GW Instek APS-7050E User manual

AC Power Source
APS-7000E Series
USER MANUAL
GW INSTEK PART NO. 82PS-7KE00MA1
ISO-9001 CERTIFIED MANUFACTURER
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
3
Table of Contents
SAFETY INSTRUCTIONS ................................................... 4
GETTING STARTED ........................................................... 8
APS-7000E Series Overview....................9
Appearance .......................................... 12
OPERATION.................................................................... 18
Set Up.................................................. 20
Basic Operation ................................... 36
Preset Settings..................................... 53
Test Mode Function ............................. 57
FAQ ................................................................................ 67
APPENDIX ...................................................................... 68
Firmware Update ................................. 68
APS-7000E Default Settings ................. 70
APS-7000E Specifications..................... 71
APS-7000E Dimensions........................ 74
Declaration of Conformity .................... 76
INDEX............................................................................. 77
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
4
SAFETY INSTRUCTIONS
This chapter contains important safety
instructions that you must follow during
operation and storage. Read the following before
any operation to ensure your safety and to keep
the instrument in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the
instrument.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the APS-7000E or to
other properties.
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
5
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.
Safety Guidelines
General
Guideline
CAUTION
 Do not place any heavy object on the APS-
7000E.
 Avoid severe impact or rough handling that
leads to damaging the APS-7000E.
 Do not discharge static electricity to the APS-
7000E.
 Use only mating connectors, not bare wires, for
the terminals.
 Do not block the cooling fan opening.
 Do not disassemble the APS-7000E unless you
are qualified.
(Measurement categories) EN 61010-1:2010 specifies the
measurement categories and their requirements as follows. The
APS-7000E doesn’t fall under category II, III or IV.
 Measurement category IV is for measurement performed at the
source of low-voltage installation.
 Measurement category III is for measurement performed in the
building installation.
 Measurement category II is for measurement performed on the
circuits directly connected to the low voltage installation.
 0 is for measurements performed on circuits not directly
connected to Mains.
Power Supply
WARNING
 AC Input voltage range: 115/230 Vac ± 15%
 Frequency: 50/60Hz
 To avoid electrical shock connect the protective
grounding conductor of the AC power cord to
an earth ground.
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
6
Cleaning the APS-
7000E
 Disconnect the power cord before cleaning.
 Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid.
 Do not use chemicals containing harsh material
such as benzene, toluene, xylene, and acetone.
Operation
Environment
 Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
 Relative Humidity: 20%~ 80%, no condensation
 Altitude: < 2000m
 Temperature: 0°C to 40°C
(Pollution Degree) EN 61010-1:2010 specifies the pollution degrees
and their requirements as follows. The APS-7000E falls under degree
2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
 Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
 Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
 Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.
Storage
environment
 Location: Indoor
 Temperature: -10°C to 70°C
 Relative Humidity: ≤80%, no condensation
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
7
Power cord for the United Kingdom
When using the instrument in the United Kingdom, make sure the
power cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the
following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with
the coloured marking identified in your plug/appliance, proceed
as follows:
The wire which is coloured Green & Yellow must be connected to
the Earth terminal marked with either the letter E, the earth symbol
or coloured Green/Green & Yellow.
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the
terminal marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment
or contact the supplier.
This cable/appliance should be protected by a suitably rated and
approved HBC mains fuse: refer to the rating information on the
equipment and/or user instructions for details. As a guide, a cable
of 0.75mm2should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the
connection method used.
Any exposed wiring from a cable, plug or connection that is
engaged in a live socket is extremely hazardous. If a cable or plug is
deemed hazardous, turn off the mains power and remove the cable,
any fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above
standard.
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
8
GETTING STARTED
This chapter describes the power source in a
nutshell, including its main features and front /
rear panel introduction.
APS-7000E Series Overview ............................................... 9
Series lineup................................................................................................................ 9
Operating Area........................................................................................................... 9
Main Features........................................................................................................... 10
Accessories ............................................................................................................... 11
Appearance ..................................................................... 12
Front Panel ............................................................................................................... 12
Rear Panel ................................................................................................................. 15
www. .com [e-mail]1.800.561.8187

