H.Wilson LUXOR WT26GYC2E-B User manual

H. Wilson WT26GYC2E-B Gray
24.5" High Tuffy Utility A/V
Cart with Cabinet
(2-Shelf Black Legs)
Instruction Manual

05/03/13
Tools Required
Parts List
-Rubber Mallet
1
3
2
4
A x1
B x1 D x4
D
B
B
A
A
F
2 Shelf Tuffy Cart Instructions
F x4
Optional uted legs for
units with cabinet pack
Install optional cabinet pack
assembly after step 1
NOTICE:
Leg lengths may
vary by model

02/01/13
Parts List Tools Required
-Rubber Mallet
Tuffy Cart Cabinet
Pack Instructions
Please consult your Tuffy cart
base unit instructions before
starting Key
IMPORTANT: Flip shelf B,
and lock the 2 locking casters
Dbefore assembling the unit.
4
1
5
2
6
3
D
B
BB
BB
F
JJ
H
G
G x1
H x1
J x2 K x2
A / C

01/16/13
Parts List
A x1 B x1 C x2 D x2
-Screwdriver
Tools Required
C
A
B
D
D
C
(Plastic or Metal
Mounting Surface)
Electric Assembly
Instructions
Number of outlets
may vary.
Push screw Cthrough electric outlet A. Make sure
the electric outlet A and cord wrap B align with the
mounting surface screw holes. Push screw Cthrough
cord wrap B and the mounting surface screw holes.
Use wing nut D and screwdriver to fasten.
1
-Phillips Screwdriver
-Pliers or Adjustable Wrench
