HAC HAC-LBee/S User manual

HAC-LBee/S
2.4G LowPowerData RadioModule
(Basedon802.15.4protocol)
V3.X
SHENZHENHACTELECOMTECHNOLOGYCO., LTD
Address :Fl.6, Building 2, Jiuxiangling NewIndustryPark, No.4227, Xilihu
Road, Nanshan, Shenzhen, China.
Tel :[phone] 23981076
Fax :[phone]
E-mail : [e-mail]
Website : http://www.rf-module-china.com

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 2
-
Catalogue
I. Features ofHAC-LBee/SWireless Module...............................................................................3
II. Applications ofHAC-LBee/SWireless Module.......................................................................4
III. Using Methods ofHAC-LBee/SWireless Module....................................................................4
IV.DevelopmentKitforHAC-LBee/SWireless Module...............................................................6
V.Working ModeofHAC-LBee/SWireless Module...................................................................11
VI. AssistantSoftware.....................................................................................................................30
VII. Appendix..................................................................................................................................32

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 3
-
IFeaturesofHAC-LBee/SWirelessModule
HAC-LBee/Sisakindoflowpower wirelessmodulebasedon802.15.4 protocolstack. The
features areshown as follow:
1. Lowpower transmission with100mW 20dBm）,and receivingsensitivityis-105dBm
BER=10-2）.
2. ISM frequencyband with no require ofapplyingfrequency.Thecarrier frequencyis 2.4GHz.
3. High anti-interferenceand LowBER(Bit errorRate)
Basedon theQuadraturePhaseShiftKeying(QPSK) modulation, thehigh-efficiencyforward
errorcorrection channelencodingtechnologyisusedtoenhance data sresistancetoboth
transientinterferenceandrandominterference.Narrowband interferenceofthesamefrequency
canbesuppressedbyDirectSequence SpreadSpectrum.The16 CRC verifybitscanbeusedto
check mistake.
4. Thetransmittingspeed in theaircan reach upto 250kbps.
5. Transmission Distance
Within thevisiblerange,thereliabletransmission distance is 1000m.
6. Multi-channels
HAC-LBee/Soffers16 channels. Itwill selectthesuitableand reliablecommunication channel
automaticallyaccordingto theuser senvironment.
7. UARTinterface
HAC-LBee/SprovidesaUARTinterface ofTTLlevel.Theparityisno-parity(8N1),and thebaud
ratecan besetbyusers.
8. Lowpower consumption
Thereceivingcurrentisless thanorequalto50mA,and thetransmittingcurrentisless thanor
equalto 160mA.
9. Small sizeand lightweight
10. Byusingmonolithicradio-frequencyintegratedcircuit and single-chipMCU,thetransceivers
haveless peripheralcircuits, higher reliability,andlower failurerate.
11. Offeringmanykinds ofantennaconnectingmethods, suchasPCB antenna,Chipantenna,IPX
antennaconnectingbaseand so on.
12. Itcan meetfortheprotocolofIEEE 802.15.4 for2.4GHz.

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 4
-
II.ApplicationsofHAC-LBee/SWireless Module
HAC-LBee/Slowpower wireless moduleis suitablefor:
﹡Homeappliances intelligentcontrol.
﹡Auto Meter Readingsystem.
﹡Industrytelemetryandautomaticdatacollection system.
﹡Securityand alarm.
﹡Wireless monitorforhoteland equipmentofcomputer room,door ssecurity,personnel
orientation.
﹡Trafficand thecontrolforstreetlamp.
﹡Logistics, activeRFID, POSsystemand wireless handheld terminal.
III. UsingMethods ofHAC-LBee/S Wireless Module
3.1 TechnicalParameterofHAC-LBee/S
ParameterName
Minimum TypicalValue Maximum
Unit
Electric Performance （-25℃）
Power Supply 3.0 3.3 3.6 V
Interface Level -0.3 VCC+ 0.3≤3.6 V
TransmittingCurrent 140 150 160 mA
ReceivingCurrent 29 30 31 mA
SleepingCurrent 3 A
Wireless Performance（-25℃）
Working Frequency 2.405 2.485 GHz
TransmittingPower 19.0 19.5 20.2 dBm
ReceivingSensitivity -105 dBm
TransmittingRate 250 Kbps
GeneralPerformance
Interface baud rate 1200 115200 bps
WorkingTemperature -40 80
Size 35.1 X24.4 X 4 mm
Antenna PCBantenna, chipantenna, IPXantenna
base
Table1 TechnicalParameterofHAC-LBee/S

