Haier QDHR20 Operating instructions

49-5000430 Rev. 3 10-20 GEA
Owner’sManualand
InstallationInstructions
Manualdelpropietarioy
instruccionesdeinstalación
QDHR20
QDHR35
QDHR50
Dehumidifier
Deshumidificador
Designmayvarybymodelnumber. Eldiseñopuedevariarsegúnelnúmero
demodelo

249-5000430 Rev.3
ENGLISH

49-5000430 Rev.3 3
ENGLISH
TABLEOFCONTENTS
SAFTEYINFORMATION ...........................................................................................4
CONTROLPANEL.................................................................................................5
INSTALLATIONINSTRUCTIONS ...................................................................................6
USINGTHEDEHUMIDIFIER ...................................................................................... 7
CAREANDCLEANING ........................................................................................... 9
TROUBLESHOOTING............................................................................................10
LIMITEDWARRANTY ............................................................................................12
RECORDKEEPING
ThankyouforpurchasingthisHaierproduct.Thisuser
manualwillhelpyougetthebestperformancefromyournew
dehumidifier.
Forfuturereference,recordthemodelandserialnumber
locatedinthedehumidifierandthedateofpurchase.
Stapleyourproofofpurchasetothismanualtoaidin
obtainingwarrantyserviceifneeded.
____________________________________________________
Modelnumber
____________________________________________________
Serialnumber
____________________________________________________
Dateofpurchase
HAIER WEBSITE
Haveaquestionorneedassistancewithyour appliance? Try the Haier Website 24hoursaday,anydayofthe year! You
canalsoshopformoregreatHaierproducts and take advantage of all ouron-linesupportservicesdesignedforyour
convenience.IntheUS,pleasevisitHaierappliances.com

449-5000430 Rev.3
ENGLISH
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING For your safety, the information in this manual must be followed to minimize the risk of fire, electric
shock or personal injury.
• Usethisapplianceonlyforitsintendedpurpose as
describedinthisOwner’sManual.
• Thisdehumidifiermustbeproperlyinstalledand grounded
asdescribedinthismanualbeforeitis used.
• Neveroperatethisdehumidifierinanarea that is likely to
accumulatestandingwater.Ifthisconditiondevelops,for
yoursafetydisconnectthepowersupplybeforestepping
intothewater.
• Neverunplugyourdehumidifierbypullingonthe power
cord.Alwaysgripplugfirmlyandpullstraight out from the
receptacle.
• Immediatelyreplaceallelectricservicecordsthathave
becomefrayedorotherwisedamaged.Adamagedpower
supplycordmustbereplacedwithanew power supply cord
obtainedfromthemanufacturerandnotrepaired.Do not
useacordthatshowscracksorabrasion damage along its
lengthorateithertheplugorconnector end.
• Ifthereceptacledoesnotmatchthe plug, the receptacle
mustbechangedoutbyaqualifiedelectrician
• IftheSUPPLYCORDisdamaged,itmustbereplacedbythe
manufacturer,itsserviceagentorsimilarlyqualifiedperson
inordertoavoidahazard.
• Theapplianceshallbeinstalledinaccordancewith national
wiringregulations.
• TurnthedehumidifierOFFandunplugitbefore cleaning.
• Haierdoesnotsupportanyservicingof the dehumidifier.
Westronglyrecommendthatyoudonotattempt to
servicethedehumidifieryourself.
• Foryoursafety,donotstoreoruse combustible materials,
gasolineorotherflammablevaporsorliquidsin the vicinity
ofthisoranyotherappliance.
• Alldehumidifierscontainrefrigerants,whichunderfederal
lawmustberemovedpriortoproductdisposal. If you are
gettingridofanoldproductwithrefrigerants, check with
thecompanyhandlingdisposalaboutwhattodo.
• Donotuseoutdoors.
• Thisdehumidifierisintendedforindoorresidential
applicationsonly.Thisdehumidifiershouldnotbeused for
commercialorindustrialapplications.
• TheseR410ADehumidifierSystemsrequirecontractors
andtechnicianstousetools,equipmentandsafety
standardsapprovedforusewiththisrefrigerant. DONOT
useequipmentcertifiedforR22refrigerantonly.
• Thisappliancecanbeusedbypersonswith reduced physical,
sensoryormentalcapabilitiesorlackofexperience and
knowledgeiftheyhavebeengivensupervisionor instruction
concerninguseoftheapplianceinasafe way and understand
thehazardsinvolved.
WARNING USE OF EXTENSION CORDS
RISK OF FIRE. Could cause serious injury or death.
• DONOTuseanextensioncordwith this Dehumidifier.
• DONOTusesurgeprotectorsormulti-outlet adaptors
withthisDehumidifier.
HOW TO CONNECT ELECTRICITY
Donot,underanycircumstances,cutorremove the third
(ground)prongfromthepowercord.Forpersonal safety, this
appliancemustbeproperlygrounded.
DONOTuseanadapterplugwiththis appliance.
Thepowercordofthisapplianceisequipped with a 3-prong
(grounding)plugwhichmateswithastandard3-prong
(grounding)walloutlettominimizethepossibilityof electric
shockhazardfromthisappliance.
Havethewalloutletandcircuitcheckedby a qualified
electriciantomakesuretheoutletisproperly grounded.
Wherea2-prongwalloutletisencountered,it is your
personalresponsibilityandobligationtohaveitreplaced with
aproperlygrounded3-prongwalloutlet.
Thedehumidifiershouldalwaysbepluggedintoits own
individualelectricaloutlet,whichhasavoltagerating
matchingtheratingplate.
Thisprovidesthebestperformanceandalsoprevents
overloadinghousewiringcircuits,whichcouldcausea fire
hazardfromoverheatedwires.
RECYCLING INFORMATION
For appliance recycling information please visit www.geappliances.com/recycling.
SAFETYINFORMATION

