GSC Golf Skate Caddy User manual
RECHARGE
INSTRUCTIONS
golfskatecaddy.com
Step 1. Ensure that your fast charger is
DISCONNECTED from the mains power supply
by switching OFF at the wall.
FAST CHARGER
CHARGER DISCONNECTED
MAINS POWER SUPPLY OFF
Step 2. Connect the charging socket to the battery.
LED LIGHTS
BOTH ON & RED
SWITCH ON
LED2 LED1
LED2 LED1
FAST CHARGER
CONNECT CHARGER
MAINS POWER SUPPLY OFF
LED2 LED1
Step 3. Switch on the fast charger by TURNING ON
THE POWER AT THE WALL ensuring that both
RED lights come on.
Step 4. After the battery has fully charged LED2
will turn GREEN indicating that the battery is
ready to use and is at full capacity.
LED2 GREEN
WHEN CHARGED
LED2 LED1
Your Golf Skate Gaddy is supplied with a specialised
Lithium Fast Charger, however you must follow the
procedure set out above to ensure your Golf Skate Caddy
battery is charged correctly. Failure to follow these
instructions may result in your battery being partially
charged or not charged at all.
GSC CHARGING TIMES*
9 Holes of golf 35% capacity used.....1.25 hrs charge time
18 Holes of golf 70% capacity used.....2.5 hrs charge time
Fully discharged................................3.75 hrs charge time
* subject to age and condition of battery
RECHARGE
INSTRUCTIONS
golfskatecaddy.com
Step 1. Ensure that your fast charger is
DISCONNECTED from the mains power supply
by switching OFF at the wall.
FAST CHARGER
CHARGER DISCONNECTED
MAINS POWER SUPPLY OFF
Step 2. Connect the charging socket to the battery.
LED LIGHTS
BOTH ON & RED
SWITCH ON
LED2 LED1
LED2 LED1
FAST CHARGER
CONNECT CHARGER
MAINS POWER SUPPLY OFF
LED2 LED1
Step 3. Switch on the fast charger by TURNING ON
THE POWER AT THE WALL ensuring that both
RED lights come on.
Step 4. After the battery has fully charged LED2
will turn GREEN indicating that the battery is
ready to use and is at full capacity.
LED2 GREEN
WHEN CHARGED
LED2 LED1
Your Golf Skate Gaddy is supplied with a specialised
Lithium Fast Charger, however you must follow the
procedure set out above to ensure your Golf Skate Caddy
battery is charged correctly. Failure to follow these
instructions may result in your battery being partially
charged or not charged at all.
GSC CHARGING TIMES*
9 Holes of golf 35% capacity used.....1.25 hrs charge time
18 Holes of golf 70% capacity used.....2.5 hrs charge time
Fully discharged................................3.75 hrs charge time
* subject to age and condition of battery
Page 1.
TABLE OF CONTENTS:
Inside Cover: - Charging Instructions
Page 2 : - Welcome
Page 4: - Features of the Golf Skate Caddy (GSC™)
Page 5: - Terms & Conditions of Warranty
Page 6: - Know your ability & ride with care
Page 7: - Unpacking the GSC™
Page 8: - Synchronizing your GSC™ to the trigger controller
- Adjusting the duel speed controller switch
Page 9: - 2.4GHz wireless controller
Page 10: - Basic Operations
Page 11: - Being in control and safety
Page 12: - Regular maintenance requirements
- Maintenance warnings
- Kevlar drive belt
Page 13: - Battery maintenance
Page 14: - General maintenance schedule
Page 15: - Trouble shooting
Golf Skate Caddy
(“GSC™” or “the product”) Owner’s Operating Manual
Welcome and enjoy this new Innovated product and have a fun day while playing a round
of golf.
Congratulations! Soon you’ll be stepping onto the Golf Skate Caddy Personal
Transporter.
But rst, there are a few things you need to familiarise yourself with the Golf Skate Caddy.
To get the most out of your new GSC™ it’s important you know your product really well.
While you’re charging your GSC™ for the rst time, we recommend you read this manual
from cover to cover, explore all your Board’s features, and follow instructions (and we
emphasise ‘follow’) on safety, care, and maintenance.
We are certain you will enjoy riding your GSC™ – especially when you’re with friends.
Page 2.
The Golf Skate Caddy (GSC™ ) is the culmination of years of board, motor, battery and
dynamic technology fusion, oering a new alternative to other golf transport vehicles such
as single player ride on units and of course golf carts.
Playing golf should be about the experience, taking a great shot, enjoying the view, the
outdoors, the fresh air, encompassing this and so much more, ensuring return visits time
after time.