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 5
-
3.2 TheSize ofHAC-LBee/S(35.1x24.4x4mm)
Picture1 TheSize ofHAC-LBee/S
3.3 PinDefinitionofHAC-LBee/S
Pin Definition Input/Outp
ut
Function Instruction
1 VCC IN Power Supply,+3.0~3.6V
2 TXD OUT Outputserialdata
3 RXD IN Inputserialdata
4 DIO1 IN/OUT DataI/O1
5 RESET IN Lowlevelreset
6 DIO2 IN/OUT DataI/O2
7 DIO3 IN/OUT DataI/O3
8 DIO4/DD IN/OUT DataI/O4 /Programdata
9 DIO5/DC/SLEEP IN/OUT DataI/O5 /Programclock/Sleep enable

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 6
-
10 GND Power supply(Negative),Ground
11 DIO6 IN/OUT DataI/O6
12 DIO7 IN/OUT DataI/O7
13 DIO8 IN/OUT DataI/O8
14 DIO9 IN/OUT DataI/O9
15 DIO10 IN/OUT DataI/O10
16 DIO11 IN/OUT DataI/O11
17 DIO12/ADC3 IN/OUT DataI/O12/AnalogInput3
18 DIO13/ADC2 IN/OUT DataI/O13/AnalogInput2
19 DIO14/ADC1 IN/OUT DataI/O14/AnalogInput1
20 DIO15/ADC0 IN/OUT DataI/O15/AnalogInput0
Table2 PinDefinitionofHAC-LBee/S
IV. Development KitforHAC-LBee/SWireless Module
4.1 GeneralInformationforHAC-DEVDevelopmentKit
Picture2 HAC-DEV

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 7
-
ConnectorDefinition:
a. J1 (DC_PLUG ）5Vpower supplyinput
b. J2 (DC_CONNECTOR)5Vpower supplyinput
Pin Name Definition
Pin1 GND
Pin2 5V
c. J3(USB_PLUG) USB port,USB toSerialport.Pleaserefer totheAppendix2forthe
installation forUSBDriver.
d. J4 (DB9/F)RS232 dataport
Pin Name Definition
Pin2 TXD
Pin3 RXD
Pin5 GND
Otherpins NoDefinition
e. J5 (Programming)CC2530F256 ProgramPort
Pin Name Definition
Pin1 GND
Pin2 3.3VInput
Pin3 DD
Pin4 DC
Pin5 RESET
Ifthere isaexternalpower supply, don tconnectthePin2:3.3V.
f. J6 (DA_IN)DigitalLevelInput
Pin Name Definition
Pin1 3.3Vinput
Pin2 IN4DigitalInput4th way
Pin3 IN3DigitalInput3rd way
Pin4 IN2DigitalInput2nd way
Pin5 IN1DigitalInput1st way
Pin6 GND
g. J7 (DA_OUT)DigitalLevelOutput
Pin Name Definition

