H2I ONEOF Accuracy Motion User manual

Accuracy Motion User Manual

1.
1.1
1.2
1.3
1.4
1.5
2.
2.1
2.2
3.
3.1
3.2
3.3
4.
4.1
4.2
5.
5.1
6.
6.1
6.2
6.3
6.4
6.5
7.
7.1
7.2
8.
8.1
8.2
8.3
9.
10.
11.
Introduction . . . . . . . . . . . . . . . 2
Equipment supplied with your ONEOF®
Accuracy Motion . . . . . . . . . . . . . . . . 2
Foreword . . . . . . . . . . . . . . . . . . . . . . 2
Appropriate use . . . . . . . . . . . . . . . . . 2
Limitation of warranty. . . . . . . . . . . . . 3
Typographical conventions . . . . . . . . 4
Safety and environment . . . . . 5
Environmental conditions. . . . . . . . . . 5
Safety and precautions for use . . . . . 5
General description . . . . . . . . . 7
Introduction . . . . . . . . . . . . . . . . . . . . 7
Description. . . . . . . . . . . . . . . . . . . . . 7
Technical specifications . . . . . . . . . . . 9
Handling and storage . . . . . . 10
Handling (safety) . . . . . . . . . . . . . . . 10
Transport . . . . . . . . . . . . . . . . . . . . . 10
Installation . . . . . . . . . . . . . . . 11
Installation and commissioning . . . . . 11
Using the application . . . . . . 13
Accuracy2 interface. . . . . . . . . . . . . . 13
Accuracy Tab. . . . . . . . . . . . . . . . . . . 14
Data tab. . . . . . . . . . . . . . . . . . . . . . . 21
Measurement parameters . . . . . . . . . 23
Application settings . . . . . . . . . . . . . . 30
Maintenance. . . . . . . . . . . . . . 31
Cleaning the device. . . . . . . . . . . . . . 31
Periodic maintenance . . . . . . . . . . . . 31
Troubleshooting . . . . . . . . . . 32
The device is not detected by your
computer . . . . . . . . . . . . . . . . . . . . . . 32
The device is not detected by your
tablet . . . . . . . . . . . . . . . . . . . . . . . . . 32
The device does not work correctly. . 32
Recycling . . . . . . . . . . . . . . . . 33
Annexes . . . . . . . . . . . . . . . . . 34
Glossary . . . . . . . . . . . . . . . . . 35
Table of content
Table of content 1|36

1.
1.1
1.2
1.3
Introduction
Manual version : 0.1 - 02.2022
This chapter contains basic information about the structure of the document. Before handling
the device, the user must read this document.
Equipment supplied with your ONEOF® Accuracy Motion
Accuracy Motion device
Power supply 5V / 0.5A
USB cable
Holding rubber bands (X2)
Quick start Guide
Foreword
This manual is intended for all users of an H2i Sàrl ONEOF® acoustic measuring device. It
contains all the information necessary for its installation, commissioning, periodic maintenance
and troubleshooting.
This manual has been compiled by Petitpierre SA with the same care as your acoustic
measurement device of which it is an inseparable part. If you have any questions or
misunderstandings, please contact your supplier immediately.
It is recommended that a copy of this manual should be given to anyone who may use the
device.
When ordering parts or maintenance, please indicate :
• the type and serial number of your device,
• your exact address,
• the reference and type of the part to be replaced,
If you need to return the device, send an email at [email protected] and send it to:
Petitpierre SA
Route de l'Europe 7
CH-2017 Boudry
[phone]
Any partial or total reproduction or communication of this document to third parties without prior
written authorization is prohibited.
We reserve the right to change the contents of this document without notice.
Appropriate use
The device is intended for the precision acoustic measurement of watch parts. It can only be
used by trained and authorized personnel.
This system is not intended to measure 100% of watches and it may be possible that
some of them are not adapted to this device.
The device can only be used in conjunction with the corresponding software developed and
supplied by H2i Sàrl.
The use of materials other than those described in this operating manual (e.g. unauthorized
substances) is prohibited.
The instructions in this user's manual must be followed, especially the safety
instructions.
Introduction 2|36

