Guardian®Tilt Automatic Overbed Table
User Instructions
Model IC-6418
POSSIBLE DAMAGE OR INJURY. Be alert of hi/lo adju tment of overbed table
when rai ing bed.
ASSEMBLY INSTRUCTIONS (FIGURE 1)
1. Using the hex bolts and washers, attach the base to the post. Tighten the bolts
securel .
2. Insert the tilt control bar into the post b loosening post screw. Tighten post
screw, once tilt control bar has been inserted into post.
3. Attach the outer tube to the top board using the screws.
4. Slide the outer tube onto the tilt control bar. If it is too tight, release the
rotating knob on the tilt control bar.
5. Tighten the rotating knob to set the top board.
6. Insert the casters into the base until the lock into place.
Tilt Control Bar
Rotating Knob
Po t Screw
Hex Bolt Ca ter
Outer Tube
Screw
Wa her
Ba e
Top Board
Figure 1

©2002 Sunrise Medical 7.02
IM-429008 Rev. A
OPERATING INSTRUCTIONS (FIGURE 2)
1. Remove fix screw located on the table post to release the inner tube and outer
tube of the post.
CAUTION– Stabilize the top board as ou remove the fix screw so that top board will
not bounce back too quickl .
2. To raise the top board, place our hand underneath the top board and move it
upward to the desired height. Remove pressure to set height.
3. To lower the top board, lift the adjustable plate and push top board downward
to the desired height. To set the height, release the adjustable plate.
4. To rotate the top board, twist the knob of the tilt control bar to loosen. Rotate
the top to the desired position. Tighten the knob to set the position.
Manufactured for:
Sunri e Medical, Inc.
7477 East Dr Creek Parkwa
Longmont, Colorado 80503
www.sunrisemedical.com
Phone: [phone]
Toll Free Phone: [phone]
In Canada: [phone]
Printed in Taiwan
Adju table Plate
Table Po t
Rotating Knob
Figure 2
