Guardian MIZCS User manual

Merge/Isolate Zone Control System
Model MIZCS
Installation Programming Operation
P006737 Rev. C 151116 11/16/2015 11:32 AM
Ph: 403.258.3100 \ email:[e-mail] \ www.guardiantelecom.com

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 2
Table of Contents
Package Contents.................................................................................2
Overview ...............................................................................................3
MICON Features ...................................................................................4
MICAB Features....................................................................................5
MICAB Back Panel Connector Tables.................................................10
Installation of MICABs and MICONs ...................................................13
Potentiometer Adjustments on the MICABs........................................14
Ten Zone Merge/Isolate System Description ......................................14
Installing Multiple Merge/Isolate Controllers (MICONs).......................15
Programming of MICABs and MICONs...............................................15
Operation.............................................................................................18
Setting and Cancelling Alarms ............................................................20
Lamp Test and Auxiliary device monitor switch report........................21
Connecting to the Telephone System .................................................21
Field Repairs & Adjustments...............................................................22
Product Specifications.........................................................................26
MICON Replacement Parts.................................................................27
Warranty..............................................................................................28
Disclaimer............................................................................................28
Warning...............................................................................................28
Service Telephone Number.................................................................28
Feedback.............................................................................................28
Guardian Product Return ....................................................................29
Page/Talk System Models and Options ..............................................30
Typical Page/Talk Installation..............................................................31
Table of Figures
Figure 1 - System Block Diagram .........................................................6
Figure 2 - Dimensions MICON & MICAB ..............................................6
Figure 3 - MICON Features...................................................................7
Figure 4 - MICON Desk Top Mounting..................................................7
Figure 5 - MICON Wall Mounting..........................................................7
Figure 6 - Back Panel Wiring Connections ...........................................8
Figure 7 - Front Panel Adjustments ......................................................8
Figure 8 - MICON PCB Layout..............................................................9
Figure 9 - MICAB Jumper Settings .......................................................9
Figure 10 - Examples of Auxiliary Alarm Inputs ..................................11
Figure 11 - Page/Talk System Wiring (typical application)..................12
Figure 12 - Page/Talk Wiring Connections (Typical Application)........12
Package Contents
(1) P9000 Merge/Isolate Control System Master Switch Unit
(1 to 6) P9001 Merge/Isolate Control System Desk Sets
(1) Installation & Operation Manual

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 3
Overview
Merge/Isolate System
The function of the Merge /Isolate system is to merge and re-isolate up to five (or ten with
expansion unit) zones of Guardian Page/Talk or GAI-Tronics Page/Party®system Stations and
Amplifiers. The system is comprised of a Master Zone Control Unit (MICAB) and one to six
Control Console Stations (MICONs). Each MICAB has a five zone page line mixer, which
allows the master controller to simultaneously monitor merge requests through the page lines
of all zones. The system can merge 2, 3, 4 or all 5 zones and is also able to merge another
zone into a merged zone group later – for example zones 1 & 2 can be merged and zone 3 can
subsequently be added. The isolate function can be performed separately as well – for
example zone 2 can be re-isolated from zone 1 & 3 leaving them to converse alone. The
system has controls to merge and isolate all five zones in one step, which is very useful in
emergency situations. The system has the ability to be configured so that if an alarm occurs
and the operator needs to send a page, the alarm will be muted while the MICON is in paging
mode. When the Push To Page is released, the alarm tone returns to full volume.
The MICON has the ability to trigger and reset up to 10 alarm channels from an alarm
generator, such as Guardian’s AG17. It also displays two summary alarms in the form of LED
indicators. The inputs for these are located on the MICAB and are a simple dry contact format.
Some examples for use of the two alarms monitors are; the facility alarm activation, which
could show that an alarm has been activated somewhere in the facility, either from the MICON
or from an external switch. The other could be tied into a UPS or door switch or other sensor
as considered essential to provide a visual monitoring aid.
The MICAB has connections for a telephone interface which – with operator assistance –
allows telephone calls to be made and received.
The system has one set of Page & Talk merge bus lines – the common Page Line & one pre-
determined Talk Line. Separate merged zone groups is not achievable, only one group of
merged zones at one time can be performed.
The system can accommodate up to six MICONs working in parallel. It can also be expanded
with another Five Zone MICAB working in tandem for merging and isolating up to ten
Page/Talk zones. The MICAB can be configured by the factory for 120VAC, 230VAC or
24VDC operation.
The MICONS are phantom powered by the MICAB eliminating the need for a local power
supply for each MICON. The MICABs are rack mounted units with user access to zone
conductor terminations (one pair of page & one pair of talk wires per zone), Alarm Control, and
Telephone Interface terminations.
Each MICON can be programmed for a unique level of control which can range from a low
level monitor desk set with no control up to a full control unit. This offers the advantage of
limiting what alarms or zones a station can set, clear or merge.

