GSL IntelliVault 3-DRAWER CABINET User manual

Installation Guide

View the latest PDF and online versions of this guide at: https://www.gslcorp.com/intellivault/
Table of Contents
Introduction ................................................................................................................................................................ 3
Specifications ............................................................................................................................................................ 5
Warnings, Precautions, Notices ............................................................................................................................. 6
General Warnings ...................................................................................................................................................... 7
Take Inventory of All Parts ....................................................................................................................................... 8
Prepare the Installation Area ................................................................................................................................. 10
Master Cabinet Setup ............................................................................................................................................. 12
Install the Anchor Straps ....................................................................................................................................... 24
Secure the Cabinet in Place .................................................................................................................................. 28
Installing the CTS .................................................................................................................................................... 35
Install the Drawers .................................................................................................................................................. 48
Align the Drawers .................................................................................................................................................... 57
Cabling a Multi-cabinet Installation ...................................................................................................................... 62
Power and Network Connections ......................................................................................................................... 66
Prepare for Pharmacy Operation .......................................................................................................................... 68
Troubleshooting ...................................................................................................................................................... 74
Appendix A - Installation Checklist ...................................................................................................................... 78
Appendix B - Replacing Circuit Boards ............................................................................................................... 79
Appendix C - MCB Drawer Configuration ............................................................................................................ 86
Appendix D - Security Strap Kit ............................................................................................................................ 90
Appendix E - Seismic Strap Kit ............................................................................................................................. 91
Appendix F - Sample GSL Equipment Layout Diagram ..................................................................................... 92
Appendix G - CTS Wiring ....................................................................................................................................... 93
Appendix H - Multi-cabinet Wiring ........................................................................................................................ 95

IntelliVault Gen II - Installation Guide
3
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Introduction
This document describes the installation procedure for the GSL Solutions IntelliCab and
IntelliVault systems. The IntelliVault is the second generation of a highly automatic pharmacy
workflow management system. The IntelliVault is built to eliminate bundling and picking errors,
monitor inventory, and track the location of individual prescriptions.
July 2019 Edition
General Product Description
The IntelliVault system is a collection of components that improves the efficiency, safety, and
security of front-end pharmacy operations. The cabinet is the main component. This system is
run on IntelliSys software, which interfaces directly with the Pharmacy Management System
(PMS) that is already in use behind the pharmacy counter. The central components of the
IntelliVault / IntelliCab system include a multi-drawer, lockable cabinet and the Cabinet Top
Server (CTS).
Cabinet Top System
The CTS communicates with the Pharmacy Management System (PMS) through IntelliSys
software to retrieve data about the prescription, including user name, drug name, and social
security number. In its database, the CTS links the prescription number with the workflow
basket. Learn more in Installing the CTS.
Additional Cabinets
Some installations involve connecting additional cabinets to the primary cabinet and the CTS.
Learn more in Cabling a Multi-cabinet Installation.
Troubleshooting
As you proceed through the installation, consult the Troubleshooting chapter if necessary.

IntelliVault Gen II - Installation Guide
4
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Appendices
There are a number of appendices at the end of this guide:
· Appendix A - Installation Checklist
· Appendix B - Replacing Circuit Boards
· Appendix C - MCB Drawer Configuration
· Appendix D - Security Strap Kit
· Appendix E - Seismic Strap Kit
· Appendix F - Sample Layout Diagram
· Appendix G - CTS Wiring
· Appendix H - Multi-cabinet Wiring

IntelliVault Gen II - Installation Guide
5
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Specifications

IntelliVault Gen II - Installation Guide
6
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Warnings, Precautions,
Notices
This warning symbol means danger. You are in a situation that could
cause bodily injury. Before you work on any equipment, be aware of
the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number
provided at the end of each warning to locate its translation in the
translated safety warnings that accompanied this device.
You will find these indicators throughout this user guide:
Indicates a hazardous situation which you must prevent to avoid
death or injury.
Indicates a hazardous situation which you should prevent to avoid
possible death or injury.
Indicates a hazardous situation which you must prevent to avoid
injury.
Specifies a good practice or conveys important information.

