GSS PROFESSIONAL PSCU 6000 User manual

English
CLASS
KLASSE
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
E-mail: [email protected]
Internet: http://www.gss.de
PSCU 6000
Monitoring Cassette

- 2 - PSCU 6000
Contents
1 Safety regulations and notes........................................................................3
2 General information ....................................................................................4
2.1 Packing contents............................................................................4
2.2 Meaning of the symbols used..........................................................4
2.3 Technical data...............................................................................4
2.4 Description ...................................................................................6
2.5 Software query..............................................................................7
3 Assembly....................................................................................................8
3.1 Setting the signal paths ..................................................................8
Positioning of the jumpers...............................................................9
Blockdiagram...........................................................................9
Audio and video signal "internal" ............................................10
Audio signal "external" / video signal "internal"........................10
Providing the info channel via the cinch sockets .........................10
Feeding of external signal sources ...........................................10
3.2 Installing the cassette....................................................................11
3.3 EMC regulations..........................................................................12
3.4 Overview of the cassette ..............................................................13
3.5 Connecting the cassette................................................................13
4 The control panel at a glance.....................................................................15
4.1 Menu items.................................................................................15
4.2 Control panel..............................................................................15
5 Programming............................................................................................16
5.1 Programming procedure...............................................................16
5.2 Programming the cassette ............................................................17
Selecting the cassette ...................................................................17
Output channel ...........................................................................18
Software version.....................................................................18
Fine-tuning.............................................................................19
Switching the modulator off or on.............................................19
Modulation depth (residual carrier)................................................20
Display mode..............................................................................20
Setting "normal" ....................................................................20
Setting "extended" .................................................................21
Saving settings ............................................................................21
6 Put the cassette into operation (channel search) ..........................................22
7 Channel and frequency table .....................................................................24

- 3 - PSCU 6000
1 safety regulations and notes
• Assembly, installationandservicing should becarriedoutby authorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work or pull out the mains plug.
 • Donotperforminstallationandserviceworkduringthunderstorms.
 • Installthesystemsoitwillnotbeabletovibrate…
 - inadust-free,dryenvironment
 - insuchamannerthatitisprotectedfrommoisture,fumes,splashingwa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
 • Ensurethatthehead-endstationisadequatelyventilated.Donotcoverthe
ventilation slots.
 • Bewareofshortcircuits
 • Noliabilityisacceptedforanydamagecausedbyfaultyconnectionsor
inappropriate handling.
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • ThestandardsIEC/EN/DINEN50083resp.IEC/EN/DINEN60728must
be observed.
 • For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
"www.gss.de".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
EuropeanCouncilfromJanuary27,2003whichaddressesoldelectronicand
electricaldevices,suchdevicesmustbedisposedofatadesignatedcollection
facility.Attheendofitsservicelife,pleasetakeyourdevicetooneofthese
public collection facilities for proper disposal.

- 4 - PSCU 6000
2 general information
2.1 PaCking Contents
1 Monitoring Cassette PSCU 6000
1 Brief assembly instructions
2.2 meaning of the symbols used
Important note
—> General note
 • Performingworks
2.3 teChniCal data
The devices meet the following EU directives:
 2006/95/EC,2004/108/EC
The product fulfils the guidelines and standards for CE labelling (Page 25).
Unless otherwise noted all values are specified as "typical".
Measurement range for analog TV picture carriers
Input frequency range: ......................................... 48.25…855.25MHz
Channels: .............................................................C2…C69,S2…S41
Input level range:..............................................................60…80dBµV
Measurement range for QAM signals
Input frequency range: ........................................ 306.00…858.00MHz
Symbol rate: ................................................................. 1…7MSymb/s
Modulation mode: ................................. 16 / 32 / 64 / 128 / 256 QAM
Input level range:..............................................................60…80dBµV
Measurement range for FM carriers
Input frequency range: ......................................... 87.5MHz…108MHz
Input level range:..............................................................60…80dBµV
Common measurement input
Input impedance:............................................................................75 Ω
Adjustment:...............................................................................> 9.5 dB

- 5 - PSCU 6000
Measurement output
Output impedance:......................................................................... 75 Ω
Measuring range tolerance :..........................................................± 3 dB
Adjustment:...............................................................................> 9.5 dB
Decoupling (measurement output on measurement input): ...................30 dB
Loop-through loss:...................................................................–2…5dB
Video and Audio output
Videooutputimpedance:................................................................. 75 Ω
Videooutputvoltage: ......................................................................1Vpp
Audio output impedance: .................................................................1 kΩ
Video and audio input
Videoinputimpedance: ..................................................................75 Ω
Videoinputvoltage:........................................................................1Vpp
Audio input impedance: .................................................................22 kΩ
Audio input voltage: ..............................................................1…2Vrms
Modulator output
Impedance:.................................................................................... 75 Ω
Channels: ............................................................................C21…C69
Frequency range: ....................................... 471.25MHz…855.25MHz
Output level: ........................................................................... 100dBµV
Power supply
Internal via 10-pin connector...........................................................+12V
External via DC IN socket.............. ,+10V…+40V,max.700mA
Power consumption: ........................................................................5 W
Connectors, control elements and display
HF input: .................................................................1IECsocket,female
HF output (measuring output): ....................................... 1IECsocket,male
HF output (modulator): ...............................................1IECsocket,female
Video(input/outputsocket): ...............................................1 Cinch socket
Audio (input/output socket): ...............................................1 Cinch socket
Push button: ........................................................starts the channel search
DC IN (low-voltage socket) :
– Outer diameter .................................................................... 5…6mm
– Inner diameter ...........................................................................2.1mm
LED (green): ...................................................operation / channel search
9-pin D-SUB socket RS 232:................................................serial interface
Connection strip (10-pin): ..................for supply voltages and control circuits

