NEC NLT-32HDB4 User manual

LCD Television
,
Owner s Manual
ENGLISH
Please read this manual carefully before operating the unit,
and retain it for future reference.
Model No:NLT-32HDB4

FOR LCD TV
Contents
Some minute dotdefects may be visible onthe screen, appearingas tiny red, green, orblue spots.
However, they have no adverse effect on the monitor's performance.
Avoid touching the LCD screenor holding yourfinger(s) against itfor long periodsof time. Doing so
may produce sometemporary distortion effects on the screen.
On Disposal
a. Do not dispose of this product with general household waste.
b. Disposal ofthis product mustbe carried outin accordance tothe regulations ofyour local authority.
1
Contents 1
FOR LCD TV 1
Installation 4
Remote Control 5
Basic Operation
7
Warning
Location
Cleaning
Wall Mount: Horizontal Installation
Power
Service
Aerial
4
4
4
4
4
4
3,4
Insertion of Batteries:
Range of Remote Control
Care For Remote Control
Connecting the DVD player or HDTV
Set-top box using YPbPr input
10
Connecting audio amplifier (for all
signal source)
9
9
9
10
Connecting the DVD, VCR or other
video apparatus using AV and S-
VIDEO input
11
How to connect a device using
HDMI Connection
12
Safety Instructions 2,3 To play from the device using HDMI 12
Connecting the Computer using
VGA input 13
Connecting directly to TV
Initial Setup Instruction Guide
Power ON/OFF
Selection of Input Mode
13
14
15
15
OSD Option Adjustment
OSD Functions
Video Page Menu
Audio Page Menu
TV Page Menu (Only for TV)
15
16
21
16
Technical Specification 32
Support the Signal Mode 33
A. VGA Mode
B. YPbPr Mode
C. HDMI Mode
33
33
33
Parental Page Menu
Setup Page Menu 25
27
20
Wall Mounting Information/
Technical Drawing 34
NEC Service Centers 35
Controls of Side Panel
9
Controls of Back Panel 8

Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
2

Safety Instructions
- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
- Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation
“WARNING
- To reduce the risk of fire or electric shock, do not expose the apparatus to rain or moisture.
-The appliance is not intended for use by young children or infirm persons without supervision.
- Young children should be supervised to ensure that they do not play with the appliance.
3
Power Connection
Power Connection
Connect the supplied AC power lead between the AC INoutlet on theLCD TV, located at the
rear of theset and convenientlylocated AC wall outlet.
Image Persistence
Avoid displaying fixed pattern in the monitor for long period of time to avoid image persistence.
"The marking orretained image on the LCD panel resulting from fixed image use is not an operating
defect and assuch is notcovered by warranty. This product is not designed to fixed image patterns
for extended periodsof time.”

Installation
Power
This set operates on an AC mains supply, the voltage is as indicated on the label on the back cover.
In the event of thunderstorms or powercuts, please pull out the aerial and mains plugs.
Warning
Toprevent fire or shock hazard, do not expose the set to rain ormoisture. Do not rub or strike the
LCD with anything hard as this may scratch, mar, or damage the Active LCD permanently.
Service
Never remove the back cover of the set as this can expose you to very high voltage and other hazards.
If the set does not operate properly, unplug it and call NEC Service centre.
Aerial
Connect the aerial cableto the socket marked ATV/DTV Tuner on the back cover. For the best reception
an outdoor aerial should be used.
Location
Position your set so that no bright light or sunlight falls directly onto the screen. Care should be taken
not to expose the set to any unnecessary vibration, moisture, dust or heat. Also ensure that the set is
placed in a position to allow a free flow of air. Do not cover the ventilation openings on the back cover.
Cleaning
Unplug the set before cleaning the faceof the LCD Screen. Dust the set by wiping the screen and the
cabinet with a soft, clean cloth. If the screen requires additional cleaning, use a clean, damp cloth. Do
not use liquid cleaners or aerosol cleaners.
Wall Mount: Horizontal Installation
When mounting the producton wall or ceiling, be sure toinstall the product using the designated
mounting tool according to the method recommended by the manufacturer.
4

