18.5Ǝ&21.5Ǝ&23.6ƎLCD TV Haier HL19LE2&HL22(24)XLE2
1
Service
Service
Service
Horizontal Frequency
31~75KHz
TABLE OF CONTENTS
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
6.1 Main Board………..…………………...…….….......29
6.2 Power Board…..…………..………….…..…….......31
6.3 Key Board………………………..……..……….......37
6.4 IR Board…………………………..……….…….......37
7. Adjustment..............................................................38
8. Block Diagram.…….................................................39
9. Wiring Diagram.……...............................................40
10. Schematic Diagram………..……..………………...41
10.1 Main Board…………….…………………...….......41
10.2 Power Board………..…....…………...……….......51
10.3 Key Board……………….………….………….......55
10.4 IR Board……………………………….……….......56
Table of Contents.......……....................................…........1
Important Safety Notice.......................................……......2
Revision List…………………………………………………3
1. General Specification.................................………........4
2. Operating Instructions…………………….……...….......6
2.1 The Use of Remote Control…….…………...…….......6
2.2 To Use the Menus…...………………….….………......8
2.3 Front Panel Control Knobs……………….………......16
2.4 How to Connect…….…………………….…..…….....17
3. Input/Output Specification…………....................…....18
4. Mechanical Instructions…………………….................21
5. Repair Flow Chart ………………………………………24
6. PCB Layout …………...………………………………...29

2
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all Haier Company Equipment. The service
procedures recommended by Haier and described in this service manual are effective methods of performing
service operations. Some of these service operations require the use of tools specially designed for the purpose.
The special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. Haier could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, Haier has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by Haier must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, Haier Company will be referred to as Haier.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics might create
shock, fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from Haier.
Haier assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiations when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)

4
1. General Specification
Note
* This model complies with the specifications listed below.
* Designs and specifications are subject to change without notice.
* This model may not be compatible with features and/or specifications that may be added in the future.

Model No. HL19LE2 HL22XLE2 HL24XLE2
DISPLAY
Viewable 18.5" 21.5" 23.6"
Television
System NTSC standard, ATSC standard (8-VSB, Clear-QAM)
Channel
Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mild band (A - 8 through A - 1, A through I),
Super band (J through W),
Hyper band (AA through ZZ, AAA, BBB),
Ultra band (65 through 94, 100 through 125)
CONNECTIONS
Rear
Connectors
Tuner input (75ȍ)
AV IN: AV/S-Video and L/R audio input
PC IN: D-SUB and PC Audio (Headphone mini-jack)
Supported scan rate: 640x480@60/72/75Hz, 720x400@70Hz,
800x600@56/60/72/75Hz, 1024x768@60/70/75Hz,
1280x720@60Hz, 1280x768@60Hz.
Note:
1360x768@60Hz: For HL19LE2 only.
1280x1024@60Hz, 1440x900@60Hz, 1680x1050@60Hz,
1920x1080@60Hz: For HL22XLE2 / HL24XLE2 only.
Recommended: For HL19LE2: 1360x768@60Hz
For HL22XLE2 / HL24XLE2: 1920x1080@60Hz
Component Video and L/R Audio input
Supported resolution: 480i,480p,720p,1080i, 1080p
HDMI input
Supported scan rates: 480i, 480p, 720p, 1080i, 1080p
AV/S-Video input
SPDIF
HDMI 1
AV/S-Video input
SPDIF
HDMI 1
AV/S-Video input
SPDIF
HDMI 1
Side
Connectors
HDMI 2
Earphone Output
USB PORT
HDMI 2
Earphone Output
USB PORT
HDMI 2
Earphone Output
USB PORT



