GVA GVAFD2-27 User manual

210L Refrigerator/ Freezer
/ GVAFD2-27

Contents
Guide to the Appliance
Caring for the Environment 3
Safety Information and Warnings 4
Getting Started 7
Basic Set Up 9
Reversing the Door Swing 10
Troubleshooting 11
Care and Maintenance 13
2

2
Guide to the Appliance
NOTE: Due to production improvements, the unit you purchased may vary slightly from the
below sketch.
Product Overview
Glass
Shelves
Salad Bin
Cover
Salad Bins
Upper
Drawers
Bottom
Drawer
Internal Light and
Thermostat Control Dial
Levelling Feet
Upper
Balconies
Bottom
Balcony
Egg Tray Ice Tray

3
Responsible disposal of the packaging
At the end of its working life, do not throw this appliance out with your household rubbish.
Electrical and electronic appliances contain materials and substances which, if handled or
disposed of incorrectly, could be potentially hazardous on the environment and human
health.
Observe any local regulations regarding the disposal of electrical consumer goods and
dispose of it appropriately for recycling and recovery of the refrigerant. This appliance
contains the flammable refrigerant isobutane (R600a) and cyclopentane (R141b) in the
cabinet insulation, and must be disposed of in a separate waste collection. Contact your
local authorities for advice on recycling facilities in your area.
Take care not to damage the pipework at the back of the appliance before or during
transportation so that the refrigerant gas cannot escape.
The plug must be rendered useless and the cable cut off directly behind the appliance or
the machine to prevent misuse.
DANGER. Risk of child entrapment: When discarding a fridge or freezer, make sure to take
off the door and the spring action or bolt catch. Leave the shelves in place so that children
cannot easily climb in, get trapped inside and suffocate.
Caring for the Environment
The packaging of your appliance has been selected from environmentally friendly materials
and can usually be recycled. Please ensure these are disposed of correctly.
Plastic wrapping can be a suffocation hazard for babies and young children, please ensure
all packaging materials are out of reach and are safely disposed of. Please ensure they are
offered for recycling rather than throwing these materials away.
Responsible disposal of the appliance

DANGER means that failure to read this safety statement may result in severe personal
injury.
WARNING means that failure to read this safety statement may result in extensive product
damage or serious personal injury.
CAUTION means that failure to read this safety statement may result in minor or moderate
personal injury, property or equipment damage.
Safety Information and Warnings
This symbol alerts you to take care as the appliance contains a
flammable refrigerant. Do not expose it to high heat, sparks or open
ames.
Pay particular attention to safety messages that follow this safety alert
symbol or the words DANGER, WARNING or CAUTION. These words are
used to alert you to a potential hazard that can seriously injure you and
others.
The instructions will tell you how to reduce the chance of injury and let
you know what can happen if the instructions are not followed.
Read this manual thoroughly before rst use, even if you are familiar with this type of
product. We have provided many important safety statements in this manual concerning the
use of this appliance. Always read and observe all safety statements. They reduce the risk of
fire, electric shock and injury when correctly adhered to.
Keep the manual in a safe place for future reference, along with the purchase receipt.
If applicable, pass these instructions on to the next owner of the appliance.
We assume no liability for any eventual damages caused by misuse of the appliance
or non-compliance with the instructions in this manual.
CAUTION:
Flammable Gas
4

Safety Information and Warnings
Installation
Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury,
consider a two person lift or mechanical aid when installing it.
Location: The room for installing appliance must be at least 1M³per 8g of refrigerant. The
amount and type of refrigerant in the appliance can be found on the rating plate on the
back of the appliance.
Moisture: Install the refrigerator in an indoor area protected from wind, rain, water spray or
drips.
Heat: Do not install it next to an oven, grill or other source of high heat.
Ventilation: To ensure proper ventilation, the front of the unit must be completely
unobstructed. Keep any ventilation openings clear of obstructions. Choose a well
ventilated area with temperatures above 16˚C and below 32˚C.
Refrigerant circuit: Do not damage the refrigerant circuit.
Level: Install the appliance on a level surface or adjust the feet to level the unit and ensure
proper operation.
Pipes: Make certain that the pipes are not pinched, kinked or damaged during installations.
Check for leaks after connection.
Electrical safety
Voltage: Make sure your outlet voltage and circuit frequency correspond to the voltage
stated on the appliance rating label. Plug the refrigerator into a 220-240V, 50Hz, 3-prong,
power outlet with a 15A fuse at the mains. The outlet must be properly earthed to the
ground.
Separate circuit: Do not use an adaptor; do not use an extension cord. We recommend you
connect the refrigerator to a separate circuit serving only this appliance. This provides the
best performance and prevents overloading the house wiring circuits that could cause a fire
hazard from overheating. Use a power point that cannot easily be turned off accidentally.
Power cord: Do not kink or damage the power cord. Do not leave it exposed or dangling.
Secure it behind the unit so no one steps on or places anything on the cord or against it.
Never unplug the unit by pulling the cord. Always grip the plug firmly and pull straight out
from the power point.
Damaged cord: Do not use a cord that shows cracks or abrasion damage along its length
or at either end. If the power cord is damaged, it must be replaced by the manufacturer or
its service agent. Contact the after sales support line to have it replaced.
Electrical work: If the installation of this appliance requires any electrical work, make sure it
is carried out by a qualified electrician.
5