49-5000430 Rev.3 5
ENGLISH
CONTROLS
Controls
NOTE: Whenthebucketisfullorremoved,thecontrolscannotbeset.
1. Power Pad
Pressto turnthedehumidifier onand off.
NOTE: Turningoff thepowerby pressingthe Powerbutton does
NOTdisconnect theappliancefrom powersupply.
"ÏäñÜóèèçÙäç
Controlsthe fanspeed.
PresstoselecteitherHigh,Medium,Low,orSmartDryfanspeed.
Setthefan controlto Highformaximum moistureremoval. When
thehumidity hasbeenreduced andquiet operationis preferred,
setthe fancontrolto Mediumor Low.
SmartDry comparestheset humiditylevel withthe actual
humidityand adjuststhefan speedautomatically.
3. Display
Showsthe set%humidity levelwhile setting,then showsthe
actual(+/– 5%accuracy)room %humidity level.
$Ñøðìçì÷üÜè÷Ìòñ÷õòïÙäçö
Ýëèëøðìçì÷üïèùèïæäñåèöè÷úì÷ëìñäõäñêèòé#%]ÛÑ¤Ûèïä÷ìùè
Ñøðìçì÷ü¥÷ò( ]ÛÑ¤Ûèïä÷ìùèÑøðìçì÷ü¥ìñ%]ìñæõèðèñ÷öòõ
inNonstop modeforcontinuous operation. Toset theunit for
continuousoperation, pressthe paduntil the“Nonstop”
indicatorlight isilluminated.
NOTE: IfNonstop isselected,the dehumidifierwill operate
continuouslyat itsmaximumdehumidification settingsif
attachedto ahoseto drainor untilthe bucketis full.
Fordrierair,pressthe padandsettoalowerpercentvalue(%).
Fordamperair,pressthe padandsettoahigherpercentvalue(%).
Whenyou firstusethe dehumidifier,set thehumidity control
to45% or50%.Allow atleast 24hours forthe dehumidifier
toachieve thehumiditylevel. Ifyou stillhave damperair than
desired,set thehumiditylevel toa lowersetting orselect
Nonstopfor maximumdehumidification.
5. Filter Timer
After250hoursofoperation,theCleantheFilterindicatorlightwill
glowtoremindyoutocleanthefilter.Removethefilterandcleanit.
Pressand holdFilter buttonfor 3seconds toreset thefilter
reminder.See theCareand Cleaningsection.
6. Delay Off
Whilethe dehumidifierisoperating pressthe Delay button.
Pressthe
/ buttonsto selectthenumber ofhours youwant
thedehumidifier tocontinueto operatebefore turningOff.
NOTE: Afterdisplaying thetime,the Displaywill revertto
showingthe currenthumidityafter 5seconds havepassed.
Pressingthe Delay buttonwilldisplay thenumber ofhours lefton
thedelay.
Delay On
Whilethe dehumidifierisoff pressthe Delay button.
Pressthe
/ buttonsto selectthenumber ofhours you
wantthe dehumidifiertoremain offbefore turningOn.
NOTE: Thedisplay willshowthe numberof hoursleft untilthe
dehumidifierturns on.
To cancel the Delay:
Pressthe Delaybuttononce, thehours remainingon theDelay
willappear onthedisplay. Pressthe Delay buttonagain andthe
Delaywill becancelled.
7. Empty Indicator
The“Empty” indicatorwillblink whenthe bucketis readyto be
emptied,or whenthebucket isremoved and/ornot replacedin
theproper position.
Appearancemayvarybymodel.
Other Features
Alarm
Ifthebucket is fullormissing,an alarm will soundforabout10 seconds to
remindyouto empty andreplacethebucket.
Auto Shut Off
TheWaterLevel Control Switchshutsoffthe dehumidifier when thebucket
isfull,or when thebucketisremoved and/or not replacedintheproper
position.
NOTE: Thefanand compressor willstoprunningas soon as thebucketis
removed.Thealarm will soundifthebucket is not replacedintheproper
positionafter3 minutes.
Auto Defrost
Whenfrostbuilds up ontheevaporatorcoils, the compressor willcycleoff
andthefan will continuetorununtil the frost disappears.
Power Outage
Inthecase of apoweroutageor interruption, the unitwillautomatically
restart,inthe settings lastused,afterthe power is restored.

