GSSI LineTrac User manual

Geophysical Survey Systems, Inc. LineTrac™ Assembly Instructions
MN 36-266 Rev B
Copyright © 2016-2017 Geophysical Survey Systems, Inc.
All Rights Reserved
LineTrac™ Assembly Instructions
LineTrac is an accessory to our UtilityScan®systems employing either the
DF or HS antennas. This accessory adds the ability to detect AC power and
induced RF energy present in buried utilities. The following assembly
instructions will assist in attaching the device to your antenna.
Contact your GSSI sales representative for more details. GSSI can be
reached at [phone] Monday-Friday,
8:30 AM – 5:00 PM EST.
Tools Required: Phillips screwdriver.
Unpack Materials
1You will need your antenna, LineTrac accessory, four screws (should
already be in antenna to the left of connections), and a Phillips
screwdriver. If you are using a Panasonic G1 tablet with your HS or DF
antenna, you will also need the silver battery mounting plate, a battery,
and battery
cable.
Attach LineTrac to Antenna
2Place the LineTrac on the front side of the antenna with the logo facing
forwards. The plate attached to the accessory should lie on top of the
antenna with the four holes lined up over the threads. Attach the four
screws through the plate and into the antenna with Phillips screwdriver.
If you have a G1 tablet, you will need to attach the silver battery
mounting plate as well. This plate is positioned on top of the black plate
for the LineTrac.

Geophysical Survey Systems, Inc. LineTrac™ Assembly Instructions
MN 36-266 Rev B
Copyright © 2016-2017 Geophysical Survey Systems, Inc.
All Rights Reserved
Attach Accessory Cable
3Grab the grey accessory cable from the top of the LineTrac and plug it into the accessory port of the HS or DF
antenna. This port is located under the control cable port.
Note: You must line the red dot up with the red line at the rim to attach the cable. The cable will not go in
otherwise.
4When ready to remove the cable and accessory, pinch the silver end at the base and pull upwards.
Do not unscrew any part of the LineTrac cable. Unscrewing the black housing at the attachment point
may damage the LineTrac accessory.
Pinch
here
Pull
up