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 4
MICON Features
Construction
Can be configured for Desktop or Wall mount
Magnetic reed hook-switch (> 1,000,000 operations)
Glass Filled Polyester Thermoset housing
Integrated paging speaker
Noise Canceling Microphone
Removable Handset Latches for on hook retention
Ergonomic handset with push to page button
Heavy-duty industrial handset cord
Heavy Duty Urethane Coated Water Tight Membrane Keypad
2 Line X 16 Character Back Lit LCD Display
Hearing aid compatible receiver
Extended length (up to 20ft) handset cord - Contact Guardian Sales for details
Cable Entrances
Includes 1 cable gland
Support for two additional glands for external peripherals
Mounting
Simple field installation - desktop or wall mount
Each MICON comes with 50M (164ft) of cable but will operate up to 500m
(1,640ft).
Options
Extended length handset cord 6m (20ft) - Contact Guardian Sales for details
Extended MICON cable – Contact Guardian Sales for details

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 5
MICAB Features
Construction
Heavy duty Steel – Corrosion protected and powder coated.
Standard 19” Rack Mount – 3U height
Connectors
Screw terminals accommodate up to 14 AWG cable
Indicators and Controls
Front Panel LED displays merged zones
Front and back panel access to system audio controls and configuration.
Support
Five Zones, can be expanded to ten zones
Up to 6 Master Control Stations
Alarm tone generator
Telephone interface module
Alarms
Remote Alarm Control and Monitor
System Summary Alarm
Support for Data Communications Monitoring
Support for door alarm, loop power monitoring (Optional)
Mounting
Rack mount
Options
Rack door alarm switches, and loop power monitoring sensors

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Figure 1 - System Block Diagram
12.2" [310mm]
5.2" [132mm]
2.25" [57mm]
19.0" [483mm]
18.3" [465mm]
R0.125" [R3mm]
Telecom Inc.
Guardian
MICAB-MERGE ISOLATE CABINET
Figure 2 - Dimensions MICON & MICAB
Page 6

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Figure 3 - MICON Features
Figure 4 - MICON Desk Top Mounting
Figure 5 - MICON Wall Mounting
Page 7

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
POWER
FUSE 1.25A
120VAC
TALK PAGE
PTTI ZONE 1 12TALK PAGE
MASTER/SLAVE
ZONE 2 ZONE 3 ZONE 4 ZONE 5 AUX ALARM
INPUTS
DATA PWR MIX
MICON 1 MICON 2 MICON 3 MICON 4 MICON 5
ALARM LOGIC INPUT ALARM LOGIC OUTPUT A ALARM LOGIC OUTPUT B
TALK PAGE TALK PAGE TALK PAGE TALK PAGE TALK PAGE LINE Z
ADJUST LINE Z ADJUST LINE Z ADJUST LINE Z ADJUST LINE Z ADJUST
+-+-
Figure 6 - Back Panel Wiring Connections
SEE DETAIL 1
JP3 JP4
JP2 JP5 JP1
F2
154
R
17
R
60
R
DETAIL 1
MERGED ZONE
INDICATOR LED
R17 Data Threshold Pot
R154 Mixed Line Level Pot.
R60 Merged Page Line Level Pot.
Refer to Figure 9 for detailed jumper settings
Figure 7 - Front Panel Adjustments
Page 8