Our research indicates that few people rate their current transport choice as being part
of the fun experience of their game. Let’s face it, how exciting is it trundling around in
a golf cart going from one ball to another (you as a fellow passenger) when you can go
directly to your own ball saving you much time by not having to zigzag across the fairways
chasing two balls. 2 seater golf carts are no longer a necessity; with the Golf Skate
Caddy you will be home quicker as your game can be shortened by at least 20%.
The Golf Skate Caddy is an amazing vehicle that you simply stand on, whilst holding onto
a mono handle which helps you stabilise and control your ride. With a special caddy up
front for your golf bag, attachment provisions for your essentials such as scorecard holder,
umbrella holder, water bottle, sand divot pourer and even space for a GPS, you are set
and ready to go.
So check out our full website for all the information on how it works, how we feel it will
make your golf day one to remember, plus our great videos, photos, specications,
pricing, and so much more. One thing is for sure, you won’t nd a product like our Golf
Skate Caddy anywhere else. Australian designed and developed, innovative, reliable,
practical, great fun and enjoyed across the world.
You will appreciate the benets and safety of our 4 wheel steer product whilst other
products are 2 and 3 wheelers which can be unsafe on slopes. With our 4 wheeler you
will achieve better balance and safety to enjoy your golf day.
Page 3.
Page 4.
Golf Skate Caddy (“GSC™”) Personal transporter.
The Golf Skate Caddy, it’s not just another golf transport vehicle, it is an amazing, reliable
and truly enjoyable way to transverse your game, gliding over your course as if you were
surng up or down the fairway with total control, precision and safety.
FEATURES:
• 2.4Ghz handheld remote control with holster
• Front and rear led lights
• ABS Regenerative brake
• Rear compartment seat standard.
• Optional cooler seat available - holds 6 drink cans or other personal items
• Score card holder
• Heavy duty wind resistant umbrella
• Drinks bottle holder
• Sand divot pourer
• Instrument panel on foldaway mono handle (Start button, high, medium, low battery
indicator, rear and front light switch)
• Lithium Iron LifePo4 18AH Battery. When fully charged will complete 18 holes
• Charge time 3-5 hours (with fast charger)
• 1000w Brushless Motor
• Water / weather resistant computer control / receiver module
• Speed 20Km/h
• Forward & Reverse Function
• Premium synthetic logo grass surface allows a comfortable ride
• Mud Guards
• Kevlar Drive Belt
• Max total weight 140kg (Bag & clubs and product weight 30kg)
TERMS AND CONDITIONS.
WARRANTY.
For your 1 year GSC™ (6 months on LifePo4 Battery) Product Warranty to be eective, it
needs registration and activation online. Complete and Register Product form at:
www.golfskatecaddy.com
The GSC™ Product Warranty covers all structural components, materials, and
workmanship - but excludes wearing parts; including drive belts, tyres and tubes, painted
surfaces, damage caused due to misuse, contravention of operating and maintenance
instructions, immersion in, or exposure to water, accidental damage, loss and theft.
The warranty applies to the original purchaser only (nontransferable), and species the
product is free of manufacturing defects in materials and workmanship for a period of 1
year from the original date of purchase.
The warranty covers use of the product only under conditions specied in this manual.
All risks associated in the operation of the product remain the sole and assumed
responsibility of the person or persons operating the product. GSC™, its Directors,
employees, contractors and suppliers are hereby excluded from any and all liabilities
stemming from personal and/or consequential damage, injury, or death, resulting from the
use of this product.
Exercising the Warranty
If you have a problem with a GSC™ product and need to resort to the warranty, please
email: sales@golfskatecaddy.com or refer to www.golfskatecaddy.com for contact
numbers in your area.
When making the call, have a good description of the problem ready, and any ideas of
which parts might need to be investigated before a board can be returned under warranty,
a return must be authorised by GSC™. Make contact by email rst so we can size up the
situation for a rapid solution.
If GSC™ gives notication of a faulty product, replacement parts, or if necessary, a whole
Board, replacement will be sent - at no charge.
GSC™ reserves the right to determine repair or replacement. In the event of a
replacement - if the same model is no longer available - GSC™ reserves the right to
replace it with a similar product. But if the fault is not with the product, charges will apply
for any parts, labour, and shipping incurred.
Page 5.
Accidents can happen. If you damage something, we’ll do everything we can to x
your GSC™. However, if we are unable to oer any warranty on components that
have been smashed due to careless operation, water damage, or which show clear
signs of abuse.
Refunds are at the discretion of the dealer where the product was purchased.
GSC™ does not enter into customer- dealer negotiations.