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 8
-
Pin1 3.3VOutput
Pin2 OUT1DigitalOutput1st way
Pin3 OUT2DigitalOutput2nd way
Pin4 OUT3DigitalOutput3rd way
Pin5 OUT4DigitalOutput4th way
Pin6 GND
h. J8 (DS18B20)Temperature SensorDS18B20port
Pin Name Definition
Pin1 GND
Pin2 TEP_SEN
Pin3 GND
i. J9 (SENSOR)I
2
Cport, connectwith sensor
Pin Name Definition
Pin1 3.3V
Pin2 SCK
Pin3 DATA
Pin4 GND
j. J10 AnalogSignalsIN）4~20mAcurrentsignalinput
Pin Name Definition
Pin1 3.3VOutput
Pin2 AIN3CurrentSignalInput3rd way
Pin3 AIN2CurrentSignalInput2nd way
Pin4 AIN1CurrentSignalInput1st way
Pin5 AIN0CurrentSignalInput0 way
Pin6 GND
k. J11 (UART_TTL)SerialPortforTTLLevel
Pin Name Definition
Pin1 TXD
Pin2 RXD
Pin3 GND

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 9
-
4.2 Connecting Methods betweenHAC-LBee/SandHAC-DEV
Picture3 Connecting Methods betweenHAC-LBee/Sand HAC-DEV
4.3 SchematicDiagramforHAC-DEV

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com - 10 -

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
11 -
V. WorkingMode ofHAC-LBee/SWireless Module
5.1. Working ModeofHAC-LBee/SWireless Module
There arethree workingmodesforHAC-LBee/S.Theyare:TransparentMode,APIMode,AT
Command Mode.
5.1.1 TransparentMode
Bydefault,Modulesoperateunder transparentworking Mode.Whenoperating undertransparent
mode,themodulesactas aseriallinereplacement-all UARTdatareceivedthroughtheRXD pinis
queued up forRFtransmission. When RFdatais received, thedatais sentouttheTXD pin.
lNo serialcharacters are receivedfortheamountoftimedetermined.
lThemaximumnumber ofcharacters thatwill fit in an RFpacket(100)is received.
Serial-to-RFPacketization
DataisbufferedintheRXD bufferuntil oneofthefollowingcausesthedatatobepacketizedand
transmitted:Ifthemodulecannotimmediatelytransmit (forinstance,ifit isalreadyreceiving RF
data),theserialdataisstoredintheRXD Buffer.Thedataispacketizedand sentattimeoutorwhen
100 bytes (maximumpacketsize) are received.
Thedestination address under thetransparentmodecomposesofDH and DL.IfDHis0, and DLis
less than0xFFFF,thedatawill besentby16-bit destination address. Or it will use64-bit
destination address.
5.1.2API Mode
API(Application ProgrammingInterface)Operation isanalternativetothedefault Transparent
Operation. Theframe-basedAPIextends theleveltowhichahostapplication caninteractwiththe
networkingcapabilities ofthemodule.
WheninAPImode,all dataenteringand leavingthemoduleiscontainedinframesthatdefine
operations orevents within themodule.
Transmit DataFrames (received through theRXDpin (pin 3)) include:
•RFTransmit DataFrame
•Command Frame(equivalenttoATcommands)
ReceiveDataFrames(sentouttheTXD pin (pin 2)) include:
•RF-received dataframe
•Command response
•Eventnotifications such as reset, associate, disassociate, etc.
TheAPIprovidesalternativemeans ofconfiguringmodulesandrouting dataatthehostapplication
layer.Ahostapplication cansend dataframestothemodulethatcontainaddress and payload

