GSi X Series User manual

PNEG-1787
42'-135' “X” Series Sidewall Stair
and Eave Platform
Assembly Instructions
PNEG-1787
Date: 02-16-11

2 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform

Table of Contents
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 3
Contents
Chapter 1 Introduction ..........................................................................................................................................4
Chapter 2 Safety .....................................................................................................................................................5
Safety Guidelines .................................................................................................................................. 5
General Safety Statement ..................................................................................................................... 6
Safety Instructions ................................................................................................................................. 7
Safety Sign-Off Sheet ........................................................................................................................... 9
Proper Storage of Grain Bin/Silo Materials Prior to Construction ....................................................... 10
Chapter 3 Decals ..................................................................................................................................................11
Chapter 4 72'-135' Assembly Instructions .........................................................................................................14
72'-135' Sidewall Stair Bracket Assembly ........................................................................................... 15
72'-135' Sidewall Stair Sub-assemblies .............................................................................................. 16
“X” Series Top Sidewall Stair Assembly ..........................................................................................16
“X” Series Standard Stair Assembly ................................................................................................17
Sidewall Stair Bracket Assembly - Reverse ........................................................................................ 18
72'-135' Sidewall Stair Sub-assemblies - Reverse .............................................................................. 19
“X” Series Top Sidewall Stair Assembly - Reverse .........................................................................19
“X” Series Standard Stair Assembly - Reverse ...............................................................................20
72'-135' Eave Platform and Manway Guard Sub-assemblies ............................................................. 21
“X” Series Platform Assembly ..........................................................................................................21
“X” Series Platform Assembly - Reverse .........................................................................................23
Platform Assembly on Bin Wall .......................................................................................................25
72'-135' Sidewall Stair, Eave Platform, Manway Guard and Roof Stair Interaction ............................ 26
72'-135' Sidewall Stair, Eave Platform, Manway Guard and Roof Stair Interaction - Reverse ........... 27
“X” Series Manway Guard Package (STX-0087-REV) ....................................................................27
72'-135' Assembly and Interaction of All Stair Components ............................................................... 28
Top and Standard Assembly to Wall Brackets (STX-0061 and STX-0062) ....................................28
Assembly to Platform (STX-0061) ...................................................................................................29
72'-135' “X” Series Platform Assembly - Sidewall Stairs Only ............................................................ 30
Assembly and Interaction of All Stair Components ............................................................................. 34
Stair Wall Bracket Layout Assembly on Bin Wall (STX-0036, STX-0023 and STX-0022) ..............34
Chapter 5 42'-60' Assembly Instructions ...........................................................................................................35
42'-60' Sidewall Stair Bracket Assembly ............................................................................................. 36
42'-60' Sidewall Stair Sub-assemblies ................................................................................................ 37
“X” Series Top Sidewall Stair Assembly ..........................................................................................37
“X” Series Standard Stair Assembly ................................................................................................38
Sidewall Stair Bracket Assembly - Reverse ........................................................................................ 39
42'-60' Sidewall Stair Sub-assemblies - Reverse ................................................................................ 40
“X” Series Top Stair Assembly - Reverse ........................................................................................40
“X” Series Standard Stair Assembly - Reverse ...............................................................................41
42'-60' Eave Platform Sub-assembly .................................................................................................. 42
42'-60' Complete Form and Roof Stair Interaction .............................................................................. 45
42'-60' Sidewall Stair, Eave Platform, Manway Guard and Roof Stair
Interaction Sub-assembly .................................................................................................................... 46
42'-60' Eave Platform Sub-assembly - Reverse .................................................................................. 47
42'-60' Sidewall Stair, Eave Platform, Manway Guard and Roof Stair
Interaction Sub-assembly - Reverse ................................................................................................... 51
Chapter 6 Warranty ..............................................................................................................................................53

