Haier HR-45 User manual

REFRIGERATOR
OPERATING
INSTRUCTIONS
The manufacturer keeps on developing various
types of refrigerators, so he has the right to modify
designs, products and technical data without further
notice.
*
MODEL HR-45

FIGURATION OF THE REFRIGERATOR
MAIN TECHNICAL DATA
1
Thermostat knob
Ice-tray
Evaporator
Bottle retainer
Door gasket
Shelf Drip tray
Lock hinge
Model
Climate class
Capacity
Voltage
Watt
Energy consumption
Refrigerant
Overall dimension(D xWxH)
HR-50
ST
50L
220V, 50Hz
75W
0.50kW h/24h
R134a 32g
460 x475 x490 (mm)
HR-45

NOTICE
The power supply
for appliance is
220V,50Hz
single phase.
It is not
recommended
to use any
extension cords.
Connect the appliance
with a properly earthed three-wire
plug and socket with a special use.
Never store anything dangerous
in the appliance, such as
combustibles, exposives,
strong acid and alkali. etc.
SETTING UP
The appliance can’t be placed with its
rear panel directly against the wall.
For a good air circulation, the vent
grille at the back of the worktop must
not be blocked, It should be placed on
flat and firm ground lest it gives off
higher noise than usual. Poorly ventilated rooms
are unsuitable. Avoid
positioning the appliance
in direct sunshine or
exposed to similar
sources of heat.
>10cm
>10cm
>
2cm
2

THERMOSTAT
The knob graduation 0, 1, 2, 3, 4, 5, 6, 7,
does not stand for concrete temperature.The smaller
the numbers,the higher the temperature in the
compartment and vice versa.Usually,it’s better to
put the thermostat in Pos. “1”,Pos. “4”.Pos, “0”
shows the power is cut off.
STORING FOOD
The temperatures in different positions inside
the refrigerator are different due to different
refrigeration distribution.Thus when store
food, select proper position to meet your
needs.
The coldest position áë=, Temperature
from low to high in order as  K
ICE-MAKING
When making ice,add water to the ice tray
until 4/5 full with the grid in it and place it
on the bottom of the ice chamber. Twist the
tray or place it briefly in warm water to
remove the ice cubes.
NOTE
Do not use a knife and the like when
removing the ice tray.
3
1
2
3
4

NOTES ON STORAGE
Where necessary, food should be
packed in bags, avoiding giving
off strong odours or getting wet
or dry.
Do not store food too full in
the appliance. Allow space among
the packages of food for a
perfect refrigerating.
Hot food or liquid must be allowed
to cool to room temperature
before placing in it.
CLEANING
The appliance can only be cleaned at drawn network plug. Clean it
with lukewarm water containing a little detergent. In any case do
not use hot water,corrosive scouring agent and anything rough.
NOTE
Do not use anything rough
for cleaning.
Pull the
plug out
4

DEFROSTING
When defrosting, switch off
the appliance. Remove food from
the ice chamber,it will be
defrosted automatically.When
defrosting process has been
completed, the drip-tray should
be depleted. Replace the food
and switch on the appliance.
NOTES
If the appliance
remains out of
use for some time,
pull out the plug
to disconnect the
appliance from
power supply.
Clean the interior
as described
above to prevent
odours from
forming inside.
In the event of power
failure,try to keep
the appliance closed
to maintain the
refrigeration as long
as possible.
The appliance door
should be opened as
little and briefly
as possible to reduce
energy consumption
5

In the event of a fault occurring during operation, check first if the
fault is due to an operation error. You can repair the following faults
yourself.
The appliance does
not run.
1. It is not switched on properly,
or mains plug properly inserted
in the socket.
2. The thermostat knob is turned to
position “0”.
3. Supply voltage is too low.
The temperature inside
the appliance is not
low enough.
1. The appliance is too full of food.
2. The appliance is located too near
a source of heat.
3. The door is not properly closed or
is opened too frequently.
4. The vent grille is covered over.
Excessive noise
from the appliance. The appliance is not standing
securely on the ground.
If none of these circumstances applies and you are not able to
repair the fault, please Contact the service point.
6

If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
The plug should be accessible after the appliance
positioned.
WARNING:
!
