Demand values of I1, I2 and I3 currents are displayed.
NOTE: If the Export LEDs are blinking, then the values shown on the display are Export values.
P and Demand: Demand values for P1, P2 and P3 powers are shown.
NOTE: If the Export LEDs are blinking, then the values shown on the display are Export values.
Q and Demand: Demand values for Q1, Q2 and Q3 powers are shown.
NOTE: If the Export LEDs are flashing, the values shown on the display are Export values.
Şekil 2.1 Toplam aktif
enerjinin cihaz
ekranındaki görüntüsü

15
Reactive Power Control Relay User Manual
VLN and Max: Maximum voltage (VMAX) values for L1, L2 and L3 phases are
displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
VLN and Min: The minimum voltage (VMIN) values for L1, L2 and L3 phases are
displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
I and Max: Maximum current (lMAX) values in phases L1, L2 and L3 are displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
I and Min: The minimum current (lMIN) values in the phases of L1, L2 and L3 phases
are displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
P and Max: Maximum active power (PMAX) values of L1, L2 and L3 phases are
displayed.
NOTE: If the Export LEDs are flashing, the values shown on the display are Export
values.
P and Min: The minimum active power (PMIN) values for L1, L2 and L3 phases are
displayed. NOTE: If the Export LEDs are blinking, the values shown on the display
are Export values.
Q and Max: Maximum reactive power (QMAX) values for L1, L2 and L3 phases are
displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
Q and Min: Minimum reactive power (QMIN) values for L1, L2 and L3 phases are
displayed.
NOTE: If the Export LEDs are blinking, the values shown on the display are Export
values.
Stage: This LED lights when the display shows information about the stages.
GAP: This LED lights when power samples are monitored. To access the power
samples, the G.A.P. sub-menu must be entered from the menu.
15 - Export LED: When this LED flashes, it indicates that the relevant phase of the
device is in export status.
16 - Product Model Number: Indicates the model of the product.

16
Reactive Power Control Relay User Manual
Reactive Power Control Relay Front Panel Key Functions
Enters menus and submenus, and also performs confirmation operations.
In the menu, it allows you to go back one step and exit the menu. On the
work screen, it allows you to return to the main worksheet.
Allows navigation in the work screen detail pages and menus. It performs
the process of increasing the values of the parameters.
Allows to navigate the work screen detail pages and menus. Performs the
process of reducing the values of the parameters.
General Features
Reactive Control Relays: 3 phase current, phase-neutral and phase-phase voltages,
frequency, active and reactive powers, angle difference between current and voltage
can be measured and displayed on the screen. In addition, it measures and records
active and reactive energies.
Demand and peak values for these measured quantities are also recorded by the
Reactive Control Relay and can be displayed on the device.
Many necessary adjustments related to the device (Current Transformer Value,
Measurement and Busbar Voltages etc.) can be made via the menu.
Thanks to the communication feature, all read parameters can be monitored
remotely via the standard MODBUS protocol and various adjustments can be made.
It can give output in the value range for the quantities (Current, Voltage, Active and
Reactive Power, Cos(φ) etc.) set via the device menu.

Reactive Power Control Relay User Manual
17
Technical Features
32-bit based microcontroller
High efficiency with operating ambient temperature from -10 °C to +55 °C
Easy access to stage recognition, setup, C.T value, MODBUS address, response time
with Quick Menu
Ability to set the desired value with the target Cos(φ) feature
Ability to add virtual power to the business with the Additional Power feature
Ability to check and display whether the relevant tap block is active or not with the
ability to detect step partners
Intelligent stage recognition and individual stage recognition
Adjustable response time (with inductive, capacitive and normal options)
RS-485 Standard MODBUS RTU protocol for ease of communication
- 247 different Modbus addresses
- Baud rate from 4800 bps up to 256000 bps
- Modbus protection option for writing and reading
Manual stage control for testing capacitor/reactor and related fuses and even related
contactors
Adjustable inductive and capacitive limit
Adjustable hysteresis limit
Automatic voltage-current matching
Three different user modes (Lean, Master and Advanced modes)
Ability to create a special PIN for high security needs
Possibility of installation according to compensator characteristics (capacitive or
inductive)
Possibility of installation according to business profile (production or consumption)
Adjustable current transformer value, adjustable line and measuring voltage
Automatic finding and correction of current transformer connection directions
Possibility to adjust the polarity direction of current transformers with three different
modes (automatic, manual and reverse)
Ability to save energy, demand, export, minimum and maximum values in permanent
memory and delete them when desired
Ability to synthesize stages thanks to the ability to view and analyze the power flow
profile of the enterprise with the Power Flow Profile feature
Thinnest ergonomic design with a depth of 48 mm allowing for narrow enclosure
design
Terminal block structure positioned for easy cable assembly
Secure C.T. secondary installation with constant current terminal input allowing the use
of 4 mm2 cables for long distances
0.5 mA measurement accuracy with automatic gain
0.5 mA - 6.0 A current measuring range

Reactive Power Control Relay User Manual
18
80 - 265 VAC voltage measurement range
Ability to feed from any phase
Safe operation in 80 - 280 VAC supply voltage range
Equipment safe against voltage connection failure
Phase - Neutral faulty connection detection
12, 18 and 24 Stage options
Easy assembly and easy installation
Ability to install monophase, diphase, triphase stages
Installation options with capacitor or reactor stages
Installation and compensation option with single current transformer
Detection of various connection errors for current transformers
Intelligent compensation response algorithm
Ability to use single-phase reactor/capacitor stages simultaneously with capacitor/
reactor stages for compensation solution
Intelligent/sequential/fast stage recognition in Adaptive mode
Single stage recognition
Recognize 1 stage in under 1 second
Monophase, diphase, triphase capacitor and reactor recognition
Manual stage input
Non-interchangeable terminal block structure with different pin numbers for stage
groups
Feed control of grouped stage partners
Capacitor and reactor can be freely connected to each stage
7 Segment LED display in bright green color
Status and value indicators with Blue, Green and Red LEDs
Determining the target Cos(φ)
Ability to be fed via generator and different Cos(φ) setting in generator use
Additional reactive power setting for inductive effect of MV power transformers
or capacitive effect of long cables, which can be set for an optional period of
time
Power Flow Profile analysis sorted by energy/time/inductive/capacitance/ratio
for stage synthesis
Easy and fast operation
Various warning/alarm codes
Smart menu with 3-level access
Indexed menu heading for technical support
Turkish, English language options
Show current access level in the main menu

Reactive Power Control Relay User Manual
19
PIN protection and different reset pins for each relay
Various parameter settings and function calls from the menu
Information menus with identification information such as serial number,
software and hardware version, etc.
Observable Values:
VLL, VLN, I, F, P, Q, Cos(φ), Q/P
Instantaneous and Accumulated Inductive/Capacitive
Q/P Ratio (%)
Demand, Min, Max, Average values
Active, Inductive/Capacitive energy indexes
Export indexes, demand, mininum, maximum values
Total phase-to-phase power of the drawn stages
Instantaneous reactive loads drawn by the enterprise
from each phase
Approximate temperature of the panel
Stage powers, number of uses
Examples of Power Flow Profile

Reactive Power Control Relay User Manual
20
RKR 12/18/24 RELAY TECHNICAL DRAWING
FRONT VIEW SIDE VIEW BACK VIEW