4 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
1. Introduction
READ THIS MANUAL carefully to learn how to properly use and install equipment. Failure to do so could
result in personal injury or equipment damage.
INSPECT the shipment immediately upon arrival. The customer is responsible for ensuring that all
quantities are correct. The customer should report and note any damage or shortage on the bill of
lading to justify their claim to the transport company.
THIS MANUAL SHOULD BE CONSIDERED a permanent part of your equipment and should be easily
accessible when needed.
This warranty provides you the assurance that the company will back its products when defects appear
within the warranty period. In some circumstances, the company also provides field improvements, often
without charge to the customer, even if the product is out of warranty. Should the equipment be abused,
or modified to change its performance beyond the factory specifications, the warranty will become void
and field improvements may be denied.

PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 5
2. Safety
Safety Guidelines
This manual contains information that is important for you, the owner/operator, to know and understand.
This information relates to protecting personal safety and preventing equipment problems. It is the
responsibility of the owner/operator to inform anyone operating or working in the area of this equipment
of these safety guidelines. To help you recognize this information, we use the symbols that are defined
below. Please read the manual and pay attention to these sections. Failure to read this manual and its
safety instructions is a misuse of the equipment and may lead to serious injury or death.
DANGER
WARNING
CAUTION
NOTICE
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a
hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE is used to address practices not related to
personal injury.
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.

2. Safety
6 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
General Safety Statement
Our foremost concern is your safety and the safety of others associated with this equipment. This manual
is to help you understand safe operating procedures and some problems which may be encountered by
the operator and other personnel.
As owner and/or operator, you are responsible to know what requirements, hazards and precautions exist
and inform all personnel associated with the equipment or in the area. Safety precautions may be required
from the personnel. Avoid any alterations to the equipment, which may produce a very dangerous
situation, where SERIOUS INJURY or DEATH may occur.
You should consider the location of the bin site relative to power line locations or electrical transmission
equipment. Contact your local power company to review your installation plan or for information
concerning required equipment clearance. Clearance of portable equipment that may be taken to the bin
site should also be reviewed and considered. Any electrical control equipment in contact with the bin
should be properly grounded and installed in accordance with National Electric Code provisions and other
local or national codes.
This product is intended for the use of grain storage only. Any other use is a misuse of the product.
Sidewall bundles or sheets must be stored in a safe manner. The safest method of storing sidewall
bundles is laying horizontally with the arch of the sheet upward, like a dome. Sidewall sheets stored on
edge must be secured so that they cannot fall over and cause injury. Use care when handling and moving
sidewall bundles.
Personnel operating or working around equipment should read this manual. This manual must be
delivered with equipment to its owner. Failure to read this manual and its safety instructions is a misuse
of the equipment.
This product has sharp edges, which may cause serious injury. To avoid injury, handle
sharp edges with caution and always use proper protective clothing and equipment.

2. Safety
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 7
Safety Instructions
Our foremost concern is your safety and the safety of others associated with this equipment. We want to
keep you as a customer. This manual is to help you understand safe operating procedures and some
problems which may be encountered by the operator and other personnel.
As owner and/or operator, it is your responsibility to know what requirements, hazards and precautions
exist, and to inform all personnel associated with the equipment or in the area. Safety precautions may be
required from the personnel. Avoid any alterations to the equipment. Such alterations may produce a very
dangerous situation where SERIOUS INJURY or DEATH may occur.
This equipment shall be installed in accordance with the current installation codes and applicable
regulations which should be carefully followed in all cases. Authorities having jurisdiction should be
consulted before installations are made.
Follow Safety Instructions
Carefully read all safety messages in this manual and
safety signs on your machine. Keep signs in good
condition. Replace missing or damaged safety signs. Be
sure new equipment components and repair parts include
the current safety signs. Replacement safety signs are
available from the manufacturer.
Learn how to operate the machine and how to use controls
properly. Do not let anyone operate without instruction.
Keep your machinery in proper working condition.
Unauthorized modifications to the machine may impair
the function and/or safety and affect machine life.
If you do not understand any part of this manual or need
assistance, contact your dealer.
Read and Understand Manual
Practice Safe Maintenance
Understand service procedures before doing work. Keep area
clean and dry.
Never lubricate, service, or adjust machine while it is in operation.
Keep hands, feet and clothing away from rotating parts.
Keep all parts in good condition and properly installed. Fix
damage immediately. Replace worn or broken parts. Remove any
built up grease oil and debris. Maintain Equipment
and Work Area