649-5000430 Rev.3
ENGLISH
INSTALLATIONINSTRUCTIONS
NOTE:Beforeplugginginthedehumidifier,removethe
castersfromthebucketandinstallasshownbelow.
InstallingtheCasters(onlyforQDHR20and
QDHR35)
1.Removethe4castersfromthebagtapedtotheinsideof
thewaterbucketlid.
2.Carefullylaythedehumidifierdownonit’sfrontorbackona
paddedsurfacetopreventdamagetounit.
3.Pushthecastersintotheholesonthebaseoftheunituntil
theylockinplace.
4.Placetheunituprightandwait1hourbeforeuse.
Dehumidifier
isonit’sfront

49-5000430 Rev.3 7
ENGLISH
Choosing a Location
Adehumidifieroperatinginabasementwillhavelittleorno
effectindryinganadjacentenclosedstoragearea,suchasa
closet,unlessthereisadequatecirculationofairinandoutofthe
area.
• Donotuseoutdoors.
• Thisdehumidifierisintendedforindoorresidentialapplications
only.Thisdehumidifiershouldnotbeusedforcommercialor
industrialapplications.
• Placethedehumidifieronasmooth,levelfloorstrongenough
tosupporttheunitwithafullbucketofwater.
• Allowatleast18inchesofairspaceonallsidesoftheunitfor
goodaircirculation.
• Placethedehumidifierinanareawherethetemperaturewill
notfallbelow41°F(5°C)orabove90°F(32°C).Thecoilscan
becomecoveredwithfrostattemperaturesbelow41°F,which
mayreduceperformance.
• Thesuggestedrangeofrelativehumidityisbetween40%and
50%
• Usethedehumidifierincooking,laundryanddishwashingareas
thathaveexcessivemoisture.
NOTE:Placethedehumidifierawayfromtheclothesdryer.
• Usethedehumidifiertopreventmoisturedamageanywhere
booksorvaluablesarestored.
• Usethedehumidifierinabasementtohelppreventmoisture
damage.
• Thedehumidifiermustbeoperatedinanenclosedareatobe
mosteffective.
• Closealldoors,windowsandotheroutsideopeningstothe
room.
NOTE:Thedehumidifierhascasterstoaidplacement,butit
shouldonlyberolledonsmooth,flatsurfaces.Donotattemptto
rollthedehumidifieroncarpetoroverobjects.
HowtheDehumidifierOperates
Moist,humidairisdrawnoveracoldrefrigerateddehumidifying
coil.Moistureintheaircondensesonthiscoilanddrainsintoa
bucket(orthroughahoseanddrain).
Dry,cleanairisdrawnthroughthecondenserwhereitisheated
anddischargedoutthetopgrilleintotheroom.
Itisnormalforthesurroundingairtobecomeslightlywarmeras
thedehumidifieroperates.
AutomaticDefrost
Whenfrostbuildsupontheevaporatorcoils,thecompressor
willcycleoffandthefanwillcontinuetorununtilthefrost
disappears.
Whenthecoilisdefrosted,thecompressororfanwill
automaticallyrestartanddehumidifyingwillresume.
When first using the dehumidifier, operate the unit continuously for 24 hours.
USINGTHEDEHUMIDIFIER
41 °F
(5 °C) 41 °F
(5 °C)
Above Below
Correct Wrong
at least 18 inches
at least 18 inches

