Gunter & Hauer EOM 867 User manual

Gunter & Hauer
EN USER MANUAL
BUILT-IN ELECTRIC OVEN
EOM 867
..

ACKNOWLEDGMENT
Thank you for purchasing our product. We hope you enjoy using the many features and benefits it
provides. Before using this product please study this entire Instruction Manual carefully. Keep this
manual in a safe place for future reference. Ensure that other people using the product are familiar
with these instructions as well.
WARNING
 When the oven is first switched on, it may give off
an unpleasant smell. This is due to the bonding
agent used for the insulating panels within the oven.
Please run up the new empty product with the
conventional cooking function, 250 ℃, 90 minutes
to clean oil impurities inside the cavity.
 During the first use, it is completely normal that
there will be a slight smoke and odors. If it does
occur, you merely have wait for the smell to clear
before putting food into the oven.
 Please use the product under the open environment.
 The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age
shall be kept away unless continuously supervised.
 If the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
 This appliance can be used by children aged from 8
years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
2

supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision.
 During use, the appliance becomes very hot. Care
should be taken to avoid touching heating elements
inside the oven.
 Do not allow children to go near the oven when it is
operating, especially when the grill is on.
 Ensure that the appliance is switched off before
replacing the oven lamp to avoid the possibility of
electric shock.
 The means for disconnection must be incorporated
in the fixed wiring in accordance with the wiring
specifications.
 Children should be supervised to ensure that they
do not play with the appliance.
 This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by person responsible for their safety.
 Accessible parts may become hot during use.
Young children should be kept away.
 An all-pole disconnection means must be
incorporated in the fixed wiring in accordance with
the wiring rules.
3

 If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
 Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they
can scratch the surface, which may result in
shattering of the glass.
 A steam cleaner is not to be used.
 The appliances are not intended to be operated by
means of an external timer or separate remote-
control system.
 The instructions for ovens that have shelves shall
include details indicating the correct installations of
the shelves.
4

SAFETY HINTS
Do not use the oven unless you are wearing something on your feet. Do not touch the oven
with wet or damp hands or feet.
For oven: Oven door should not be opened often during the cooking period.
The appliance must be installed by an authorized technician and put into use. The producer is
not responsible for any damage that might be caused by defective placement, and installation
by unauthorized personnel.
When the door or drawer of oven is open do not leave anything on it, you may unbalance your
appliance or break the door.
Some parts of appliance may keep its heat for a long time; it is required to wait for it to cool
down before touching onto the points that are exposed to the heat directly.
If you will not use the appliance for a long time, it is advised to plug i off.
FITTING THE OVEN INTO THE KITCHEN UNIT
Fit the oven into the space provided in the kitchen unit; it may be fitted underneath a work top or into
an upright cupboard. Fix the oven in position by screwing into place, using the two fixing holes in the
frame. To locate the fixing holes, open the oven door and look inside. To allow adequate ventilation,
the measurements and distances adhered to when fixing the oven.
IMPORTANT
If the oven is to work properly, the kitchen housing must be suitable. The panels of the kitchen unit
that are next to the oven must be made of a heat resistant material. Ensure that the glues of units
that are made of veneered wood can withstand temperatures of at least 120 ºC. Plastics or glues
that cannot withstand such temperatures will melt and deform the unit, once the oven has been
lodged inside the units, electrical parts must be completely insulated. This is a legal safety
requirement. All guards must be firmly fixed into place so that it is impossible to remove them without
using special tools. Remove the back of the kitchen unit to ensure an adequate current of air
circulates around the oven. The hob must have a rear gap of at least 45 mm.
DECLARATION OF COMPLIANCE
When you have unpacked the oven, make sure that it has not been
damaged in any way. If you have any doubts at all, do not use it:
contact a professionally qualified person. Keep packing materials
such as plastic bags, polystyrene, or nails out of the reach of children
because these are dangerous to children.
t
5