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
12 -
information insteadofusingcommand modetomodifyaddresses. Themodulewill send data
frames to theapplication containingstatus packets;as well assource, RSSIand payload information
fromreceiveddatapackets. TheAPIoperationoption facilitatesmanyoperations suchasthe
examples cited below:
•Transmittingdatato multipledestinations withoutenteringCommand Mode
•Receivesuccess/failurestatus ofeach transmitted RFpacket
•Identifythesourceaddress ofeach received packet
* Howto let themoduleworkundertheAPImodeafterpowerup?
User can useATcommand to enter theAPImode.Thesetup steps areshown as follow:
Enter theATCommand page
Inputthe3-character command sequence “+++”and wait forthereply “OK”frommodule.
Input “ATAP1<CR>”command, themodulewill reply “OK”.Itisusedtosetthemoduleworking
under APImode.
Input “ATWR<CR>”command, themodulewillreply “OK”.Itisusedtosavethesetting.Sothe
modulewill enter APImodeautomaticallywhenrestartthemodulenexttime.
Input “ATCN<CR>”command toexit fromtheATCommand mode.Now,themoduleworks under
theAPImode. Even power up themoduleagain, it still enters theAPImodedirectly.
5.1.3ATCommand Mode
To modifyorread RFModuleparameters, themodulemustfirstenter intoCommand Mode-astate
inwhichincomingcharactersareinterpretedascommands. TwoCommand Modeoptions are
supported:ATCommandMode[refer to section below]and APICommand Mode
Send the3-character command sequence “+++”and observeguardtimesbefore and afterthe
command characters.
NOTE:Failure toenterATCommand Modeismostcommonlyduetobaud ratemismatch. Ensure
the ‘Baud settingon the “PC Settings”tabmatchestheinterface datarateoftheRFmodule.By
default, theBDparameter=3 (9600 bps).
To readaparameter valuestored in theRFmodule s register, omit theparameter field.
TheprecedingexamplewouldchangetheRFmoduleChannelto “0x0B”.Tostore thenewvalueto
non-volatile(longterm)memory, subsequentlysend theWR(Write) command.
Formodifiedparameter valuestopersistinthemodule sregistryafter areset,changesmustbe

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
13 -
savedtonon-volatilememoryusingtheWR(Write) Command. Otherwise,parametersare restored
to previouslysaved values after themoduleis reset.
SystemResponse:Whenacommand issenttothemodule,themodulewill parseand executethe
command. Upon successfulexecution ofacommand, themodulereturns an “OK”message.If
execution ofacommand results in an error, themodulereturns an “ERROR”message.
NOTE: Someparameterswill validateatonce after setting,butsomeparameterswill validateafter
restartthemodule. So pleasereadeveryATcommand verycarefully.
To ExitATCommand Mode:
Send theATCN(Exit Command Mode) command(followed byacarriagereturn). [OR]
Ifno validATCommands are received within 10 seconds.
5.1.4 Howto select theworking mode
Thedefault settingin thefactoryis transparentworkingmode.
1. Under thetransparentmode,input3-character command sequence “+++”fromserialport,it will
changefortheATCommand mode.
2. Whenyou selectthetransparentworkingmode(ATAP0),inputting “ATCN”command canexit
fromtheATCommand modeand enterthetransparentmode.Orwhenyou selectthetransparent
working mode(ATAP0),ifthereisno inputin10 seconds, themodulewill exit fromtheAT
Command modeand enter thetransparentmode.
3. Whenyou selecttheAPIworkingmode(ATAP1), inputting “ATCN”command can exit fromthe
ATCommand modeand enter theAPImode.Or whenyou selecttheAPIworking mode(ATAP1),
ifthere isnoinputin10seconds, themodulewillexit fromtheATCommand modeandenterthe

