Gryphon Legato Legacy User manual

Legato Legacy
Owner´s Manual
Legato: Italian, means literally
"bound together." In classical music,
a composer's instruction to play in a
smooth, flowing manner without
detached notes

Table of Contents:
Introduction....................... 3
The Gryphon....................... 3
Legato................................. 4
The Man.............................. 4
Made in Denmark............... 4
Musical Objectives.............. 5
The Gryphon Master Tape
Collection............................ 5
Design Principles................ 5
Exterior Design................... 7
Manufacture and Assembly. 8
Using Your Gryphon......... 8
AC Voltage.......................... 8
Burn-in and Warm-up.......... 8
Placement........................... 9
Balanced Connections....... 9
Choice of Cables................ 9
Care and Maintenance....... 9
Unpacking........................... 10
Installation........................... 10
Power Supply........................ 10
AC Fuses............................ 11
AC Power............................ 11
AC Grounding..................... 11
AC Power cords................. 11
AC Polarity.......................... 11
Balanced Cables................. 12
Lemo Connectors................ 12
Tonearm Connectors.......... 13
MM or MC ?........................ 13
Grounding............................ 13
Specifications...................... 14
Impedance Selector............ 14
Custom Loads...................... 14
Tweak Alert ........................ 16
Warranty............................. 17

Introduction
Welcome to the global family of
proud owners of fine audio com-
ponents from Gryphon Audio
Designs of Denmark. Your new
Gryphon unit has been painstak-
ingly designed to re-create the
sound of live music taking place
in its original recorded space.
Every Gryphon product is
designed to cater to the needs of
the most discerning music
enthusiast with sumptuous
styling and superb user-friendli-
ness which elevate it above the
mundane world of con-
ventional audio compo-
nents.
As audiophiles, the
members of the
Gryphon design team are con-
stantly reminded to keep their
priorities straight. We are not
involved in “hi-fi” for its own
sake, but strictly as a means to
an end, in the service of our life-
long love of the live music expe-
rience in all its sonic and emo-
tional glory.
Our higher goal is to bring to the
listener a “You-Are-There” sen-
sation. In taking up this chal-
lenge, the Gryphon designers go
back to basics to analyze the
essential nature of the live music
experience. For us, an aware-
ness of soundstaging, ambience
and concert hall dimensions are
necessary components.
Dynamics and an unambiguous
sense of instrument location
even in the loudest passages
are also high priorities. To
achieve these objectives,
Gryphon products offer excep-
tional speed and agility along
with seamless coherence in the
time domain.
Since 1985, Gryphon Audio
Designs has quietly gone about
the business of creating fine
home audio components. We
know that you will appreci-
ate and enjoy the benefits
of our accumulated expe-
rience and share our abid-
ing passion for music.
The Gryphon
In Greek mythology: A fabled
creature, half-lion and half-
eagle, combining the power of
the “King of Beasts” with the
grace of the “King of Birds”. The
guardian of the source of gold
and protector of the Dionysian
cup of infinite wealth.
In the real world: An acclaimed
Danish audio engineering com-
pany employing cutting edge
technology and common sense
in the pursuit of the purest musi-
cal experience. We feel that the
gryphon is an appropriate sym-
bol for our high sonic goals.
3

Legato
Legato: Italian, means literally
"bound together." In classical
music, a composer's instruction
to play in a smooth, flowing man-
ner without detached notes
The Man
Gryphon Audio Designs is the
brainchild of Flemming E.
Rasmussen and the fulfillment of
a lifelong dream to allow the
purest essence of the live music
experience to be recreated in the
home environment.
Rasmussen holds a degree in
painting and graphic arts from
the Aarhus Art Academy,
Denmark. During his studies,
Rasmussen developed close
relationships with the local music
community and designed many
LP covers and concert posters.
After graduation, he taught pho-
tography and painting and
designed textiles, before found-
ing 2R Marketing, which quickly
became Denmark’s leading High
End audio import company.
Gryphon Audio Designs was
founded in 1985 as an offshoot
of 2R Marketing, The first prod-
uct, the now legendary Gryphon
Head Amp, grew from a one-off
spare time project developed
only for the designers’ own home
systems. Although the Gryphon
project was initially strictly a
hobby, not an actively pursued
commercial venture, demand
generated by reviews and word-
of-mouth led to the formal estab-
lishment of Gryphon Audio
Designs as a separate corporate
entity.
Following the immediate suc-
cess of the Gryphon brand, all
import business was phased out
in 1993, so that Rasmussen
could dedicate his efforts entire-
ly to Gryphon.
Made In Denmark
Every product from Gryphon
Audio Designs is designed and
built in Denmark. This is much
more than just a geographical
fact. It is also a seal of approval,
a stamp of quality. Living in a
region with no natural resources
(no oil, coal, precious metals,
etc.), the Danes have learned to
rely on their quick wits and
skilled hands. Innovative tech-
nology, beautiful craftsmanship,
pride in one’s craft and a keen
eye for attractive design are
some of the long-standing
Danish traditions which are dis-
tilled to their finest essence in
every unit that bears the
Gryphon name.
The Gryphon Head Amp
4
Flemming E. Rasmussen painting 1967