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
J6 J7 J5
J1
J2
J3
J4
LCD DISPLAY
MIC + (BLACK) MIC - (WHITE) RX (YELLOW) RX (YELLOW) PTP (RED) PTP (GREEN) HOOK SWITCH
45
SPEAKER
MICON CABLE
HANDSET
RX
VOLUME
SIDE TONE
CONTROL
TX
VOLUME
DATA
THRESHOLD
CONTROL
1
10
MICON Connector
Pin # Function
1 Merged Talk Line A
2 Merged Talk Line B
3 Merged Page Line A
4 Merged Page Line B
5 Data Signal A
6 Data Signal B
7 24VDC
8 VDC Ground
9 Mixed Signal A
10 Mixed Signal B
Note: Cable has one spare pair of
conductors
Figure 8 - MICON PCB Layout
JP1 – Merged Talk Line Impedance Control
Position Pins Description
1, 2 PTTI Not Installed
2, 3 PTTI Installed or Slave MICAB
Configuration
JP 2, 3, 4 – Master / Slave Control
Position
JP2 JP3 JP4 Pins Description
1, 2 Master MICAB Select
2, 3 Second MICAB Slave Select
JP5 – Merged Page Line Impedance Control
Position Pins Description
1, 2 Master MICAB Select
2, 3 Slave MICAB Select
Figure 9 - MICAB Jumper Settings
Page 9

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 10
MICAB Back Panel Connector Tables
(pin numbering is from left to right)
Power Input Connector Aux. Alarm Input Connector
Pin # Function Pin # Function
1 Neutral 1 Warning 1 - Dry contact input
2 Ground 2 Ground
3 Hot 3 Warning 2 - Dry contact input
4 Ground
Master / Slave Connector Zone (1 - 5) Connectors
(Zone 6 -10 in Slave MICAB)
Pin # Function Pin # Function
1 Merged Talk Line A 1 Isolated Talk Line A
2 Merged Talk Line B 2 Isolated Talk Line B
3 Merged Page Line A 3 Isolate Page Line A
4 Merged Page Line B 4 Isolate Page Line A
5 Data Signal A
6 Data Signal B
7 N/C Alarm Logic Input Connector
(connected to AG17 Logic Outputs)
8 VDC Ground Pin # Function
9 Mixed Signal A 1 Alarm I/P #1
10 Mixed Signal B 2 Alarm I/P #2
3 Alarm I/P #3
PTTI Connector 4 Alarm I/P #4
Pin # Function 5 Alarm I/P #5
1 Merged Talk Line A 6 Alarm I/P #6
2 Merged Talk Line B 7 Alarm I/P #7
3 Merged Page Line A 8 Alarm I/P #8
4 Merged Page Line B 9 Alarm I/P #9
10 Alarm I/P #10
11 Alarm I/P Common
12 Alarm I/P Common
Alarm Logic Output Connector A
(connected to AG17 Logic Inputs) Alarm Logic Output Connector B (connected to AG17 Logic Inputs)
Pin # Function Pin # Function
1 Alarm O/P #1 1 Alarm O/P #9
2 Alarm O/P #2 2 Alarm O/P #10
3 Alarm O/P #3 3 Alarm RST 2
4 Alarm O/P #4 4 Alarm Mute
5 Alarm O/P #5 5 Alarm O/P Common
6 Alarm O/P #6 6 Alarm O/P Common
7 Alarm O/P #7 7 Alarm Tone Input+
8 Alarm O/P #8 8 Alarm Tone Input-
9 Alarm RST 1 9 Alarm RST 1
10 Alarm Mute 10 Alarm Mute
11 Alarm O/P Common 11 Alarm O/P Common
12 Alarm O/P Common 12 Alarm O/P Common

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Note: The back panel MICON 1 - 5 connectors permit connection of five
MICONs. If a sixth MICON is required, the cable of the sixth MICON may be
connected to the MICON 5 connector, i.e. wired in parallel with #5.
See: MICAB Back
Panel Connector
Tables
CASCADE CONFIGURATION MICON #6 WIRED IN PARALLEL
DRY CONTACT O/P
Page 11
AUX
ALARM INPUT CONNECTOR
If no dry contact use interface (simple interface shown)
Figure 10 - Examples of Auxiliary Alarm Inputs

