Guidosimplex 1096 User manual

User Guide
The Infra Red
Remote Control
1096
.guidosimplex.it

Dear Customer,
Thank you for having purchased a Guidosimplex device.
As with all of our products, this device, was designed and created
respecting the highest possible levels of quality and safety standards.
All Guidosimplex products are manufactured from the best materials
available on today’s market , this means that when you buy a
Guidosimplex product you buy quality and reliability, which results in
less maintenance.
Guidosimplex products coexist in perfect harmony in parallel with the
original commands and design of the vehicle and conventional
driving can be restored on command.
This device is capable of fulfilling all needs as per design as long as
a correct usage is performed.
Therefore we advise you to consult
the below reported user guide
prior to using the device.

The device is made up of the following components:
- Infra Red Remote Control complete with hand knob
(Which is installed on the steering wheel)
- Car Battery Charger
(Charge the battery in the vehicle without having to remove it)
- Standard Battery Charger
(Charge the battery directly from the mains)
- ECU
(Electronic control unit elaborates the signal requested and
activates the correct command )
- Dusk Sensors
automatically activate the headlights
when the available daylight
diminishes
1
2
3
1
2
3
INFRA RED REMOTE CONTROL

3
2
1
4
5
6
9
10
8
INFRA RED REMOTE CONTROL FUNCTION
7A

Windscreen washer
Hazard lights
Rear Windscreen washer
Wipers
Windscreen wipers "+"
1st stage – Intermittent
2nd stage – Speed 1
3rd stage – Speed 2
Windscreen wipers “-”
1st stage – from speed 2 to speed 1
2nd stage – from speed 1 to intermittent
3rd stage – from intermittent to off
Headlights
Dipped Headlights (low beams)
Lights off = Flashes
Lights on = Light Changes
Left Indicator
Right Indicator
Horn
On/Off Key pad illumination , press
simultaneously keys 7 and 10.
The remote control can be extracted using button (A) situated
on the steering wheel clamp
1
2
3
3
5
4
8
6
7
9
10
INFRA RED REMOTE CONTROL FUNCTION

BATTERY CHARGING
DOPO L’USO, SPEGNERE
LA TASTIERA.
car battery charger using a
dedicated Aux 12v Socket
Standard battery charger directly
from the mains 220v
When the battery is low on power and/or flat, the keyboard
will start to flash approximately every 4 seconds.
BATTERY CHARGING: When the device is being charged the
keyboard will light up one LED at a time , when all keys are
illuminated indicates that charging is almost complete , when the
device is fully charged the LED will flash every 2 seconds.
The full charging cycle from flat to full power will take
approximately 3 -4 hours , during this time the device should
not be used, if the device should reach a temperature which
exceeds 40° charging will be automatically terminated.
DO NOT CHARGE WHILST DRIVING, THE LEAD MAY
INTERFERE WITH STEERING WHEEL FUNCTIONALITY AND
THE DEVICE DOES NOT WORK DURING CHARGING.

In the case of malfunctions or failures of this
device we invite you to contact a Guidosimplex
Service Center.
To find the nearest Guidosimplex Service Center
please consult our website
www.guidosimplex.it
This user guide as printed by Guidosimplex S.r.l. and cannot
be considered a valid arranty document. Guidosimplex
reserves the right to update ithout notice the document in
question.
Reserved Copyrights. © Guidosimplex S.r.l.
