hager XEV1K22T2S User manual

Hager witty solar charging station for the
flow energy management system
XEV1K22T2S, XEV1K22T2SEMC,
XEV1K22T2SEMCC (3-phase)
XEV1K07T2S, XEV1K07T2SEMC (1-phase)
Charging
station
witty solar
Installation instructions
EN

02 Ladestation witty solar – XEV1K22T2S, XEV1K07T2S
Legal information
The information contained in these documents is the property of HagerEnergy GmbH.
Publication, either in whole or in part, requires written approval.
Internal reproduction, intended for the evaluation of the product or for correct use, is permitted and
does not require approval.
Manufacturer's guarantee
You are given the current guarantee documents on purchasing the device.
If necessary, you can also download the documents from the customer portal.
Additional information
The device was developed, produced and tested with great care and using state-of-the-art technology.
HagerEnergy GmbH fulfils the requirements of DIN EN ISO 9001 and proves this through a certified
quality management system.
Please obtain the current version of these instructions from the customer portal. Read the instructions
through carefully before installation at the customer's premises. Images in these instructions can
deviate from the actual state of production of the device.
The instructions have been optimised for duplex printing.
If you have questions, feel free to contact us.
You can find more information on the product and HagerEnergy GmbH on the company website.
HagerEnergy GmbH
Ursula-Flick-Straße 8
49076 Osnabrück
Germany
T+49 (0) 541 760 2680
F+49 (0) 541 760 268199
[e-mail]
hager.com
Portal: https://flow.hager.com
© 2023 HagerEnergy GmbH. All rights reserved.
These instructions relate to the following devices and software versions:
Device: witty solar charging station
Date and version of these instructions 03.2023 | Version: V1.1
The instructions of HagerEnergy GmbH are continually developed further.
You can download the current version of these instructions using the QR code shown on
https://hgr.io/r/XEV1K22T2S or https://hgr.io/r/XEV1K07T2S.

03 Ladestation witty solar – XEV1K22T2S, XEV1K07T2S
01 Notes on these instructions
01.01 Scope of validity....................................................................................................................06
01.02 Target groups ........................................................................................................................06
01.03 Qualification of the specialists carrying out the installation ............................................06
01.04 Danger levels in warning informations ...............................................................................07
01.05 Symbols in the instructions .................................................................................................07
02 Safety
02.01 Correct use............................................................................................................................08
02.02 Improper use.........................................................................................................................08
02.03 Consequences of non-observance of these instructions.................................................09
02.04 Safety instructions................................................................................................................09
03 Product description
03.01 General...................................................................................................................................11
03.02 Operation in conjunction with the Hager flow energy management controller .............11
03.03 Identification through type label .........................................................................................12
03.04 Structure of the witty solar charging station ....................................................................13
04 Scope of delivery and transport check
04.01 Scope of delivery ..................................................................................................................15
04.02 Electrical accessories not included in scope of delivery..................................................15
04.03 Transport check ....................................................................................................................16
05 Specifications and recommendations
05.01 Requirements for the location for installation ...................................................................17
05.01.01 Explaining the installation conditions to the customer...........................................................17
05.01.02 Select the location for installation carefully ............................................................................18
05.01.03 Requirements for the installation wall (wall device)................................................................18
05.01.04 Requirements for concrete foundations and cable pipes (pedestal)......................................18
05.01.05 Minimum distances.................................................................................................................19
05.02 Cable recommendations and necessary protection switches.........................................19
06 Installation
06.01 For your safety ......................................................................................................................21
06.02 Weight....................................................................................................................................21
06.03 Dimensions of the charging station....................................................................................22
06.04 Installation of the charging station on the wall..................................................................22
06.05 Installation of the cable holder (option)..............................................................................27
Table of Contents