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Assignment Designation Description
Guardian
System
Cable Wire -
Jacket Color
Guardian
System Cable
Wire - Stripe
Color
Wire
Gauge
System Power J4A/J5A HOT Black 14 AWG
J4A/J5A COM White 14 AWG
J4A/J5A GND Green 14 AWG
Ambient Noise J6A MIC + n/a n/a n/a
Microphone J6A MIC - n/a n/a n/a
Speaker J7A SPK + n/a n/a n/a
J7A SPK - n/a n/a n/a
Page Line J2A/J3A PA Page Line Blue Red 18 AWG
J2A/J3A PB " Red Blue "
Channel J2A/J3A 1A Channel 1 Red 18 AWG
J2A/J3A 1B " L. Brown Red "
J2A/J3A 2A Channel 2 Violet 18 AWG
J2A/J3A 2B " L. Brown Violet "
J2A/J3A 3A Channel 3 Blue 18 AWG
J2A/J3A 3B " L. Brown Blue "
J2A/J3A 4A Channel 4 Brown 18 AWG
J2A/J3A 4B " L. Brown Brown "
J2A/J3A 5A Channel 5 Yellow 18 AWG
J2A/J3A 5B " L. Brown Yellow "
Group Muting of J2A/J3A Mute
Loudspeakers J2A/J3A Park Orange 18 AWG
Spare
Conductor
(Special Order) n/a Extra Red 12 AWG
Figure 11 - Page/Talk System Wiring (typical application)
Figure 12 - Page/Talk Wiring Connections (Typical Application)
Page 12

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 13
Installation of MICABs and MICONs
Installing the Merge/Isolate Master Switch Unit (MICAB)
WARNING – high voltages are present in this equipment when it is
connected to the power source.
Follow all appropriate electrical codes and use only approved electrical
fittings for the installation.
Install the MICAB in the rack.
If the Control System is being installed in a five channel system determine
which channel will be dedicated to the Merge/Isolate function.
See: Figure 2 -
Dimensions MICON &
MICAB
Ensure that none of the electrical connection circuits are live.
Following the color codes in the System Wiring Connections table connect
the Page Lines and the dedicated Talk Lines from each zone to the zone
connectors on the back panel of the MICAB.
Following the wire identification information in the MICAB to MICON Wiring
Connections table connect the MICON(s) to the MICAB. Up to six MICONs
can be connected to the MICAB.
See: Figure 11 -
Page/Talk System
Wiring (typical
application)
See: MICAB Back Panel
Connector Tables and
Installing Multiple
Merge/Isolate Controllers
(MICONs)
Connect the Alarm Generator. See: AG17 Manual
To reduce noise on the Page/Talk system, 33 Ohm resistors – usually
installed in a Line Balance Unit (LBU) – are connected across every page
& talk line in every zone in/near the MICAB. The MICON provides the
loading for all the page and dedicated merge talk lines. Resistors for the
un-merged talk lines should be placed near the MICAB and remote LBU’s
must not be connected.
See: LBU Manual
If a Telephone interface is to be connected into the system do so at this
time. See: PTTI Manual
Jumpers JP1, JP2, JP3, JP4 and JP5 are configured at the factory for the
most common setup. If changes to the system occur relocate jumpers to
the appropriate positions.
See: Figure 9 - MICAB
Jumper Settings
Ensure all connections are secure.
Connect the power supply to J1. The voltage is set at the factory to
120 VAC, 230 VAC or 24 VDC. Ensure that the power being supplied is
correct by checking the label on the back of the MICAB. Connect the
MICAB power cord to the proper power source then turn on the power
switch.
Program the system.
Adjust the front and back panel potentiometers.
See: Programming of
MICABs and MICONs
See: Potentiometer
Adjustments on the
MICABs
Test the system as described in the operation section. See: Operation