Safety Information and Warnings
Usage conditions and restrictions
Indoor domestic use only: This appliance is intended for indoor household use only. It is
not suitable for commercial, industrial or outdoor use.
Intended purpose: Do not use this appliance for anything other than its intended purpose
and only use it as described in this manual. Do not attempt to alter or modify this appliance
in any way.
Electrical type appliances: Do not use any such appliances inside the food storage com-
partments of the appliance, unless they are specifically recommended in this manual.
Usage restrictions: The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children: Supervise children to ensure they do not play with the refrigerator. Never allow
children to operate, play with or crawl inside the refrigerator.
Cleaning and maintenance
Disconnect: Unplug the refrigerator or disconnect power before cleaning or servicing
Failure to do so can result in electrical shock, injury or death. Do not connect or disconnect
the electric plug when your hands are wet.
Flames: Do not let open ames or ignition sources enter the appliance.
Flammable/explosive substances: Never clean this appliance with flammable fluids. Do
not store or use volatile, flammable or explosive propellants or liquids close to this or any
other appliance. The fumes can create a fire hazard or explosion caused by electric sparks.
Solvents: Do not use solvent based cleaning agents or abrasives on the interior. These
cleaners may damage or discolour the interior.
Service: Do not attempt to repair or replace any part of the refrigerator unless it is
specifically recommended in this manual. Refer all other servicing to a qualified technician,
or contact the after sales support line for advice on repair or replacement. It is hazardous
for anyone other than an Authorised Service Person to service this appliance. In
Queensland - the authorized Service Person MUST hold a Gas Work Authorisation for
hydrocarbon refrigerants, to carry out Servicing or repairs which involve the removal of
covers.
6

7
Getting Started
Before rst use
• Unpack the appliance but keep all packaging materials until you have made sure your new
refrigerator is undamaged and in good working order.
• Plastic wrapping can be a suocation hazard for babies and young children, so ensure all
packaging materials are out of their reach.
•Check to ensure you have all the parts listed on the 'Guide to the Appliance' page, plus
aninstruction manual and a warranty certificate.
•Read this manual to familiarise yourself with all the parts. Pay particular attention to the
safety instructions on the previous pages.
•Unwind the cord to its full length and inspect it for damage. Do not use the appliance if
the appliance or its cord have been damaged. In case of damage, contact our after sales
support line for advice on examination, repair or return of the damaged product.
•Make sure the refrigerator is disconnected from the power supply before cleaning the
interior surfaces with lukewarm water using a soft cloth to remove any dust from transit
and storage. Dry the appliance thoroughly.
•Your refrigerator has the capability of the door opening from the right or left side. If your
setup requires reversal of the door swing, follow the instructions on page 10.
•Your new refrigerator is now ready for use – see page 9for set up instructions.
Installing the refrigerator
•Before installing your new upright refrigerator, read all safety instructions in this manual,
especially the sections on electrical safety and installation. Then follow the instructions below.
• This appliance is designed to be freestanding only and should not be recessed or built in.
• Place the refrigerator on a sturdy, level oor that is strong enough to support the unit when
it is fully loaded.
•DO NOT install the appliance directly on carpeting or soft material. Carpeting must be
removed or protected by a metal or wood panel beneath the appliance, which extends at
least the full width and depth of the appliance.
NOTE: Ensure that the appliance does not stand on the electrical supply cable. Parts which
heat up should not be exposed. Whenever possible, the back of the appliance should be
close to a wall but leaving the required distance for ventilation.
Overloading the refrigerator will aect cold air circulation and cooling performance. We
therefore recommend you only load refrigerator up to about 70% of its storage volume,
always leave some space around food stored, and do not use containers that are too
large and block ventilation openings.