04 Ladestation witty solar – XEV1K22T2S, XEV1K07T2S
06.05.01 Installation of the cable holder on the charging station (optional)..........................................28
06.05.02 Installation of the cable holder on the wall .............................................................................29
06.06 Installation of the pedestal (optional) .................................................................................31
06.07 Installation of the charging station on the pedestal..........................................................37
07 Electrical connection
07.01 Installation diagrams............................................................................................................40
07.02 Electrical connection of the charging station....................................................................41
07.02.01 Overview of connections ........................................................................................................41
07.02.02 Connecting the AC lead and Ethernet cable ..........................................................................41
08 Commissioning
08.01 Adjusting the charging capacity of the device ..................................................................42
08.02 Switching the device on.......................................................................................................43
08.03 Closing the device ................................................................................................................43
08.04 Applying the sticker for the operating elements ...............................................................45
08.05 Settings in the Hager flow EMC ..........................................................................................46
08.06 LED display of the device in case of faults ........................................................................47
08.07 Hand over the operating instructions to your customer...................................................48
08.08 Technical Support.................................................................................................................48
09 Operation
09.01 Users and operators of the device......................................................................................49
09.02 For your safety ......................................................................................................................49
09.02.01 Important safety information ..................................................................................................49
09.02.02 Safety information on charging with the charging station. .....................................................50
09.03 Basic information on charging an electric vehicle ............................................................51
09.03.01 Do I have to charge my electric vehicle with 1 or 3 phases? .................................................51
09.03.02 Charging current strength or charging capacity per phase....................................................51
09.04 Smart charging concept ......................................................................................................52
09.05 LED displays of the device in normal operation ................................................................53
09.06 Charging the electric vehicle with the charging station (Type 2 charging) .....................54
09.06.01 Starting the charging operation ..............................................................................................54
09.06.02 Ending the charging operation ...............................................................................................56
09.07 Settings for the charging station in the Hager flow EMC .................................................56
10 Appendix
10.01 Maintenance information.....................................................................................................57
10.01.01 Device ....................................................................................................................................57
10.01.02 Charging cables and plugs ..................................................................................................57
10.02 Decommissioning .................................................................................................................57
Table of Contents

05 Ladestation witty solar – XEV1K22T2S, XEV1K07T2S
10.03 Technical data .......................................................................................................................57
10.04 Disposal .................................................................................................................................59
Table of Contents

06
01 Notes on these instructions
The following instructions describe the installation, commissioning and operation of the device. Keep
this document in an accessible place at all times during the entire lifespan of the device!
The mounting and electrical installation work described relates to the intended standard installation of
the device.
In particular, please pay special attention to the safety and warning information!
The images in these instructions are used for explanation and may deviate from the actuation produc-
tion version of the device and its components.
01.01 Scope of validity
This document applies to the witty solar charging station device.
HagerEnergy GmbH reserves the right to make technical changes.
On the following pages of this document, the device is termed a charging station or a witty solar
charging station.
01.02 Target groups
Specialists
The chapters "Installation", "Electrical connection", "Commissioning" and "Decommissioning" are
intended for qualified electricians.
Users and operators of the charging station:
The chapter "Operation" and its subchapters are intended for users, who are also operators of the
witty solar charging station.
People, who, on account of their physical, sensory or mental abilities or inexperience, are not able to
operate the witty solar charging station safely, may not use the device without supervision or instruc-
tion from a responsible person.
01.03 Qualification of the specialists carrying out the installation
Qualified electrician
Electrical devices may only be installed and assembled by a qualified electrician in accord-
ance with the relevant installation standards, guidelines, regulations, directives, safety and
accident prevention regulations of the country.
The qualified electrician must have read and understood these instructions and know the safety
precautions.
In general, these preconditions are considered as having been fulfilled when the qualified electrician
has specialist training and knows the relevant standards and requirements.
If further units are required for installation, then the necessary activities may only be carried out by
specialists trained in the work.
Notes on these instructions
Scope of validity
Ladestation witty solar – XEV1K22T2S, XEV1K07T2S

07
01.04 Danger levels in warning informations
Warning word Consequence on non-observance
Danger Leads to serious injuries or death.
Warning Can lead to serious injuries or death.
Caution Can lead to minor injuries.
Caution Can lead to device damage.
Tab. 1: Danger levels
01.05 Symbols in the instructions
The following types of general notes are used in these instructions:
Note
Additional information, which is important for the appropriate topic, but has no safety
relevance.
Notes on these instructions
Danger levels in warning informations
Ladestation witty solar – XEV1K22T2S, XEV1K07T2S