IntelliVault Gen II - Installation Guide
7
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
General Warnings
Always unplug the equipment from the electrical outlet before
cleaning.
Risk of Electric Shock – Connect this furnishing to a properly
grounded outlet only. See Grounding Instructions
Close supervision is necessary when this equipment is in use by or
near children, invalids, or disabled persons.
Only trained and qualified personnel should ever install, replace, or
service this equipment.
Keep the cord away from heated surfaces.
Never operate this equipment if it has a damaged cord or plug, if it is
not working properly, if it has been dropped or damaged, or dropped
into water. Return the furnishing to a service center for examination
and repair.
Use this equipment only as intended, and as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
Ultimate disposal of this equipment should be handled according to
all national laws and regulations.
Never operate the furnishing with the air openings blocked. Keep the
air openings free of lint, hair, and the like.
Do not use outdoors.
Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
To disconnect, turn all controls to the off position, then remove plug
from outlet.

IntelliVault Gen II - Installation Guide
8
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Take Inventory of All Parts
Before unpacking the components of the IntelliVault system, read through this topic to ensure
that you have the right tools and locate/position all of the components.
Components
Ensure you have all the components for this installation, including:
· Master cabinet
· Any additional slave cabinets that were ordered
· CTS unit
· Security anchor kit OR seismic-grade floor anchor kit
Tools necessary
The following tools are necessary to install the cabinet:
· #2 Phillips Screwdriver
· M4 hex key wrench
· 9/16-inch Open-end Wrench
· IP 15 TORX Driver
· 3/8-inch deep-socket wrench for adjusting the cabinet legs
· 1/16-inch hex key to remove drawer-handle covers
· A telescoping hook
· An override handle key
Cabinets
Any master or slave cabinet comes with the following:
· Five legs - four corner legs and one center leg
· Front toe kick and two side toe kicks
· Network cables and a 120V power cable
· Installation Guide

IntelliVault Gen II - Installation Guide
9
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
CTS
Locate the CTS box and position it near where it will be raised up onto the primary cabinet.
Bolts for securing the CTS to the cabinet can be found in the back-right corner inside the CTS.
The UPS and servers are in separate boxes.
Anchor straps
It is necessary to install an anchor strap kit, which may be either a security strap kit or a
seismic kit.

IntelliVault Gen II - Installation Guide
10
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Prepare the Installation Area
Remove the packaging that secures the cabinet to the pallet.
Adequate space to install cabinet feet and anchor straps: It will be
necessary to tilt the cabinet about 30 degrees to install the cabinet feet, but it
will be necessary to lay the cabinet onto its backside to install the security
straps.
Ensure that there is enough room in the installation area to tilt the cabinet onto
its backside. Otherwise, it will be necessary to install the feet and anchors in a
larger room prior to moving the cabinet into its final destination in the
pharmacy.
GSL Pallet
It may be best to keep the cabinet on the GSL pallet to move it to the location at which the
anchors and feet will be installed. Remember that this pallet should be returned to GSL when
the installation is complete.
Prior to uncrating
Before uncrating the IntelliVault Gen II System, ensure that the installation site is ready:
· Ensure the installation site is accessible. The door to the final location must be wide
enough to accommodate the width and height of the cabinet. If necessary, the height of
the cabinet as it sits on the pallet must be considered.
· The height of the final installation area must accommodate the CTS unit when it is set in
place atop the cabinet.
· The installation site should have a level floor without carpet.
· Install the cabinets according to the placement given on the installation diagram.
· Ensure that 120V AC power is available.
· Ensure that an active 10Gb network connection is available.

IntelliVault Gen II - Installation Guide
11
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
· Verify that standard or seismic floor anchors have been installed. The Anchor Straps will
attach to these anchors. Also, see example diagrams in Appendix D - Security Strap Kit
and Appendix E - Seismic Strap Kit.
Prior to moving
Refer to the site-specific installation layout to verify cabinet placement, power and network
connections, et cetera. An example of this diagram can be seen in Appendix F - Sample
Layout Diagram.

IntelliVault Gen II - Installation Guide
12
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Master Cabinet Setup
Setting up the master cabinet involves these steps:
1. Unlock the drawers (if on pallet, the drawers will already be unlocked)
2. Remove the drawers
3. Attach the corner feet
4. Remove cabinet shell from pallet
5. Install the anchor strap kit
6. Move to final location
7. Level the cabinet
Details for each of these steps are given in the sections below.
Refer to the site-specific GSL equipment layout to verify cabinet placement,
power and network connections, et cetera. An example of this diagram can
be seen in Appendix F - Sample GSL Equipment Layout Diagram.
Unlock the drawers
NOTE: Lock motors are only present on IntelliVault cabinets.
Prior to powering on the cabinet, the drawers are not locked. At shipment, the lock motor cams
are manually turned to the unlock position. When the cabinet receives power, the lock motor
cams will automatically move to a locked position. If you don't power on the cabinet, the
drawers remain unlocked.
Override handle: If you do power on the cabinet, the drawers will lock, and
you will need to pull the override handle. The override handle is locked when
the key slot is in the vertical position.

