GVA G67BFW15 User manual

G67BFW15
67L Bar Fridge

1
Contents
Guide to the Appliance
13
7
4
3
2
14
16
18
Cari ng f o r the Envir
Safety Info rmatio n and
Gett i ng Started
Operation Instr uc tions
Tro ubleshooting
Car e and Mainte nan ce
Technic al Sp ec ific a tions

morfylthgilsyravyamdesahcrupuoytinueht,tnemevorpmis’noitcudorpehtoteuD:ETON
below sketch.
1. Cabinet
2. Evaporator compartment
3. Thermostat knob
4. Shelf
5. Hinge cover
1
2
3
4
8
10
7
6
5
9
11
6. Door
7. Gasket
8. Adjustable legs
9. Evaporator compartment cover
10. Bottle rack
11. Drip Tray
Guide to the Appliance
morfylthgilsyravyamdesahcrupuoytinueht,tnemevorpmis’noitcudorpehtoteuD:ETON
below sketch.
1. Cabinet
2. Evaporator compartment
3. Thermostat knob
4. Shelf
5. Hinge cover
1
2
3
4
8
10
7
6
5
9
11
6. Door
7. Gasket
8. Adjustable legs
9. Evaporator compartment cover
10. Bottle rack
11. Drip Tray
2

Responsible disposal of the packaging
•The packaging of your appliance has been selected from environmentally friendly materials
and can usually be recycled. Please ensure these are disposed of correctly.
•Plastic wrapping can be a suffocation hazard for babies and young children, please ensure
all packaging materials are out of reach and are safely disposed of. Please ensure they are
offered for recycling rather than throwing these materials away.
Responsible disposal of the appliance
•At the end of its working life, do not throw this appliance out with your household rubbish.
An environmentally friendly method of disposal will ensure that valuable raw materials can
be recovered and used again.
•Electrical and electronic appliances contain materials and substances which, if handled or
disposed of incorrectly, could be potentially hazardous on the environment and human
health.
•Observe any local regulations regarding the disposal of electrical consumer goods and
dispose of it appropriately for recycling and recovery of the refrigerant. This appliance
contains the flammable refrigerant isobutane (R600a) and cyclopentane (R141b) in the
cabinet insulation, and must be disposed of in a separate waste collection. Contact your
local authorities for advice on recycling facilities in your area.
•Take care not to damage the pipework at the back of the appliance before or during
transportation so that the refrigerant gas cannot escape.
•The plug must be rendered useless and the cable cut off directly behind the appliance or
the machine to prevent misuse.
•DANGER. Risk of child entrapment: When discarding a fridge or freezer, make sure to
take off the door and the spring action or bolt catch. Leave the shelves in place so that
children cannot easily climb in, get trapped inside and suffocate.
Caring for the Environment
3

4
Read this manual thoroughly before first use, even if you are familiar with this type of
fire, electric shock and injury when correctly adhered to.
Safety Information and Warnings
DANGER means that failure to read this safety statement may result in severe personal
injury.
WARNING means that failure to read this safety statement may result in extensive product
damage or serious personal injury.
CAUTION means that failure to read this safety statement may result in minor or moderate
personal injury, property or equipment damage.
This symbol alerts you to take care as the appliance contains a
flammable refrigerant. Do not expose it to high heat, sparks and open
flames.
Pay particular attention to safety messages that follow this safety alert
symbol or the words DANGER ,WARNING or CAUTON. These words are
used to alert you to a potential hazard that can seriously injure you and
others.
The instructions will tell you how to reduce the chance of injury and let you
know what can happen if the instructions
are not followed.
product. We have provided many important safety statements in this manual concerning the
use of this appliance. Always read and observe all safety statements. They reduce the risk of
Keep the manual in a safe place for future reference, along with the completed warranty
card, purchase receipt and carton.
If applicable, pass these instructions on to the next owner of the appliance.
We assume no liability for any eventual damages caused by misuse of the appliance or
noncompliance with the instructions in this manual.
CAUTION:
Flammable Gas