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
14 -
APImode.
4. UndertheAPImode,input3-charactercommand sequence “+++”will letthemoduleswitchto
ATCommand mode.
5. Under APImode, when usingATCommand tosetup transparentmode(ATAP0), themodulewill
switch to transparentmode.
5.2ATCommand
AT
Command
Command
Category Nameand Description ParameterRange Default Firmware
Version
WR Special Write.Writeall configurableparameter
values tonon-volatilememorysothat
parametermodificationspersistthrough
subsequentpower-up orreset.
- - >=0x1000
RE Special RestoreDefaults.Restoremodule
parameterstofactorydefaults. - - >=0x1000
FR Special SoftwareReset.Immediatelyperformsa
hardreset. - - >=0x1000
CH Networking Channel.Set/Readthechannelnumberused
fortransmittingand receivingdatabetween
RF modules (uses 802.15.4protocolchannel
numbers).
0x0B-0x1A 0x0B >=0x1000
ID Networking PANID.Set/ReadthesetupPAN(Personal
AreaNetwork)ID.0-0xFFFF 0x234 >=0x1000
DH Networking 64-bit DestinationAddress High.Set/Read
theupper32 bitsofthe64-bit destination
address. WhencombinedwithDL, it defines
thedestinationaddress usedfor
transmission.0x000000000000FFFFisthe
broadcastaddress forthePAN.
0-0xFFFFFFFF 0x00 >=0x1000
DL Networking 64-bit Destination Address Low.Set/Read
thelower32 bitsofthe64-bit destination
address.WhencombinedwithDH,DL
defines thedestinationaddressusedfor
transmission.0x000000000000FFFFisthe
broadcastaddress forthePAN.
0-0xFFFFFFFF 0xFFFF >=0x1000
MY Networking 16-bit Source Address.ReadtheRFmodule
16-bit source address.0-0xFFFF 0x0001 >=0x1000
SH Networking SerialNumberHigh.Set/Readhigh32 bits
oftheRFmodule'suniqueIEEE 64-bit
address.
0-0xFFFFFFFF - >=0x1000
SL Networking SerialNumberLow.Set/Readlow32 bitsof
theRFmodule'suniqueIEEE 64-bit
address.
0-0xFFFFFFFF - >=0x1000
SM Sleep Sleepstate.Set/readthesleepstateof
module 0-5 0 >=0x1000
AP Serial
Interfacing APIEnable.Disable/EnableAPIMode. 0-1 0=Transparent
1=APIenabled
0 >=0x1000
BD Serial
Interfacing Interface DataRate.Set/Readtheserial interface datarateforcommunications
betweentheRF moduleserialportand host.
1-7
1=2400
2=4800
3=9600
4=19200
5=38400
6=57600
7=115200
3 >=0x1001
CN ATCommand
ModeOptions Exit Command Mode.Explicitlyexit the modulefromATCommand Mode. - - >=0x1000
HV Diagnostics HardwareVersion.Readhardwareversion
oftheRF module. 0-0xFFFF (Readonly) - >=0x1000

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
15 -
VR Diagnostics FirmwareVersion.Readfirmwareversion
oftheRF module. 0-0xFF (Readonly) - >=0x1000
5.2.1AP
<SerialInterfacing>TheAPcommand isusedtoenabletheRFmoduletooperateusinga
frame-basedAPIinsteadofusingthedefault Transparent(UART)mode.
Command
ATAP(
APIEnable
)
Range
0
-
1
Default Value
0
Parameter
Value 0:Disabled(Transparentoperation)
1:APIenabled
EffectiveConditions
V
alidateatonce afterthecommand
MinimumFirmwareVersion Requir
ed
：
0x1
000
Theexamples forchanging theworking mode:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
Using ATAPcommand tosetup theworkingmodeyou want,suchasATAP0<CR>orATAP
1<CR>.
Ifthesettingisstill neededtobevalidatedafter restartthemodulenexttime,usingATWR<CR>
command to writethesettinginto Non-volatilememory.
Input “ATCN<CR>command toexitfromATCommand mode,themodulewill enter thesetting
workingmode.
5.2.2 BD
<SerialInterfacing>TheBDcommandisusedtosetandreadtheserialinterfacedatarateused
betweentheRFmoduleand host.Whenparameters1-7aresenttothemodule,therespective
interfacedataratesare used (as shown in thetableon thebelow). TheRFdatarateis notaffected by
theBDparameter (it isfixedto250kbps).Werecommend thatusersdon tselecttoo lowinterface
datarate,orit will causetheserialportdatacommunication overflow.Weonlyoffer theAT
command to changetheserialportdatarate, no command forchangingdatarateunder APImode.
Command
ATBD
(Interface DataRate)
Range
1
-
7
Parameter
Default Value
3

