H3C S3100V3-EI Series User manual

H3C S3100V3-EI Switch Series
Installation Guide
New H3C Technologies Co., Ltd.
http://www.h3c.com
Document version: 6W106-20210427

Copyright © 2021, New H3C Technologies Co., Ltd. and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior written
consent of New H3C Technologies Co., Ltd.
Trademarks
Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this
document are the property of their respective owners.
Notice
The information in this document is subject to change without notice. All contents in this document, including
statements, information, and recommendations, are believed to be accurate, but they are presented without
warranty of any kind, express or implied. H3C shall not be liable for technical or editorial errors or omissions
contained herein.
Environmental protection
This product has been designed to comply with the environmental protection requirements. The storage, use,
and disposal of this product must meet the applicable national laws and regulations.

Preface
H3C S3100V3-EI Switch Series Installation Guide describes the appearance, installation, power-on,
maintenance, and troubleshooting of the H3C S3100V3-EI Switch Series.
This preface includes the following topics about the documentation:
•
Audience.
•
Conventions.
•
Documentation feedback.
Audience
This documentation is intended for:
•
Network planners.
•
Field technical support and servicing engineers.
•
Network administrators working with the S3100V3-EI switch series.
Conventions
The following information describes the conventions used in the documentation.
Command conventions
Convention
Description
Boldface Bold text represents commands and keywords that you enter literally as shown.
Italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from which
you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical bars,
from which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by vertical
bars, from which you select a minimum of one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntaxchoices separated byvertical
bars, from which you select one choice, multiple choices, or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&) sign
can be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
GUI conventions
Convention
Description
Boldface Window names, button names, field names, and menu items are in Boldface. For
example, the New User window opens; click OK.
> Multi-level menus are separated by angle brackets. For example, File > Create >
Folder.

Symbols
Convention
Description
WARNING! An alert that calls attention to important information that if not understood or followed
can result in personal injury.
CAUTION:
An alert that calls attention to important information that if not understood or followed
can result in data loss, data corruption, or damage to hardware or software.
IMPORTANT:
An alert that calls attention to essential information.
NOTE:
An alert that contains additional or supplementary information.
TIP:
An alert that provides helpful information.
Network topology icons
Convention
Description
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that
supports Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the access
controller engine on a unified wired-WLAN switch.
Represents an access point.
Represents a wireless terminator unit.
Represents a wireless terminator.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Represents a security product, such as a firewall, UTM, multiservice security
gateway, or load balancing device.
Represents a security module, such as a firewall, load balancing, NetStream, SSL
VPN, IPS, or ACG module.
Examples provided in this document
Examples in this document might use devices that differ from your device in hardware model,
configuration, or software version. It is normal that the port numbers, sample output, screenshots,
and other information in the examples differ from what you have on your device.
T
T
T
T

Documentation feedback
You can e-mail your comments about product documentation to inf[email protected].
We appreciate your comments.

i
Contents
1 Preparing for installation··········································································1-1
Safety recommendations ································································································································1-1
Examining the installation site·························································································································1-2
Temperature/humidity·····························································································································1-2
Cleanliness··············································································································································1-2
Corrosive gas limit···································································································································1-3
EMI··························································································································································1-4
Laser safety·············································································································································1-4
Installation tools ··············································································································································1-4
2 Installing the switch··················································································2-5
Installing the switch in a 19-inch rack··············································································································2-5
Mounting brackets···································································································································2-5
Attaching the mounting brackets to the switch························································································2-6
Rack-mounting the switch·······················································································································2-7
Mounting the switch on a workbench··············································································································2-9
Mounting the switch on a wall·························································································································2-9
Grounding the switch ····································································································································2-11
Grounding the switch with a grounding strip·························································································2-11
Grounding the switch with a grounding conductor buried in the earth ground······································2-12
Connecting the power cord···························································································································2-13
Connecting the switch to an AC power source ·····················································································2-14
Connecting the switch to an RPS··········································································································2-14
Connecting the switch to an external DC power supply system ···························································2-15
Verifying the installation································································································································2-16
3 Accessing the switch for the first time····················································3-17
Connecting the switch to a configuration terminal·························································································3-17
Connecting a DB9-to-RJ45 console cable····························································································3-17
Connecting a USB-to-RJ45 console cable····························································································3-18
Setting terminal parameters··························································································································3-20
Powering on the switch·································································································································3-20
4 Setting up an IRF fabric·········································································4-22
IRF fabric setup flowchart ·····························································································································4-22
Planning IRF fabric setup······························································································································4-23
Planning IRF fabric size and the installation site···················································································4-23
Identifying the master switch and planning IRF member IDs································································4-23
Planning IRF topology and connections································································································4-23
Identifying IRF physical ports on the member switches········································································4-24
Planning the cabling scheme················································································································4-25
Configuring basic IRF settings······················································································································4-27
Connecting the IRF physical ports················································································································4-27
Verifying the IRF fabric setup························································································································4-27
5 Maintenance and troubleshooting··························································5-28
Power module failure ····································································································································5-28
AC input failure······································································································································5-28
DC input failure ·····································································································································5-28
Concurrent DC and AC inputs failure····································································································5-29
Fan tray failure··············································································································································5-29
Symptom···············································································································································5-29
Solution·················································································································································5-30
Configuration terminal issues························································································································5-30
No display on the configuration terminal·······························································································5-30
Garbled display on the configuration terminal·······················································································5-30