5
Installation
•Heavy:
•Location:
•Moisture:
•Heat:
•Ventilation:
•Level:
•Pipes:
•Refrigerant circuit:
This appliance is heavy, take care when moving it. To avoid back or other injury,
consider a two person lift or mechanical aid when installing it.
The room for installing appliance must be at least 1M³per 8g of refrigerant.
The amount and type of refrigerant in the appliance can be found on the rating plate on
the back of the appliance.
Install the fridge in an indoor area protected from wind, rain, water spray or
drips.
Do not install it next to an oven, grill or other source of high heat.
To ensure proper ventilation, the front of the unit must be completely
unobstructed. Keep any ventilation openings clear of obstructions. Choose a well
ventilated area with temperatures above 16˚C and below 43˚C.
Do not damage the refrigerant circuit.
Install the appliance level in order to ensure proper operation.Adjust the feet
to level the appliance.
Make certain that the pipes are not pinched, kinked or damaged during
installations. Check for leaks after connection.
•Voltage:
•Separate circuit:
•Power cord:
•Damaged cord:
•Electrical work:
Electrical safety
Make sure your outlet voltage and circuit frequency correspond to the voltage
stated on the appliance rating label. Plug the bar fridge into a 220-240V, 50Hz, 3-prong,
power outlet with a 15A fuse at the mains. The outlet must be properly earthed to the
ground.
Do not use an adaptor; do not use an extension cord. We recommend
you connect the bar fridge to a separate circuit serving only this appliance. This provides
the best performance and prevents overloading the house wiring circuits that could
cause a fire hazard from overheating. Use a power point that cannot easily be turned off
accidentally.
Do not kink or damage the power cord. Do not leave it exposed or dangling.
Secure it behind the unit so no one steps on or places anything on the cord or against it.
Never unplug the unit by pulling the cord. Always grip the plug firmly and pull straight out
from the power point.
Do not use a cord that shows cracks or abrasion damage along its length
or at either end. If the power cord is damaged, it must be replaced by the manufacturer or
its service agent. Contact the after sales support line to have it replaced.
If the installation of this appliance requires any electrical work, make sure
it is carried out by a qualified electrician.

6
Safety Information and Warnings
Usage conditions and restrictions
•This appliance is intended to be used in household and similar applications such as:
1）Staff kitchen areas in shops, offices and other working environments;
2）Farm houses and by clients in hotels, motels and other residential type environments;
3）Bed and breakfast type environments;
4）Catering and similar non-retail applications.
•Intended purpose: Do not use this appliance for anything other than its intended
purpose, and only use it as described in this manual. Do not attempt to alter or modify this
appliance in any way.
partments of the appliance, unless they are specifically recommended in this manual.
•Electrical type appliances: Do not use any such appliances inside the food storage com-
•Usage restrictions : The ap pliance is not intended for use b y persons(includi n g ch il dren) with
reduced physical, sens ory o r mentalcapabilities , o r lack of experience and know le dge , u nless
they have been given sup ervision or ins truction concern in g u se of the ap pliance b y a person
respon sible for their safety.
•Children: Supervise children to ensure they do not play with the fridge. Never allow chil-
dren to operate, play with or crawl inside the bar fridge.
specifically recommended in this manual . Refer a ll other servicing to a qualified technician,
Cleaning and maintenance
•Disconnect: Unplug the bar fridge or disconnect power before cleaning or servicing.
Failure to do so can result in electrical shock, injury or death. Do not connect or disconnect
Do n ot
Do not let open flames or ignition sources enter the appliance.
the electric plug when your hands are wet.
•Flames:
•Flammable/explosive substances:Never clean this appliance with flammable fluids.
store explosive substances such as aerosol cans with a flammable propellant in this appliance.
The fumes can create a fire hazard or explosion caused by electric sparks.
•Solvents: Do not use solvent based cleaning agents or abrasives on the interior. These
cleaners may damage or discolour the interior.
•Defrosting aids: Do not use mechanical devices, steam cleaners or other means to
accelerate the defrosting process. Never use a sharp or metal instrument to remove frost
as it may damage the cooling system and will void the warranty. We recommend using a
plastic scraper.
•Service: Do not attempt to repair or replace any part of the bar fridge unless it is
or contact the after sales supportline for advice on repair or replacement. It is
hazardous for anyone other than an Authorised Service Person to service this appliance.
In Queensland - the authorized Service Person MUST hold a Gas Work Authorisation for
hydrocarbon refrigerants, to carry out Servicing or repairs which involve the removal of
covers.