1.4 Limitation of warranty
Even though the device and its software have been tested, it is strongly recommended to make
a backup of the database before updating the software.
When the database is remote, the IT department takes care of the backup. If the database is
local, it is possible to copy the data file (oneof.dat) available in the link Application data folder
from the settings.
[See Application settings, page 30]
Petitpierre SA and H2i Sàrl are not responsible for :
• misuse of the device ;
• unauthorized modification (voluntary or not) ;
• failure to follow the instructions and recommendations in the various manuals supplied with the
device and software ;
• non-compliance with the safety instructions in the various manuals ;
• damage related to the use of the device, in particular any loss of data or financial loss that may
be related to the use of the software or the device.
The warranty will be null and void if it is found that the malfunction is due to abuse,
misuse, unauthorized or inadequate maintenance or service, accidental deterioration,
improper storage conditions, or use of the product outside of its stated limits, outside of
its specifications, contrary to the instructions in this manual, or following
recommendations other than those of the manufacturer.
Each Accuracy Motion is tested before delivery.
Introduction 3|36

1.5
(1)
(2)
(3)
Typographical conventions
The styles used in this manual are the following:
Designation Definition Example
Ordered list
Used in conjunction with the
illustration numbers, preceded by
the corresponding numbers.
First element
Second element
Etc...
Software
commands
All software commands, buttons,
function keys, windows and the like
used in the manual is indicated in
bold and italics.
The On button (Switching on) allows
to switch the group on.
Procedure
Each step of the procedure to be
followed by the user is preceded by
a letter.
A. Remove the cover plate.
B. Replace the defective
element.
C. Put the sheet back on.
Cross-
reference Link to further information. [See Typographical conventions, page 4]
Attention
Used to refer to a potentially
hazardous situation that, if not
avoided, may result in minor injury or
property damage.
ATTENTION
The unit should be
transported upright and
should not be subject to
shock.
Note
Used to accompany a general
remark or a purely informative
comment.
The unit has been checked,
adjusted and tested in our
workshops.
Link to glossary Used to link a word to its definition in
the Glossary section. Lift angle.
Introduction 4|36

2.
2.1
2.2
2.2.1
2.2.2
Safety and environment
This chapter defines the safety instructions for the proper operation of the Accuracy Motion
device and the associated software. It also describes the handling and storage conditions.
Environmental conditions
The Accuracy Motion device must be used exclusively indoors.
The electrical safety of the device is guaranteed only if the electrical installation of the
building complies with the regulations for industrial buildings, and if it functioning
properly.
The device should not be exposed to heat, dust or excessive moisture.
The device should not be close to a powerful sound source as this may distort the
results.
Operating values
Designation Value Unit
Max. ambient humidity 79 %
Ambient work place temperature 5-35 °C
Relative temperature range -15 +15 °C
Safety and precautions for use
Importance of safety instructions
The safety and protection instructions in this manual must be followed to avoid injury,
property damage or environmental pollution.
In the same way, the legal provisions, accident prevention and environmental protection
measures, as well as the technical regulations to ensure safe and suitable working conditions
applicable in the country and at the location where the device is used must be observed.
Use of the device in any manner other than that described in this manual may void the
warranty.
General safety instructions and signs
Repair and maintenance work should only be carried out by a qualified service
technician designated by the manufacturer.
Heed all warnings and follow all instructions provided on the device and in the the device
and in the documentation.
The device should only be connected to the indicated power sources.
Never use components other than those supplied by the manufacturer.
The device must be installed on a flat, dry and stable surface.
Never force or stop the motor movements by hand.
The device must be used with the supplied software and accessories approved by the
manufacturer.
Safety and environment 5|36