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 14
Potentiometer Adjustments on the MICABs
Back Panel access Potentiometers
The Page line impedance adjusting potentiometers for each of the isolated
zones are located next to the Zone connectors on the back panels of both
Master and Slave MICABs. With the Page Line not in use inject a test
signal into the Page Line. Adjust the potentiometer in the Line Balance
Assembly until the signal on the Page Line reads 0.5VRMS. If new
stations are added to a zone, the Page Line impedance of that zone should
be adjusted to adapt to the new load.
See: Figure 6 - Back
Panel Wiring
Connections
Front Panel access Potentiometers
The Merged Page line impedance adjusting potentiometer is located on the
front of the Master MICAB once the Plexiglas is removed. This adjustment
will affect the impedance of the merged page lines. Adjust it when the
system is first set up or when stations are added to the system.
See: Figure 7 - Front
Panel Adjustments
The mixed line signal strength adjusting potentiometer is located at the
front of the MICAB and is accessible once the Plexiglas is removed. All the
audio signals on the isolated and merged page lines are mixed and sent
back to the MICON speakers to monitor requests. A system may have one
to six MICONs. This potentiometer is utilized to adjust the mixed line audio
for the existing load (one to six MICONs). Adjust this potentiometer as
follows:
Using any MICON as a reference station set the speaker volume to a
maximum level.
Adjust the mixed line level potentiometer until the reference MICON picks
up lowest noise.
Page from one of the Page/Talk stations from an isolated zone. Listen to
the speaker volume on the reference MICON (with speaker volume to
max.).
Adjust the mixed line level pot until the speaker on the reference MICON
provides an acceptable audio level (~ 85dB @ 0.5 meter).
Adding or removing MICONs in the system may affect the speaker volume
of the other MICONs. If the volume control in the MICON cannot
compensate for the increase or decrease of the speaker volume, the
system may require re-adjustment of this potentiometer.
The data line Signal Threshold potentiometer is located at the front of the
MICAB and is accessible once the Plexiglas is removed. This adjustment
affects the received data signal strength detection threshold of the MICAB.
Adjust it until the MICAB can detect the instructions sent from the MICONs.
Ten Zone Merge/Isolate System Description
A Ten Zone Merge/Isolate System consists of two MICABs, and a maximum of six MICONs. Of the two
MICABs, one is configured as the master, and the other one as the slave. All six MICONs have the
same status in accessing the MICAB on a first come first served basis. The full capacity of the system
is ten zones. If the setup is less than six zones, one MICAB is all that is required.
The system supports an alarm tone generator, a telephone interface module and line balance
assemblies (omit).
The system has to be set up prior to operation.

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 15
Installing Multiple Merge/Isolate Controllers (MICONs)
Up to six controllers (MICONs) can be connected to the MICABs. MICON wiring
can be in parallel, series, or a combination of both.
MICONs can be desk mounted or wall mounted
If a MICON is to be desk mounted simply set it in position.
If a MICON is to be wall mounted remove the faceplate and secure the
base to the wall in the desired location, with the deepest dimension
towards the bottom. The handset retainer clips should be installed to the
handset cradle to hold the handset properly.
Tip: There are only five
connections for MICONs
on the MICAB. The sixth
MICON can be wired in
parallel with #5.
Caution: The electronic
components are secured
to the faceplate, handle
with care.
Wire the MICONs back to the MICAB.
Ensure all connections are secure.
See: MICAB Back Panel
Connector Tables
Program the MICON and the MICAB.
Test the system by merging zones as would be done during normal
operations.
See: Programming of
MICABs and MICONs
Programming of MICABs and MICONs
MICON Programming:
Once the system is powered up the MICON is ready for programming its function registers. To enter
Programming Mode, press the [PVT] key and the [LMP TST] key simultaneously. The LCD display will
respond with a greeting message and then the main menu.
1 = MICON, 2 = MICAB
3 = AlrZn, 4 = STORE
1. MICON setup:
Press key [1] while in the main menu to program the existing MICON. Once key [1] is selected the
screen will display the register number and its setting. Enter or change the setting by keying in the
proper numeric key.
Any out of range entry will be prompted with a message.
Use the [VOL UP] or the [VOL DWN] to scroll through all the other registers.
Once all these registers are verified to be correct, press the [PVT] to get back to the main program
menu.
The following table describes the MICON registers and functions:
Register code Function Description Parameter Default Settings
Reg00 Station Number The MICON
station number
Note 1
1 digit number
(1 to 6 and 8)
8 = station disabled
8
Reg01 Alarm key lockout Alarm key access
Note 2 0 = disable access
1 = access 1
Reg02 Language English Note 3 English only 1
Reg03 Speaker Volume Power up Speaker
volume Note 4 0 to 7 3
Reg04 Zone key lockout Zone key access
Note 5 0 = disable access
1 = access 1
Reg05 Select default Restoring the
MICON to the
default settings
Note 6
0, or 7 to restore
default settings 1