GETTING STARTED
9
APS-7000E Series Overview
Series lineup
The APS-7000E series consists of 2 models, the APS-7050E and the
APS-7100E, differing only in capacity. Note that throughout the
user manual, the term “APS-7000E” refers to both the APS-7050E
and APS-7100E, unless stated otherwise.
Model name
Max. Output Current
Power Rating
Output Voltage
APS-7050E
4.2A/2.1A
500VA
0~310.0 Vrms
APS-7100E
8.4A/4.2A
1000VA
0~310.0 Vrms
Operating Area
Voltage (V)
Current (A)
0
1
2
0
3
4
5
100 200 300 400
120 155 240 310
4.2
3.23
2.1
1.62
APS-7050E Output Operating Area
155V Range 310V Range
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
10
Voltage (V)
Current (A)
0
2
4
0
6
8
10
100 200 300 400
120 155 240 310
8.4
6.45
4.2
3.23
155V Range 310V Range
APS-7100E Output Operating Area
Main Features
Performance
 Low output ripple and noise
 Excellent and feature-rich measurement
capacity
 Standard maximum output voltage is 310Vrms
 Maximum frequency of 500Hz.
www. .com [e-mail]1.800.561.8187

GETTING STARTED
11
Features
 OVP, OCP and OTP protection
 Variable voltage, frequency and current limiter
 Test function to simulate line voltage and
frequency variations
 Large 4.3 inch TFT panel
 Globally adjustable power inlet not restricted by
the power supply environment
 USB interface is equipped as standard with the
ability to upgrade the software.
 Only 88mm (2U) case height.
Interface
 USB host
Accessories
Standard
Accessories
Part number
Description
CD ROM
User manual
Region dependent
Type I Power cord
(APS-7050E)
Region dependent
Type II Power cord
(APS-7100E)
62PS-7K0SC701 x1
5302-01613001 x1
Mains terminal cover set
(APS-7050E)
62PS-7K0SC401 x1
5302-01613001 x2
Mains terminal cover set
(APS-7100E)
GTL-123
Test leads: 1x red, 1x black
Optional
Accessories
Part number
Description
GRA-423
APS-7000E rack mount kit
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
12
Appearance
Front Panel
APS-7050E, APS-7100E
Display
F 1
F 2
F 3
F 4
Output
: Long Push
Menu Test Preset
V
0
1
4
7
2
5
8
3
6
9
V-Limit F-Limit IPK-Limit
F I rms
Cancel
Shift
Range
Enter
Lock
ALM CLR
IPK CLR
Unlock
APS-7050E AC Power Source
USB A port
Power
switch
Front voltage
output socket
Menu, Test,
Preset keys
LCD
display
Function keys
Display
mode key
Arrow keys,
Scroll wheel
Voltage, Frequency &
Current settings and limits
Keypad
Range, Shift, Cancel,
Enter, Lock keys
Output key
Item
Description
Power Switch
Turns on the mains power.
Front Voltage
Output Socket
Neutral
GND
Line
Output voltage
terminal using a
regional universal
plug. There is a Euro
and a Universal
regional plug.
CAUTION
Maximum allowable output voltage
and current are 250Vrms and
10Arms.
For voltages exceeding 250Vrms,
please use the rear output terminal.
www. .com [e-mail]1.800.561.8187

GETTING STARTED
13
USB A Port
The USB port is used for
upgrading software.
LCD Screen
Displays the measured values or
menu system.
Display Mode
Select Key
Display
Selects between Standard mode
and Simple mode.
Function Keys
F 1
F2
F3
F4
Assigned to the functions
displayed on the right-hand side
of the screen.
Menu Key
Menu
Enters the Main menu or goes
back to one of the display modes.
Test Key
Test
Puts the instrument into the Test
mode.
Preset Key
Preset
Puts the instrument into Preset
mode.
Arrow Keys
The arrow keys are used to select
the digit power of a value that is
being edited.
V
V
V-Limit
Used for setting the output
voltage.
V-Limit
(Shift + V)
Used for setting the output voltage
limit value.
F
F
F-Limit
Used for setting the output
frequency.
F-Limit
(Shift + F)
Used for setting the output
frequency limit value.
I rms
I rms
IPK-Limit
Used for setting the maximum
output current.
IPK-Limit
(Shift + I rms)
Used to set the peak output
current limit value.
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
14
Range Key
Range
Switches between the 155V and
310V ranges.
Scroll Wheel
Used to navigate menu items or
for incrementing/decrementing
values one step at a time.
Lock Key
Lock
Unlock
Locks the number pad to prevent
accidentally changing panel
settings.
Unlock Key
(Long press)
Disables the key lock.
Enter Key
Enter
Confirms selections / settings
Cancel Key
Cancel
Clears entries that are made in the
number entry dialog when a value
is edited using the arrow keys or
the scroll wheel.
The Cancel key can also be used to
cancel function setting menus or
dialogs.
Shift Key
Shift
Turns on the shift state, which
enables shortcut operations.
Output Key
Output
Turns the output on or off.
Number Pad
0
1
4
2
5
8
3
6
9
Lock
Unlock
7
IPK CLR
ALM CLR
Used to enter values.
ALM CLR
(Shift + 6)
Clears alarms.
IPK CLR
(Shift + 9)
Clears peak current hold.
www. .com [e-mail]1.800.561.8187