ii

1-1
1 Preparing for installation
This document is applicable to the S3100V3-EI switch series. Table1-1 describes the S3100V3-EI
switch series models.
Table1-1 S3100V3-EI switch series models
Switch model Product code (PID)
S3100V3-10TP-EI LS-3100V3-10TP-EI
LS-3100V3-10TP-EI-GL
S3100V3-18TP-EI LS-3100V3-18TP-EI
LS-3100V3-18TP-EI-GL
S3100V3-18TP-EI-DC LS-S3100V3-18TP-EI-DC
S3100V3-28TP-EI LS-3100V3-28TP-EI
LS-3100V3-28TP-EI-GL
LS-3100V3-28TP-EI-H1
S3100V3-28TP-EI-DC LS-S3100V3-28TP-EI-DC
S3100V3-52TP-EI LS-3100V3-52TP-EI
LS-3100V3-52TP-EI-GL
S3100V3-10TP-PWR-EI LS-3100V3-10TP-PWR-EI
LS-3100V3-10TP-PWR-EI-GL
S3100V3-20TP-PWR-EI LS-3100V3-20TP-PWR-EI
LS-3100V3-20TP-PWR-EI-GL
S3100V3-20TP-PWR-EI-DC LS-S3100V3-20TP-PWR-EI-DC
S3100V3-28TP-PWR-EI LS-3100V3-28TP-PWR-EI
LS-3100V3-28TP-PWR-EI-GL
NOTE:
Switches of the same model but different PIDs might differ in
hardware and software features.
You
can view the PID of a switch on the label located on its rear panel or top panel.
Safety recommendations
To avoid equipment damage or bodily injury, read the following safety recommendations before
installation. Note that the recommendations do not cover every possible hazardous condition.
•
Before cleaning the switch, remove all power cords from the switch. Do not clean the switch
with wet cloth or liquid.
•
Do not place the switch near water or in a damp environment. Prevent water or moisture from
entering the switch chassis.
•
Do not place the switch on an unstable case or desk.
•
Ensure good ventilation at the installation site and keep the air inlet and outlet vents of the
switch free of obstruction.
•
Connect the yellow-green protection grounding cable before power-on.

1-2
•
Make sure the power source voltage is as required.
•
To avoid electrical shocks, do not open the chassis while the switch is operating or when the
switch is just powered off.
•
To avoid ESD damage, always wear an ESD wrist strap during installation.
Examining the installation site
The S3100V3-EI switches must be used indoors. You can mount your switch in a rack or on a
workbench, but make sure:
•
Adequate clearance is reserved at the air inlet and exhaust vents for ventilation.
•
The rack or workbench has a good ventilation system.
•
The rack is sturdy enough to support the switch and its accessories.
•
The rack or workbench is reliably grounded.
To ensure correct operation and long service life of your switch, install it in an environment that meets
the requirements described in the following subsections.
Temperature/humidity
Maintain temperature and humidity in the equipment room at acceptable ranges.
•
Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•
Lasting low relative humidity can cause washer contraction and ESD and cause issues
including loose mounting screws and circuit failure.
•
High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the switch.
For the temperature and humidity requirements of different switch models, see technical
specifications in Hardware Information and Specifications.
Cleanliness
Dust buildup on the chassis might cause electrostatic adsorption and dust corrosion, resulting in
poor contact of metal connectors and contact points. This might shorten the device's lifetime and
even cause device failure in the worst case. Table1-2 describes the dust concentration limits in the
equipment room.
Table1-2 Dust concentration limits in the equipment room
Substance Particle diameter Concentration limit
Dust particles ≥ 0.5 µm ≤ 3.5 × 106particles/m3
Dust particles ≥ 5 µm ≤ 3 × 104particles/m3
Dust (suspension) ≤75 µm ≤0.4 mg/m3
Dust (sedimentation) 75 µm to 150 µm ≤15 mg/(m2h)
Sand ≥ 150 µm ≤300 mg/m3
To maintain cleanliness in the equipment room, follow these guidelines:
•
Keep the equipment room away from pollution sources. Do not smoke, eat, or drink in the
equipment room.