IntelliVault Gen II - Installation Guide
13
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
To unlock the override handle, insert the key and rotate it clockwise so that the slot is in the
horizontal position. Then, pull the handle outward until the override catch engages to unlock the
drawers.
For Intellicab: There is no handle. There's only a key, which locks the anti-tilt mechanism and
locks all drawers. If unlocked, then only one drawer may be open at a time.
Removing the drawers
The cabinet is heavy, and extremely heavy with the drawers inside. You must
remove all of the drawers from the cabinet, one drawer at a time, before
installing the feet and the straps.
It is VERY IMPORTANT that only one drawer is open at a time. The weight of
a drawer is comparable to the cabinet itself, so opening two or more drawers
at a time can be very dangerous. The cabinet may tip forward, so be watchful
of this when removing a drawer. During normal operation, the UltraTrack

IntelliVault Gen II - Installation Guide
14
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
permits only allows one drawer to be open at a time. However, this is not the
case during installation. Though it is possible to open all drawers
simultaneously, it must be diligently avoided.
Each drawer is heavy, so the drawers should be removed and remain outside
of the cabinet until the cabinet is put into its final position and leveled.
Leave the cabinet on the pallet until the time comes to move it into its final
position at the installation site.
During the removal of each drawer: To aid in reinstallation, use tape to label
each drawer with its parent cabinet and position.
PRIOR to opening the drawers: Ensure that there is enough flat floor space on
which to remove, maneuver, and place the four large vertical drawers.
Follow these steps to remove the drawers:
1. Open drawer in order to remove the shipping block from its upper slide channel.

IntelliVault Gen II - Installation Guide
15
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
2. Remove the slide pin from its shipping position in the lower drawer slide and reinstall it in
the drawer installation and removal position.
3. Underneath the drawer, depress the small tab and unplug the network cable.
4. Detach the cable track from the drawer by loosening the thumbscrew until the cable
track bracket drops away.

IntelliVault Gen II - Installation Guide
16
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
5. Release the red slide lock bracket at the top of the drawer by loosening it with a #2
Phillips screwdriver and rotating it to the side.
6. Disengage the upper channel slide lock by pulling it forward until its locking toe is free. If
needed, use a small tool like a flat head screwdriver to assist in moving the lock.

IntelliVault Gen II - Installation Guide
17
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
Each drawer is quite heavy. Use a drawer dolly when removing and installing each
drawer.
7. Pull the drawer all the way forward and position a drawer dolly at the in front of the
drawer and on its center line. Line up the front face of the drawer with the flat to angled
transition on the top of the drawer dolly.

IntelliVault Gen II - Installation Guide
18
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
8. While holding the drawer by its handle with one hand for support, slide the upper drawer
slide back into the cabinet.
9. While holding the drawer by its handle with one hand for support, slide the upper drawer
slide back into the cabinet. Lift the front of the drawer by the handle approximately two
inches in order to disengage the drawers hard stop from its lower slide.

IntelliVault Gen II - Installation Guide
19
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
· Be mindful of the network cable that is hanging from the bottom of the drawer. It
will incur damage if you step on it or dropping a drawer edge onto it.
· Place each drawer on a location where it won't tip over. A slight nudge can easily
tip over a drawer and cause damage.
10. Set the front of the drawer into the saddle of the drawer dolly. Support the drawer with
one hand on the drawer handle and one hand holding the rear of the drawer.

IntelliVault Gen II - Installation Guide
20
https://www.gslcorp.com/intellivault/
View the latest PDF and online versions of this guide at:
11. Stand the drawer up in a safe location where nothing can tip it over.
12. Repeat these steps for any remaining in the cabinet.s
Attach the corner feet
Cabinet feet can be installed by tipping the cabinet first backward and them
forward 30°, but it is necessary to lay the cabinet onto its backside to install the
security straps. Ensure that you have adequate room to perform these steps.
Follow these steps to attach the feet:
1. Because the interconnect box is suspended beneath the cabinet, it is necessary to leave
the cabinet on the pallet while installing the feet.
2. Ensure that you have enough space to tilt the cabinet about 30 degrees backward and
forward.
3. Remove all washers and nuts from each foot.