08
02 Safety
Please read these instructions before installing and commissioning the device, in order to avoid pos-
sible injuries and/or physical damage. Every user must always comply with the safety and warning
information.
Each user of the device must read and observe the safety and warning information.
When selling, loaning and/or passing on the device in any other manner, please also pass on these
instructions as well.
02.01 Correct use
The device is an alternating current vehicle charging device, with which the batteries of electric or
hybrid vehicles can be charged according to charging mode 3 - or charging mode 2 with restricted
functions.
The device is suitable for use in interior areas and can also be used in weatherproof outdoor areas
(IPprotection class 55).
Qualified electrician
Electrical devices may only be installed and assembled by a qualified electrician in accord-
ance with the relevant installation standards, guidelines, regulations, directives, safety and
accident prevention regulations of the country.
Danger
Danger to life from improper changes to the device!
Improper changes to the device can lead to serious safety problems and a danger to life
and limb.
•Avoid improper changes of any kind to the device and the external wiring!
Caution
Improper changes to the device will render the manufacturer's guarantee null and void!
If improper changes are made to the devices, the manufacturer's guarantee will be ren-
dered null and void.
02.02 Improper use
Any other use than that described under Correct use is improper and therefore not permitted.
HagerEnergy GmbH will not accept any liability for damage resulting from improper use. The user shall
bear the sole responsibility for risks resulting from improper use.
Improper use of the device shall include, for example:
− The electrical connection and opening of the device by lay persons!
− Installation and operation of the device in areas at risk of explosions!
− Installation and operation of the device in areas in which highly flammable substances are located!
− Operation of the device at an ambient temperature outside the temperature range specified in the
Technical Data Sheet.
Safety
Correct use
Ladestation witty solar – XEV1K22T2S, XEV1K07T2S

09
− Perfect and safe operation of the device assumes correct and suitable transport, storage, mounting
and installation, as well as careful operation and maintenance of the device.
− Non-observance of these instructions!
Caution
Physical damage or injury through non-observance of these instructions!
•The device is only intended for the purpose described in these instructions.
•Any installations shall be performed as described in these instructions.
•Only use the device in accordance with the information given in these instructions.
Anyother use can lead to physical damage or injury.
•Perfect and safe operation of the device assumes correct and suitable transport, stor-
age, mounting and installation, as well as careful operation and maintenance of the
device.
Note
•The instructions belonging to this device are a component part of the product and must
available to specialist personnel at all times.
•Read and comply with the instructions.
02.03 Consequences of non-observance of these instructions
Any other use of the device than those described in these instructions shall be considered improper.
HagerEnergy GmbH shall not accept any liability for damage resulting from non-observance of the
instructions, as well as its safety and warning information.
02.04 Safety instructions
This chapter lists safety and warning information, which must be observed when working on and with
the device. Read all the information through carefully before operation!
If the contents or the language of the explanations cannot be perfectly understood, please contact or
inform us.
Safety
Consequences of non-observance of these instructions
Ladestation witty solar – XEV1K22T2S, XEV1K07T2S

10
Danger
Risk to life from electrical voltage!
Energised parts can cause serious injuries.
•Before starting work, ensure the system is volt-free.
•Observe the 5 safety rules of electrical engineering:
(1) De-energise!
(2) Secure against restart!
(3) Ensure voltage freedom on all poles!
(4) Earth and short-circuit!
(5) Cover or fence o neighbouring parts which are energised!
•The fuse integrated into the device is used for device protection and is only designed
for this device.
•The installation engineer must design and plan the necessary cable and personal
protection.
Danger
Risk to life from fire or explosion
A fire can occur on electrical devices.
•Do not install the device in areas in which easily flammable substances are located.
•Do not install the device in areas at risk of explosions.
Caution
Risk of injury to children.
Children can injure themselves by playing with the device and the packaging.
•Ensure that children do not play with the device, the packaging and the accessories.
Caution
Damage to the device through non-compliance with the permitted environmental
conditions!
The device can be damaged by non-compliance with the permitted environmental
conditions.
•Always comply with the permitted environmental conditions: Temperature, humidity,
sucient air supply and cooling.
Safety
Safety instructions
Ladestation witty solar – XEV1K22T2S, XEV1K07T2S