1-3
•
Use double-layer glass in windows and seal doors and windows with dust-proof rubber strips.
Use screen doors and window screens for doors and windows open to the outside and make
sure the external windows are air tight.
•
Use dustproof materials for floors, walls, and ceilings and use wallpaper or matt paint that does
not produce powders.
•
Clean the equipment room regularly and clean the air filters of the rack each month.
•
Wear ESD clothing and shoe covers before entering the equipment room, keep the ESD
clothing and shoe covers clean, and change them frequently.
Corrosive gas limit
Corrosive gases can accelerate corrosion and aging of metal components. Make sure the corrosive
gases in the equipment room do not exceed the concentration limits as shown in Table1-3.
Table1-3 Corrosive gas concentration limits in the equipment room
Gas Average concentration (mg/m3) Maximum concentration (mg/m3)
SO20.3 1.0
H2S 0.1 0.5
Cl20.1 0.3
HCI 0.1 0.5
HF 0.01 0.03
NH31.0 3.0
O30.05 0.1
NOX0.5 1.0
CAUTION:
As a best practice, control the
corrosive gas concentrations in the equipment room at their
average
values
. Make sure the corrosive gas concentrations do not exceed 30 minutes per day at their
maximum values.
To control corrosive gases, use the following guidelines:
•
As a best practice, do not build the equipment room in a place with a high concentration of
corrosive gases.
•
Make sure the equipment room is not connected to sewer, vertical shaft, or septic tank pipelines
and keep it far away from these pipelines. The air inlet of the equipment room must be away
from such pollution sources.
•
Use environmentally friendly materials to decorate the equipment room. Avoid using organic
materials that contains harmful gases, such as sulfur or chlorine-containing insulation cottons,
rubber mats, sound-proof cottons, and avoid using plasterboards with high sulfur concentration.
•
Place fuel (diesel or gasoline) engines separately. Do not place them in the same equipment
room with the device. Make sure the exhausted air of the engines will not flow into the
equipment room or towards the air inlet of the air conditioners.
•
Place batteries separately. Do not place them in the same room with the device.
•
Employ a professional company to monitor and control corrosive gases in the equipment room
regularly.

1-4
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the switch and application
system, adversely affect the switch in the following ways:
•
A conduction pattern of capacitance coupling.
•
Inductance coupling.
•
Electromagnetic wave radiation.
•
Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:
•
If AC power is used, use a single-phase three-wire power receptacle with protective earth (PE)
to filter interference from the power grid.
•
Keep the switch far away from radio transmitting stations, radar stations, and high-frequency
devices to make sure the EMI levels do not exceed the compliant range.
•
Use electromagnetic shielding when necessary. For example, use shielded interface cables.
•
To prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning
strikes, only route interface cables indoors.
Laser safety
WARNING!
Disconnected optical fibers or
transceiver modules might emit invisible laser light. Do not stare into
beams or view directly with optical instruments when the switch is operating.
The S3100V3-EI switches are Class 1 laser devices.
Installation tools
No installation tools are provided with the switch. Prepare the installation tools yourself as required.
•
Flat-blade screwdriver
•
Phillips screwdriver
•
ESD wrist strap

2-5
2 Installing the switch
CAUTION:
Keep the tamper
-
proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence.
Figure2-1 Hardware installation flow
Installing the switch in a 19-inch rack
Mounting brackets
Table2-2 describes mounting brackets applicable to the switch.
Start
Install the switch
Ground the swtich
Connect the power cords
Verify the installation
Turn on the circuit
breakers
Operating correctly? Turn off the circuit
breakers
Troubleshoot the
switch
No
Yes
End
Install interface connectors
and cables

