GSS STC 1200 User manual

Assembly Instruction
STC 1200

- 2 - STC 1200
Contents
1 Notes about safety and hazards ..................................................................4
2 General information ....................................................................................6
2.1 Meaning of the symbols used ..........................................................6
2.2 Scope of delivery ..........................................................................6
2.3 Available accessories .....................................................................6
2.4 Technical data ...............................................................................6
2.5 Description ...................................................................................8
3 Overview ....................................................................................................9
3.1 Front cover ...................................................................................9
3.2 Connectors and components .........................................................10
Front view / side view (type label) ............................................10
View from below ....................................................................10
Rear view ..............................................................................11
3.3 Control unit .................................................................................12
4 Installing the head-end station ...................................................................13
4.1 EMC regulations (electromagnetic compatibility) ..............................13
4.2 Remove front cover ......................................................................13
4.3 Mounting the head-end station ......................................................14
Wall mounting .......................................................................14
Mounting in a cabinet .............................................................15
5 Installing a cassette ...................................................................................16
6 Power supply ............................................................................................17
6.1 SAT IF input distributor .................................................................17
6.2 Hybrid amplifier ..........................................................................17
6.3 Connecting peripheral devices ......................................................17
7 Connecting the head-end station ................................................................18
7.1 Potential equalisation (PE) .............................................................18
7.2 Connecting the SAT IF input distributor ...........................................18
Overview ..............................................................................18
Connecting SAT IF inputs .........................................................19
Using two reception levels (factory settings) ...............................19
Using one reception level (loop-through operation) .....................19
7.3 Connecting HF output of the head-end station .................................19
7.4 Mains connection ........................................................................20
8 Setting the contrast of the display ...............................................................21

- 3 - STC 1200
9 The control panel at a glance .....................................................................21
9.1 Control panel ..............................................................................21
9.2 Menu items .................................................................................21
10 Updating the software of the control unit ....................................................22
10.1 Updating software via PC .............................................................22
10.2 Updating the software via second control unit .................................22
Removing master control unit ...................................................22
Programming slave control unit ................................................23
Inserting master control unit .....................................................24
11 Programming ............................................................................................24
11.1 Preparation .................................................................................24
11.2 Programming procedure ...............................................................25
Message after temperature exceeding .......................................26
11.3 Programming the head-end station ................................................27
Activating system information ...................................................28
System information – control unit ..............................................28
To perform settings: .................................................................28
To call up information about the head-end station: ......................28
System information – output collector ........................................29
System information – temperature .............................................29
System information – number of the head-end station ..................30
System information – clock frequency ........................................30
Setting the HF output level of the cassettes ................................30
Setting the HF output level of the head-end station ......................31
Setting the consecutive number of the head-end station................31
Activating the modem connection .............................................32
Setting the password ...............................................................32
Saving settings .......................................................................33
Programming the head-end station (following excess temperature) 33
– System information ...............................................................34
12 Final procedures ........................................................................................35

- 4 - STC 1200
1 notes about safety and hazards
• Observe the relevant VDE regulations.
• If the power cord needs to be replaced, only use an OEM power cord (EMV!).
• Only replace fuses with fuses of the same type, and which also have the
same cut-off characteristics.
• The standards IEC/EN/DIN EN 50083 resp. IEC/EN/DIN EN 60728 must
be observed, especially concerning equipotential bonding and earthing .
• Observe the relevant country-specific standards, regulations and guidelines
on the installation and operation of antenna systems.
• Before starting installation or service work disconnect the receiving system
from mains.
• Do not perform installation and service work during thunderstorms.
• Assembly, installation and servicing must be carried out by an authorised
electrician.
• For a complete disconnection from the mains, the mains plug must be pulled
out of the mains socket. Ensure that the mains plug can be pulled out without
difficulties.
• The head-end station should only be installed in a room where the permissi-
ble ambient temperature range (0 °C and +50 °C ) can be maintained, even
during fluctuations in climatic conditions.
• Make sure there is a minimum space at wall mounting and stand mounting of
20 cm on either side and 50 cm above.
• To avoid too strong interacted heating of the head-end stations it is not
admissible to mount them one upon the other without using thermic precau-
tions (e.g. permanently air recirculation, ventilation, heat deflectors etc.).
• Install the head-end station
- in a dry, dust-free environment
- in such a manner that it is protected from moisture, fumes, splashing wa-
ter and dampness
- where it is protected from direct exposure to sunlight
- on a vibration-free wall or floor construction
- not within the immediate vicinity of heat sources
• In case of the formation of condensation wait until the system is completely
dried.
• Ensure that the head-end station is adequately ventilated.
• Do not cover the ventilation openings!
• Do not install the head end in cabinets or recesses which are not ventilated.
• If additional fans are to be used to circulate the air, ensure that the system will
be shut down (disconnected from mains) should any one of the fans fail.
• Do not place any vessels containing liquids on the head-end station.