8
• Locate the refrigerator:
• Away from direct sunlight, which may aect the acrylic coating.
•Away from sources of heat (stove, heater, radiator, dishwasher, etc.), which may increase
power consumption.
•In an area without extreme cold ambient temperatures, which may affect cooling
performance.
• In a cool, well ventilated area, without excessive moisture and high humidity.
•Installing the unit in the coolest area of the room will save energy consumption and
running costs.
•To ensure correct operation, this appliance must not be located where the temperature
will be below 10°C or above 43°C.
• Ensure there are no obstructions that could prevent the refrigerator door from closing.
• To level the refrigerator, adjust the levelling legs at the bottom of the unit.
•The refrigerator must have at least 50mm clearance between the rear of the appliance and
the wall, 100mm between the sides and wall, and the space above the top should be at
least 100mm. Ensure that there is enough spacing to open the door to 160°.
•Before plugging in your new refrigerator, let it stand upright for approximately 2
hours. This will allow the refrigerant gases to settle into the compressor and reduce the
possibility of a malfunction in the cooling system from handling during transportation.
• The refrigerator is suitable for connection to 220-240VAC 50Hz supply. The refrigerator must
be plugged into a dedicated individual 220-240VAC main socket outlet.
• Plug the unit into an exclusive, properly installed and earthed wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. If in doubt
about your setup, direct any questions concerning power and/or grounding to a certied
electrician.
• Do not use an extension cord or an adapter plug.
• Secure the refrigerator’s supply cord behind the unit. Do not leave it exposed or dangling to
prevent injury and accidental disconnection from the power supply.
Getting Started
Note: After plugging the appliance into a wall outlet, allow the unit to cool down for 2 to
3 hours before placing food in the refrigerator compartment.

9
Fresh food storage
The fresh food (refrigerator) compartment is suitable for short-term storage of fresh food.
The temperature inside varies depending on the amount of food stored and the frequency of
door opening.
In order to maintain good cooling eciency and save energy, we recommend you do not
open the door for too long or too often. Do not overload the refrigerator, and keep enough
space around items for cold air ow. Do not block ventilation openings.
Normal Operating Sounds
The following noises are characteristic of refrigeration appliances:
Clicks: Whenever the compressor is switched on or o, a click sound may be heard.
Humming: As soon as the compressor is in operation, you may hear it humming.
Bubbling/Splashing: When refrigerant ows into thin tubes, you may hear bubbling or
splashing noises. Even after the compressor has been switched o, this noise may still occur
for a short time.
Basic Set Up
Switching On Your Unit
1. Before connecting the unit to the mains supply, adjust the
thermostat control dial to the desired position. Bear in mind
that the higher the number, the lower the temperature.
Position 3is the recommended setting when operating at
normal room temperature (between 16°C and 38°C).
2. The unit may not operate at the correct temperature if it is in
a particularly hot or a particularly cold room, or if you open
the door often.
3. To ensure that the unit is cool enough to suciently chill
your food, wait 24 hours before lling it with food.
4. If you are concerned that your unit is not being kept cold
enough and wish to check the temperature, you will need a
special fridge/freezer thermometer. These are available from
most supermarkets and hardware shops.
Place the thermometer in the centre of the unit, where it can
be read easily. Leave overnight, the temperature in the unit
should be an average of 5°C.
3
3
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat. The recommended
position is between 1 to 4 for colder working environments (i.e. during winter) and
between 5 to 7 for hotter environments. Please adjust according to the environment.

10
Reversing the Door Swing
This refrigerator can be opened from either the left side (as supplied) or right side to suit your
individual installation requirements. If you want to open the door from the right side, follow
the instructions below and opposite to reverse the door swing (the numbers in brackets
refer to the parts in the illustrations).
WARNING! Ensure the refrigerator is disconnected from the power supply when reversing
door swing.
NOTE:Keep all parts you remove for re-installation of the door on the other side.
1. Removethetwoscrews(3)holdingthetophinge(4)(rightside)totheframe. Removethetop
hinge(4).
2. Lift thedooroffthemiddlehingepinandplaceitonanon-scratchingsurface.
3. Removethetwoscrews(5)holdingthemiddlehinge(6).Removethemiddlehinge(6).
4. Liftthelowerdooroffthebottomhingepinandplaceitonanon-scratchingsurface.
5. Removethetwoscrews(7)holdingthebottomhinge(8).Removethebottomhinge(8).
6. Removetheleftfrontleg(9)andtransferittotherightside.
7. Beforereplacingthebottomhinge(8),removethehingepin(10)andreversethedirectionof
thehinge(8).Reassemblethebottomhinge(6)onthelefthandsideusingthetwoscrews(7).
8. Refit the hinge pin (10) into the bottom hinge (8).
9. Lower the door onto the bottom hinge pin (10).
10. While holding the lower door in the closed position, reassemble the middle hinge (6) on
theleft hand side using the two screws (5). Do not tighten the screws (5) until the top of the lower
door is level with the counter top.
11. Be re replacing the upper hinge (4), remove the hinge pin (2) from right hole to left hole of
the upper hinge (4).
12. Lower the upper door onto the middle hinge pin.
13. While holding the upper door in the closed position, reassemble the upper hinge (4) on the
left hand side using the two crews (3). Do not tighten the screws (3) until the top of the upper door
is level with the counter top.
Door opening from left side fig. 1 Door opening from right side fig. 2