Remote Control
1. POWER( ): Press to turn on and off.
2. Mute( ): Switches the sound on or off.
3. 0~9 Number Buttons: Press 0~9 to select a
channel, and input the password.
4. SLEEP:Press repeatedly untilit displays the time
in minutes (10,20, 30, 40, 50,60, 90, 120 andOff)
that you want the TVto remain on beforeshutting
off. To cancel sleep time, press Sleep button
repeatedly until sleep Off appears.
5. Recall: Press to return to previous channel. (Only
for TV)
6. VOL +/-: Press to adjust the audio levels.
7. PR+/-(PRO +/-) : Press to select the channel
forward or backward.
8. I/II: Selects the language during dual language
broadcasting.Selects the sound output.
9. INPUT(TV/AV): Press to select the signal source, such
as TV, AV, S-Video,YPbPr1, VGA, or HDMI.
10. : Press to move the on-screen
cursor.
11. Enter: Press to enter or confirm.
12. Menu: Press to enter into the on-screen setup
menu, press again to exit.
13. EXIT: Press this button to exit in the menu.
14. FAVOURITE: Press to select the favourite
channel from list. Press or to select the
channel then press Enter to confirm.
15. FAV Add/Erase: Press to add or delete favourite
channels.
, , , ,, ,
16. EPG(Digital TV Timetable): Press to display the
( Digital TV Timetable) mode. Press again to exit.
Red: Press This button to display the EPG “prev
day” program information.
Green: Press This button to display the EPG
“next day” program information.
Yellow: Press This button to browse the EPG
program details.
Blue: Press This button to browse the EPG “Type
filter” program information.
5
Remote Control
TELETEXT
12
3
45
67
8
9
11
12 13
16
14
15
10
10

TELETEXT
17
21
20. ARC: Press to change the screen size, such as
Auto, Normal, Letterbox.
(Note: inactive for VGA)
22. TEXT : Press to activate the teletext and press
again to deactivate the teletext.
30. R/G/Y/B: Press to select the pictures with
various colors of text. Different channels display
different functions.
23. MIX: Displays the teletext pages superimposed
on the TV picture
24. SIZE: Selects doubleheight text.
Press this button to enlarge thetop half of the page.
Press this button again to enlargethe bottom half
of the page.
Press this button again to returnto the normal display.
25. REVEAL: Press to reveal hidden information
such as answers to a quiz.
26. HOLD: Press to stop the scrolling of text pages.
The text decoder stops receiving data.
21. STILL(Freeze): Press to freeze the picture,
press again to restore the picture.
17. INFO: Press to display the channel information;
this information disappears after 9 seconds.
18. PSM: Press to cycle through the picture modes:
Cinema/Sport/Vivid/Hi-Bright/User.
19. SSM: Press to cycle through the sound modes:
Concert/LivingRoom/Hall/Bathroom/Cave/Arena
/Church/Off.
27. INDEX (indexing): Return to teletext main menu.
28. S.PAGE: Press to display the sub page (when
available).
29. S.TITL: Show the subtitle of diagram text.
6
Remote Control
20
30
18
19
22
23
24
28
25
26
27 29

Controls Of Side Panel
- Shown is a simplified representation of theset.
- Here shown may be somewhat different from your set.
Infrared Receiver Window
To receive the signal from remote control.
Power Indicator
To receive the signal from remote control.
Red indicator lighting,this means theTV
is in standby mode;
Green indicator lighting,this means theTV
is in normal working condition;
INPUT
SelectTV,VIDEO,S-VIDEO,YPbPr1,
YPbPr2,VGA,HDMI.
Switches the set on from standby.
MENU
Selects a menu.
PR+/PR-(Programme Up/Down)
Selects a programmeor a menuitem.
Switches the set on from standby.
VOL+/VOL-(Volume Up/Down)
Adjusts the volume.
Adjusts menu settings.
POWER( )
Switches the setOn from standbyor On to
standby.
INPUT
MENU
PR+
PR-
VOL+
VOL-
POWER
Infrared Receiver Window
Power Indicator
7

Controls Of Back Panel
- Shown is a simplified representation of theset.
- Here shown may be somewhat different from your set.
POWER CORD SOCKET
This set operates on an AC power. The volt-age
is indicated on the Specifications page. Never
attempt to operate the set on Dcpower.
HDMI IN (DVI) SOCKETS
Connect the set output socket of the equipment
with HDMI output to this socket.
VGA{1024X768(60Hz)/800X600(60Hz)/640X480
(60Hz)/720X400(70Hz)}
Connect the VGA signal of computer with this port
by VGA cable, connect audio signalwith VGA's
audio input port by audio cable.
VGA-AUDIO
Port for VGA audio input
VGA Connection cannot display 50Hz signal.
COMPONENT1/2 IN (480i / 576i / 480p / 576p /
720p / 1080i) SOCKETS
NLT-32HDB4
S-VIDEO IN
Connect video out from an S-Video VCR to the
S-VIDEO input.
Connect the S-Video sound input socket of the
VCR to component sound sockets of the set.
VIDEO IN SOCKET
Connect the video out sockets of theVCR to
AVsockets of the set.
VIDEO OUT SOCKET
Connect a second TV or monitor. This function
will only works at TV, VIDEO and S-VIDEO.
SPDIF
Port for TV audio output.
RF
Aerial socket
8
HDMI
IN
VGA
IN
VGA-AUDIO
IN
Y2PB2 PR2 LR
Y1PB1 PR1 LR
COAXIAL OUT
S-VIDEO IN
ATV/DTV
TUNER
LR
LR
AV-OUT
AV-IN
Main Power Switch