2.2.2.1
2.2.2.2
2.2.3
2.2.3.1
2.2.3.2
Mechanical hazards
There is a risk of entrapment. Be careful not to leave your hand between the head and the
base of the device during operation.
Electrical hazards
It is forbidden to open the device in any way.
A faulty main power supply (outside the range specified in the device features section) or
a faulty cable can damage the device. If it is necessary to use the 2nd usb port, a
standard usb charger (5v) can be used.
To turn the power off, disconnect the power cable by pulling on the connector, never pull
directly on the cable.
Safety symbols
No specific signage is required for the Accuracy Motion.
If technical developments involve risks, symbols are placed on different parts of the device to
draw attention to a potential danger, to prohibited operations or to the obligation to wear safety
equipment.
Alert symbols
Symbol Description
ATTENTION :
Warning (general), consult documentation.
Obligation Symbols
Symbol Description
Mandatory instructions:
Only persons who have been trained in the handling of the device and who
know these instructions may work on it.
Safety and environment 6|36

3.
3.1
3.2
3.2.1
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
General description
This chapter contains general information about the ONEOF® Accuracy Motion.
Introduction
The ONEOF® Accuracy Motion is an automated acoustic measuring instrument with backlash-
free positioning. It is designed to measure watches or mechanical movements in production,
laboratory or after-sales service.
One connector allow the device to be controlled by the software. The other one is an optionnal
power supply (iPhone/iPad only).
No other access to the components of the device is possible outside the technical services of
Petitpierre SA and H2i Sàrl.
Description
Overall view
FIG. 3-1 - Accuracy Motion (Overall view)
Sensor
Cart
Measuring head
Alpha axis
Base
USB Input 1
USB Input 2 (iPhone/iPad only)
Beta axis
The motor control, based on an inertial measurement unit, allows to reach any position of the
half-sphere with the required degree of accuracy. The device is supplied with a software
allowing the control of several devices in real time. The software is also equipped with a
sequence editor to automate the testing process. All data collected by the device can then be
stored locally or in a database.
General description 7|36

3.2.2
3.2.3
(1)
(2)
(3)
(4)
(5)
(6)
Rotation axes
FIG. 3-2 - Accuracy Motion (Rotation axes)
The Accuracy Motion rotation axes are:
• Alpha (1) corresponds to movement from top (0°) to bottom (90°).
The position in the illustration corresponds to 0°.
• Beta (2) corresponds to the rotation movement (360°), the positive direction is
counterclockwise.
The position in the illustration corresponds to 0°.
Measuring positions
The Accuracy Motion has 6 standard pre-registered positions which are the most commonly
used positions, but the sequences also allow measurement at all intermediate positions.
FIG. 3-3 - Accuracy Motion (Measuring positions)
DU (Dial up)
DD (Dial down)
CD (Crown down)
CR (Crown right)
CU (Crown up)
CL (Crown left)
General description 8|36

3.3
3.3.1
3.3.2
Technical specifications
Approximate dimensions and weight
Designation Value Unit
Length x Width 25 x 12 cm
Height 25 cm
Weight 1 kg
Power supply
Designation Value Unit
Type of cable USB type-C
Voltage 5 V
Current 0.5 A
General description 9|36

4.
4.1
4.2
Handling and storage
Handling (safety)
When handling the device, make sure that:
- it does not suffer from shock ;
- there are no objects on or in the unit.
Transport
During transport, the device must be placed in its original packaging and not be
subjected to shock.
Handling and storage 10|36

