GW Instek GRA-441 User manual

Rack Adapter Panel
GRA-441
Assembly Manual
GW INSTEK PART NO. 82RA-44100M01
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER

GRA-441 Assembly Manual
GRA-441
The GRA-441 rack mount is suited for the PPX DC Power Supply Series. The
GRA-441 supports both the EIA (GRA-441-E) and JIS (GRA-441-J) standards for
use with standard sized rack units.
Rack Mount Adapter Component List and Assembly
Description
Please check to make sure all the components of the
GRA-441 rack mount kit are provided. The JIS and EIA rack
mounts have slightly different component sets.
GRA-441-E
Assembly
Item
Part NO.
Description
QTY
1
59CA-04017NS1
SCREW ROTATION ,- ,M4*17*0.7P ,L=25
ISO N RoHS
3
2
62RA-410HP2A1
CA GRA-410 FRONT BRACKET ,RoHS
1
3
62RA-441HP401
*CA GRA-441 BLANK PANEL ,RoHS
3
4
62RA-410HP1A1
CA GRA-410 MIDDLE BARCKET ,RoHS
1
5
62RA-410HPAA1
CA GRA-410-E 3U BRACKET ,RoHS
2
6
593B-03008NS1
SCREW FMS ,3*8*0.5m/m ,ISO ,N ,RoHS
4
7
593B-03005NS1
SCREW FMS ,+ ,3*5 ,ISO ,N ,RoHS
4

GRA-441 Assembly Manual
3
8
62RA-441HP201
*CA GRA-441 RIGHT BRACKET ,RoHS
1
9
62RA-410HPD01
CA GRA-410 RACK HP ,RoHS
1
10
599B-03006NS1
SCREW IMS ,+ ,3*6 ,ISO ,N ,RoHS
4
11
592B-W3008NS1
SCREW PMS ,+ ,M3*8 ISO ,N (WASHER
P.S) ,RoHS
6
12
62RA-410HP9A1
CA GRA-410 RACK HP ,RoHS
3
13
62RA-410HP3B1
CA GRA-410 REAR BRACKET ,RoHS
1
14
62RA-441HP101
*CA GRA-441 LEFT BRACKET ,RoHS
1
15
5320-00403011
SNAP RIVET SR3-3.5 ,BLACK ,KY ,RoHS
4
16
62RA-441HP301
*CA GRA-441 HOLDER ,RoHS
2
17
592B-W3006NS1
SCREW PMS ,+ ,3*6*0.5P ,ISO ,N
(WASHER P.S) ,RoHS
8
GRA-441-J
Assembly
Item
Part NO.
Description
QTY
1
59CA-04017NS1
SCREW ROTATION ,- ,M4*17*0.7P ,L=25
ISO N RoHS
3
2
62RA-410HP2A1
CA GRA-410 FRONT BRACKET ,RoHS
1
3
62RA-441HP401
*CA GRA-441 BLANK PANEL ,RoHS
3
4
62RA-410HP1A1
CA GRA-410 MIDDLE BARCKET ,RoHS
1
5
62RA-410HPBA1
CA GRA-410-J 3U BRACKET ,RoHS
2
6
593B-03008NS1
SCREW FMS ,3*8*0.5m/m ,ISO ,N ,RoHS
8
7
593B-03005NS1
SCREW FMS ,+ ,3*5 ,ISO ,N ,RoHS
4
8
62RA-441HP201
*CA GRA-441 RIGHT BRACKET ,RoHS
1
9
62RA-410HPD01
CA GRA-410 RACK HP ,RoHS
1
10
599B-03006NS1
SCREW IMS ,+ ,3*6 ,ISO ,N ,RoHS
4
11
592B-W3008NS1
SCREW PMS ,+ ,M3*8 ISO ,N (WASHER
P.S) ,RoHS
6
12
62RA-410HP9A1
CA GRA-410 RACK HP ,RoHS
3
13
62RA-410HP3B1
CA GRA-410 REAR BRACKET ,RoHS
1

Assembly
4
14
62RA-441HP101
*CA GRA-441 LEFT BRACKET ,RoHS
1
15
5320-00403011
SNAP RIVET SR3-3.5 ,BLACK ,KY ,RoHS
4
16
62RA-441HP301
*CA GRA-441 HOLDER ,RoHS
2
17
592B-W3006NS1
SCREW PMS ,+ ,3*6*0.5P ,ISO ,N
(WASHER P.S) ,RoHS
8
18
62RA-410HPC01
CA GRA-410-J TOP BRACKET ,RoHS
1
Assembly
Initial setup
1. Remove the handle (from) the unit.
Remove the handle cover.
Remove the screws securing the handle to the case.
Remove the handle.
2. Remove the feet from the underside of the unit.

GRA-441 Assembly Manual
5
Instrument
insertion
1. Ensure the Middle Bracket is latched onto the catch on
the underside of the unit.
Unit
catch Middle Bracket
2. Attach the Front Bracket to the Middle Bracket with
fastening the rack screws.
Unit
Front Bracket
rack
screw
3. Secure the Rack Holding Plates (Rack HP) to the groove
on the Rear Bracket and to the unit
Unit
Rack HP
Rear Bracket
Rear panel
illustration
Ensure the Rack HP is fixed on the rear panel with rack
screws as shown below.
Rack HP (62RA-410HP9A1*3)
Rack HP (62RA-410HPD01)*1

Appearance
6
Blank panel
insertion
1. Insert the blank panel into the
groove of the Front and Middle
Brackets.
2. Secure the panel with the PMS-W-3*8 screws.
Appearance
GRA-441-E
Blank Panel

GRA-441 Assembly Manual
7
GRA-441-J

Specification
8
Specification
Load Capacity
Max 20kg
Rack installation
Diagram
Please note the
minimum width
that is needed to
be supported on
the L-brackets.