Musical Objectives
While scientific method and
sophisticated technology play an
important role in our electronics
design work, at Gryphon we
never lose sight of the fact that
the keen ears of an experienced
listener are the most crucial “cal-
ibration tools.” Therefore, every
Gryphon product exists for one
simple purpose: to bring the user
closer in the never-ending quest
for a more natural and convinc-
ing musical illusion.
Every Gryphon design has been
built to cruise effortlessly through
even the most demanding musi-
cal passages, regardless of vol-
ume level, with a musical pres-
entation defined by supreme
articulation and immediacy, sub-
tle dynamic shading and razor-
sharp focus. Refinement and
delicacy are combined with
power and authority for a natu-
ral, involving listening experi-
ence.
The Gryphon Master
Tape Collection
In the Gryphon listening rooms,
we are fortunate to possess a
unique library of more than
1,000 original master tapes of
recordings made during the
Golden Age of studio engineer-
ing from 1956-1976.
Unlike conventional commercial
releases, our master tapes cap-
ture the dynamic contrasts and
subtle inner harmonic structure
of the musical event, forcing us
to work to a higher standard in
our efforts to maintain the integri-
ty of the original musical per-
formance.
Design Principles
With state of the art technical
equipment and some of the
finest minds in the audio engi-
neering field at our disposal, the
Gryphon brand name continues
to define the highest audiophile
standards of subjective and
technical performance.
The dual mono configuration
radically eliminates any possibil-
ity of crosstalk or other interfer-
ence between channels and pro-
vides infinite channel separation
which contributes to the ability to
create space, focus, depth and
transparency.
Because the electrical power
coming out of your wall fluctu-
ates wildly in terms of voltage
and distortion, Gryphon incorpo-
rates heavily regulated multi-
stage power supplies that act as
effective mains conditioning fil-
ters. Displays and control circuits
are fed by a separate power sup-
ply to isolate any digital noise
artifacts and effectively prevent
them from contaminating the sig-
nal path.
Gryphon is located in beautiful
tranquil surroundings.
5

While the printed circuit boards
in more conventional audio prod-
ucts utilize conductor tracks a
mere 35 micron thick, Gryphon
employs at least 70 micron
traces of the highest purity.
Beginning with our very first
product, “The Head Amp” all
Gryphon products have featured
extremely wide frequency band-
width, because the ability to
reproduce ultra-sonic frequen-
cies with no difficulty ensures lin-
ear phase across the audible fre-
quency range.
The implementation of circuits
with wideband frequency
response is a painstaking
endeavor in which the actual lay-
out and ground pattern of the PC
boards are crucial to the
achievement of superior sonic
performance with no loss of
inherent stability.
Wideband frequency response
ensures the high slew rate
essential to the realistic handling
of the ultra-fast transients which
routinely occur in live music and
is crucial in recreating the natu-
ral decay of musical instruments.
Wide bandwidth also improves
phase characteristics, for more
correct soundstaging and imag-
ing.
All Gryphon designs are realized
with an absolute minimum of
negative feedback, which when
present in large amounts can
actually increase TIM distortion.
All Gryphon preamplifiers are
designed with zero negative
feedback. Gryphon power ampli-
fiers apply negative feedback
judiciously for improved linearity
and bandwidth.
Gryphon research into the detri-
mental effects of magnetically
induced distortion (MID) has led
to the elimination of magnetiz-
able materials wherever possi-
ble. To eliminate the effects of
stray magnetic fields, non-mag-
netic materials are employed
throughout, with the unavoidable
exception of the transformer
shield box.
The mechanical design of the
cabinet and assembly methods
are all carefully calculated to
ensure minimal resonance,
either through the use of
mechanically grounded high
mass or decoupling. Vibration-
sensitive components, capaci-
tors in particular, are thus guar-
anteed a non-resonant environ-
ment.
The heavy, thick chassis offers a
vibration-proof environment for
the sensitive electronics inside
and provides crucial shielding
from a polluted world of low and
Typical Gryphon module
6