2. Safety
8 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
Prepare for Emergencies
Be prepared if fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambulance service,
hospital and fire department near your telephone. Keep Emergency Equipment
Quickly Accessible
Wear Protective Clothing
Wear close fitting clothing and safety equipment appropriate
to the job.
Remove all jewelry.
Long hair should be tied up and back.
Safety glasses should be worn at all times to protect eyes
from debris.
Wear gloves to protect your hands from sharp edges on
plastic or steel parts.
Wear steel toe boots to help protect your feet from falling
debris. Tuck in any loose or dangling shoe strings.
A respirator may be needed to prevent breathing potentially
toxic fumes and dust.
Wear hard hat to help protect your head.
Wear appropriate fall protection equipment when working at
elevations greater than six feet (6').
Eye Protection
Gloves
Steel Toe Boots
Respirator
Hard Hat
Fall Protection

2. Safety
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 9
Safety Sign-Off Sheet
As a requirement of O.S.H.A., it is necessary for the employer to train the employee in the safe operating
and safety procedures for this equipment. This sign-off sheet is provided for your convenience and
personal record keeping. All unqualified persons are to stay out of the work area at all times. It is strongly
recommended that another qualified person who knows the shut down procedure be in the area in the
event of an emergency.
Date Employee Name Supervisor Name

2. Safety
10 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
Proper Storage of Grain Bin/Silo Materials Prior to Construction
Wetstoragestain(rust)willdevelopwhencloselypackedbundlesofgalvanized material, suchassidewall
and roof sheets, have moisture present. Inspect roof and sidewall bundles on arrival for any moisture. If
moisture is present, it must not be allowed to remain between the sheets. Separate the sheets or panels
immediately and wipe them down. Spray with a light oil or diesel fuel.
If possible, sidewall bundles, roof sheets and other closely packed galvanized materials should be stored
in a dry, climate controlled building. If outdoor storage is unavoidable, the materials should be stored so
that they are raised above the ground and vegetation. Any stacking and spacing materials should not be
corrosive or wet. Be sure to protect materials from the weather, but permit air movement around the
bundles if possible.
Storing roof bundles and sidewall sheets at a slight incline can also help minimize the presence of
moisture. Storing the bundles with the center of the dome up (like an arch) is one option for minimizing
moisture during storage. Sidewall bundles can also be stored on edge but must be secured so that they
do not fall over and cause injury.
If “white rust” or “wet storage stain” occurs, contact the manufacturer immediately about ways to minimize
the adverse effect upon the galvanized coating.

PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 11
3. Decals
The manufacturer does not warrant any roof damage caused by excessive vacuum or internal
pressure from fansor other air moving systems. Adequate ventilation and/or“makeup air” devices
should be provided for all powered air handling systems. The manufacturer does not recommend
the use of downward flow systems (suction). Severe roof damage can result from any blockage of
air passages. Running fans during high humidity/cold weather conditions can cause air exhaust
or intake ports to freeze.
Excessive vacuum (or pressure) may
damage roof. Use positive aeration
system. Make sure all roof vents are
open and unobstructed. Start roof
fans when supply fans are started.
Do not operate when conditions exist
that may cause roof vent icing.
DC-969
CAUTION!