849-5000430 Rev.3
ENGLISH
RemovingCollectedWater
Thereare2waystoremovecollectedwater:
Usethebucket.Whenthebucketisremoved,theunitwillshut
off.Emptyandreplacethebucket.
IMPORTANT:Donotusethehoseifusingthebuckettocollect
water.Whenthehoseisconnected,waterwillflowthroughit
ontothefloorinsteadofintothebucket.
NOTES:
• Donotremovethebucketwhilethedehumidifierisoperating
orifithasjuststoppedoperating.Thismightcausesome
watertodripfromthedrainpan.
• Thebucketmustbeinplaceandsecurelyseatedforthe
dehumidifiertooperate.
Useahose.Watercanbeautomaticallyemptiedintoafloor
drainbyattachingagardenwaterhose(notincluded).
1.Removethebucketfromthefrontoftheunit.
2.Openthedraincoveronthesideoftheunit.
3.Threadagardenhose(notsupplied)ontothenozzleand
ensureitisseatedsecurely.Cuttolengthandleadittothe
floordrain.
4.Replacethebucketintheunit.
NOTE:Thebucketmustbeinplaceandsecurelyseatedforthe
dehumidifiertooperate.Thedrainhosemustrundownfromthe
dehumidifiertothefloordrain.
Always make sure the water bucket is locked into place on the dehumidifier.
WaterLevel
Thedehumidifierwillturnoffautomaticallywhenthebucketis
full,orwhenthebucketisremovedornotreplacedintheproper
position.
Thebucketmustbereplacedintheproperpositionforthe
dehumidifiertowork.Theemptyindicatorwillblinkandthe
dehumidifierwillnotrunifthebucketisnotintheproper
position.
USINGTHEDEHUMIDIFIER
BucketOperation
DONOTremovethefoampieceandmagnetblockinthebucket
assembly.IfremovedtheDehumidifierwillnotworkproperly.

49-5000430 Rev.3 9
ENGLISH
Air Filter
Theairfilterbehindthereargrilleshouldbecheckedandcleaned
atleastevery250hoursofoperationormoreoftenifnecessary.
After250hoursofoperation,theFilterindicatorlightwillglow
toremindyoutocleanthefilter.Removethefilterandclean
it.Replacethefilterandpressandholdthefilterbuttonfor3
seconds.
To remove:
Removethereargrilleandthefilterwillbeattached.
To clean:
Cleanthefilterwithwarm,soapywater.Rinseandletthefilter
drybeforereplacingit.
NOTE:ÍØ×ØÝóø÷÷ëèéìï÷èõìñäñäø÷òðä÷ìæçìöëúäöëèõ
CAUTION DONOToperatethedehumidifier
withoutafilterbecausedirtandlintwillclogtheunitandreduce
performance.
GrilleandCase
To cleanthe case:
Usewaterandamilddetergent.Donotuse
bleachorabrasives.
To cleanthe reargrille:
Useavacuumattachmentorbrush.
WaterBucket
To clean:
Everyfewweeks,cleanthebuckettopreventgrowthofmold,
mildewandbacteria.Partiallyfillthebucketwithcleanwaterand
addalittlemilddetergent.Swishitaroundinthebucket,empty
andrinse.
NOTE:Donotuseadishwashertocleanthewaterbucket.
To remove:
Removethebucketandpouroutanywater.
To replace:
Slidethebucketintothedehumidifier.
NOTE:Thebucketmustbeinplaceandsecurelyseatedforthe
dehumidifiertooperate.
Turn off the dehumidifier and remove the plug from the wall outlet before cleaning.
CAREANDCLEANING
Airfilter