5.
5.1
5.1.1
5.1.2
A. Unhook a rubber band (1) from the bottom of the
Accuracy Motion.
The rubber band will be used to secure the watch
or movement to be measured on the Accuracy
Motion.
FIG. 5-1 - Holding rubber bands
location
The device can be used with a single power cable
(2) on a computer but requires a second power
cable (3) to be connected to a standard USB 5 V
charger (phone charger type) when used on an
iPhone or iPad with Lightning connector.
A 5 cm space around the base of the Accuracy
Motion must be left free to avoid any impact. FIG. 5-2 - Electrical connections
Installation
Installation and commissioning
The device has been checked, adjusted and tested in our workshops.
Application installation
A. Download and install the ONEOF® Accuracy2 App for Windows at https://h2i.ch/apps
System requirements :
• Windows 10 version 1803 or higher
• 64 bits
• Intel i5 processor or higher
• 4GB RAM or higher
The Accuracy Motion is also compatible with iOS and macOS.
Commissioning
B. Place the device on a flat surface before connecting it.
C. Connect the power cable (2).
D. The device goes to the initialization position
E. Wait 3 seconds during the calibration of the inertial measurement unit.
It is important not to touch the Accuracy Motion during this 3 seconds period.
The Accuracy Motion is closed-loop controlled and the measuring head cannot be
moved. It is not recommended to move the device once connected.
Installation 11|36

F. Open the cart and place the watch or piece to
measure.
G. Insert the holding rubber band into the lugs
provided (4) and (5).
The holding rubber band is used to secure the
watch or movement to be measured on the
Accuracy Motion.
It is very important to secure the object to be
measured with the holding rubber band provided
for this purpose. Petitpierre SA and H2i Sàrl cannot
be held responsible for any damage caused by a
falling piece or a watch during a measurement.
FIG. 5-3 - Position the rubber band
2 rubber bands are provided with the Accuracy Motion.
In case of loss or wear, contact Petitpierre SA to get new ones.
H. Start the application.
It is very important not to touch the device during a measurement or during a change of
position.
Installation 12|36

6.
6.1
(1)
(2)
(3)
(4)
(5)
6.1.1
Using the application
Accuracy2 interface
To use the Accuracy Motion correctly, it is important to understand the different areas that
make up the application window.
FIG. 6-1 - Accuracy Motion (User interface areas)
Application settings control area
Results or listing area
Editing area
Control area
Contextual menu area
The editing area windows (3) can be shown or hidden
Description of the contextual menu tabs (5)
Accuracy
The Accuracy tab is dedicated to device overview and control. The Accuracy2 application
allows simultaneous control of multiple devices from the ONEOF® range. All connected devices
are displayed directly on the screen in the accuracy window. From there you can start
measurements, sequences and access all current data of your measurement.
[See Accuracy Tab, page 14]
Parameters
The Parameters contain the data about the watch you want to measure (frequency, lift angle,...)
but also how you want to measure it (how much integration time, stabilization,...). A
measurement cannot be made without parameters. There is always at least one set of built in
parameters called "default" that is used in situations where no parameters have been chosen.
[See Measurement parameters tab, page 23]
Criteria
The Criteria are used to control the way measures are displayed.
[See Criteria tab, page 29]
Using the application 13|36

6.2
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Data
Contains all saved results and measurements. Here you can create new watches
(measurement folders), delete them, view old results and export your measurement data.
[See Data tab, page 21]
Sequences
Create and manage sequences involving movement operations and measurements.
[See Sequence tab, page 26]
Accuracy Tab
FIG. 6-2 - Accuracy Motion (Accuracy Tab)
Device status
Device overview window
Summary table
Views
Device parameters
Device parameters button
Control bar
Device name
To make the Device parameters (5) appear, the Device overview window (2) must be
selected before clicking the Parameters (6) button in the Control bar (7).
Using the application 14|36