GETTING STARTED
15
Rear Panel
SER. NO. LB
L N N L
310Vac MAX. 115 / 230V 15%
50 / 60Hz
3.6kVA MAX.
OUTPUT INPUT
115 / 230V 15%
50 / 60Hz
1.8kVA MAX.
SER. NO. LB
OUTPUT
310Vac MAX.
L N
Fan Line voltage input
Rear panel voltage
output terminal
Line voltage input
APS-7050E
APS-7100E
Fan
Line Voltage
Input
APS-7050E
115 / 230V 15%
50 / 60Hz
1.8kVA MAX.
Voltage Input: 115/230±15% VAC;
Line frequency: 50Hz/60 Hz
(Automatically switchable)
APS-7100E
L N N L
310Vac MAX. 115 / 230V 15%
50 / 60Hz
3.6kVA MAX.
OUTPUT INPUT
Voltage Input: 115/230±15%
VAC ; Line frequency:
50Hz/60 Hz (Automatically
switchable)
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
16
Rear Voltage
Output Socket
Output voltage terminal.
APS-7050E
OUTPUT
310Vac MAX.
L N
APS-7100E
L N N L
310Vac MAX. 115 / 230V 15%
50 / 60Hz
3.6kVA MAX.
OUTPUT INPUT
FAN
Temperature controlled fan.
www. .com [e-mail]1.800.561.8187

GETTING STARTED
17
Status Bar Icons
Status bar
/
Indicates if the output is ON or OFF.
Indicates the output power as a percentage of full
scale.
The alarm icon will appear on the status bar
when one of the protection functions are tripped.
Applies to Over Power, Over Irms, Over Ipeak
and Over Temperature protection.
Indicates that a USB drive is detected in the front
panel host port.
Indicates that the panel lock is active.
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
18
OPERATION
Set Up............................................................................. 20
Line Voltage Connection (APS-7100E)................................................................ 20
Power Up.................................................................................................................. 23
Output Terminals .................................................................................................... 24
Using the Rack Mount Kit ..................................................................................... 28
How to Use the Instrument ................................................................................... 28
Reset to Default Settings ........................................................................................ 32
View System Version and Serial Number............................................................. 33
LCD Configuration ................................................................................................. 34
Buzzer........................................................................................................................ 35
Basic Operation .............................................................. 36
Setting the Voltage Range....................................................................................... 36
Setting the Voltage Limit ........................................................................................ 37
Setting the Output Voltage..................................................................................... 38
Setting the Frequency Limit ................................................................................... 40
Setting the Output Frequency................................................................................ 41
Setting the Peak Current Limit .............................................................................. 42
Setting the Current RMS Level .............................................................................. 45
Alarm Clear............................................................................................................... 48
Display Modes.......................................................................................................... 49
Panel Lock ................................................................................................................ 51
Turning the Output On .......................................................................................... 52
Preset Settings ................................................................ 53
Save Preset Settings to Local Memory.................................................................. 53
Load Preset Settings to Local Memory................................................................. 54
Manage Preset Settings............................................................................................ 55
Test Mode Function ......................................................... 57
Test Mode Overview............................................................................................... 58
Test Settings ............................................................................................................. 60
Save a Test to Local Memory................................................................................. 62
www. .com [e-mail]1.800.561.8187

OPERATION
19
Recall a Test from Local Memory ......................................................................... 62
Manage Test Settings...............................................................................................63
Running a Test ......................................................................................................... 65
www. .com [e-mail]1.800.561.8187

APS-7000E Series User Manual
20
Set Up
Line Voltage Connection (APS-7100E)
Background
The APS-7100E is equipped with an input
power terminal that can accept 115V/230V ±
15%. To connect or replace the power cord (GW
Instek part number: APS-7100E: 4300-31000101,
use the procedure below:
Warning
The following procedure should only be attempted
by competent persons.
Ensure the AC power cord is not connected to
power.
Removal
1. Turn off the power switch.
1
APS-7100E
2. Unscrew the power cord strain relief on the rear
output socket.
3. Remove the 2 screws holding the power cord
cover and remove.
www. .com [e-mail]1.800.561.8187

OPERATION
21
APS-7100E
3
2
4. Remove the AC
power cord wires.
4
CAUTION
The power line inputs for the APS-7100E are on the
outer cluster of terminals.
The terminals to the inner of the panel are the rear
panel outputs.
www. .com [e-mail]1.800.561.8187