2-6
Table2-2 Mounting brackets applicable to the switch
Switch model Mounting brackets Views
S3100V3-28TP-EI
S3100V3-28TP-EI-DC
S3100V3-52TP-EI
S3100V3-28TP-PWR-EI
Mounting brackets A (provided) See A in Figure2-2.
S3100V3-10TP-PWR-EI
S3100V3-20TP-PWR-EI
S3100V3-20TP-PWR-EI-DC
Mounting brackets B with
product code
SOHO-SWITCH-FL-02
(optional)
See B in Figure2-2.
S3100V3-10TP-EI
S3100V3-18TP-EI
S3100V3-18TP-EI-DC
Mounting brackets C with
product code
SOHO-SWITCH-FL-01
(optional)
See C in Figure2-2.
Figure2-2 Mounting brackets
(1) Screw hole for attaching the bracket to the switch
(2 ) Screw hole for attaching the bracket to the rack post
Attaching the mounting brackets to the switch
1. Align one mounting bracket with the screw holes at the mounting position. Use M4 screws to
attach the mounting bracket to the chassis. See Figure2-3 for installing mounting bracket A,
Figure2-4 for installing mounting bracket B, and Figure2-5 for installing mounting bracket C.
M4 screws are provided only for switches shipped with mounting brackets. For switches not
shipped with mounting brackets, you can order an optional mounting bracket kit, which contains
M4 screws.
2. Repeat step 1to attach the other mounting bracket to the chassis.
1
2
1
2
(A) (B)
1
2
(C)

2-7
Figure2-3 Attaching mounting bracket A (S3100V3-28TP-PWR-EI switch)
Figure2-4 Attaching mounting bracket B (S3100V3-10TP-PWR-EI switch)
Figure2-5 Attaching mounting bracket C (S3100V3-10TP-EI switch)
Rack-mounting the switch
This task requires two people. To mount the switch in the rack:
1. Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.
2. Verify that the mounting brackets have been securely attached to the switch chassis.
3. Install cage nuts in the mounting holes in the rack posts.

2-8
4. One person holds the switch chassis and aligns the mounting brackets with the mounting holes
in the rack posts, and the other person attaches the mounting brackets to the rack with M6
screws.
M6 screws are provided only for switches shipped with mounting brackets. For switches not
shipped with mounting brackets, prepare M6 screws yourself.
5. Verify that the switch chassis is horizontal and secure.
Figure2-6 Mounting an S3100V3-28TP-PWR-EI switch in the rack
Figure2-7 Mounting an S3100V3-10TP-PWR-EI switch in the rack

2-9
Figure2-8 Mounting an S3100V3-10TP-EI switch in the rack
Mounting the switch on a workbench
IMPORTANT:
•
Ensure 10 cm (3.9 in) of clearance around the chassis for heat dissipation.
•Do not place heavy objects on the switch.
If a standard 19-inch rack is not available, you can place you switch on a workbench.
To mount the switch on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.
2. Place the switch with bottom up, and clean the round holes in the chassis bottom with dry cloth.
3. Attach the rubber feet to the four round holes in the chassis bottom.
4. Place the switch with upside up on the workbench.
Mounting the switch on a wall
CAUTION:
•
Before drilling holes in a wall, make sure no electrical lines exist in the wall.
•Leave a minimum clearance of 10 mm (0.39 in) around the chassis for heat dissipation.
Table2-2 describes the switch models that support wall mounting and installation holes distances
required for wall-mounting the switch. Screw anchors and screws as shown in Figure2-9 are
provided with these switches for wall-mounting.
Table2-3 Installation hole distances for switch models that support wall mounting
Switch model Hole distance
S3100V3-10TP-EI 170 mm (6.69 in)
S3100V3-18TP-EI
S3100V3-18TP-EI-DC 172 mm (6.77 in)
S3100V3-10TP-PWR-EI 102 mm (4.02 in)

2-10
Switch model Hole distance
S3100V3-20TP-PWR-EI
S3100V3-20TP-PWR-EI-DC 116 mm (4.57 in)
Figure2-9 Screw anchor and screw
To mount the switch on a wall:
1. Mark two installation holes on the wall. Make sure the two holes are on the same horizontal line.
See Table2-2 for the distance requirement between the two holes.
Figure2-10 Installing the switch on a wall (1)
2. Drill two holes with a diameter of 6 mm (0.24 in) and a depth of 25 mm (0.98 in) at the marked
locations. Hammer the screw anchors into the wall and use a Phillips screwdriver to fasten the
screw into the screw anchor. Leave 1.5 mm (0.06 in) between the screw head and the wall for
hanging the switch.
Figure2-11 Installing the switch on a wall (2)
3. Align the installation holes in the switch rear with the screws on the wall and hang the switch on
the screws. Make sure the port side faces down and the left and right sides are perpendicular to
the ground.