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 16
Notes:
1) All MICON stations have to be programmed with a station number. The station numbers range
from 1 to 6. Only station number 1 can get access to program the other functions of the MICAB.
There cannot be two stations with the same station number. Stations have a default setting of 8 to
ensure that adding a new station does not conflict with existing stations. The default setting must be
changed to a number between 1 and 6 that has not been assigned to another station.
2) Once Reg01 is stored with 0, all the red alarm function keys will be disabled. Pressing these keys
will result in receiving the deny message on the display.
3) Only English is supported in this version.
4) Use volume keys on the keypad to alter the initial volume.
5) Once Reg04 is stored with 0, all the blue zone function keys (excluding the [PVT] key) will be
disabled. Pressing of these keys will result in receiving the deny message on the display.
6) Setting Reg05 to 0 or 7 will restore all the registers back to the default settings of the MICON.
MICAB programming:
Programming the MICAB is done in two stages. First, use the MICON (station 1) to register all the
settings that are available in the MICAB. Once the system registers are verified as correct, transfer
these registers from the MICON to the MICAB. Below is the main menu on the MICON:
1 = MICON, 2 = MICAB
3 = AlrZn, 4 = STORE
2. MICAB setup:
Press key [2] while in the main menu to program the MICAB function registers. Once key [2] is
selected the screen will display the MICAB register number and the setting. Enter or change the setting
by keying in the proper numeric key.
Any out of range entry will be prompted with a message.
Use the [VOL UP] or the [VOL DWN] to scroll through all the other registers.

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 17
The following table describes the MICAB registers and functions:
Register code Function Description Parameter Default Settings
Reg06 Master MICAB Always exists 1 = exists 1
Reg07 MICON station #1 Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 1
Reg08 MICON station #2 Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 0
Reg09 MICON station #3 Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 0
Reg10 MICON station #4 Assertion of its
existence in the
system (Note 1))
0 = not installed
1 = installed 0
Reg11 MICON station #5 Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 0
Reg12 MICON station #6 Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 0
Reg13 Slave MICAB Assertion of its
existence in the
system (Note 1)
0 = not installed
1 = installed 0
Reg14 Merged Time
(Note 2) 1-9 X 10 minutes 6
Reg15 Default Settings Restoring the
MICON to the
default settings
(Note 3)
0, or 7 to restore
default settings 1
Notes:
1) All MICON stations and the MICAB slave units have to be programmed to indicate their existence
in the system. Any MICON station or MICAB slave that is not registered will not be polled by the
MICAB master unit.
2) The merged time is the maximum duration of zone merging since the last change. Once the time
runs out the merged zones will be isolated.
3) Setting Register 15 to 0 or 7 will restore all the registers back to the default settings in the MICAB.
3. Alarm Channel and the Associated Merged Zones setup:
Press key [3] while in the main menu to program the MICAB Alarm function registers. Once key [3] is
selected the screen will display the MICAB Alarm register number and the setting. Enter or change the
zone that will be merged when the existing Alarm channel is activated.
Use the [VOL UP] or the [VOL DWN] to scroll through all the other registers.

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 18
The following table describes the MICAB Alarm registers and functions:
Alarm Register Associated Zones Description Parameter Default Settings
Alarm 01 1234567890 Alarm channel 1
and its associated
zones
Zone 1 to 10 All Zones
Alarm 02 1234567890 Alarm channel 2
and its associated
zones
Zone 1 to 10 All Zones
Alarm 03 1234567890 Alarm channel 3
and its associated
zones
Zone 1 to 10 All Zones
Alarm 04 1234567890 Alarm channel 4
and its associated
zones
Zone 1 to 10 All Zones
Alarm 05 1234567890 Alarm channel 5
and its associated
zones
Zone 1 to 10 All Zones
Alarm 06 1234567890 Alarm channel 6
and its associated
zones
Zone 1 to 10 All Zones
Alarm 07 1234567890 Alarm channel 7
and its associated
zones
Zone 1 to 10 All Zones
Alarm 08 1234567890 Alarm channel 8
and its associated
zones
Zone 1 to 10 All Zones
Alarm 09 1234567890 Alarm channel 9
and its associated
zones
Zone 1 to 10 All Zones
Alarm 00 1234567890 Alarm channel 0
and its associated
zones
Zone 1 to 10 All Zones
4. Transfer the registers settings in the MICON to the MICAB:
Pressing key [4] while in the main menu will cause the MICON to send all the register settings to the
MICAB. If the master MICAB and the slave MICAB exist they both will be updated with the new
settings. If the transfer is successful the MICAB will blink all the zone lights.
Operation
Requesting a Merge:
The caller first sets the Talk Channel Selector to the dedicated Talk channel. A request for a merge is
made by the caller making a Page to the Control System operator in the normal manner. The system
circuitry has a five zone mixer therefore a Page from any zone will be heard by the operator. If the
requirement is for a simple Merge the information can be conveyed in the original Page. If the
requirement is more complicated – say an inquiry as to the Zone in which a particular individual is
located – the Page can simply ask the operator to speak on the dedicated line. In this case the
operator can check on the LCD display for the origin of the page zone; then press the button to merge
the Zone from which the call is coming, and can then have a conversation with the caller. The operator
can page the person being called and the person requesting the merge will know that the merge has
been made when the called party comes on the line.