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
16 -
Value 1=2400
2=4800
3=9600
4=19200
5=38400
6=57600
7=115200
EffectiveConditions
U
se WRcommand tosavesetting, it will
beeffectiveafterrestart themoduleagain.
MinimumFirmwareVersion Required
：
0x1
001
Theexamples forchanging theserialport baudrate:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATBDcommand to setup theserialportbaud rateyou want, such asATBD5<CR>.
UsingATWRcommand (ATWR<CR>)to writethesettinginto Non-volatilememory.
Input “ATFR<CR>command, themodulewill restartatonce.
5.2.3 CH
<Networking{Addressing}>TheCHcommand isusedtoset/readtheoperatingchannelon which
RFconnections aremadebetweenRFmodules. HAC-LBee/Sprovides16channels(0x0B-0x1A).
Inorderformodulestocommunicatewitheachother,themodulesmustshare thesamechannel
number.Differentchannelscanbeusedtopreventmodulesinonenetworkfromlistening to
trans-missions ofanother.Themoduleuseschannelnumbersofthe802.15.4 standard. Center
Frequency=2.405 +(CH-11d)* 5 MHz(d =decimal)
Command ATCH (Channel)
Range 0x0B-0x1AParameter
Default Value 0x0B
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forchanging thechannel:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATCHcommand to setup thechannelyou want, such asATCH0E<CR>.
UsingATWRcommand (ATWR<CR>) to writethesettinginto Non-volatilememory
Input “ATCN<CR>command to exit theATcommand mode
5.2.4 CN
<ATCommand ModeOptions>TheCNcommand isusedtoexplicitlyexit theRFmodulefromAT
Command Mode.

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
17 -
Command ATCN(Exit CommandMode)
Parameter None
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x19
5.2.5 DH
<Networking{Addressing}>TheDH command isusedtosetand readtheupper 32 bitsoftheRF
module's64-bit destination address.WhencombinedwiththeDL(Destination Address Low)
parameter, it defines thedestination address usedfortransmission.
Under transparentmode,HAC-LBee/Ssends datawiththisdestination address. Whenthe
destination address(DH+DLparameters)is 0x000000000000FFFF,HAC-LBee/Swill send the
datathroughbroadcasting.Whenthe64-bit destination address isless than0x000000000000FFFF,
HAC-LBee/Swill send thedataaccordingto the16-bit destination address.
Onlyunderthetransparentmode, and DT=0, thesettingwill beeffective.
Command ATDH (DestinationAddress High)
Range 0x00 -0xFFFFFFFFParameter
Default Value 0x00
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forchanging theupper32-bitofdestinationaddress:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATDH command tosetup theupper32-bitofdestination address you want,suchasATDH
0<CR>.
UsingATWRcommand to writethesettinginto Non-volatilememory
Input “ATCN<CR>command to exit fromtheATCommand mode.
5.2.6 DL
<Networking{Addressing}>TheDLcommandisusedtosetandreadthelower32 bitsoftheRF
module's64-bit destination address. WhencombinedwiththeDH (Destination Address High)
parameter, it defines thedestination address usedfortransmission.
Under transparentmode,HAC-LBee/Ssends datawiththisdestination address. Whenthe
destination address(DH+DLparameters)is 0x000000000000FFFF,HAC-LBee/Swill send the
datathroughbroadcasting.Whenthe64-bit destination address isless than0x000000000000FFFF,