7
Before first use
Getting Started
•Unpack the appliance but keep all packaging materials until you have made sure your new
bar fridge is undamaged and in good working order.
•Plastic wrapping can be a suffocation hazard for babies and young children, so ensure all
•Check to ensure you have all the parts listed , plus aninstruction manual and a warranty
certificate.
packaging materials are out of their reach.
•Read this manual to familiarise yourself with all the parts. Pay particular attention to the
safety instructi ons on the previous pages.
•Unwind the cord to its full length and inspect it for damage. Do not use the appliance if
the appliance or its cord have been damaged. In case of damage, contact our after sales
support line for advice on examination, repair or return of the damaged product.
•Make sure the bar fridge is disconnected from the power supply before cleaning the
interior surfaces with lukewarm water using a soft cloth to remove any dust from transit
and storage. Dry the appliance thoroughly.
•Your bar fridge has the capability of the door opening from the right or left side. If your
setup requires reversal of the door swing, follow the instructions on page 9.
Installing the bar fridge
•Before installing your new upright bar fridge, read all safety instructions in this manual,
especially the sections on electrical safety and installation . Then follow the instructions
below.
•This appliance is designed to be freestanding only and should not be recessed or builtin.
•Place the bar fridge on a sturdy, level floor that is strong enough to support the unit when
it is fully loaded.
•DO NOT install the appliance directly on carpeting or soft material. Carpeting must be
removed or protected by a metal or wood panel beneath the appliance, which extends at
least the full width and depth of the appliance. NOTE: Ensure that the appliance does not
stand on the electrical supply cable. Parts which heat up should not be exposed. Whenever
possible , the back of the appliance should be close to a wall but leaving the required
distance for ventilation.
Overloading the fridge will affect cold air circulation and cooling performance. We
therefore recommend you only load the fridge up to about 70% of its storage volume,
always leave some space around food stored, and do not use containers that are too
large and block ventilation openings.

about your setup, direct any questions concerning power and/or grounding to a certified
•Locate the bar fridge:
•Away from sources of heat (stove, heater, radiator, dishwasher, etc.),which may increase
•In an area without extreme cold ambient temperatures, which may affect cooling
•Away from direct sunlight, which may affect the acrylic coating.
power consumption.
performance.
•In a cool, well ventilated area, without excessive moisture and high humidity.
•Installing the unit in the coolest area of the room will save energy consumption and
running costs.
•To ensure correct operation, this appliance must not be located where the temperature
will be below 10°C or above 43°C.
•En su re there are no obstru ctions tha t could p revent the fridge door from c losing.
•To level the bar fridge, adjust the levelling legs at the bottom of the unit.
•The refrigerator must have at least 50mm clearance between the rear of the appliance and
the wall, 25mm between the sides and wall, and the space above the top should be at
least 25mm. Ensure that there is enough spacing to open the door to 160°.
•Before plugging in your new bar fridge, let it stand upright for approximately 2
hours. This will allow the refrigerant gases to settle into the compressor and reduce the
possibility of a malfunction in the cooling system from handling during transportation.
•The Bar Fridge is suitable for connection to 220-240VAC 50Hz supply. The Bar Fridge must
be plugged into a dedicated individual 220-240VAC main socket outlet.
•Plug the unit into an exclusive, properly installed and earthed wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power co rd. Ifin doubt
electrician.
•Do not use an extension cord or an adapter plug.
•Secure the bar fridge’s supply cord behind the unit. Do not leave it exposed or dangling to
prevent in ju ry an d acciden tal dis conne ction from the power su ppl y.
NOTE: After plugging the appliance into a wall outlet, allow the unit to cool down for two
to 3 hours before placing food in the refrigerator compartment.
Getting Started
8

9
1. Tilt the unit slightly towards the rear and
prop it securely. Two people are required
to tilt the unit during the door reversal
process.
2. Remove the top right hinge cover.
3. Undo the screws. Then remove the hinge
bracket.
This bar fridge can be opened from either the left side (as supplied) or right side to suit your
individual installation requirements. If you want to open the door from the right side, follow
the instructions below
WARNING! gnisrevernehwylppusrewopehtmorfdetcennocsidsiegdirfrabehterusnE
door swing.
NOTE: Keep all parts you rem ove for re-installationof the door on the other side.
Getting Started

10
4.Remove the top left screw cover.
5. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
6. Remove the screws and bottom hinge.
Then remove the levelling feet from
both side.
Unscrew
Getting Started

7. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
Unscrew Screw
8. Refit the bracket fitting the bottom hinge
pin. Replace both levelling feet.
Screw
9. Place the door back on. Ensure the door
is aligned horizontally and vertically
so that the seals are closed on all sides
before finally tightening the top hinge.
10. Insert the hinge bracket and screw it to
the top of the unit.
11. Use a spanner to tighten it if necessary.
11
Getting Started

12. Put the hinge cover and the screw cover
back.
13. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
12
Getting Started

13
Temperature control
•The control for regulating the temperature inside the refrigerator is located on the upper
•Position “0” means OFF.
right hand side of the compartment.
•Turning clockwise in direction will turn the refrigerating unit ON.
•Position “1” means: Highest temperature, warmest setting.
•Position “5” means: Lowest temperature, coldest setting.
•At a low ambient temperature of around 16°C, setting “1” should be selected.
•At ambient temperatures of around 25 °C, select setting “2-3”. If you require a
lower temperature, select setting “4” or “5”.
NOTE: High ambient temperatures (e.g. on hot summer days) and a cold setting on
the temperature regulator (position 5) can cause the compressor to run continuously.
Reason: when the ambient temperature is high, the compressor must run continuously to
maintain the low temperature in the appliance.
and location of the appliance .
•In determining the correct temperature control setting, all these factors have to be
considered and some experimentation may be necessary.
NOTE:
minutes before restarting the unit. If you attempt to restart before this time delay,
the unit will not start.
Operation Instructions
•The tem perature will be affected by: Roo m tem p erature, h ow often the doo r is op ene d
If the unit is unplugged, turned off or has lost power, you must wait three to five
Fresh food storage
The fresh food (refrigerator) compartment is suitable for short-term storage of fresh food.
The temperature inside varies depending on the amount of food stored and the frequency of
In order to maintain good cooling effciency and save energy, we recommend you do not
space around items for cold ai r flow. Do not block ve ntilation openings.
door opening.
open the door for too long or too often. Do not overload the bar fridge, and keep enough
Normal Operating Sounds
The following noises are characteristic of refrigeration appliances:
Whenever the compressor is switched on or off, a click sound may be heard.
Clicks:
Humming: As soon as the compressor is in operation, you ma y hear it humming .
splashing noises. Even after the compressor has been switched off, this noise may still occur
When refrigerant flows into thin tubes, you may hear bubbling orBubbling/Splashing:
for a short time.

14
Troubleshooting
Problem Possible cause
The fridge temperature is not
cool enough.
•The room temperature is hotter than normal.
•A large amount of food has been added at once.
•The door is opened too often.
•The door is not closed completely.
•The temperature control is not set correctly.
•The
•A rattling noise may come from the flow of the
door gasket does not seal properly.
There are vibrations. •The fridge is not level.
The fridge seems to make too
much noise. refrigerant, which is normal. A popping and crackling
noise may be caused by the contraction and expansion
of the inside walls.
•The fridge is not level, or is touching other furniture.
•Bottles or packages inside the fridge are touching each
other.
The door will not close
properly.
•The fridge is not level.
•The door was reversed and is not properly installed.
•The gasket is dirty or bent.
•The shelves, racks or crisper are out of position.
The fridge door will not open. •If the door has just been opened, leave it for a few
minutes to allow the air pressure to equalise before
trying again.
Moisture forms on the inside
or outside walls of the bar
fridge.
•Hot and humid weather increases the internal rate of
frost build-up. This is normal.
•Open the door less often and make sure it is always
properly closed.
The fridge does not operate. •It is not plugged in. Ensure it is properly plugged in and
there is power at the socket (plug another appliance into
the outlet to check).
•The circuit breaker tripped or has blown a fuse.
•The fridge temperature control is set to OFF.
•A general power outage has cut power to your home
(check the household lights).
If you experience a problem with your bar fridge, check in the following table for solutions
to help you solve the problem. If after these checks you still have a problem with your bar
fridge, call the after sales supportline for advice.