- 5 - STC 1200
• Do not place anything on the head-end station which could initiate fires
(e.g. candles).
• Due to the risk of fires caused by lightning strikes, we recommend that all
mechanical parts (e.g. distributor, equipotential bonding rail, etc.) be mounted
on a non-combustible base. Wood panelling, wooden beams, plastic covered
panels and plastic panels are all examples of combustible bases.
• Avoid short circuits!
• To ensure electromagnetic compatibility, make sure all connections are tight
and that the covers are screwed on securely.
• No liability is accepted for damage caused by faulty connections or inap-
propriate handling of the device.
• You can obtain additional information from the "Planning handbook" bro-
chure which can be found on the website "http://www.mygss.eu" under
the " Miscellaneous" category.
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 6 - STC 1200
2 General information
2.1 meaninG of the symbols used
Important note
• Performing works
Danger by electrical shock
—> General note
2.2 sCope of delivery
1 STC 1200 head-end station (without cassettes)
1 Brief assembly instructions 1 DVD (assembly instructions)
1 Ferrite sleeve Mounting material
2.3 available aCCessories
For cassettes and accessories see website "www.gss.de".
2.4 teChniCal data
The devices meet the following EU directives:
2011/65/EU, 2014/30/EU, 2014/35/EU
The product fulfils the guidelines and standards for CE labelling (page 36 ).
Unless otherwise noted all values are specified as "typical".
General
Cassette slots: ...................................................................................12
Admissible ambient temperature: ....................................... 0 °C … +50 °C
Dimensions (W x H x D) [mm]: .......................... approx. 700 x 383 x 315
Weight (fully equipped): .....................................................approx. 30 kg
LNB operating voltage: ....................+18 V / ≤1 A total (short-circuit-proof)
Other operating voltage: ................+12 V / ≤1 A total (not short-circuit-proof,
use with appropriate external fuse only)
RS 232 socket: ................................data interface for software update and
remote maintenance
SAT IF input distributor: ............................................................. quantity 3

- 7 - STC 1200
Data of one SAT IF input distributor
Frequency range: ....................................................... 950 … 2150 MHz
SAT IF inputs: ......................................................................... 2 F sockets
SAT IF loop-through output: ....................................................... 1 F socket
SAT IF outputs: ......................................................................10 F sockets
Input / output impedance: .............................................................. 75 Ω
Decoupling of the outputs: ..............................................................20 dB
Loss 1-6 fold (see page 8): .......................................................9 … 14 dB
Loop-through loss: ............................................................................8 dB
Loss 1-4 fold (see page 8) ........................................................9 … 12 dB
LNB operating voltage: ......................................... +18 V / max. 1 A total
(1 A at one LNB connector,
0.5 A at two LNB connectors
0.25 A at four LNB connectors etc.)
HF output collector
Input frequency range: .................................................... 45 … 862 MHz
Control range of each input: .............................0 … –25 dB (electronically)
Control range of each output: .............................0 … –6 dB (electronically)
Input, output impedance: .................................................................75 Ω
Return loss: ...................................................................................14 dB
HF output: ..........................................................................IEC connector
Decoupling loss of the inputs: ..........................................................30 dB
Hybrid amplifier
Input frequency range: .....................................................45 ... 862 MHz
Gain: ...........................................................................................24 dB
Output level (CSOA ≤60 dB, 29 channels): .............................. ≤106 dBμV
Input, output impedance: .................................................................75 Ω
Operating voltage: ........................................................................+24 V
Current consumption: ..................................................................230 mA
HF output: .................................................................................. F socket
Measuring output: ...............................................................IEC connector
Decoupling loss: ............................................................................20 dB
Power supply
Mains voltage: .................................................... 220–240V~, 50/60 Hz
Power consumption: ............................................................max. 210 W