high-frequency radio waves,
power-line radiation and other
electrical interference.
Meticulous attention to such
issues makes a significant con-
tribution to the relaxing, open
and transparent Gryphon sound.
Unique, non-invasive protection
circuitry offers reliable, fuss-free
protection without compromising
signal purity and signal path sim-
plicity, with no conventional
relays in the signal path to
degrade or compress sound.
The ground path has been care-
fully laid out in order to achieve
superior sonic performance with
no loss of stability. Component
layout has been designed to
ensure the shortest conceivable
signal path.
Exhaustive investigation under-
lies the selection of every com-
ponent part and many original,
proprietary components are cus-
tom-built exclusively for
Gryphon. Because what is left
out is just as important as what
goes in, an absolute minimum of
internal wiring is included.
By lavishing attention on each
aspect of the circuit and fully
understanding the purpose and
behavior of every single part of
the whole, our designers can
optimize performance in each
section, before moving on to the
next step. This ensures simplici-
ty, a short signal path and a unity
of purpose with a single, well-
defined objective: musical purity.
In the interest of ultimate fidelity,
tone controls, balance controls
and other unnecessary compo-
nents have been banished from
the signal path.
Exterior Design
From the very beginning, every
Gryphon product has offered
stunning audio performance,
sumptuous styling and superb
user-friendliness, catering to the
needs of the discerning audio-
phile who demands musicality,
convenience and aesthetics, all
without compromise.
In every Gryphon product, form
follows function in a unique syn-
thesis of aesthetics and practi-
cality. Gryphon stands for
sophisticated technology with a
high standard of industrial finish
that also incorporates the best of
handcraftsmanship.
The peerless finish, build quality,
ergonomics and pride of owner-
ship that contribute to the totality
of the Gryphon concept can only
be fully understood and appreci-
ated up close and in person.
Rasmussen’s background in fine
arts and industrial design gives
every Gryphon product a distinc-
Gryphon Audio Designs in the
outskirts of the small town of
Ry
7

tive, luxuriant finish which arises
organically out of the audio cir-
cuit design and the user inter-
face for a truly unique integration
of form and function.
Manufacture and
Assembly
At our laboratories and manufac-
turing facilities in Denmark, we
maintain full control over every
aspect of development and pro-
duction, and the members of our
conscientious staff diligently fol-
low each Gryphon model from
initial concept to early prototype,
through to final quality control.
Printed circuit boards are
assembled by a supplier of pre-
cision military and medical
equipment with strict standards
of quality control and pre-inspec-
tion of components. Chassis
parts are manufactured by a
specialist chosen solely for the
outstanding quality of workman-
ship. In every aspect of every
Gryphon product, the same
stringent standards of excel-
lence apply.
Following a 48-hour burn-in,
each product is tested again,
before being subjected to
Gryphon’s custom-developed
transport simulator which simu-
lates the inevitable shaking that
a product will encounter in tran-
sit. The product is placed on top
of a very large loudspeaker
which plays a special CD with
low frequencies which simulate
the vibrations of an airplane.
Each unit “travels” the equivalent
of 40 round trips from Denmark
to Australia before leaving the
factory.
AC Voltage
Your Gryphon unit is especially
made for the AC voltage of the
country to which it has been
shipped. If the voltage has been
changed, the warranty is void
and the product may be unsafe
or malfunction.
Correct AC polarity contributes
greatly to optimum performance.
If you are not using a three-pin,
non-reversible power plug,
please experiment with the ori-
entation of the plug for optimum
performance.
Burn-In and Warm-
Up
Your Gryphon unit has been
thoroughly tested and burned in
before shipping. Performance
will continue to improve during
the first 40 – 50 hours of normal
use. After this period optimum
performance will be reached
approximately 45 minutes after
turn-on. With the exception of
Class A power amplifiers, we
8