Insertion of Batteries:
- Turn over the remote control, press and slide off the battery cover.
- Insert two 1.5V (AAA) batteries into the compartment, take care to observe the and markings
indicated inside.
- Replace the cover and slide in reverse until the lock snaps.
Range of Remote Control
- Ensure the remote control is pointedtowards the remote controlwindow on the display unit.
- No obstacles should be placed between the remote control and the remote control window.
Care For Remote Control
- Avoid spilling liquids on the remote.
- Avoid dropping or otherwise jarring the remote.
- Always store the remote control at dry and normal room temperature place.
- If the remote is not performing satisfactorily, replace the batteries. The batteries should be replaced
after one year.
- If the remote control will be idled for a long time (over 1 month), please take out the batteries to avoid
leakage from the batteries.
- Clean up the entire remote controlespecially the battery compartmentif any leakage found.
- Do not mix different kind of new and used batteries together to avoid leakage.
- The effective receiving range for the signal is within 5-8 meters from the front of the remote control
window, and 30 to the left or right side and 20 above or below the control window.
9
Basic Operation
30
30
20
20

Connecting the DVD player or HDTV
Set-top box using YPbPr input
Remove power from the LCD (unplug from the wall
outlet) and external equipment before connecting
cables.
1. Connect the YPbPr output of the DVD or HDTV
Set-top box to the YPbPr input of the LCD.
2. Connect the audio output of the DVD player or
HDTV Set-top box to the audio input of the LCD.
3. Please ensure the Power Cord is connected
before it is operated.
4. Press the POWER to turn on the LCD TV,then
turn on external equipment.
5. Press the INPUT button to select YPbPr signal
source.
6. Press the and Enter to confirm your source
selection.
Connecting audio amplifier (for all
signal source)
Remove power from the LCD (unplug from the wall
outlet) and external equipment before connecting
cables. ,
1. Connect the LCD s COAXIAL OUT to the Audio
Amplifier COAXIAL Input terminal by a coaxial
cable.
2. Press the POWER to turn on the LCD, then turn
on external equipment.
3. Press the INPUT to select signal source, and set
the Audio Amplifier to coaxial input mode.
YPBPRLR
Green Red
Red
White
10
Basic Operation
HDMI
IN
VGA
IN
VGA-AUDIO
IN
Y2PB2 PR2 LR
Y1PB1 PR1 LR
COAXIAL OUT
S-VIDEO IN
ATV/DTV
TUNER
LR
LR
AV-OUT
AV-IN

Connecting the DVD, VCR or other video apparatus using AV and S-VIDEO
input
Remove power from theLCD (unplug from thewall outlet) and externalequipment before connecting
cables.
1. With a S-VIDEOcable connect the LCDto the VCR orother device. S-VIDEO willconnect only the
video portion (image only) of the signal. With an AUDIO cable (RCA type) connect the AUDIO OUT
from the device to the AUDIO IN on the LCD.
2. With an AV cable, connect to the VIDEO input of the LCD to the VCR or other video apparatus.
With an AUDIO cable, connect theAUDIO OUT ofthe VCR or othervideo apparatus to theAUDIO IN
of the LCD.
3. Please ensure the Power Cord is connected before it is operated.
4. Press the POWERto turn on theLCD, then turn onexternal equipment.
5. To watch the VCR or other video apparatus, please press the INPUTbutton to select S-VIDEOor AV.
6. Press the and Enter to confirm your source selection.
7. AV Audio and S-VideoAudio use the same of audio frequency passage.
S-VIDEO RLAV-IN
S-VIDEO RLAV-IN
11
Basic Operation

12
Basic Operation
How to connect a device using HDMI Connection:
Connect the HDMI cable between the HDMI interface on the unit and HDMI output on the device.
To play from the device using HDMI:
1. Turn on your TV, then press Source button. The Source menu opens.
2. Press or to select HDMI, then press OK to confirm.
3. Turn on your device and set it to the correct mode. See the device’s user guide for more information.
If the external device has DVI output only, use a DVI to HDMI adapter cable to connect to the HDMI
terminal. Connect the audio cable to the D-SUB AUDIO IN jack on the TV rear.
Note:

Connecting the Computer using VGA input
Remove power from the LCD (unplug from the wall
outlet) and external equipment before connecting cables.
1. Connect the LCD to the computer with the D-Sub
(VGA) cable.
2. Connect the audio output of the computer to the
VGA-Audio input on the LCD
3. Please ensure the Power Cord is connected before it
is operated.
4. Press the POWER to turn on the LCD, then turn on
external equipment.
5. The LCD and Computer are working at the same time.
Press the Source button to select VGA signal source.
6. Press the and Enter to confirm your INPUT
selection.
13
Basic Operation
Connecting directly to TV
Remove power from theLCD (unplug from thewall outlet)
and external equipment before connecting cables.
Using 75 coaxial Aerial: Connect directly to the RF
terminal of the tuner.
ATV
ATV/DTV Tuner DTV

Initial Setup Instruction Guide
Connect the power and antenna to your television; then
turn on the TV.The first time you use your LCD the initial
setup menu Welcome will appear on the screen:“”
Operate as follows:
1. Press the Enter button to enter the initial setup menu
4. The Initial Setup menu will read Complete after
the scanning is finished.
Press the Enter button to exit.
“”
Note: Initial setup isfor the TV stations only.
1. If you don’t select Scan to start the scanning in the
initial setup menu Channel Scan , the process will
repeat itself the next time you turn on your television.
2. If you would like to end the scanning process, press the
Exit button to exit.
If you would like to scan for stations again, select
Channel Scan in the TV menu.
“”
“”
“”
Initial Setup Welcome
Welcome to use Wizard for
Initial Setup !!
Please press [ENTER] to start the
wizard.
Initial Setup
Skip Scan
Back Next Exit
Select EXIT
First,please connect antenna.
Start channel scan now?
If you skip this step, the channel
scan could be performed in Menu.
Channel Scan
Scan
0%
Initial Setup
Cancel
EXIT
The channel scan may take a while
to complete.
Status: Scanning
Analog Channels: 0
Digital Channels: 0
Channel Scan
51%
Initial Setup
Congratulations !!
Completed Initial Setup.
Complete
Back
Please press [ENTER] to exit the
wizard.
3. Press or Enter button to confirm your selection.
* When select Scan , Press or Enter button to start the
scanning.
* When select Skip Scan , Press or Enter button to skip
the scanning.
* Analog Channels will be tune in starting from 900.
“”
“”
2. Press or button to select Scan or Skip Scan .“”“ ”
14
Basic Operation
Please make sure the main power switch is
in the"ON" position.

Power ON/OFF: The Display is in Standby mode
- Press POWER ( ) button on the remote control or on
the side panel to turn on the unit.
The power indicator changes from red to green.
- Press POWER ( ) button on the remote control or on
the side panel again to return the display to standby
mode. The power indicator changes from green to red.
Selection of Input Mode
- Press the INPUT button to display the signal source
menu.
- press or button to select the signal source you
desired, then press the Enter button to confirm.
TV
AV
S-Video
YPBPR1
Main
15
Basic Operation
RS-32PX
TELETEXT
RS-32PX
POWER
INPUT
VGA
HDMI
YPBPR2
Please make sure the main power switch is
in the "ON" position.
NOTE: When turning the unit "OFF" using the main power
switch, please wait for at least 2 seconds before turning
the main powerswitch to "ON"to allow theunit to reset.
OSD Option Adjustment
Learning about the menu system
After you have installed the batteries intothe remote
control, you may want to set some preferences on
the PDP using the menu system.
- The buttons for OSD option adjustment include:
Menu, , Enter and Exit buttons.
- Press the Menu button to open the OSD Menu then
press or button to select the pages.
The pages are displayed in the following sequence
(circular display):
Video Audio TV Setup Parental
Note: TV menu page is only for TV mode.
, , ,
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Enter
ENTER EXIT Exit
Picture Mode Vivid