10 49-5000430 Rev.3
ENGLISH
Savetimeandmoney!Reviewthechartson the following pages first and youmaynotneedtocallforservice.
Problem Possible Cause What To Do
Dehumidifier does not start The dehumidifier is unplugged. Makessure thedehumidifier’splug ispushed completelyinto
theoutlet.
The fuse is blown/circuit breaker is
tripped. Checkthe housefuse/circuitbreaker boxand replacethe fuse orreset thebreaker.
Dehumidifier has reached its set
humidity level or bucket is full. Thedehumidifier automaticallyturnsoff wheneither conditionoccurs. Change toalower settingor emptythe
bucketand replaceproperly.
Bucket is not in the proper position. Thebucket mustbein placeand securelyseated forthe
dehumidifierto operate.
Power Failure. Thereis aprotectivetime delay(up to3 minutes)to prevent
trippingof thecompressoroverload. Forthis reason,the unit
maynot startnormaldehumidification for3 minutesafter it
turnedback on.
Dehumidifier does not dry
the air as it should Did not allow enough time to remove the moisture. Whenfirst installed,allowat least24 hoursto maintainthe desireddryness.
Airflow is restricted. Makesure thereareno curtains,blinds orfurniture blocking
thetop orbackof thedehumidifier. See theChoosing a
Locationsection.
Dirty Filter Seethe CareandCleaning section.
The Humidity Control may not be set
low enough. Fordrier air,pressthe źpadand setto alower percentvalue
(%)or attheNonstop settingfor maximumdehumidification.
Doors and windowsmay not be
closedtightly. Checkthat alldoors, windowsandotheropeningsare securelyclosed.
Clothes dryer maybe blowing
moisure-ladenairinto the room. Install thedehumidifier awayfrom thedyer. Thedryer should bevented totheoutside.
Room temperature is too low. Moistureremoval isbestat higherroom temperatures.
Lowerroom temperatureswillreduce themoisture removal
rate. Modelsare designedtobe operatedat temperatures
above41°F (5°C).
Dehumidifier runs too much
Area to be dehumidified is too large. Thecapacity ofyourdehumidifier maynot beadequate.
Doors and windows are open. Closeall doorsandwindows tothe outside.
Frost appears on the coils Room temperature is below 41°F
(5°C) Pleaseoperate unitattemperatures above41 F(5 C).Frost willusually disappearwithin60 minutes.Under certain
conditions,frost mayappearon thecoils ofyour dehumidifier
attemperatures above41°F(5°C). Thisis normaland frost
willusually disappearwithin60 minutes.See theAutomatic
Defrostsection.
Fan noise Air is moving through the
dehumidifier. Thisis normal.
Water on floor Hose connection may be loose. Checkthe hoseconnection. Seethe RemovingCollected
Watersection.
Intended to use the bucket to collect
water, but a hose was attached. Disconnectthe hoseifusing abucket tocollect water. See theRemoving CollectedWatersection.
Bucket Full LED light
flashing and alarm sounds
while drain hose is
connected.
Drain hose not tight on fitting. Checkdrain hoseconnection.
Drain hose is kinked. Ensurethe drainhoseis pointedstraight downto thefloor
andis notkinkedin anyway.
TROUBLESHOOTING