recommend leaving your
Gryphon components powered
up at all times.
Balanced
Connections
All Gryphon products use the
AES standard for balanced con-
nections.
1. Ground
2. Positive
3. Negative
We recommend the use of dedi-
cated balanced cables. Avoid the
use of adaptors as they degrade
performance.
Choice of Cables
Because your Legato is a high-
resolution Gryphon audio
device, it will immediately reveal
the characteristics and possible
limitations of the other compo-
nents in your system, as well as
those of the interconnects and
loudspeaker cables used to con-
nect your system.
Wiring should never be utilized
as "equalizers" to correct errors
elsewhere in the system.
Instead, any error should be cor-
rected at the source, so that
interconnects and loudspeaker
cables can be selected solely on
the basis of sonic neutrality. For
this reason, we employ
Gryphon's own range of inter-
connects and cables in every
stage of the design of every
Gryphon product.
Care and
Maintenance
Gryphon products are handcraft-
ed by individuals who take great
pride in the high level of fit and
finish which we achieve. To
maintain your Gryphon compo-
nents in pristine condition,
please follow these simple
instructions.
Metal surfaces may be cleaned
with a damp cloth. Some product
made for treatment of vinyl inte-
riors in cars may be useful. Test
the product on a non-visible sur-
face, before using any fluids.
Acrylic surfaces should only be
wiped with a very soft, dry cloth.
Small scratches may be
removed with fiberglass polish.
Fingerprints may be removed
with a damp cloth. Do NOT use
spirits or paper tissue.
9

The Gryphon
Legato
Despite the massive digital hype
of the past 20 years, the LP
remains by a significant margin
the finest high fidelity medium
ever offered for home use. Its
comprehensive catalogue of
titles will never be rivaled by the
compact disc, which already
appears to be on its way to a
carefully planned obsolescence.
The LP holds a very special
place in our hearts here at
Gryphon, having been the inspi-
ration for our very first product,
the now legendary Gryphon
Head Amp. Today, Gryphon con-
tinues to support analog play-
back with the full force of our
considerable research and
development resources. While
the vast majority of self-pro-
claimed high end manufacturers
have ceased to take any real
interest in LP playback, Gryphon
forges ahead.
The Gryphon Legato phonos-
tage is the fruit of our explo-
rations into the latest circuit
topologies, low-noise compo-
nent breakthroughs and power
supply innovations in the service
of a vast body of musical treas-
ures that will continue to enlight-
en the lives of dedicated music
lovers for years to come.
But it is far more than nostalgia
that motivates our ongoing
efforts to extract the very best
from those black vinyl grooves.
Through our travels and exten-
sive correspondence we are
aware of a small, yet significant
circle of true vinyl connoisseurs.
It is our hope that they will appre-
ciate our meticulous efforts on
their behalf in the development
of the Gryphon Legato phonos-
tage.
It is to this uncompromising
group of music lovers that we
dedicate the Gryphon Legato
with our heartfelt appreciation for
your support.
Flemming E. Rasmussen
President, Gryphon Audio Designs,
Denmark, December 2011
10

Unpacking
During unpacking and installa-
tion, please take care to avoid
scratching the Gryphon Legato.
Hard, sharp objects such as
tools should not be nearby dur-
ing this process. You might want
to remove your wristwatch, rings
or other jewellery before han-
dling the preamplifier. Please
keep the carton and all packing
materials in a dry place for safe
future transportation.
The following items are
enclosed:
(this list does not apply if the
Legato is factory fitted inside
Gryphon Sonata Allegro)
1 Gryphon Legato phono stage
1 Gryphon Legato power supply
(with stand alone version)
2 AC power cables
(with stand alone version with
powersupply )
2 DC power supply cables
(with stand alone version)
1 pair of Lemo connectors
( with all Legatoversions)
1 pair of white gloves
1 acrylic polish
1 packing list
1 purchase registration card
If anything is missing or dam-
aged, please contact your
Gryphon dealer immediately.
Installation
In order to minimize any possible
risk of electrical interference, do
not place the preamplifier direct-
ly above or below the power
supply. The length of the power
supply cables allows you to
place them some distance apart.
If you wish to place them side by
side, please place the power
supply to the left of the preampli-
fier as seen from the front.
Power supply
For each channel, connect a DC
connector cable to the socket
marked DC OUTPUT on the
supply and to the socket marked
DC INPUT on the preamplifier.
Turn the locking connector
clockwise to lock firmly to pre-
vent accidental disconnection.
Each channel has its own On/Off
switch located under the unit.
For optimum performance, we
recommend that you leave the
Legato powered up at all times.
If you choose to turn the Legato
on and off, please remember:
ALWAYS turn the Legato on,
BEFORE turning on the power
amplifier.
ALWAYS turn the power amplifi-
er off, BEFORE turning off the
Legato.
11

