Hüsler Nest bedstead Couch User manual

Assembly instructions
bedstead Couch
Frame
· Assemble frame sections (1a, 1b, 1c, 1d).
· The Hüsler Nest logo on the parts for the side
of the bedstead (1b, 1d) face inwards.
Headboard (optional)
· Position section (1a) with screw holes for
headboard at the head of the bed.
Base
· Insert plastic latches (2a) into the longitudinal
supports.
· Push longitudinal supports (2b) underneath the
head and foot sections (2c), assemble and hold
in place using plastic latches (2e).
· Screw holes (2d) must face outwards.
· For the double couch, the holes (2f) on the two
inner longitudinal supports must face inwards.
Leg sections (optional)
· Assemble leg sections (3a) and (3b).
Upper edge must be flush.
Applies to bench support.
Secure leg sections
· Insert wooden dowels (4a) into the countersunk
holes.
· Place leg sections (4b) underneath the longitudinal
supports (4c) and secure with wooden screws
(use a coin or wood screwdriver).
1
1a
1d
1c
1b
2
3
4
2c
2f
2d
2b 2b
2d
2f
2b 2a 2e
4a
4b 4c
4b
3b
3a

131 40
171
26
64
Couch - interior width: 90cm, 95cm, 100cm
Couch - interior width: 120cm
Couch - interior width: 140cm single/double bed, 160cm, 170cm, 180cm, 200cm
Inner side
28
17.5
2525
16
131 40
171
131 40
171
28
28
26
64
26
64
Inner side
Inner side
17.5
17.5
272272 918 / 1118 / 1218 / 1318 / 1518
317 317628
92 92778 / 828 / 878
16
2525
16 16
2525
16 16
Mst.:
Rev.:Rev.:
Rev.:Rev.:
Freigabe:
Gez.:
Position of holes in headboard
valid from summer 2018
1:8
30.07.09 / tgr 02.08.09 / tgr
09.03.18 / tgr
Adjustable back and leg rests (optional)
· Apply glue to the two folding sections (5a) and
the connecting strips (5b) and join together.
Disassembling the adjustable back and leg rests
(optional)
· To disassemble the adjustable back and leg rests
(6a), the bolt on the hinge can be knocked out.
Securing the headboard (optional)
· Screw the headboard (7a) to the bed (7b) with 4
wooden screws incl. rubber washers (use a coin
or wood screwdriver).
Attaching the headboard: position of the holes in the headboard
Assembly instructions
bedstead Couch
7
6
55a
5b
6a
7a
7b
7
6
55a
5b
6a
7a
7b