16
Basic Operation
OSD Functions
Video Page Menu
Adjustment of Brightness or Contrast“”“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
“”
“”
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
3. Press or button to highlight your selection.
4. Press or button to adjust.
5. Press the Menu or Exit button to return or exit.
Main Menu Menu/exit
Sub Menu exit exit
1. Press the Menu button to display the menu
system.
2. Press or button to select the menu pages.
3. Press the Enter or button to enter.
4. Press or button to select an item.
5. Press button to select or adjust a setting.
6. If you do not make a selection within several
seconds, the main menu closes automatically;
the other menus close automatically within
several seconds.
7. Press the Menu or Exit button to
return or exit OSD menu.
, , ,
Press the Menu button on the remote control or on
the side panel, it will change in the following
sequence:
RS-32PX
TELETEXT
EXIT
MENU
Picture Mode Vivid
1. Press the Menu button, and then press or
to select the menu .
2. Press or Enter button to enter the menu.
3. Press or button to highlight your selection.
4. Press or button to select
5. Press the Menu or Exit button to return or exit.
“Video”
“Video”
“User”, “Cinema”,
“Sport”, “Vivid”, “Hi-Bright”.
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
Picture Mode Vivid
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
Picture Mode Vivid

6. Basic Operation
17
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
Picture Mode Vivid
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
Picture Mode Vivid
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Adjust
ENTER EXIT Back
Picture Mode Vivid
Adjustment of Hue (only for NTSC)“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
3. Press or button to highlight your selection.
4. Press or button to adjust.
5. Press the Menu or Exit button to return or exit.
“”
“”
Adjustment of Sharpness (inactive for VGA)“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
3. Press or button to highlight your selection.
4. Press or button to adjust.
5. Press the Menu or Exit button to return or exit.
“”
“”
Adjustment of Saturation (inactive for VGA)“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
3. Press or button to highlight your selection.
4. Press or button to adjust.
5. Press the Menu or Exit button to return
or exit.
“”
“”

18
Basic Operation
Selection of Color Temperature“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video
menu.
3.Press or button to highlight your selection.
4. Press or Enter button to enter the sub-menu.
5. Press or button to select one of Cool ,
Standard , Warm or User for balance of
whitening.
6. Press the Menu or Exit button to return
or exit.
“”
“”
“”
“”“”“”
If you adjust one item of R Gain , G Gain , Or
B Gain , the color temperature will change to User
Automatically.
“”“”
“” “”
Selection of Advanced Video (Inactive for VGA)“”
1.Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
3. Press or button to highlight your selection.
4. Press or Enter button to enter the sub-menu.
“”
“”
5. Press or button to highlight
your selection.
6. Press or button to select.
7. Press the Menu or Exit button to return
or exit.
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
50
50
50
0
5
Video
Video Select
Enter
ENTER EXIT Back
Audio
TV
Setup
Parental
-2
1
4
Video
Select EXIT Back
Color Temperature Cool
R Gain
G Gain
B Gain
Color Temperature
Audio
TV
Setup
Parental
0
Video
Select EXIT Back
Color Temperature
R Gain
G Gain
B Gain
Color Temperature
User
0
0
Brightness
Contrast
Saturation
HUE
Sharpness
Color Temperature
Advanced Video
Audio
TV
Setup
Parental
48
55
70
0
6
Video
Video Select
Enter
ENTER EXIT Back
Audio
TV
Setup
Parental
Video
Select EXIT Back
DNR Medium
CTI
Flesh Tone
Adaptive Luma Control
Medium
On
On
Advanced Video
Picture Mode Vivid
Picture Mode Vivid

Selection of VGA (only for VGA)“”
1. Press the Menu button, and the Video menu
appears.
2. Press or Enter button to enter the Video menu.
3. Press or button to highlight your selection.
4. Press or Enter button to enter the sub-menu.
“”
“”
Selection of Auto Adjust“”
After entering the VGA menu:
1. Press or button to highlight your selection.
2. Press or Enter button to confirm.
3. Press the Menu or Exit button to return or exit.
Note: This item will auto-adjust the picture display.
“”
Brightness
Contrast
Color Temperature
Advanced Video
Audio
Setup
Parental
60
50
Video
Video Select
Enter
ENTER EXIT Back
VGA
Audio
Setup
Parental
60
50
Video
VGA Select
Enter
ENTER EXIT Back
Auto Adjust
H.Position
V.Position
Phase
Clock
0
127
Selection of H.Position , V.Position , Phase ,
Clock
“”“”“”
“”
After entering the VGA menu:
1. Press or button to highlight your selection.
2. Press or button to select.
3. Press the Menu or Exit button to return or exit.
“”
Table of Video Adjustment Setting
Item Status Description
DNR Off, Low, Medium,
Strong Auto
Select to control the sharpness and
noise reduction.
CTI
Flesh Tone
Adaptive Luma
Control
Off, Low, Medium,
Strong
On, Off
On, Off
Select dynamic color improvement
level.
Selecting On to correct the flesh
tone automatically.
“”
Select to control the luminance.
This feature will set the contrast
and brightness levels for optimum
performance.
19
Basic Operation
Picture Mode Vivid