AC Fuses
(Stand alone units with dedicated
power supply )
The Legato powersupply has an
AC fuse holder for each chan-
nel.
100-120V. countries: 800m AT
200 -240V. countries:400m AT
DO NOT REPLACE WITH ANY
OTHER FUSE VALUE.
AC Power
The Legato should ideally be
connected to a separate AC
group independent of other
equipment.
The Legato is designed for use
with a three-pin AC connection
with separate ground, but may in
some countries be used with
alternative grounding. Your
Gryphon dealer or importer will
give you further details.
AC Grounding
In order to utilize the AC filtering
section of the power supply, con-
nection to ground is essential.
Generally, overall performance
can be greatly improved with
proper grounding. The degree of
improvement will depend on
local conditions
AC Power Cords
Use only a dedicated AC power
cord. Do NOT use loudspeaker
cable or other wire not expressly
designed to carry high current.
Improper cable or cables of
insufficient gauge will generate
heat and the insulation may melt
with disastrous results.
AC cords DO have an audible
effect on sound quality, but
experiments should be carried
out with due consideration to
safety.
Power Line
Conditioners?
The Legato has its own built-in
AC conditioner (each channel).
If you use external line condi-
tioners or other devices, we
strongly recommend that you lis-
ten to the Legato without these
devices before making your
decision.
Remember to listen for correct
sound and not merely different
sound.
AC Polarity
Do not run, thin, coiled, exten-
sion cords.
The Legato is a true dual mono
construction and we must stong-
ly emphasize the importance of
symmetrical AC power polarity
for each channel. Asymmetrical
AC polarity will strongly degrade
12

soundstage recreation and other
important aspects of the Legato
performance.
Balanced Cables
The Legato is only made
for Balanced operation and
failure to make correct ter-
mination will diminish per-
formance and may dam-
age the unit.
Pin configuration of
Lemo Connectors
For absolutely superior perform-
ance, the Swiss made Lemo
connector was chosen. 1 Pair is
supplied with the Legato.
ILLUSTRATION SHOWS
CABLE CONNECTIONS AS
SEEN FROM INSIDE THE
CONECTOR.
Wiring Schematic
EXAMPLE: LEFT CHANNEL
VERY IMPORTANT:
THE SHIELD OF THE CABLE
MUST BE INSULATED FROM
THE OUTER PART OF THE
LEMO CONNECTOR.
SHIELD MUST ONLY BE CON-
NECTED TO THE SOLDERING
POINT OF THE LEMO CON-
NECTOR. NEVER THE TONE
ARM
13

Tonearm
Connections
STANDARD CARTRIDGE PIN
CONNECTION:
WHITE: POSITIVE LEFT
BLUE: NEGATIVE LEFT
RED: POSITIVE RIGHT
GREEN: NEGATIVE RIGHT
DO NOT CONNECT THE SHIELD
AT CARTRIDGE END OR CON-
NECT NEGATIVE (MINUS) WITH
SHIELD AT ANY POINT.
MC or MM?
The Legato must be turned off
and cables removed before top
plate is removed
The Legato is factory set for
Moving Coil cartridges loaded at
80 Ohms, but can be changed to
MM 47K by removing the cabinet
top plates and relocating 5
straps on the circuit board. Do
not change anything on the
impedance load sockets. The
MM 47K load is automatic in the
MM position.
The straps (red) are located in
the center of the Legato circuit
board ( J1 / J07 / J08 & J2 / J3
) The correct positions are
marked on the PC board.
See fig. 1 & 2
Grounding
The Ground wire from the ton-
earm can be connected to the
the cabinet grounding posts.
Most Audiophiles have learned
that there are no clean cut rules
when it comes to efficient
grounding of Tonearms.
It pays to experiment and some-
times no grounding will do the
trick or the solution may turn out
to be very unusual.
Experiment.
Unless you are a wizard with a
soldering iron, we recommend
that you ask your Gryphon deal-
er to make a dedicated Legato
phono cable.
Legato phono cables based on
our Solid silver/Gold Guideline
cables can be factory made to
your specifications:
14
Fig. 1
Fig 2