3. Decals
12 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
ATTENTION: The decal shown below should be present on the outside of the door cover of the 2 ring,
24" porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of
these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: [phone]
Rotating flighting will
kill or dismember.
Flowing material will
trap and suffocate.
Crusted material will
collapse and suffocate.
Keep clear of all augers.
DO NOT ENTER this bin!
Failure to heed these
warnings will result in
serious injury or death.
If you must enter the bin:
1. Shut off and lock out all power.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
DC-GBC-1A

3. Decals
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 13
ATTENTION: The decal shown below should be present on the outside of the door cover of the 2 ring,
24" porthole door cover and the roof manway cover. If a decal has been damaged or is missing in any of
these locations, contact the manufacturer for a free replacement decal.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: [phone]
Failure to heed these warnings
could result in serious injury, death,
structural damage or collapse of tank.
1. Use CENTER FLOOR OUTLET ONLY until NO grain
remains above this outlet.
2. Side floor outlets to be used ONLY when above
condition is satisfied.
3. Lock all side floor outlets to avoid accidental
premature use.
4. See manufacturers instructions for proper use of
factory supplied sidedraw (wall) discharge systems.
UNLOADING INSTRUCTIONS:
DC-GBC-2A
WARNIN
DON’T DO

14 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
4. 72'-135' Assembly Instructions
Sidewall Stair Handrail Lengths and Part Numbers
Description Handrail Length 105' Versions Handrail Length 135' Versions
Top Section Handrail Outside 49.062" STX-0030 48.562" STX-0096
Top Section Handrail Inside 48.187" STX-0031 48.062" STX-0093
Standard Section Handrail Outside 50.936" STX-0032 50.436" STX-0094
Standard Section Handrail Inside 49.687" STX-0033 49.562" STX-0095
Description Handrail Length 90' Versions Handrail Length 72'-78' Versions
Top Section Handrail Outside 49.452" STX-0126 50.125" STX-0130
Top Section Handrail Inside 48.360" STX-0127 48.500" STX-0131
Standard Section Handrail Outside 51.326" STX-0128 51.854" STX-0132
Standard Section Handrail Inside 49.860" STX-0129 50.000" STX-0133

4. 72'-135' Assembly Instructions
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 15
72'-135' Sidewall Stair Bracket Assembly
Figure 4A

4. 72'-135' Assembly Instructions
16 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
72'-135' Sidewall Stair Sub-assemblies
“X” Series Top Sidewall Stair Assembly
Figure 4B
Top section handrail inside
(See chart on Page 14 for
part numbers.)
Top section handrail outside
(See chart on Page 14 for
part numbers.)
Stair bracket assembly
(See Page 15 for part
numbers.)

4. 72'-135' Assembly Instructions
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 17
72'-135' Sidewall Stair Sub-assemblies (Continued)
“X” Series Standard Stair Assembly
Figure 4C
Standard section handrail
inside (See chart on
Page 14 for part numbers.)
Standard section handrail
outside (See chart on
Page 14 for part numbers.)
Stair bracket assembly
(See Page 15 for part
numbers.)

4. 72'-135' Assembly Instructions
18 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
Sidewall Stair Bracket Assembly - Reverse
Figure 4D

4. 72'-135' Assembly Instructions
PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform 19
72'-135' Sidewall Stair Sub-assemblies - Reverse
“X” Series Top Sidewall Stair Assembly - Reverse
Figure 4E
Top section handrail outside
(See chart on Page 14 for
part numbers.)
Top section handrail inside
(See chart on Page 14 for
part numbers.)
Stair bracket assembly
(See Page 18 for part
numbers.)

4. 72'-135' Assembly Instructions
20 PNEG-1787 42'-135' “X” Series Sidewall Stair and Eave Platform
72'-135' Sidewall Stair Sub-assemblies - Reverse (Continued)
“X” Series Standard Stair Assembly - Reverse
Figure 4F
Standard section handrail
outside (See chart on Page 14
for part numbers.)
Standard section handrail
inside (See chart on
Page 14 for part numbers.)
Stair bracket assembly
(See Page 18 for part
numbers.)
