Caddytek CaddyCruiser ONE V4 User manual

CaddyCruiser ONE V4
User Manual

CaddyTek Inc.
20175 S. Atlantic Blvd., # C
Monterey Park, CA 91754, USA
www.caddytek.net

WARNING:
FOR YOUR OWN SAFETY, PLEASE REVIEW THESE WARNINGS AND
KEEP THIS USER GUIDE FOR FUTURE REFERENCE.
●Before using this golf cart, please read and understand the important
instructions and warnings in this user guide.
●AVOID INJURY by always following the instructions carefully.
●AVOID INJURY by keeping clear of moving parts while adjusting, folding
or unfolding this cart.
●ALWAYS make sure the cart is fully extended and locked before use.
●ALWAYS make sure the cart is folded and locked properly before lifting or
transporting.
●ALWAYS use the brake when parking the cart.
●DO NOT run while using this cart.
●DO NOT use accessories other than those designed specifically for this
cart.
●Keep hands and fingers away from moving parts or sliding sections of the
cart

Package contents:
1. The main frame of the cart
2. Two front wheels and 2 rear wheels.
3. Umbrella holder
4. Basket (pre-installed on the cart)
5. Drink holder
6. This user manual
7. Hangtags on the handle
8. Tools for adjustment
In case any of the above items are missing or damaged, please call 800-906-6918 or email
service [email protected] to report.
Parts identification:
A: TPE handle grip
B: Scorecard holder assembly
C. Handle frame
D: Upper bag holder bracket assembly
E: Adjustable handle mechanism
F: Main connecting rod
G: Main frame
H: Leg bracket
I: 2 holes right leg frame
J: 4 holes leg frame
K: 2 holes left leg frame
L: Left stabilization bar
L1: Right stabilization bar
M: Footbrake assembly
N: Left rear wheel holder
N1: Right rear wheel holder
O: Holding slot for folded cart frame
P: Supporting cable
Q: Sub-connecting rods
R: Front wheel fork assembly
S: Rear wheel assembly
T: Lower bag holder bracket assembly
U: Front wheel lock mechanism
V: Front wheel assembly
W: Umbrella holder base
X: Umbrella holder
Y: Basket with cooler
Y1: Handle mesh net
Z: Drink holder
Z1: Umbrella holder storage rack
O
A
BX
W
Z
DC
E
G
F
Q
I
P
J
S
N1
L1
R
T
UV
M
H
N
Z1
L
KY
Y1

Extending the cart
Lift the upper bag bracket
as shown in Fig. 1.
Simply pull the handle and upper bag bracket
as shown in Fig. 2 to extend the cart. (Shake
the cart slightly to release the main frame
from the holding slot if necessary.)
Press the button on the leg frame and
insert the wheels as shown in Fig. 3
to install the rear wheels.
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Press the button on the front wheel axel
and insert the wheels as shown in Fig. 4
to install the front wheels.
Unfolding motion
Install wheels
Button
Button

Folding the cart
Cart folding button
Fig. 10
Turn the knob as shown in
Fig. 5 to release and tighten
the handle.
Fig. 5
Fig. 7
Fig. 9
To achieve the optimal folded size, adjust the
handle to the 2nd highest location marked by the
small label near knob as shown in Fig. 6.
Press the folding button and push the handle downward as
shown in Fig. 7 and Fig. 8 to fold the cart till the main frame clicks
into the holding slot as in FIG. O.
Push the upper bag
bracket downward as
shown in Fig. 9.
Fig. 10 shows the
cart is folded.
Fig. 8
Fig. O
Fig. 6
Knob
Knob

Install umbrella holder
Install drink holder
Use the brake
To put in use:
Simply attach the umbrella holder
onto the cart as in Fig. 11 & 12.
To store:
Attach the umbrella holder to the storage
rack on the right leg frame as in Fig. 13.
Press the foot brake to brake, Lift
it up to release as Fig.17
Fig. 11 Fig. 12 Fig. 13
Fig. 17
Fig. 15
When installing the drink holder as Fig.14, align the smallest part of
the slot on the holder with the fixed blocks. Then pull horizontally to fit
the holder on the base as Fig.15 & 16.
Fixed block on base
Fig. 16
Fig. 14
Slot on
Hole 1
Hole 2
Hole 2
To open the scorecard holder cove
r
Fig. 18
Button
Press the button to open the scorecard
holder cover as Fig. 18

Front wheel alignment
Fig. 19
Left Right
A B
Fig. 20
Fig. 21
Hex wrench
Alignment adjusting screws A/B
If the cart veers to the left, please use the hex wrench to turn screw A
counterclockwise and Screw B clockwise to adjust the alignment.
If the cart veers to the right, please use the hex wrench to turn screw A
clockwise and screw B counterclockwise to adjust the alignment.

WARRANTY
CaddyTek Inc. warrants its products to be free of defects and workmanship for one year
from the date of purchase. We will either repair or replace defective products at our option.
Normal wear and fading of products is not considered a manufacturer's defect. This
warranty does not apply to claim of damage to items used in connection with CaddyTek Inc.
products. In the case of deterioration due to normal use we will repair the item for a normal
charge. CaddyTek Inc. is the sole judge of any claim or warranty.
For customers in North America, please contact CaddyTek Inc. for the service. For
customers outside of North America, please either contact your dealer for the warranty
service or you are welcome to contact CaddyTek Inc. directly.

6