KNOW YOUR ABILITY AND ALWAYS RIDE WITH CARE
IMPORTANT! The GSC™ is not a toy and not to be ridden by young children below
the age of 16. It’s a serious piece of innovative engineering and must be treated
with respect while riding. Before you attempt to ride your GSC™, be sure you
completely understand and are familiar with all its features controls safety devices
and maintenance advice in this manual.
GSC™ will run safely on most hard-packed surfaces, gravel, and trimmed grass.
But care must be taken with rough and uneven ground, and especially potholes.
Stay clear of mud, sand and water.
GSC™ is basically designed for golf course use and surrounding areas on the golf
course, it is not intended for road use or footpath/sidewalk use. GSC™ will not be
liable for any claims whatsoever whilst riding the GSC™. While riding the GSC™
please make every eort to see that it is safe and free of dangerous obstacles,
potholes or debris. Do not ride in crowded public areas. Your GSC™ is designed
for a single-rider only. Once you’ve developed reliable technique, ride within your
limits. But there are always limits, so stay alert as with most vehicles there are
certain risks involved.
Page 6.
Please check carefully that all items are included as we take every care to see that
all items are included when packaged.
UNPACKING THE GSC™.
Check rst that your new GSC™ is free of any damage that might have been caused
in transit. If any damage is noticeable, do not ride the GSC™. Contact your freight
carrier and your GSC™ supplier immediately within 7 days or your claim may be
refused. (To substantiate your claim please take photos and write a description of
the damage in question).
On receiving the product the following items will also be included in the packaging.
• 1 x Fully Assembled GSC™
• 1 x Pistol Grip 2.4GHz Wireless Controller, with 2 x 9V Rechargeable
Li-ion Batteries and Dual Charger
• 1x 36v LiFePo4 5A Battery Fast Charger
• 1 x Basic Tool Kit
• 1 x Spare Drive Belt
• 1 x Spare Fuse
• 1 x Owners Manual
We highly recommend you immediately give the GSC™ a full charge. Plug the
charger in and connect it to the charging jack on the side of the battery-pack. The
light on the charger will be RED. That means the battery is on charge. Once the
battery reaches full charge, the light turns GREEN. Follow the charging instructions
on page 1 of this owners manual.
Charging time may vary. The charge time takes 3-5 hours, depending on the
remaining charge in the battery. Use the battery often, and do not store for more
than 60 days without charging.
Tyre pressure on GSC™ should be set at 35psi. These recommended pressures
have been set to give optimum board control and battery performance. Get into a
habit of checking tyre pressure regularly.
DO NOT RIDE THE GSC™ WITH OUT FIRSTLY PUMPING UP YOUR TYRES TO
THE RECOMMENDED PRESSURE AS VALVE DAMAGE MAY OCCUR. THIS IS NOT
COVERED BY WARRANTY.
Order replacements at: www.golfskatecaddy.com or see your local dealer.
Page 7.
The following instructions take you through setting the GSC™ speed controls. This
is especially important when familiarising yourself with your new GSC™, or when
introducing friends to ride for the rst time.
One more thing, do the right thing for the environment and - recycle what packaging
you can, and dispose of the rest considerately.
SYNCHRONIZING YOUR GSC™ TO ITS VARIABLE SPEED 2.4GHz HAND
CONTROLLER.
Your GSC™ should come synchronized to its own hand controller. This oers the
advantage of eliminating interference from other GSC™ Units operating close by.
In the event that your GSC™ and hand controller lose their unique pairing or a new
hand controller is required, it is a simple process to re establish this link.
On the control panel situated on the mono handle, press the top power button and
keep this pressed until the control panel lights up.
Open up the 9v battery compartment on the remote trigger controller, remove the
9v battery from the compartment whilst leaving it connected. Inside the battery
compartment you will see a two way micro switch for adjusting speed. Next to this
you will see a small micro sync button. Using your nger or at blade screwdriver,
press and hold for 8-10 seconds. The ashing red light inside your remote trigger
controller will stop and indicates that it is now synced with your GSC™. Once this is
complete re-insert the 9v battery and replace the battery compartment cover.
ADJUSTING THE DUAL-SPEED CONTROLLER
Start Slow - Finish Fast.
For safety, your GSC™ has a speed restrictor: HIGH and LOW. To adjust the
speed restrictor, rst be sure to switch OFF the Wireless Controller.
You’ll nd the dual stage speed restrictor switch in the battery compartment of the
Wireless Controller. Remove the battery cover from the base of the handle.
Find the dual-stage switch inside the battery compartment of the hand controller.
Set the switch to a speed suitable for your riding ability. Use LOW if this is your
rst time on the GSC™. Low is the standard setting from the factory to increase to
maximum speed and torque ensure you move this switch by sliding to next position.
Page 8.
Table of contents
Other GSC Golf Trolley manuals