Technical
Specifications
(Balanced operation)
Signal to Noise ratio:
MM 86 dB Unweighted Ref. 10
mV
MM 90 dB A weighted Ref. 10
mV
MC 68 dB Unweighted Ref. 0.5
mV
MC 72 dB A weighted Ref. 0.5
mV
Gain MC: 68 dB
Gain MM: 38 dB
RIAA tracking: +/- 0.1 dB 20 -
20 kHz
THD: 0.01%
Output impedance: 50 Ohms
Input overload margin:
MC 30 mV pp
MM 700 mV pp
RIAA out: voltage sving 60 V pp
15
MC Impedance
Selector
Turn off power before removing
cabinet top plate.
The impedance selector is a
super high grade socket using
removeable gold-plated jumpers
to secure lasting superior con-
tact. The selector has 6 positions
marked on the circuit board.
Position 1 10 Ohm
Position 2 40 Ohm
Position 3 80 Ohm
Position 4 300 Ohm
Position 5 800 Ohm
Position 6 47 kOhm
See figure 3
Custom Loads
Besides these values it is possi-
ble to load the cartridge with any
impedance between 10 Ohm
and 47 kOhm, by inserting resis-
tors in the sockets found on the
PC board just left of the imped-
ance loading socket (as seen
from the rear) RIN 1/RIN 2.
See fig. 4
Fig. 4
Use only high quality, precision
resistors.
Fig. 3

16
Formula for finding the
desired resistor value for
custom load
Rload x 23500
47000 - Rload
Tweak Alert
In the best Gryphon tradition we
have spent a huge amount of
time with our prototypes before
we release a new product. We
are obsessed with what we do
and consider ourselves to be
open minded and are fascinated
by the "Grey area" between logi-
cal, technical facts and things we
just hear that make no obvious
technical sense, we will imple-
ment it as long as it does not
sacrifice safety or reliability. In
the Legato design a number of
tweaks can be found and the
result is a fine balance that can
easily be disturbed.
We strongly advise against any
alteration of the original design,
it will void the warranty and most
certainly not provide more than a
difference instead of a real
improvement of musical realism.
We are fully aware of the fun of
playing with AC conditioners,
bricks, platforms, cables and so
on. We appreciate much of it,
but please listen to our intentions
before you go ahead and if you
do, do yourself (and us) the favor
of now and then going back and
listening to the "naked" design
as it was intended.
Enjoy…

Warranty
The Gryphon Legato is warrant-
ed against failures arising
through faulty workmanship and
materials for a period of 5 years
from date of purchase. The war-
ranty is not transferable. This
warranty is only valid in the
country where the product was
purchased. All claims under this
warranty must be made to the
distributor in the buyer
` s country
by returning the unit securely
packed in the original box with all
accessories, postage/freight pre-
paid and insured. The unit will be
repaired or replaced at no
charge for parts and labor.
This warranty remains valid only
if the serial number of the unit
has not been defaced or
removed and if repairs are per-
formed only by authorized
Gryphon dealers or distributors.
It does not cover damage due to
misuse, accident or neglect. This
warranty is not valid if the oper-
ation voltage of the product has
been changed. The distributor or
manufacturer, Gryphon Audio
Designs, Denmark, retains the
exclusive right to make such
judgement on the basis of
inspection.
The retailer, distributor or manu-
facturer of the Gryphon shall not
be liable for consequential dam-
age arising from the use, misuse
or failure of this product, includ-
ing injuries to persons or proper-
ty.
To qualify, the enclosed warranty
registration card must be filled
out and returned to the manufac-
turer within 10 days of purchase.
Alternatively, you may choose
to register your Legato on our
website:
www.gryphon-audio.dk