6.2.1
(1)
(2)
(3)
(4)
(5)
(6)
6.2.1.1
6.2.1.2
6.2.1.3
Control bar
The control bar allows you to select the standard measurement positions, to start or stop a
measurements sequence, to start or stop a single measurement according to the chosen
position, to save and to visualize the parameters related to the Accuracy Motion.
FIG. 6-3 - Accuracy Motion (Control bar)
Measurement positions
Measurement sequence control
Simple measures control
Measurement saving
Exporting results
Device parameters
Measurement positions
The standard available measurement positions are DU, DD, CD, CR, CU, CL.
[See Measuring positions, page 8]
Performing a measurement
Simple measures
The control bar (see FIG. 6-3) allows you to make a simple measurement by selecting a
position.
The Simple measures control (3) button enables you to stop or restart the measurement.
Selecting a new position allows the measurement to be continued at the newly selected
position.
Sequence measurement
The Measurement sequence control button (2) is used to start or stop a sequence of
measurements.
A measurement cannot be performed without parameters. When a device is connected, a
set of default parameter, defined in the parameters tab, will be used. If no default
parameters are set in the parameters tab, the application will use the "built-in"
parameters instead. . You can view these parameters by clicking on the Device
parameters button (6) located in the Control bar (voir FIG. 6-3).
To view the Device parameters, remember to select the Device overview window.
Saving a measurement
The Measurement saving button (4) of the Control bar (see FIG. 6-3) enables you to save the
measurement that has just been made.
Using the application 15|36

6.2.2
(1)
(2)
(3)
(4)
Device Overview Window
This window allows you to select one or more devices, to display and edit the name (saved in
database), and allows you to view the measurements table.
FIG. 6-4 - Accuracy Motion (Device overview)
Device name + serial number
Summary table
Status bar
Detail views
• In the Status bar (3), the message indicates whether the program is searching for the
frequency, integrating, measuring or whether it is in standby.
• The Detail views (4) button gives access to the Scope, Graph, Diagram and Data view.
[See Detail views, page 17]
In order to access the different views, the device must be performing a measure.
Using the application 16|36

6.2.2.1
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Detail views
A. Clic on the Detail views button (4) of the Device overview window (see FIG. 6-4). In the
detail view, you can analyze the current measurements of your watch. You can select
different views to get a better overview of the data.
The Scope view opens by default
Scope view
FIG. 6-5 - Accuracy Motion (Scope view)
Selected view
Next view button
Data view button
Diagram view button
Graphic view button
Scope view button
Results area
Device status
The Results area (7) displays the result of the measurement in real time. It includes the
beat error, the accuracy and the amplitude of the measured watch. Each of these values
is updated every second.
The Scope view is the graphic display of the ticking signal of the watch movement. Through the
bezel, expert watchmakers can detect problems with the escapement phase. It is also a very
useful tool to determine if the upcoming signal is good enough for a correct measurement of the
watch.
The Swiss lever escapement is composed of 3 distinct impulses. The first pulse is
temporally very accurate and is therefore used for the calculation of the rate accuracy
and the beat error. The second pulse is very irregular and cannot be used. The third
pulse, the most powerful, is used to estimate the amplitude of the balance wheel.
Using the application 17|36

(1)
(2)
(3)
(4)
Graphic view
FIG. 6-6 - Accuracy Motion (Graphic view)
Graphic view
Previous view button
Next view button
Graphic view button
Every second, a new value of precision rate, amplitude and beat error is added to the graph. It
is always interesting to check how these two values vary over time. Some particular and natural
fluctuations may appear, such as the impact of gear train defects, the drop of the amplitude at
the time of change, or more generally the variation of the rate over the whole power reserve of
the watch. Each position is represented by a color.
Using the application 18|36

(1)
(2)
(3)
(4)
Diagram view
FIG. 6-7 - Accuracy Motion (Diagram view)
Diagram view
Previous view button
Next view button
Diagram view button
As soon as the frequency is detected, the diagram starts to display the results. Each point
represents a tick or a tock in time, which is shown as two lines.
• If the watch tends to run faster, the slopes are positive.
• If the watch tends to slow down, the slopes are negative.
• If the watch is perfectly accurate, the graph displays flat lines.
If the watch has no beat error, the two lines are superimposed. If the beat error is greater than
0.0 ms, the lines are spaced. The greater the beat error, the greater the space between the
lines.
Using the application 19|36