- 8 - STC 1200
2.5 desCription
The head-end station has a modular structure and can hold up to Standard
cassettes. You can find a list of the current Standard cassettes at the website
"www.mygss.eu". This head-end station is designed exclusively for use with
cassettes of the Standard marketing programme. The various expansion op-
tions for the head-end station allow for the installation of a wide range of
broadband cable systems.
Each of the three integrated SAT IF input distributors has two SAT IF inputs.
You can use them to distribute two reception levels over 4 or 6 outputs. Using
the loop-through output enables you to distribute reception level 1 over the 10
outputs for each SAT IF input distributor. The F sockets of both reception levels
are coloured.
Basic signal pattern:
9-12 dB 9-14 dB
8 dB
Unused loop-through outputs must be terminated with the resistors supplied.
The power supply in the head-end station is designed to supply power to
components (e.g. LNBs) connected upstream. These are supplied via the SAT
IF input distributors’ input sockets with operating voltage (+18 V) at a total
current of max. 1 A.
In addition, the head-end station’s power supply unit can be used to supply
peripheral devices with voltage (+12 V / max. 1 A, with an external fuse).
The cassettes’ HF output signals are accumulated in a programmable HF out-
put collector and then directed to the HF output and to the test output via the
downstream hybrid amplifier.
When the head-end station is shipped from the factory, the default setting for
the HF output level of the output collector is -3 dB. You can use the software of
the control unit to program the master output level of the head-end station.
The software version of the control unit appears on the two-line LC display
after switching on the head-end station. If the inner temperature of the head-
end station exceeds the permissible temperature of 65 °C when operating, a
message appears in the display instead of the standby menu. This message
contains the maximum measured temperature and the number of the head-end

- 9 - STC 1200
station. The display also supports dialogue guidance when programming the
head-end station. Use the buttons of the control unit to program the head-end
station. You can also use the PSW 1000 software and the HRCU 8 / RCU 1
management unit to program the head-end station.
The RS 232 interface of the control unit enables you to use a PC or a note-
book and the "BE-Flash" software to update the operating software of the
control unit. You can find the current operating software for the control unit,
the software "BE-Flash" and the current assembly instructions on the website
"www.mygss.eu".
3 overview
3.1 front Cover
2
1
Abb. 1
1 Front cover 2 Lock
—> To maintain compliance with the EMC regulations, the head-end sta-
tion must not be operated without this front cover.

- 10 - STC 1200
3.2 ConneCtors and Components
front view / side view (type l abel)
7
4
5
J
J J
J
5
6
3
K
Fig. 2
3 Cassette slots 1 … 12
4 Outputs of the SAT IF input distributors
5 Openings for cable terminals
6 HF measuring output (-20 dB)
7 Control unit
J Locators for the front cover
K Type label
view from below
0 0 09 9 988 89
Fig. 3
8 SAT IF input distributors
9 Inputs of the SAT IF input distributors
0 SAT IF loop-through outputs

- 11 - STC 1200
$ $ $ %
@
!
^
#
Fig. 4
! HF output of the head-end station
@ Mains connector
# Distributor for LNB operating voltage
$ Openings for cable terminals
% Earth connection terminal, connection for potential equalisation
^ Aeration openings
rear view
^
&
*
* *
*
Fig. 5
^ Aeration openings
& Cord grip of the mains connection cable
* Openings for wall mounting

- 12 - STC 1200
3.3 Control unit
™
(
)
¡
£
Fig.6
( LC display
) Control to set the contrast of the LC display.
¡ 9-pin D-SUB socket to update the operating software, to connect the
HRCU 8 / RCU 1 management unit.
™ Control buttons (control panel)
£ Operation display

- 13 - STC 1200
4 installinG the head-end station
4.1 emC reGulations (el ec t romag netic Co mpati bi l it y)
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station (e.g. Cinch, HF) using standard
cable terminals.
Fig. 7
• According to figure 8 insert the required number of standard cable termi-
nals in the openings provided in the front of the head-end station (fig. 2 5,
page10).
Tighten the nuts on the cable terminals until the teeth on the lock washers have
penetrated the exterior coating and a good connection is made between the
housing and the cable terminals.
—> To maintain compliance with the EMC regulations, the head-end sta-
tion must not be operated without this front cover.
4.2 remove front Cover
2
1
Fig. 8

- 14 - STC 1200
• Unlock the lock 2 (fig. 8).
• Slide the front cover 1 upwards and unhook it.
4.3 mountinG the head-end station
– Install the head-end station vibration-free.
Avoid, for example, mounting the head-end station onto a lift shaft or any
other wall or floor construction that vibrates in a similar way.
– Ensure that
- the mounting area can support the weight of the head-end station (ca. 30 kg) .
- there is an adequate ventilation
- the permissible ambient temperature will be maintained
- the mounting position is dry and protected against splashing water.
—> For a complete disconnection from the mains, the mains plug must
be pulled out of the mains socket. Ensure that the mains plug can be
pulled out without difficulties.
wall mountinG
—> Use mounting material suitable for the wall properties.
—> To avoid too strong interacted heating of the head-end stations it
is not admissible to mount them one upon the other without using
thermic precautions (e.g. permanently air recirculation, ventilation,
heat deflectors etc.).
—> Position the head-end station so that the distance of free space on ei-
ther sides is minimum 20 cm, below and above is minimum 50 cm.
—> For the distance of the mounting holes see the picture below.
668 mm
270 mm