PRODUCT DESCRIPTION
Cooking function Temperture knob
Decreasing control
Increasing control
Time function
6
Convention with fan: The top heating element and the bottom heating element are
working with fan. The appliance to be cooked is evenly and quickly cooked all around.
Symbol Function description
Oven Lamp: Which enables the user to observe the progress of cooking without
opening the door. Oven lamp will light for all cooking functions.
Grill-small: This cooking method is normal grilling, utilizing the inner part only of the top
heating element, which directs heat downwards onto the food.
This is optional function that can be work with rotisserie motor.
Conventional cooking: Heaters from the upper and the lower side uniformly heat the
exposed food. Baking and roasting is possible only at single level.
Bottom heater: Heat is applied only by the bottom side of the oven. Use this option for
browning the bottom side of the food. This function is suitable for slow cooking recipes
or for warming up meals.
Defrost: The circulation of air at room temperature enables quicker thawing of frozen food
(without the use of any heat). It's a gentle but quick way to speed up the defrosting time
and thawing of ready-made dishes and cream filled produce etc.
Double grill: The inner heating element and the outer heating element in the top of the
oven are working. Suitable for grilling larger quantities.
This is optional function that can be work with rotisserie motor.
Double grill with fan (at the rear panel): The inner heating element and the outer heating
element in the top of the oven are working with fan. It is suitable for grilling large amount
of meat. This is optional function that can be work with rotisserie motor.

7
Time function setting
OPERATION INSTRUCTIONS
When the oven is first connected to the electrical supply, wait for the display automatically show
" 12.30 ", a beep sound once and the " 12 " " . " flash. Ensure the correct time of the day
is set before using the oven. please note: that is 24 hour clock, for example 2PM shown as 14.00.
To set the correct time of day
1> Press " + " " - " button to adjust the hour setting.
2> Press " " to confirm the hour setting.
3> Press " + " " - " button to adjust the minute setting.
4> Press "" to confirm the minute setting and the timer will be in standby mode.
Note: If the display does not flash, adjust the time of day by pressing the " + " and " - " buttons at
the same time for more than 3 seconds.
Manual mode
:
In manual mode, only the day's time and the symbol " " lights up. The cooking duration has to
be controlled by the user.
Notes: In manual mode, to ensure the oven is not left on accidentally, after 5 hours no any button
pressed, the timer will flash once a second to warn you the oven will enter standby mode. After a total of
10 hours, the timer will enter standby mode.
When the timer is flashing in manual mode, press any button to reset the timer if you intend to continue
using the oven. Or press " " and " + " together for more than 3 seconds to enter standby mode if
oven will not be used.
Oven On and Off
If the timer is in standby mode，press "
" for more than 3 seconds, the timer will enter manual
mode and the symbol " " will light up continuously .
1> Set the desired cooking function and the temperature degree.
2> Set the time function, then the oven will on.
If you set Dur or End, after cooking, the oven will automatically turn off.
If you set manual or minute minder, after cooking, bring the cooking function and oven temperature
knob to " 0 " position. Press " " and " + " buttons for more than 3 seconds to return to standby mode.
In manual mode, pressing " " can enter the time function setting, the sequence of the function
setting is Mamual mode - Minute minder-Dur-End-Manual mode. Then selected cooking function
and adjust the cook temperature if required.