2-11
Figure2-12 Installing the switch on a wall (3)
Grounding the switch
WARNING
!
Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection.
The power input end of the switch has a noise filter, whose central ground is directly connected to the
chassis to form the chassis ground (commonly known as PGND). You must securely connect this
chassis ground to the earth to minimize the potential for system damage, maximize the safety at the
site, and minimize EMI susceptibility of the system.
You can ground the switch in one of the following ways, depending on the grounding conditions
available at the installation site:
•
Grounding the switch with a grounding strip
•
Grounding the switch with a grounding conductor buried in the earth ground
NOTE:
The
chassis views and power module and grounding terminal positions in the following figures are
for illustration only.
Grounding the switch with a grounding strip
WARNING
!
Connect the grounding cable to the grounding system in the equipment room. Do not connect it to a
fire main or lightning rod.
If a grounding strip is available at the installation site, use the grounding strip to ground the switch.
To ground the switch by using a grounding strip:
1. Attach the ring terminal end of the grounding cable to the grounding hole in the switch.
a. Remove the grounding screw from the grounding hole in the rear panel of the switch.
b. Attach the grounding screw to the ring terminal of the grounding cable.
c. Use a screwdriver to fasten the grounding screw into the grounding screw hole.

2-12
Figure2-13 Attaching the grounding cable to the grounding hole of the switch
(S3100V3-28TP-PWR-EI switch)
(1) Grounding screw
(2) Ring terminal
(3) Grounding sign
(4) Grounding hole
(5) Grounding cable
2. Connect the other end of the grounding cable to the grounding strip.
a. Cut the grounding cable to a length according to the distance between the switch and the
grounding strip.
b. Peel 20 mm (0.79 in) of insulation sheath by using a wire stripper.
c. Use the needle-nose pliers to bend the bare wire.
d. Hook the grounding cable to the post on the grounding strip, and use the hex nut to secure
the cable to the post.
Figure2-14 Connecting the grounding cable to a grounding strip
(1) Grounding post
(2) Grounding strip
(3) Grounding cable
(4) Hex nut
Grounding the switch with a grounding conductor buried in
the earth ground
If the installation site has no grounding strips, but earth ground is available, hammer a 0.5 m (1.64 ft)
or longer angle iron or steel tube into the earth ground to serve as a grounding conductor.
The dimensions of the angle iron must be at least 50 × 50 × 5 mm (1.97 × 1.97 × 0.20 in). The steel
tube must be zinc-coated and its wall thickness must be at least 3.5 mm (0.14 in).
5
1
2
3
4
1 2
34

2-13
Weld the yellow-green grounding cable to the angel iron or steel tube and treat the joint for corrosion
protection.
Figure2-15 Grounding the switch by burying the grounding conductor into the earth ground
(1) Grounding screw
(2) Grounding cable
(3) Earth
(4) Joint
(5) Grounding conductor
(6) Chassis rear panel
Connecting the power cord
CAUTION:
•
Provide a circuit breaker for each power cord.
•Before connecting the power cord, make sure the circuit breaker on the power cord is turned off.
Table2-4 Power cord connection procedures at a glance
Switch model Available power
source Connection procedure reference
S3100V3-10TP-EI
S3100V3-18TP-EI
S3100V3-28TP-EI
S3100V3-52TP-EI
S3100V3-10TP-PWR-EI
S3100V3-20TP-PWR-EI
AC power source Connecting the switch to an AC power
source
S3100V3-28TP-PWR-EI AC power source Connecting the switch to an AC power
source
H3C RPS1600-A Connecting the switch to an RPS
S3100V3-18TP-EI-DC
S3100V3-28TP-EI-DC
–48 VDC power source in
the equipment room or H3C
RPS1600-A Connecting the switch to an external DC
power supply system
S3100V3-20TP-PWR-EI-DC
DC power supply system
that provides voltage within
the input voltage range of
the switch or H3C
RPS1600-A
1
2
5
4
3
6