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
Page 19
Alternatively the operator can merge the zones requested and the caller can make the page and wait
for the called party to come on the line.
If a merge request comes in from an unmerged zone while a merge of other zones is in progress the
operator can merge the zone from which the request is coming with the merged zones and butt in, to
convey to the person that the request cannot be processed at that time. The MICON display will
indicate if the caller has a handset picked up in their zone by illuminating the respective zone number.
Keying of instructions from a MICON Unit to the MICAB:
ACTION KEY STROKES
Merge zones MERGE, (ZONE(s)), MERGE
Isolate zones ISOLATE, (ZONE(s)), ISOLATE
Merge all zones MERGE, ALL
Isolate all zones ISOLATE, ALL
Trigger alarm ALARM SET, (alarm #)
Reset alarm (from highest priority first) ALARM RESET
Clear all alarms ALARM CLEAR
Test alarm LEDs LAMP TEST
Increase speaker/receiver volume VOLUME UP
Decrease speaker/receiver volume VOLUME DOWN
Cancel incomplete instructions (Merge
zones, Isolate zones, and Alarm trigger
instructions)
PVT
Enter into Programming mode PVT + LMP TST (pressing both keys
simultaneously)
MICON Controls
Standard PTP handset operation similar to any Page/Talk station.
Internal Page Speaker volume up & down (when handset on hook)
Handset Receiver volume up & down (when handset off hook)
Remote Alarm System activation (10 possible alarm triggers)
Remote Alarm System resetting
Remote Alarm System clearing
Two summary LEDs on the unit face (indicating alarm activation & M/I system status)
Lamp test button (to check all Alarm LED indicators)
Keypad Matrix
MRG ISO PVT ALL
1 2 3 LMP
TST
4 5 6 ALM
SET
7 8 9 ALM
CLR
VOL
DWN 0 VOL UP ALM RST

Guardian Telecom Inc. Installation Programming Operation
Merge/Isolate Zone Control System
LCD Indication of System Status:
• Merged Zones (Displayed at same time as Active Zones)
• Active Zones (showing a station is off hook on pre-determined Talk Line in respective zone)
• Alarm Setting (as a priority override to normal Merged /Active Zones status display)
• Alarm Activation (showing alternately with Merged /Active Zones display)
The Display is as illustrated below when the MICON is in the activating state:
Note: The right arrow symbol (>) indicates that the
command has not been completed
M R G - > : 1 . . . . . . . . 0
A C T V : 1 . . . . . . . . 0
I S O - > : . . . . . . . . . .
A C T V : . . . . . . . . . .
A L A R MS E T : 2
A C T V : 1 . . . . . . . . 0
The Display is as illustrated below when the MICON is in the report state:
M R G : 1 . . . . . . . . 0
A C T V : 1 . . . . . . . . 0
I S O : . . . . . . . . . .
A C T V : . . . . . . . . . .
M R G : 1 . . . . . . . . 0
A L A R M: 1 2 3 4 5 6 7 8 9 0
Setting and Cancelling Alarms
If an AG17 Alarm Tone Generator or similar is connected into the system the Master Controller can
generate alarms on the Page lines of selected zones.
Trigger Alarms:
To trigger an alarm press [ALM SET] key, then select the alarm channel through the numeric keys. If
another [ALM SET] key is pressed prior to any numeric key being entered, the MICON will exit the
alarm setup and return to the standby state.
Once the alarm is triggered the zones associated with the alarm will be merged. The red General Alarm
LED will be on to alert the operator for alarm status.
Page 20