5

Model No. HL19LE2 HL22XLE2 HL24XLE2
WEIGHT & DIMENSIOIN
Dimensions
with Stand
(W x H x D)(inch)
18.48x13.92x5.91 21.11x15.4x6.3 22.88x16.41x6.3
Dimensions
without Stand
(W x H x D)(inch)
18.48x12.35x1.62 21.11x13.84x1.62 22.88x14.84x1.62
Weight with Stand 6.88(lbs) 8.82(lbs) 9.48(lbs)
Weight without Stand and Base 6.37(lbs) 8.27(lbs) 8.93(lbs)
WALL MOUNTING
VESA-compatible wall bracket
(W x H) 100 x 100 mm 100 x 100 mm 100 x 100 mm
Screw type Metric 4 x 10 mm Metric 4 x 10 mm Metric 4 x 10 mm
POWER
Power Consumption 33W 50W 50W
Standby <1W
Mains Power 120V 60Hz
Audio Power 3W + 3W 3W + 3W 3W + 3W
Ambient Temperature 41°F ~ 95°F
PACKAGE CONTENTS
Supplied Accessories
TV unit x 1
Base x 1
Remote control x 1 (with two size AAA alkaline batteries)
User manual x 1
Registration Card x 1


6
2. Operating Instructions
2.1 The Use of Remote Control

7

8
2.2 To Use the Menus

9

10

11

12

13

14

15

16
2.3 Front Panel Control Knobs


1. POWER Press to turn on / off (standby) the TV set.
2. VOL + Press to increase the volume.
3. VOL - Press to decrease the volume.
4. CH ŸPress to increase the channel number.
5. CH źPress to decrease the channel number.
6. MENU Press to open or exit the OSD (on-screen display) menu.
7. INPUT Press to select the input source.

17
2.4 How to Connect
1. HDMI– Connect the primary source for digital video such as a DVD multimedia player or set top box through this
all digital connector.
2. PC IN– Connect the video and audio cables from a computer here.
3. AV IN (AV/S-VIDEO)– Connect the input source for composite video devices, such as a VCR or video game. Use
the white and red connectors to connect the external audio from the same source. The signal being carried by the
S-Video cable and connector, if connected, will take priority over the Video RCA connector (yellow connector).
4.COMPONENT (Y/Pb/Pr with Audio L/R)– Connect the primary source for component video devices such as a
DVD Player or set top box here. Use red for Pr, blue for Pb, green for Y, red for right audio (R) and white for left
audio (L) inputs.
5.ANTENNA/CABLE DIGITAL/ANALOG– Connect to an antenna or digital cable (out-of-the-wall, not from Cable
Box) for Digital TV.
6.SPDIF (Optical Digital Audio Out)– When a digital audio signal is associated with the input selected for viewing,
the digital audio will be available on this SPDIF connection to your home theater system.
7.USB PORT– Insert USB storage device to the USB port to view JPEG photos, listen to MP3 music, or to run the
[Time Shift] function. (Please refer to page 22~24 for more information.)
8.Earphone Output– Connect to the headphones. When the headphone is inserted to the plug, all the speakers
will be muted.
Once your equipment is connected, use the following procedure to view the input signal:
Press the INPUT button on the remote control to select the relevant source to view. (ex: Press INPUT button to
select “Component” if you have connected a video recorder to the Component input.)

18
3. Input/Output Specification
3.1 Input Signal Connector
D-SUB
Pin No. Description Pin No. Description
1Red Video 9No Pin
2Green Video 10 Sync Ground
3Blue Video 11 SDA(Remote Control)
4SCL(Remote Control) 12 Serial Data for DDC
5Ground 13 H. Sync
6Red Ground 14 V. Sync
7Green Ground 15 Serial Clock for DDC
8Blue Ground
HDMI
Pin No. Description Pin No. Description
1 TMDS Data2+ 11 TMDS Clock Shield
2 TMDS Data2 shield 12 TMDS Clock-
3 TDMS Data2- 13 CEC
4 TMDS Data1+ 14 NC
5 TMDS Data1 shield 15 SCL
6 TMDS Data1- 16 SDA
7 TMDS Data0+ 17 DDC/CEC Ground
8 TMDS Data0 shield 18 +5V Power
9 TMDS Data0- 19 Hot Plug Detect
10 TMDS Clock+