The external fridge surface is
warm.
•The exterior walls can be warmer than room
temperature. This is normal while the compressor works
to transfer heat from inside the fridge cabinet.
Excessive frost and ice has
built up.
•The fridge door has been left open.
•Something is preventing the door from closing.
•The door gasket is dirty or damaged.
•Make sure to defrost the fridge regularly.
The compressor runs
continuously.
•The temperature is set too cold: select a lower (warmer)
setting.
•The door is open, or something is obstructing proper
door closure.
•The door gaskets are worn, dirty or damaged.
•Large quantities of food have been added to the fridge.
•The room temperature is hotter than usual.
Troubleshooting
Troubleshooting
15

16
Care and Maintenance
For the most efficient operation and minimum energyconsumption, defrost the bar
Defrosting the bar fridge
When？
fridge when the frost accumulated on the evaporator is about 5mm thick.
How？Turn the thermostat dial to the [0] position and unplug the bar fridge. Remove
perishable food items from the fridge and keep them in another fridge or cooler bag to
protect the food.
Defrosting usually takes a few hours. After defrosting, dry the food compartments and
return the thermostat dial to the desired position.
To defrost quickly, remove all foods from the fridge and leave the door open.
CAUTION: Do not use boiling water because it may damage the plastic parts. Never use
a sharp or metallic instrument to remove frost as it may damage the cooling
system. Use a plastic scraper, if required.
Cleaning the bar fridge
•CAUTION: Before cleaning the fridge, make sure to turn the temperature control to the
[0] position, unplug the bar fridge and remove the food and shelves.
•Wash the inside surfaces with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to 1.2L of water. Wring excess water out
of the sponge or cloth before cleaning around the temperature control or any electrical
parts.
•Clean the shelves and inside fridge, as well as the outside of the fridge, with a mild
detergent solution and warm water. Rinse and dry thoroughly.
•Never use acids, chemical thinners, petrol, benzene or thelike for cleaning any part of
the bar fridge.
•It is advisable to periodically clean the refrigeration system at the back of the appliance
with a duster or vacuum cleaner.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature
of your fridge if you minimise the number of times the door is opened. If the power is going
to be off for a longer period of time, take appropriate steps to protect your food.

17
•Remove the mains plug or switch off or disconnect the electricity supply.
Switching off the appliance
Energy saving tips
•Place the fridge in the coolest area of the room, away from heat-producing appliances
and out of direct sunlight.
•Let hot foods cool down a little before placing them into the fridge. Overloading the
fridge forces the compressor to run longer.
•Wrap foods properly and wipe containers dry before placing them in the fridge. This
cuts down on frost build-up inside the fridge.
Liners interfere with cold air circulation, reducing cooling efficiency.
•Do not line any fridge storage bin with aluminum foil, wax paper or paper towels.
•Do not leave the fridge door open for longer than required.
When away on holidays
•Short holidays: leave the fridge operating during vacations of less than three weeks.
•Long holidays: if the appliance will not be used for several months, remove all food,
unplug the unit and thoroughly clean and dry the interior. To prevent odour and mould
growth, block the door open slightly.
Moving the bar fridge
•Remove all food from inside the fridge, tape the door shut and securely tape down all
loose items inside. Turn the levelling feet up to the base.
•We recommend moving the fridge inits original packaging. Otherwise, make sure to
protect the outside of the fridge with a blanket or similar item during transportation.
•Do not apply force on any external part such as pipes, condenser or door when moving.
•Ensure the fridge stays secure in an upright position; do not tiltit for more than 45 °
from upright.
not going to be used for an extended period:
To switch off the appliance, turn the temperature regulator to position”0”.If the appliance is
•Remove all refrigerated items
•Switch off the appliance by turning the temperature regulator to position “0”
•Clean thoroughly.
•Once the unit has been turned off, allow the unit to settle down for about 10 minutes
•Leave the door open to avoid the build up of odours.
before turning the unit on. This will prevent the compressor from being damaged.

18
-Model: G67BFW15
-Group: 2 (Refrigerator)
-Product dimension WxDxH : 440mm x 510mm x 640mm
-Total gross volume: 67L
-Total storage volume: 62L
-Fresh-food compartment storage volume: 57.0L
-Special compartment storage volume: 5.0L
-Climate class: T
-Rated voltage: 220-240V~
-Rated Frequency: 50Hz
-Rated Current: 0.45A
-Star Rating: 1
-Energy consumption: 268 kWh per year

M.E.W. (Australia) Pty Ltd
15 Vaughan Street
Essendon Fields VIC 3041
ACN 152 719 036
1300 725 885
[email protected]
gvaproducts.com.au
CKGVA-B01-G
