Haden HL173W User manual

USER’S MANUAL
HL173W
To request a service call
Tel. [phone]
Or visit
www.appliancesupport.co.uk

1
SAFTEY WARNINGS
For your continued safety and to reduce the risk of injury
or electric shock, please follow all the safety precautions
listed below.
Read all instructions carefully before using the unit
and keep them for future reference.
Retain the manual. If you pass the unit onto a third
party, make sure to include this manual.
This appliance is intended for indoor household use
and similar applications such as by guests in a hotel.
Ensure that the plug is easily accessible to enable
disconnection from the mains supply.
If the mains cable is damaged, it must be replaced
by the manufacturer, its service agent or a qualified
technician in order to avoid a hazard.
Choose a location for your unit away from heat
sources such as radiators or fires as refrigerant and
vesicant are burnable.
The unit must be maneuvered by a minimum of 2
persons.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Childrenshallnot play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children should be supervised to ensure that they
do not play with the unit.

2
If your unit is fitted with a lock to prevent children
being trapped inside, keep the key out of reach and
not in the vicinity of the unit.
Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
Keep ventilation openings in the unit enclosure or in
the built-in structure clear of obstructions.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not use electrical appliances inside the food

storage compartments of the unit, unless they are of
the type recommended by the manufacturer.
Do not damage the refrigerant circuit (The refrigerant
is a very environmental-friendly gas but is also combustible.
Take care when transporting or moving the unit to
ensure that the refrigeration circuit is not damaged.
In the event of damage avoid naked flames or
ignition sources and ventilate the room in which the
unit is placed for a few minutes.)

3
Dear customer:
Thank you for purchasing your new under counter fridge.
To ensure that you get the best results from your new
fridge, please take tme to read through the simple
instrucons in this booklet.
Please ensure that the packing material is disposed of in
accordance with the current environmental requirements.
As old refrigerator equipment may contain CFC’s which
will damage the ozone layer.
When disposing of any refrigerator equipment please
contact your local waste disposal department for advice
on safe disposal.
This appliance must be only used for its intended purpose.

4
PRODUCT OVERVIEW
1
2
3
4
5
1、Thermostat
2、Glass shelf
3、Plastic pallet
4、Crisper
5、Leveler leg

5
INSTALLATION
Place the fridge in a location with a firm base. In order to
prevent vibration and noise, the fridge must be leveled
by adjusting the front feet.
Choose a well ventilated location with no less than 10cm
clearance around the fridge.
Site the fridge away from direct sunlight and heat
sources such as an oven or boiler.
WARNING: ALLOW THE GASES IN THE FRIDGE TO
SETTLE FOR 24 HOURS BEFORE PLUGGING IN!
For your safety, please read the following information:
Warning: This appliance must be earthed.
DANGER or WARNING:
1. Risk of child entrapment. Before you throw away
your old refrigerator or freezer:
-Take off doors.
-Leave the shelves in place so that children may not
easily climb inside.”
2. Do not use extension cords.

6
USE OF THE APPLIANCE
1. When operating the refrigerator for the first time, run it without
loading any food until it autos tops at the desired temperature.
Usually it takes 2 or 3hours, then set the thermostatic dial at the
setting desired and put foods in the refrigerator.
2. The temperature of the refrigerator can be adjusted by turning
the thermostatic dial. A medium setting of the thermostatic dial is
the most suitable for general operation.
3. Defrost the freezing compartment whenever the layer of frost on
the surface of the evaporator reaches 3 or 4 mm. When defrosting,
remove all food and set the thermostat at the “OFF” position. Put
the drip tray under the evaporator to collect melted water. After the
frost has melted, discard the melted water and dry the interior of
refrigerator. The refrigerator can then be restarted by turning its
thermostat to the desired setting.
Cautions for Use
1. The more you fill the Fridge and the longer you have the door
open, the higher the electric consumption. Overloading the
appliance can lead to a malfunction.
2. Do not place objects which are too heavy, pointed or corroded in
the Fridge.
3. Leave a 10 minute interval between unplugging and then plugging
in the Fridge.
4. Try not to open the door during a power-cut.
When defrosting, never use any sharp or metallic objects to
5.
remove the frost on the surface of the evaporator as it will damage
the evaporator.
7. Don’t touch with wet hands.