11
Troubleshooting
Problem Possible cause
The refrigerator does not
operate.
• It is not plugged in. Ensure it is properly plugged in and
there is power at the socket (plug another appliance into
the outlet to check).
• The circuit breaker tripped or has blown a fuse.
• The refrigerator temperature control is set to OFF.
• A general power outage has cut power to your home
(check the household lights).
The refrigerator temperature
is not cool enough.
• The room temperature is hotter than normal.
• A large amount of food has been added at once.
• The door is opened too often.
• The door is not closed completely.
• The temperature control is not set correctly.
• The door gasket does not seal properly.
There are vibrations. • The refrigerator is not level.
The refrigerator seems to
make too much noise.
• A rattling noise may come from the ow of the
refrigerant, which is normal. A popping and crackling
noise may be caused by the contraction and expansion
of the inside walls.
• The refrigerator is not level, or is touching other furniture.
• Bottles or packages inside the refrigerator are touching
each other.
The door will not close
properly.
• The refrigerator is not level.
• The door was reversed and is not properly installed.
• The gasket is dirty or bent.
• The shelves, racks or crisper are out of position.
The refrigerator door will
not open.
• If the door has just been opened, leave it for a few
minutes to allow the air pressure to equalise before
trying again.
Moisture forms on the inside
or outside walls of the refrig-
erator.
• Open the door less often and make sure it is always
properly closed.
If you experience a problem with your refrigerator, check in the following table for solutions
to help you solve the problem. If after these checks you still have a problem with your refrig-
erator, call the after sales support line for advice.

12
Troubleshooting
The external refrigerator
surface is warm.
• The exterior walls can be warmer than room
temperature. This is normal while the compressor works
to transfer heat from inside the refrigerator cabinet.
The compressor runs
continuously.
• The temperature is set too cold: select a lower (warmer)
setting.
• The door is open, or something is obstructing proper
door closure.
• The door gaskets are worn, dirty or damaged.
• Large quantities of food have been added to the refrige-
rator.
• The room temperature is hotter than usual.

13
Care and Maintenance
Cleaning the refrigerator
•CAUTION: Before cleaning the refrigerator, make sure to turn the temperature control
to the [0] position, unplug the refrigerator and remove the food and shelves.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature
of your fridge if you minimise the number of times the door is opened. If the power is going
to be off for a longer period of time, take appropriate steps to protect your food.
• Remove all the shelves and drawers.
• Wipe the inside of the unit with a weak solution of bicarbonate soda and then rinse with
warm water using a sponge or cloth. Wipe completely dry before replacing the shelves and
drawers.
• Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure that the door is closed to avoid the polish getting on the magnetic door seal or inside
the unit.
•The grille of the condenser at the back of the unit and the adjacent components can be
vacuumed using a soft brush attachment.

14
Care and Maintenance
Energy saving tips
•Place the refrigerator in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight
• Let hot foods cool down a little before placing them into the refrigerator.
Overloading the refrigerator forces the compressor to run longer.
• Wrap foods properly and wipe containers dry before placing them in the
refrigerator.
• Do not line any refrigerator storage bin with aluminum foil, wax paper or paper
towels. Liners interfere with cold air circulation, reducing cooling efficiency.
•Do not leave the refrigerator door open for longer than required.
When away on holidays
• Short holidays: leave the refrigerator operating during vacations of less than three
weeks.
• Long holidays: if the appliance will not be used for several months, remove all
food, unplug the unit and thoroughly clean and dry the interior. To prevent odour
and mould growth, block the door open slightly.
Moving the refrigerator
•Remove all food from inside the refrigerator, tape the door shut and securely tape
down all loose items inside. Turn the levelling feet up to the base.
• We recommend moving the refrigerator in its original packaging. Otherwise, make
sure to protect the outside of the refrigerator with a blanket or similar item during
transportation.
•Do not apply force on any external part such as pipes, condenser or door when moving.
• Ensure the refrigerator stays secure in an upright position; do not tilt it for more
than 45° from upright.
Switching off the appliance
To switch off the appliance, turn the temperature regulator to position“0”. If the
appliance is not going to be used for an extended period:
• Remove all refrigerated items
•Switch off the appliance by turning the temperature regulator to position“0”
•Remove the mains plug or switch off or disconnect the electricity supply.
•Clean thoroughly.
•Leave the door open to avoid the build up of odours.
•Once the unit has been turned off, allow the unit to settle down for about 10 minutes
before turning the unit on. This will prevent the compressor from being damaged.

M.E.W(Australia) Pty Ltd
15 Vaughan St
Essendon Fields VIC 3041
ACN 152 719 036
www.gvaproducts.com.au
CKGVA-L01-A