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
18 -
HAC-LBee/Swill send thedataaccordingto the16-bit destination address.
Command ATDL(DestinationAddress Low)
Range 0x00 -0xFFFFFFFFParameter
Default Value 0xFFFF
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forchanging thelower32-bitofdestinationaddress:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATDLcommand tosetup thelower32-bitofdestination address you want,suchasATDL
FFFF<CR>.
UsingATWRcommand to writethesettinginto Non-volatilememory
Input “ATCN<CR>command to exit fromtheATCommand mode.
5.2.7 FR
<Special>TheFRcommand isusedtoforce asoftware reseton theRFmodule. Theresetsimulates
poweringoffand then onagain themodule.
Command ATFR(SoftwareReset)
Parameter None
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
5.2.8 HV
<Diagnostics>TheHVcommand is used to read thehardware version oftheRFmodule.
Command ATHV(HardwareVersion)
Parameter Range 0-0xFFFF[Read-only]
MinimumFirmwareVersion Required：0x1000
5.2.9 ID
<Networking{Addressing}>TheIDcommandisusedtosetand readthePAN (PersonalArea
Network)IDoftheRFmodule.Onlymoduleswithmatching PAN IDscancommunicatewitheach
other. UniquePAN IDs enablecontrolofwhich RFpackets arereceived byamodule.

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
19 -
Command ATID (PAN ID)
Range 0x00 -0xFFFFParameter
Default Value 0x234
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forchanging thePAN IDofmodule:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATIDcommand to setup thePAN IDyou want, such asATID12AB<CR>.
UsingATWRcommand to writethesettinginto Non-volatilememory
Input “ATCN<CR>”command to exit theATcommand mode.
5.2.10 MY
<Networking{Addressing}>TheMYcommand isusedtoreadthe16-bit source address oftheRF
module.
Command ATMY(16-bit Source Address)
Range 0x00 -0xFFFEParameter
Default Value 0x0001
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forchanging the16-bitaddress ofmodule:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATMYcommand to setup the16-bit address you want, such asATMY1<CR>.
UsingATWRcommand to writethesettinginto Non-volatilememory
Input “ATCN<CR>”command to exit theATcommand mode.
5.2.11PL
<RFInterfacing>ThePLcommand isusedtoselectand readthepowerlevelatwhichtheRF
moduletransmits conducted power.
Iftheparameter isnot4(maximumpower),it will takeeffecttothemodulecommunication. Sowe
don trecommend theusers to changethis parameter.
Command ATPL(PowerLevel)
Parameter Range 0-4

HAC-LBee/SmanualV3.XSHENZHENHACTECHNOLOGYCO., LTD.
FAX:[phone] E-MAIL [e-mail] www.rf-module-china.com -
20 -
Default Value 4
Value 0=MinPower
4=MaxPower
EffectiveConditions Use WRcommand tosavesetting, it will beeffectiveafterrestart themoduleagain.
MinimumFirmwareVersion Required：0x1000
Withdifferenttransmitting power, thecorresponding currentis shownas thefollowing table.
Power level Transmitting power Transmitting current
0 0 dBm 70mA
1 5 dBm 75mA
2 10 dBm 85mA
3 15 dBm 108mA
4 20 dBm 160mA
Theexamples forchanging thepowerlevel:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATPLcommand tosetup thepower levelyou want, such asATPL4<CR>.
UsingATWRcommand to writethesettinginto Non-volatilememory
Input “ATCN<CR>”command to exit theATcommand mode.
5.2.12 RE
<(Special)>TheREcommand isusedtorestore all configurableparameterstotheirfactorydefault
settings. TheREcommand will writerestoredvaluestonon-volatile(persistent)memoryand force
asoftwarereseton theRFmodule.
Thiscommand will makethemoduledrop outofthenetworkand maychangesomesettingslike
PAN ID, 16-bit address and so on.
Command ATRE(Restoreddefaults)
Parameter None
EffectiveConditions Validateimmediately
MinimumFirmwareVersion Required：0x1000
Theexamples forrestoring thefactory defaultsetting:
Input3-charactercommand sequence “+++”and switch to theATCommand mode.
UsingATRE command to restore thefactorydefault setting,ATRE<CR>