- 6 - PSCU 6000
Remote maintenance
Remotely controllable (via PSW 1000*): ..............................................yes
Remote update (via BEflash*):.............................................................yes
(* and a corresponding management unit)
2.4 desCriPtion
The monitoring cassette PSCU6000,inthefollowingcalledcassette,isusedto
provide the output levels and the output data of the head-end stations monitored
via an info channel in the cable network. The info channel is programmable in
therangeofC21…C69.
The following parameters are controlled:
 – AnalogTVchannels:HFlevelandsynchronizationpulse.
 – DigitalTVchannels: HFlevel,BER(BitErrorRate).
 – Radiostations: HFlevel,RDSidentifier
 Theinfochannelcontainsthechannelsofthecablenetworkset,theappropri-
atechannelnames(identifiedfromtheRDSresp.VPSdata),thebiterrorrate
(BER) and the output level of the respective channels. In addition the signals
fed via the audio and video sockets can be transmitted via the info channel or
the data of the info channel can be provided as audio and video signals.
Is the cassette connected to a corresponding management unit via the "RS-232"
socket,errormessagescanbesentviaphone,informofe-mailorSNMPin-
form requests, if any pre-stored reference level is exceeded. Therefore the
configuration is to be done with the help of a PC and the PSW 1000 software.
For this observe the operation instruction of the PSW1000software,tobe
downloaded from our home page "www.gss.de".
To operate this cassette the software version of the control unit must be "V 44"
or higher. You can find the current operating software for the control unit and
thecassette,thesoftware"BE-Flash" and the current assembly instructions on
the website "www.gss.de".
The cassette is intended for use in the PROFI-LINE head-end stations.

- 7 - PSCU 6000
2.5 soft ware query
Control unit
 If necessary, you can activate the indication of the software version of the
control unit manually:
 • Pressanytwokeysonthecontrolunitofthehead-endstationsimultaneously
untilthedisplaygoesdarkandthesoftwareversion,e.g."V 44" appears.
Cassette
 Seechapter"Queryingthesoftwareversion",page19.

- 8 - PSCU 6000
3 assembly
3.1 setting the signal Paths
The signal paths are adjustable via jumpers.
Note
Take action to prevent static discharge when working on the device.
Danger of cut injuries!
The cassette is made of punched stainless steel parts. Some of them may have
sharp edges.
 • Screw3screwsS(TORX TX6) out of the cassette cover.
 • Pushthecassettecovertotherearandremoveit.
S

- 9 - PSCU 6000
Positioning of the jumPers
Jumpers
—> The position of the jumpers meets the "internal" setting.
bloCkdiagram
Modulator
HF Ausgang
HF output
Video
Video
Audio
Audio
BU60121 BU60111
Video
Audio
AV
ext
int
Infokanal
Info channel
Test
-20dB

- 10 - PSCU 6000
audio and video signal "internal"
AUDIO
internal
VIDEO
internal
For this positioning of the jumpers (factory setting) the
internal signals are used only.
The info channel is provided via the measuring out-
put of the cassette using the output channel set on the modulator. Additionally
the info channel is fed into the cable system via the output collector of the
head-end station.
—> ControllingtheinfochannelconnectatestreceiveroraTVsettothe
measuring output of the cassette or to the cable system.
audio signal "external" / video signal "internal"
AUDIO
external VIDEO
internal
For this positioning of the jumpers an external audio
signal (e.g. music) can be fed via the cinch socket
and combined with the internal video signal provided
as the info channel.
The info channel is provided via the measuring output of the cassette using the
output channel set on the modulator. Additionally the info channel is fed into
the cable system via the output collector of the head-end station.
—> ControllingtheinfochannelconnectatestreceiveroraTVsettothe
measuring output of the cassette or to the cable system.
Providing the info Channel via the CinCh soCkets
AUDIO
Cinch
VIDEO
Cinch
For this positioning of the jumpers the info channel is
provided exclusively via the audio and video cinch
sockets.
—> ControllingtheinfochannelconnectamonitororTVsettothecinch
sockets "AUDIO" and "VIDEO" of the cassette .
feeding of external signal sourCes
AUDIO
external
VIDEO
external
For this positioning of the jumpers the external signals
fed via the cinch sockets "AUDIO" and "VIDEO" are
provided via the cable system and the measuring out-
put of the cassette.