7
MAINTENANCE
1. While cleaning the refrigerator, pull out the electric power plug,
rub carefully with a piece of cloth soaked with natural cleanser then
wipe with clean water. The abrasive cleaning power, alkali cleansers,
chemical cloth, thinner, alcohol, acid petroleum product and hot
water are not suitable for cleaning the refrigerator, they may
damage the painting cover and plastics.
2. The door gasket is dirty and fogged easily, so clean it frequently.
3. If the refrigerator is out of use for a long time, please pull out the
plug, clean and dry the freezing compartment then close the door
tightly.
The following cases are not malfunction
1. A flowing water sound:
Flowing water sound will be heard under normal operation.
2. Outside condensation:
Outside condensation is normal in high humidity condition. You may
just wipe it up yourself.
3. It takes some times for the temperature to become cold after
the refrigerator starts to operate: If the temperature of the two
compartments is higher while the refrigerator is operating, it takes
some times for the temperature of the two compartments to
become cold. If the environmental temperature is higher, it takes a
long time to make the compartments to become cold.
4. The surface of the compressor becomes hot:
The surface of the compressor may become hot under normal
operation. Don’t touch it with hands.

8
Methods of inspecting malfunction
If any case of malfunction happens, please inspect and dispel it
according to the methods shown in the following table.
case
Inspection
Not refrigerating
Is there no electric current?
Is the voltage normal or not?
Has the socket fused?
Has the plug been put in effectively?
Not efficient
Is the thermostatic dial set to the correct
position?
Is there any suitable clearance surrounding the
refrigerator?
Has the door been opened too frequently or too
long?
Is the refrigerator exposed to sunlight directly or
placed near some heating devices.
Are there too many foods inside?
Or are they too hot?
Food frozen in the
refrigerator
Compartment
Is the thermostatic dial set to the correct
position?
Have the foods stuff been put too crowded?
Noises
Is the refrigerator installed firmly?
Has the refrigerator been struck by some other
objects?
Compressor
Cannot stop
automatically
Are the foods stored too much at one setting?
Is the door opened too frequently or too long?
If the above methods are not yet effective, please contact with the
maintenance service department for help without any delay.

9
PROLONGED OFF PERIODS.
If the fridge is not in use for a long period of time,
proceed as follows:
Disconnect the fridge from the main supply by removing
the plug from the wall socket.
Clean and dry the inside as instructed under the heading
of cleaning the fridge.
Leave the door open to prevent any unpleasant smells
from building up while the fridge is not in use.
For household refrigerating appliances
Try not to open the door too often, especially when the weather is
wet and hot. Once you open the door, mind to close it as soon as
possible.
Every now and then check if the appliance is sufficiently ventilated
(adequate air circulation behind the appliance).
For household refrigerating appliances, in normal temperature
conditions, please arrange the thermostat at the middle setting.
Before loading the appliance with packages of fresh food, make sure
they are cooled to ambient temperature.
Ice and frost layer increase energy consumption, so do clean the
appliance as soon as the layer is 3-5 mm thick.
If it is the outer condenser, the rear wall should be always clean free
of dust or any impurities.
Always consider instructions stated in sections Positioning and
Energy Saving Tips, otherwise the energy consumption is
substantially higher.

10
DISPOSAL
5021961193063
This appliance/tting is marked according to the European directive 2002/96/EC on
Waste
Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and
human health, which could otherwise be caused by inappropriate waste handling of
this product.
The symbol on the product, or on the documents accompanying the product, the
crossed out wheelie bin symbol, indicates that this appliance/tting may not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal
must be carried out in accordance with local environmental regulations for waste
disposal.
For more detailed information about treatment, recovery and recycling of this
product, please ontact your local authority, your household waste disposal service or
the retailer where you
purchased the product.