19
3.2 Input Signal Timing
Analog RGB
HL19LE2
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
VGA
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
640x480@75Hz 840 x 500 37.500 N 75 N 31.500
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
SVGA
800x600@56Hz 1024 x 625 35.156 P 56.250 P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000
800x600@75Hz 1056 x 625 46.875 P 75 P 49.500
XGA
1024x768@60Hz 1344 x 806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328 x 806 56.476 N 70.069 N 75.000
1024x768@75Hz 1312 x 800 60.023 P 75.029 P 78.750
CVT-0.92M9 1280x720@60Hz 1664 x 748 44.722 N 59.855 P 74.500
WXGA 1280x768@60Hz 1440 x 790 47.396 P 59.995 N 68.250
WXGA 1360x768@60Hz 1720 x 795 75.000 P 60.020 P 162.000
HL22XLE2/HL24XLE2
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
VGA
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
640x480@75Hz 840 x 500 37.500 N 75 N 31.500
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
SVGA
800x600@56Hz 1024 x 625 35.156 P 56.250 P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000
800x600@75Hz 1056 x 625 46.875 P 75 P 49.500
XGA
1024x768@60Hz 1344 x 806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328 x 806 56.476 N 70.069 N 75.000
1024x768@75Hz 1312 x 800 60.023 P 75.029 P 78.750
CVT-0.92M9 1280x720@60Hz 1664 x 748 44.722 N 59.855 P 74.500
WXGA 1280x768@60Hz 1440 x 790 47.396 P 59.995 N 68.250
SXGA 1280x1024@60Hz 1688 x 1066 63.981 P 60.020 P 108.000
WXGA+ 1440x900@60Hz 1600 x 926 55.469 P 59.901 N 88.750
WSXGA+ 1680x1050@60Hz 2240 x 1089 65.290 N 59.954 P 146.250
FHD 1920x1080@60Hz 2200 x 1125 67.500 P 60.000 P 148.500

20
HDMI
HL19LE2
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
DOS 720 x 400@70Hz 900 x 449 31.469 N 70.087 P 28.322
VGA 640 x 480@60Hz 800 x 525 31.469 N 59.940 N 25.175
SVGA 800 x 600@60Hz 1056 x 628 37.879 P 60.317 P 40
XGA 1024 x 768@60Hz 1344 x 806 48.363 N 60.004 N 65
WXGA 1280 x 768@60Hz 1664 x 798 47.396 P 59.995 N 68.25
CVT-0.92M9 1280 x 720@60Hz 1664 x 748 44.772 N 59.855 P 74.5
WXGA 1360x768@60Hz 1720 x 795 75.000 P 60.020 P 162.000
1080P 1920 x 1080P 2200 x 1125 67.5 60, 148.5
720P 1280 x 720P 1650 x 750 45.00 60, 74.25
1080i 1920 x 1080i 2200 x 1125 33.75 60, 74.25
480P 720 x 480P 858 x 525 31.50 60, 27.03
480i 720 x 480i 1716 x 525 15.75 60, 13.51
HL22XLE2/HL24XLE2
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
DOS 720 x 400@70Hz 900 x 449 31.469 N 70.087 P 28.322
VGA 640 x 480@60Hz 800 x 525 31.469 N 59.940 N 25.175
SVGA 800 x 600@60Hz 1056 x 628 37.879 P 60.317 P 40
XGA 1024 x 768@60Hz 1344 x 806 48.363 N 60.004 N 65
WXGA 1280 x 768@60Hz 1664 x 798 47.396 P 59.995 N 68.25
CVT-0.92M9 1280 x 720@60Hz 1664 x 748 44.772 N 59.855 P 74.5
SXGA 1280 x 1024@60Hz 1688 x 1066 63.981 P 60.02 P 108
WXGA+ 1440 x 900@60Hz 1904 x 934 55.469 P 59.901 N 88.75
WSXGA+ 1680 x 1050@60Hz 1840 x 1080 65.29 N 59.954 P 146.25
FHD 1920x1080@60Hz 2200 x 1125 67.500 P 60.000 P 148.500
1080P 1920 x 1080P 2200 x 1125 67.5 60, 148.5
720P 1280 x 720P 1650 x 750 45.00 60, 74.25
1080i 1920 x 1080i 2200 x 1125 33.75 60, 74.25
480P 720 x 480P 858 x 525 31.50 60, 27.03
480i 720 x 480i 1716 x 525 15.75 60, 13.51

21
4. Mechanical Instructions
Step1. Remove the STAND, BASE and REAR COVER.
Step2. Remove the AC COVER, HINGE BKT, MAIN BOARD and POWER BOARD.
HL19LE2