8
Semi automatic programming accroding to finishing time-:
Semi automatic programming according to cooking period-:
This function is used to cook in the desired time range The food to be cooked are put into the
oven, The oven is adjustment to the desired cooking function and temperature degree.
The maximum setting of cooking period is 10 hours.
1> Press " " button until you see " Dur " on the timer screen. (Before setting cooking period.)
2
>Use " +""-"button to adjust cooking period for the food you wish to cook. ( Refer to the
instructions for setting the correct time of day .)
Pr es s " "
button to co nfir m , the
day '
s
time
will appear on the screen and the symbols " A " " "will light on the screen.
While doing
this, the oven will also start to operate.
Audible warning time adjustment:
This function can be used to receive audible warning at the completion of the ajusted time period.
1> Press " " button to select the minute minder function. The relevant " " " . " symbol will flash.
2> Use " +""-"button to adjust minute minder. (Refer to the instructions for setting the correct time
3> When the time is up, the timer gives an audible warning and the " " symbol begins to flash on the
screen
.
butto
n le ss t
han 3 se cond
s, it will stop the audible warning and the symbol
"
"
disappears on the screen Audible warning time adjustment is for warning purposes only..
Press ""
and "+"together for more than 3 seconds to enter standby mode if oven will not be used.
This function is used to cook according to the desired finishing time. The food to be cooked is put into
the oven. The oven is adjusted to the desired cooking function and temperature degree.
1> Press " " button until you see " End " on the timer screen. (Before setting finished time).
2
>Use " +""-"button to adjust finishing time. (Refer to the instructions for setting the correct time of
day. )
Pr ess any
3> Press " " button to confirm, the day's time will appear on the screen and the symbols " A " " "
will light on the screen. While doing this, the oven will also start to operate.
of day. ) Press " " button to confirm, the " " symbol will begin to light continuously. When the
" " symbol begins to light continuously, the audible warning time adjustment is done.
4> At the completion of the set duration, the timer will stop the oven and give an audible warning. Also,
the symbol " A " will begin to flash on the screen. After bringing the cooking function and oven
temperature knob to " 0 " position. Pressing any button less than 3 seconds, it will stop the audible
warning. Pressing " " for more than 3 seconds set the oven to Manual mode again to use the
oven.
3> At the completion of the set duration, the time will stop the oven and give an audible warning. Also,
the symbol " A " will begin to flash on the screen. After bringing the cooking function and oven
temperature knob to " 0 " position. Pressing any button less than 3 seconds, it will stop the audible
warning. Pressing " " for more than 3 seconds set the oven to Manual mode again to use the
oven.

9
Spectification
5> We suggest that you run the oven elements for 15 minutes at 200 degrees to burn off any residuce
from their surfaces.
Full automatic programming-:
2> When setting each of the time function,
if there is none operation for 5 minutes then it will return to
manual mode.
1> When setting the date of each function, long press on " + " or " - " for more than 3 seconds, the
date will progressively and rapidly increase or decrease.
6HFRQGNHHSSUHVVLQJRQEXWWRQXQWLO\RXVHH(QGRQWKHWLPHr screen. When you see " End "
on the time screen, Use " + " " - " button to adiust finshing time, Press " " button to confirm, the day's
time will appear on the csreen and the symbol " A " will begin to continuously light on the screen. The
symbol " " disappears until the time cooking starts.
You can set a time which can be up 23.59 hours after the time obtained by adding the
cooking period to the day's time.
The oven will start operating at the time calculated by deducting the cooking period from the set finishing
time, and will stop at the set finishing time. The timer will give an audible warning and the symbol " A "
will begin to flash. After bringing the cooking function and oven temperature knob to " 0 " position.
Pressing and button less than 3 seconds, it will stop the audible warning.
Pressing " " for more than 3 seconds set the oven to Manual mode again to use the oven.
Please note: Once setting full-automatic mode, all the time can not be changed, Change time means
cancle automatice progamme and enter into corresponding mode. If you need to reset automatic mode,
need to stop setting the current mode, to set the automatice mode according to the above steps again.
This function is used to cook after a certain period of time, with a certain duration. The food to be cooked
is put into the oven. The oven is adjusted to the desired cooking function. The oven temperature is
adjusted to the desired degree depending on the food to be cooked.
First: Press " " button until you see " Dur " on the timer screen. Use " + " " - " button to adjust cooking
period for the food you wish to cook. Press " " button to confirm, the day's time will appear on the
screen and the symbols " A " will begin to continuously light on the screen.
3> When settiing each of the time function, pressing on " " for more than 3 seconds can cancel
current setting and enter manual mode.
4> During time function setting, pressing on " + " and " " for more than 3 seconds, a beep sounds it
can cancle the curent time function setting and enter standby mode.