- 15 - STC 1200
• Mount the fastening screws at the wall and check for a secure hold.
• Hang the head-end station onto the screws.
mountinG in a Cabinet
In cabinets a circular aeration (e.g. by means of ventilators) is to be ensured.
In addition it is necessary to permanently control the ambient temperature of
max. +50 °C by means of thermo elements. If the ambient temperature inside
the cabinet exceeds +50 °C, a thermo switch with reclose inhibition must au-
tomatically disconnect the system from the mains power supply.
• Position the head-end station in the cabinet so that the distance to the cabi-
net walls on either side is minimum 20 cm. Ensure minimum 50 cm of free
space above the head-end station as well.
—> To avoid too strong interacted heating of the head-end stations it
is not admissible to mount them one upon the other without using
thermic precautions (e.g. permanently air recirculation, ventilation,
heat deflectors etc.).

- 16 - STC 1200
5 installinG a Cassette
Before installing or changing a cassette unplug the power cable of the head-
end station from the mains power socket.
S
S
3
Fig. 10
• Remove the fastening screws S of an unoccupied slot 3 from the bracket
of the head-end station.
• Insert the cassette in this slot and push it into the housing.
• Align the cassette according to the connections in the board and the HF
collector and press it firmly into place in the head-end station.
• Fasten the cassette with the screws S.

- 17 - STC 1200
6 power supply
6.1 sat if input distributor
See figures 11 and 12 for the power supply for the SAT IF input distributors.
The power distributor (fig. 12) is supplied with power (+ 18 V / max. 1 A )
via the V connection (fig. 11). The Y connections of the power distributor
(fig. 12) are for providing power for the LNBs connected via the SAT IF input
distributors.
The total output current for all LNBs connected must not exceed 1 A.
V W X
Fig. 11
Y
Fig. 12
6.2 hybrid amplifier
Via connector X (fig. 11) the hybrid amplifier is supplied with power (+24
V).
6.3 ConneCtinG peripher al deviCes
Via connector W (fig. 11) peripheral devices can supplied with power
(+12 V/ max. 1 A ).
Connect peripheral devices via external fuses only!

- 18 - STC 1200
7 ConneCtinG the head-end station
7.1 potential equalisation (pe)
Equalise the potential (PE) in accordance with IEC/EN/DIN EN 50083 and
IEC/EN/DIN EN 60728.
GH
Housing
Fig. 13
• Put the PE wire (Cu 4 - 20 mm2) into the hole G (fig. 13) of the PE connection
terminal % (fig. 4) and fasten the PE wire with the screw H securely.
• Connect the PE connection terminal to a PE rail (supplied by customer) using
the PE wire.
7.2 ConneCtinG the sat if input distributor
overview
E
A
B
D
C
F
Fig. 14
A LNB power connection D Input 1 (fig. 3 9)
B Input 2 (fig. 3 9) E Outputs of input 1 D
C Loop-through output of F Outputs of input 2 B
input 1 D with terminating
resistor

- 19 - STC 1200
ConneCtinG sat if inputs
The following description refers to one of the SAT IF input distributors. The
other SAT IF input distributors are connected in the same manner.
• Connect outputs E and F of the input distributor (fig. 14) on the front of
the head-end station (fig. 2 4) to the corresponding inputs on the cassettes.
Using two reception levels (factory settings)
• Connect inputs B and D of the SAT IF input distributor (fig. 14) to the
LNBs.
—> For this use cable terminals mounted in the openings $ (fig. 15).
• Terminate loop-through output C (fig. 14) using the terminating resistor
supplied.
Using one reception level (loop-through operation)
• Connect input D of the SAT IF input distributor (fig. 14) to the LNB.
—> For this use a cable terminal mounted in one of the openings $
(fig.15).
• Connect loop-through output C to input B using a HF cable made on-site.
7.3 ConneCtinG hf output of the head-end station
$ $ $
!
Fig. 15
• Connect the HF output of the hybrid amplifier ! to the cable system.

- 20 - STC 1200
7.4 mains ConneCtion
To maintain compliance with current EMC regulations (electromagnetic com-
patibility), it is necessary to route the power cord & through the supplied
ferrite sleeve ≤.
Mount the ferrite sleeve as near as possible to the housing of the head-end
station (fig. 16).
≤
&
Fig. 16
• Open the ferrite sleeve.
• Make a loop in the power cord and lay the loop inside the ferrite sleeve as
shown in fig. 17.
• Close the ferrite sleeve (fig. 18).
Fig. 17 Fig. 18
• Connect the power cord of the head-end station to the mains socket.
